Public Member Functions | |
| def | __init__ (self, *skims, NoisyModules=None, additionalDataDescription=None, udstOutput=None, mdstOutput=False, mdst_kwargs=None, CombinedSkimName="CombinedSkim", OutputFileName=None, mc=None, analysisGlobaltag=None) |
| def | __str__ (self) |
| def | __name__ (self) |
| def | __call__ (self, path) |
| def | __iter__ (self) |
| def | load_standard_lists (self, path) |
| def | additional_setup (self, path) |
| def | build_lists (self, path) |
| def | output_udst (self, path) |
| def | output_mdst_if_any_flag_passes (self, *path, **kwargs) |
| def | apply_hlt_hadron_cut_if_required (self, path) |
| def | set_skim_logging (self) |
| def | TestFiles (self) |
| def | flags (self) |
| def | flag (self) |
| def | initialise_skim_flag (self, path) |
| def | update_skim_flag (self, path) |
| def | produce_on_tau_samples (self) |
| def | merge_data_structures (self) |
| def | __description__ (self) |
| def | __category__ (self) |
| def | __authors__ (self) |
| def | __contact__ (self) |
| def | code (self) |
| def | validation_histograms (self, path) |
| def | postskim_path (self) |
| def | skim_event_cuts (self, cut, *path) |
Public Attributes | |
| Skims | |
| name | |
| SkimLists | |
| mc | |
| analysisGlobaltag | |
| mdst_kwargs | |
| OutputFileName | |
| additionalDataDescription | |
Private Member Functions | |
| def | _check_duplicate_list_names (self) |
| def | _method_unchanged (self, method) |
Private Attributes | |
| _udstOutput | |
| _mdstOutput | |
| _validation | |
Static Private Attributes | |
| list | __authors__ = ["Phil Grace"] |
| __description__ = None | |
| string | __category__ = "combined" |
| __contact__ = None | |
| _MainPath = None | |
| _ConditionalPath = None | |
Class for creating combined skims which can be run using similar-looking methods
to `BaseSkim` objects.
A steering file which combines skims can be as simple as the following:
.. code-block:: python
import basf2 as b2
import modularAnalysis as ma
from skim.WGs.foo import OneSkim, TwoSkim, RedSkim, BlueSkim
path = b2.Path()
ma.inputMdstList("default", [], path=path)
skims = CombinedSkim(OneSkim(), TwoSkim(), RedSkim(), BlueSkim())
skims(path) # load standard lists, create skim lists, and save to uDST
path.process()
When skims are combined using this class, the `BaseSkim.NoisyModules` lists of each
skim are combined and all silenced.
The heavy-lifting functions `BaseSkim.additional_setup`, `BaseSkim.build_lists` and
`BaseSkim.output_udst` are modified to loop over the corresponding functions of each
invididual skim. The `load_standard_lists` method is also modified to load all
required lists, without accidentally loading a list twice.
Calling an instance of the `CombinedSkim` class will load all the required particle
lists, then run all the setup steps, then the list building functions, and then all
the output steps.
| def __init__ | ( | self, | |
| * | skims, | ||
NoisyModules = None, |
|||
additionalDataDescription = None, |
|||
udstOutput = None, |
|||
mdstOutput = False, |
|||
mdst_kwargs = None, |
|||
CombinedSkimName = "CombinedSkim", |
|||
OutputFileName = None, |
|||
mc = None, |
|||
analysisGlobaltag = None |
|||
| ) |
Initialise the CombinedSkim class.
Parameters:
*skims (BaseSkim): One or more (instantiated) skim objects.
NoisyModules (list(str)): Additional modules to silence.
additionalDataDescription (dict): Overrides corresponding setting of all individual skims.
udstOutput (bool): Overrides corresponding setting of all individual skims.
mdstOutput (bool): Write a single MDST output file containing events which
pass any of the skims in this combined skim.
mdst_kwargs (dict): kwargs to be passed to `mdst.add_mdst_output`. Only used
if ``mdstOutput`` is True.
CombinedSkimName (str): Sets output of ``__str__`` method of this combined skim.
OutputFileName (str): If mdstOutput=True, this option sets the name of the combined output file.
If mdstOutput=False, this option does nothing.
mc (bool): If True, include MC quantities in output.
analysisGlobaltag (str): Analysis globaltag.
| def __call__ | ( | self, | |
| path | |||
| ) |
|
private |
|
privateinherited |
| def additional_setup | ( | self, | |
| path | |||
| ) |
| def apply_hlt_hadron_cut_if_required | ( | self, | |
| path | |||
| ) |
| def build_lists | ( | self, | |
| path | |||
| ) |
|
inherited |
| def flag | ( | self | ) |
| def flags | ( | self | ) |
| def initialise_skim_flag | ( | self, | |
| path | |||
| ) |
| def load_standard_lists | ( | self, | |
| path | |||
| ) |
Add all required standard list loading to the path.
