Class to store results of TOPBunchFinder. More...

#include <TOPRecBunch.h>

Inheritance diagram for TOPRecBunch:

Collaboration diagram for TOPRecBunch:

[legend]

Public Member Functions
	TOPRecBunch ()
	Default constructor.

void	clearReconstructed ()
	Clear reconstruction data members.

void	setReconstructed (int bunchNo, double time, double currentOffset, double currentOffsetError, double averageOffset, double averageOffsetError, bool fineSearch)
	Set reconstructed relative bunch number and time. More...

void	setNumTracks (int numTracks, int usedTracks, int nodEdx)
	Set number of tracks. More...

void	setRevo9Counter (unsigned short revo9Counter)
	Sets number of global clock tics since last revo9 flag. More...

void	addHistogram (const TH1F &histo)
	Add histogram. More...

void	setSimulated (int bunchNo, double time)
	Set simulated relative bunch number and time. More...

int	getBunchNo () const
	Returns reconstructed bunch number relative to L1 trigger signal at TOP note: depends on the "look back" setting. More...

int	getAbsoluteBunchNo (int offset) const
	Returns reconstructed absolute bunch number within the ring. More...

double	getTime () const
	Returns reconstructed bunch time relative to L1 trigger signal at TOP (time to be subtracted to correct time of digits) More...

double	getCurrentOffset () const
	Returns current offset to reconstructed bunch. More...

double	getCurrentOffsetError () const
	Returns uncertainly of current offset. More...

double	getAverageOffset () const
	Returns average offset to reconstructed bunch. More...

double	getAverageOffsetError () const
	Returns uncertainly of average offset. More...

int	getNumTracks () const
	Returns number of tracks in acceptance of TOP. More...

int	getUsedTracks () const
	Returns number of tracks used for bunch reconstruction. More...

int	getNodEdxTracks () const
	Returns number of used tracks without dEdx information. More...

const std::vector< TH1F > &	getHistograms () const
	Returns histograms. More...

bool	isReconstructed () const
	Check if reconstructed return values are valid. More...

bool	isFineSearch () const
	Check if fine search is done. More...

int	getMCBunchNo () const
	Returns simulated bunch number (= bunch used for the event start time) More...

double	getMCTime () const
	Returns simulated bunch time (= time used as event start time) More...

bool	isSimulated () const
	Check if simulated return values are valid. More...

unsigned short	getRevo9Counter () const
	Returns 127 MHz clock ticks since last revo9 marker. More...

void	addRelationTo (const RelationsInterface< BASE > *object, float weight=1.0, const std::string &namedRelation="") const
	Add a relation from this object to another object (with caching). More...

void	addRelationTo (const TObject *object, float weight=1.0, const std::string &namedRelation="") const
	Add a relation from this object to another object (no caching, can be quite slow). More...

void	copyRelations (const RelationsInterface< BASE > *sourceObj)
	Copies all relations of sourceObj (pointing from or to sourceObj) to this object (including weights). More...

template<class TO >
RelationVector< TO >	getRelationsTo (const std::string &name="", const std::string &namedRelation="") const
	Get the relations that point from this object to another store array. More...

template<class FROM >
RelationVector< FROM >	getRelationsFrom (const std::string &name="", const std::string &namedRelation="") const
	Get the relations that point from another store array to this object. More...

template<class T >
RelationVector< T >	getRelationsWith (const std::string &name="", const std::string &namedRelation="") const
	Get the relations between this object and another store array. More...

template<class TO >
TO *	getRelatedTo (const std::string &name="", const std::string &namedRelation="") const
	Get the object to which this object has a relation. More...

template<class FROM >
FROM *	getRelatedFrom (const std::string &name="", const std::string &namedRelation="") const
	Get the object from which this object has a relation. More...

template<class T >
T *	getRelated (const std::string &name="", const std::string &namedRelation="") const
	Get the object to or from which this object has a relation. More...

