This class contains the initial state for the given event. More...

#include <MCInitialParticles.h>

Inheritance diagram for MCInitialParticles:

Collaboration diagram for MCInitialParticles:

[legend]

Public Types
enum	EGenerationFlags { c_generateCMS = 1 << 0 , c_smearBeamEnergy = 1 << 1 , c_smearBeamDirection = 1 << 2 , c_smearBeam = c_smearBeamEnergy \| c_smearBeamDirection , c_smearVertex = 1 << 3 , c_smearALL = c_smearVertex \| c_smearBeam }
	Possible Flags for initial event generation. More...

Public Member Functions
	MCInitialParticles ()
	Default constructor.

	MCInitialParticles (const MCInitialParticles &b)
	Copy constructor.

MCInitialParticles &	operator= (const MCInitialParticles &b)
	Assignment operator.

bool	operator== (const MCInitialParticles &b) const
	Equality operator.

virtual	~MCInitialParticles ()
	Free memory of the LorentzRotation if it was created.

void	set (const TLorentzVector &her, const TLorentzVector &ler, const TVector3 &vertex)
	Set the initial event values, i.e. More...

void	setHER (const TLorentzVector &her)
	Set the High Energy Beam 4-momentum.

void	setLER (const TLorentzVector &ler)
	Set the Low Energy Beam 4-momentum.

void	setVertex (const TVector3 &vertex)
	Set the vertex position.

void	setTime (double time)
	Set collison time.

void	setGenerationFlags (int flags)
	Set the generation flags to be used for event generation (ORed combination of EGenerationFlags)

const TLorentzVector &	getHER () const
	Get 4vector of the high energy beam.

const TLorentzVector &	getLER () const
	Get 4vector of the low energy beam.

const TVector3 &	getVertex () const
	Get the position of the collision.

double	getTime () const
	Get collison time.

double	getEnergy () const
	Get the the actual collision energy (in lab system)

double	getMass () const
	Get the invariant mass of the collision (= energy in CMS)

const TLorentzRotation &	getLabToCMS () const
	Return the LorentzRotation to convert from lab to CMS frame.

const TLorentzRotation &	getCMSToLab () const
	Return the LorentzRotation to convert from CMS to lab frame.

bool	getValidFlag () const
	Get the flag to check if a valid MCInitialParticles object was already generated and filled in an event.

int	getGenerationFlags () const
	Get the generation flags to be used for event generation (ORed combination of EGenerationFlags)

bool	hasGenerationFlags (int flags) const
	Check if a certain set of EGenerationFlags is set.

std::string	getGenerationFlagString (const std::string &separator=" ") const
	Return string representation of all active flags for printing. More...

Private Member Functions
void	calculateBoost () const
	Calculate the boost if necessary.

void	resetBoost ()
	Reset cached transformations after changing parameters.

	ClassDef (MCInitialParticles, 3)
	ROOT Dictionary.

Private Attributes
TLorentzVector	m_her
	HER 4vector.

TLorentzVector	m_ler
	LER 4vector.

TVector3	m_vertex
	collision position

double	m_time = 0
	collision time

TLorentzRotation *	m_labToCMS {nullptr}
	Boost from Lab into CMS. More...

TLorentzRotation *	m_CMSToLab {nullptr}
	transient More...

double	m_invariantMass {0.0}
	transient More...

bool	m_validFlag = false
	transient More...

int	m_generationFlags {0}
	Flags to be used when generating events.

Detailed Description

This class contains the initial state for the given event.

This is not to be confused with the nominal beam parameters but is an event dependent info which contains all implemented smearing effects. It is only set in Montecarlo.

Definition at line 25 of file MCInitialParticles.h.

Member Enumeration Documentation

◆ EGenerationFlags

enum EGenerationFlags

Possible Flags for initial event generation.

Enumerator
c_generateCMS	generate initial event in CMS instead of lab
c_smearBeamEnergy	smear energy of HER and LER (but not direction)
c_smearBeamDirection	smear direction of HER and LER (but not energy)
c_smearBeam	smear the full beam momentum (energy and direction)
c_smearVertex	smear vertex
c_smearALL	smear all

Definition at line 30 of file MCInitialParticles.h.

                           {
       c_generateCMS = 1 << 0,
       c_smearBeamEnergy = 1 << 1,
       c_smearBeamDirection = 1 << 2,
       c_smearBeam = c_smearBeamEnergy | c_smearBeamDirection,
       c_smearVertex = 1 << 3,
       c_smearALL = c_smearVertex | c_smearBeam,
     };

Member Function Documentation

◆ getGenerationFlagString()

std::string getGenerationFlagString ( const std::string & separator = " " ) const

Return string representation of all active flags for printing.

Parameters

separator separation string to be put between flags

Definition at line 13 of file MCInitialParticles.cc.

 {
   std::string flags = "";
   const std::vector<std::pair<int, std::string>> flagvalues{
     {c_generateCMS, "generateCMS"},
     {c_smearBeamEnergy, "smearBeamEnergy"},
     {c_smearBeamDirection, "smearBeamDirection"},
     {c_smearVertex, "smearVertex"}
   };
   for (auto& i : flagvalues) {
     if (hasGenerationFlags(i.first)) {
       if (flags.size() > 0) flags += separator;
       flags += i.second;
     }
   }
   return flags;
 }

◆ set()

void set	(	const TLorentzVector &	her,
		const TLorentzVector &	ler,
		const TVector3 &	vertex
	)

inline

Set the initial event values, i.e.

the four momenta of both beams and the vertex

Parameters

her	4vector of the high energy beam
ler	4vector of the low energy beam
vertex	position of the actual collision vertex

Definition at line 91 of file MCInitialParticles.h.

Member Data Documentation

◆ m_CMSToLab

TLorentzRotation* m_CMSToLab {nullptr}

mutableprivate

transient

Boost from CMS into lab. (calculated on first use, not saved to file)

Definition at line 186 of file MCInitialParticles.h.

◆ m_invariantMass

double m_invariantMass {0.0}

mutableprivate

transient

invariant mass of HER+LER (calculated on first use, not saved to file)

Definition at line 188 of file MCInitialParticles.h.

◆ m_labToCMS

TLorentzRotation* m_labToCMS {nullptr}

mutableprivate

Boost from Lab into CMS.

(calculated on first use, not saved to file)

Definition at line 184 of file MCInitialParticles.h.

◆ m_validFlag

bool m_validFlag = false

private

transient

Flag to check if a valid MCInitialParticles object was already generated and filled in an event.

Definition at line 190 of file MCInitialParticles.h.

The documentation for this class was generated from the following files:

framework/dataobjects/include/MCInitialParticles.h
framework/dataobjects/src/MCInitialParticles.cc