Note:
To avoid loading standard lists twice, this function creates dummy paths
that are passed through ``load_standard_lists`` for each skim. These dummy
paths are then inspected, and a list of unique module-parameter combinations
is added to the main skim path.
Parameters:
path (basf2.Path): Skim path to be processed.
Reimplemented from BaseSkim.
| def merge_data_structures | ( | self | ) |
Read the values of `BaseSkim.MergeDataStructures` and merge data structures
accordingly.
For example, if ``MergeDataStructures`` has the value ``{"FEIChannelArgs":
_merge_boolean_dicts.__func__}``, then ``_merge_boolean_dicts`` is run on all
input skims with the attribute ``FEIChannelArgs``, and the value of
``FEIChannelArgs`` for that skim is set to the result.
In the FEI skims, this is used to merge configs which are passed to a cached
function, thus allowing us to apply the FEI once with all the required particles
available.
| def output_mdst_if_any_flag_passes | ( | self, | |
| * | path, | ||
| ** | kwargs | ||
| ) |
Add MDST output to the path if the event passes any of the skim flags.
EventExtraInfo is included in the MDST output so that the flags are available in
the output.
The ``CombinedSkimName`` parameter in the `CombinedSkim` initialisation is used
for the output filename if ``filename`` is not included in kwargs.
Parameters:
path (basf2.Path): Skim path to be processed.
**kwargs: Passed on to `mdst.add_mdst_output`.
| def output_udst | ( | self, | |
| path | |||
| ) |
|
inherited |
Return the skim path. * If `BaseSkim.skim_event_cuts` has been run, then the skim lists will only be created on a conditional path, so subsequent modules should be added to the conditional path. * If `BaseSkim.skim_event_cuts` has not been run, then the main analysis path is returned.
| def produce_on_tau_samples | ( | self | ) |
| def set_skim_logging | ( | self | ) |
|
inherited |
Apply event-level cuts in a skim-safe way.
Parameters:
cut (str): Event-level cut to be applied.
path (basf2.Path): Skim path to be processed.
Returns:
Path on which the rest of this skim should be processed.
On this path, only events which passed the event-level cut will
be processed further.
.. Tip::
If running this function in `BaseSkim.additional_setup` or
`BaseSkim.build_lists`, redefine the ``path`` to the path returned by
`BaseSkim.skim_event_cuts`, *e.g.*
.. code-block:: python
def build_lists(self, path):
path = self.skim_event_cuts("nTracks>4", path=path)
# rest of skim list building...
.. Note::
The motivation for using this function over `applyEventCuts` is that
`applyEventCuts` completely removes events from processing. If we combine
multiple skims in a single steering file (which is done in production), and
the first has a set of event-level cuts, then all the remaining skims will
never even see those events.
Internally, this function creates a new path, which is only processed for
events passing the event-level cut. To avoid issues around particles not
being available on the main path (leading to noisy error logs), we need to
add the rest of the skim to this path. So this new path is assigned to the
attribute ``BaseSkim._ConditionalPath``, and ``BaseSkim.__call__`` will run
all remaining methods on this path.
| def TestFiles | ( | self | ) |
Location of test MDST sample. To modify this, set the property `BaseSkim.TestSampleProcess`, and this function will find an appropriate test sample from the list in ``/group/belle2/dataprod/MC/SkimTraining/SampleLists/TestFiles.yaml`` If no sample can be found, an empty list is returned.
Reimplemented from BaseSkim.
| def update_skim_flag | ( | self, | |
| path | |||
| ) |
|
inherited |
Create validation histograms for the skim.
Parameters:
path (basf2.Path): Skim path to be processed.
Reimplemented in TDCPV_ccs, TDCPV_qqs, TauThrust, TauGeneric, TauLFV, SystematicsPhiGamma, SLUntagged, PRsemileptonicUntagged, CharmoniumPsi, LowMassTwoTrack, LeptonicUntagged, feiSLBplus, feiSLB0, feiHadronicBplus, feiHadronicB0, inclusiveBplusToKplusNuNu, BtoXll, BtoXgamma, BtoD0h_Kshh, BtoD0h_hh, BtoD0h_Kspipipi0, and BtoD0h_Kspi0.