template<class TO >
std::pair< TO *, float >	getRelatedToWithWeight (const std::string &name="", const std::string &namedRelation="") const
	Get first related object & weight of relation pointing to an array. More...

template<class FROM >
std::pair< FROM *, float >	getRelatedFromWithWeight (const std::string &name="", const std::string &namedRelation="") const
	Get first related object & weight of relation pointing from an array. More...

template<class T >
std::pair< T *, float >	getRelatedWithWeight (const std::string &name="", const std::string &namedRelation="") const
	Get first related object & weight of relation pointing from/to an array. More...

virtual std::string	getName () const
	Return a short name that describes this object, e.g. More...

virtual std::string	getInfoHTML () const
	Return a short summary of this object's contents in HTML format. More...

std::string	getInfo () const
	Return a short summary of this object's contents in raw text format. More...

std::string	getArrayName () const
	Get name of array this object is stored in, or "" if not found.

int	getArrayIndex () const
	Returns this object's array index (in StoreArray), or -1 if not found.

Protected Member Functions
TClonesArray *	getArrayPointer () const
	Returns the pointer to the raw DataStore array holding this object (protected since these arrays are easy to misuse).

Private Member Functions
	ClassDef (TOPRecBunch, 3)
	ClassDef.

Private Attributes
int	m_recBunchNo = 0
	reconstructed relative bunch number

float	m_recTime = 0
	reconstructed relative bunch time

float	m_currentOffset = 0
	current offset

float	m_averageOffset = 0
	running average of offset

float	m_currentOffsetError = 0
	uncertainty of current offset

float	m_averageOffsetError = 0
	uncertainty of running average of offset

int	m_numTracks = 0
	number of tracks in acceptance of TOP

int	m_usedTracks = 0
	number of tracks used for bunch reconstruction

int	m_nodEdx = 0
	number of used tracks with no dEdx information

bool	m_fineSearch = false
	if true, fine search was done

std::vector< TH1F >	m_histograms
	histograms, like chi2 vs t0

bool	m_recValid = false
	status of rec

int	m_simBunchNo = 0
	simulated relative bunch number

float	m_simTime = 0
	simulated relative bunch time

bool	m_simValid = false
	status of sim

unsigned short	m_revo9Counter = 0
	number of clock ticks since last revo9 flag

DataStore::StoreEntry *	m_cacheDataStoreEntry
	Cache of the data store entry to which this object belongs.

int	m_cacheArrayIndex
	Cache of the index in the TClonesArray to which this object belongs.

Detailed Description

Class to store results of TOPBunchFinder.

Definition at line 25 of file TOPRecBunch.h.

Member Function Documentation

◆ addHistogram()

void addHistogram ( const TH1F & histo )

inline

Add histogram.

Parameters

histo one dimensional histogram

Definition at line 101 of file TOPRecBunch.h.

     {
       m_histograms.push_back(histo);
     }

◆ addRelationTo() [1/2]

void addRelationTo	(	const RelationsInterface< BASE > *	object,
		float	weight = `1.0`,
		const std::string &	namedRelation = `""`
	)		const

inlineinherited

Add a relation from this object to another object (with caching).

Parameters

object	The object to which the relation should point.
weight	The weight of the relation.
namedRelation	Additional name for the relation, or "" for the default naming

Definition at line 142 of file RelationsObject.h.

◆ addRelationTo() [2/2]

void addRelationTo	(	const TObject *	object,
		float	weight = `1.0`,
		const std::string &	namedRelation = `""`
	)		const

inlineinherited

Add a relation from this object to another object (no caching, can be quite slow).

Parameters

object	The object to which the relation should point.
weight	The weight of the relation.
namedRelation	Additional name for the relation, or "" for the default naming

Definition at line 155 of file RelationsObject.h.

◆ copyRelations()

void copyRelations ( const RelationsInterface< BASE > * sourceObj )

inlineinherited

Copies all relations of sourceObj (pointing from or to sourceObj) to this object (including weights).

Useful if you want to make a complete copy of a StoreArray object to make modifications to it, but retain all information on linked objects.

Note: this only works if sourceObj inherits from the same base (e.g. RelationsObject), and only for related objects that also inherit from the same base.

Definition at line 170 of file RelationsObject.h.

◆ getAbsoluteBunchNo()

int getAbsoluteBunchNo ( int offset ) const

inline

Returns reconstructed absolute bunch number within the ring.

Parameters

offset offset [RF clock ticks] (to be calibrated)

Returns: bunch number w.r.t revolution marker

Definition at line 130 of file TOPRecBunch.h.

◆ getAverageOffset()

double getAverageOffset ( ) const

inline

Returns average offset to reconstructed bunch.

Returns: offset

Definition at line 158 of file TOPRecBunch.h.

◆ getAverageOffsetError()

double getAverageOffsetError ( ) const

inline

Returns uncertainly of average offset.

Returns: uncertainly

Definition at line 164 of file TOPRecBunch.h.

◆ getBunchNo()

int getBunchNo ( ) const

inline

Returns reconstructed bunch number relative to L1 trigger signal at TOP note: depends on the "look back" setting.

Returns: bunch number relative to L1 trigger signal at TOP minus "look back"

Definition at line 123 of file TOPRecBunch.h.

◆ getCurrentOffset()

double getCurrentOffset ( ) const

inline

Returns current offset to reconstructed bunch.

Returns: offset

Definition at line 146 of file TOPRecBunch.h.

◆ getCurrentOffsetError()

double getCurrentOffsetError ( ) const

inline

Returns uncertainly of current offset.

Returns: uncertainly

Definition at line 152 of file TOPRecBunch.h.

◆ getHistograms()

const std::vector<TH1F>& getHistograms ( ) const

inline

Returns histograms.

Returns: 1D histograms

Definition at line 188 of file TOPRecBunch.h.

◆ getInfo()

std::string getInfo ( ) const

inlineinherited

Return a short summary of this object's contents in raw text format.

Returns the contents of getInfoHTML() while translating line-breaks etc.

Note: : You don't need to implement this function (it's not virtual), getInfoHTML() is enough.

Definition at line 370 of file RelationsObject.h.

◆ getInfoHTML()

virtual std::string getInfoHTML ( ) const

inlinevirtualinherited

Return a short summary of this object's contents in HTML format.

Reimplement this in your own class to provide useful output for display or debugging purposes. For example, you might do something like:

std::stringstream out;
out << "<b>PDG</b>: " << m_pdg << "<br>";
out << "<b>Covariance Matrix</b>: " << HTML::getString(getCovariance5()) << "<br>";
return out.str();

See also: Particle::getInfoHTML() for a more complex example.; HTML for some utility functions.; Use getInfo() to get a raw text version of this output.

Reimplemented in RecoTrack, TRGSummary, TrackFitResult, Track, SoftwareTriggerResult, PIDLikelihood, MCParticle, Cluster, and Particle.

Definition at line 362 of file RelationsObject.h.

◆ getMCBunchNo()

int getMCBunchNo ( ) const

inline

Returns simulated bunch number (= bunch used for the event start time)

Returns: bunch number relative to the interaction

Definition at line 206 of file TOPRecBunch.h.

◆ getMCTime()

double getMCTime ( ) const

inline

Returns simulated bunch time (= time used as event start time)

Returns: time relative to interaction time

Definition at line 212 of file TOPRecBunch.h.

◆ getName()

virtual std::string getName ( ) const

inlinevirtualinherited

Return a short name that describes this object, e.g.

pi+ for an MCParticle.

Reimplemented in SpacePoint, MCParticle, and Particle.

Definition at line 344 of file RelationsObject.h.

◆ getNodEdxTracks()

int getNodEdxTracks ( ) const

inline

Returns number of used tracks without dEdx information.

Returns: number of tracks

Definition at line 182 of file TOPRecBunch.h.

◆ getNumTracks()

int getNumTracks ( ) const

inline

Returns number of tracks in acceptance of TOP.

Returns: number of tracks

Definition at line 170 of file TOPRecBunch.h.

◆ getRelated()

T* getRelated	(	const std::string &	name = `""`,
		const std::string &	namedRelation = `""`
	)		const

inlineinherited

Get the object to or from which this object has a relation.

Template Parameters

T	The class of objects to or from which the relation points.

Parameters

name	The name of the store array to or from which the relation points. If empty the default store array name for class T will be used. If the special name "ALL" is given all store arrays containing objects of type T are considered.
namedRelation	Additional name for the relation, or "" for the default naming

Returns: The first related object or a null pointer.

Definition at line 278 of file RelationsObject.h.

◆ getRelatedFrom()

FROM* getRelatedFrom	(	const std::string &	name = `""`,
		const std::string &	namedRelation = `""`
	)		const

inlineinherited

Get the object from which this object has a relation.

Template Parameters

FROM	The class of objects from which the relation points.

Parameters

name	The name of the store array from which the relation points. If empty the default store array name for class FROM will be used. If the special name "ALL" is given all store arrays containing objects of type FROM are considered.
namedRelation	Additional name for the relation, or "" for the default naming

Returns: The first related object or a null pointer.

Definition at line 263 of file RelationsObject.h.

◆ getRelatedFromWithWeight()

std::pair<FROM*, float> getRelatedFromWithWeight	(	const std::string &	name = `""`,
		const std::string &	namedRelation = `""`
	)		const

inlineinherited

Get first related object & weight of relation pointing from an array.

Template Parameters

FROM	The class of objects from which the relation points.

Parameters

name	The name of the store array from which the relation points. If empty the default store array name for class FROM will be used. If the special name "ALL" is given all store arrays containing objects of type FROM are considered.
namedRelation	Additional name for the relation, or "" for the default naming

Returns: Pair of first related object and the relation weight, or (NULL, 1.0) if none found.

Definition at line 314 of file RelationsObject.h.

◆ getRelatedTo()

TO* getRelatedTo	(	const std::string &	name = `""`,
		const std::string &	namedRelation = `""`
	)		const

inlineinherited

Get the object to which this object has a relation.

Template Parameters

TO	The class of objects to which the relation points.

Parameters

name	The name of the store array to which the relation points. If empty the default store array name for class TO will be used. If the special name "ALL" is given all store arrays containing objects of type TO are considered.
namedRelation	Additional name for the relation, or "" for the default naming

Returns: The first related object or a null pointer.

Definition at line 248 of file RelationsObject.h.

◆ getRelatedToWithWeight()

std::pair<TO*, float> getRelatedToWithWeight	(	const std::string &	name = `""`,
		const std::string &	namedRelation = `""`
	)		const

inlineinherited

Get first related object & weight of relation pointing to an array.

Template Parameters

TO	The class of objects to which the relation points.

Parameters

name	The name of the store array to which the relation points. If empty the default store array name for class TO will be used. If the special name "ALL" is given all store arrays containing objects of type TO are considered.
namedRelation	Additional name for the relation, or "" for the default naming

Returns: Pair of first related object and the relation weight, or (NULL, 1.0) if none found.

Definition at line 297 of file RelationsObject.h.

◆ getRelatedWithWeight()

std::pair<T*, float> getRelatedWithWeight	(	const std::string &	name = `""`,
		const std::string &	namedRelation = `""`
	)		const

inlineinherited

Get first related object & weight of relation pointing from/to an array.

Template Parameters

T	The class of objects to or from which the relation points.

Parameters

name	The name of the store array to or from which the relation points. If empty the default store array name for class T will be used. If the special name "ALL" is given all store arrays containing objects of type T are considered.
namedRelation	Additional name for the relation, or "" for the default naming

Returns: Pair of first related object and the relation weight, or (NULL, 1.0) if none found.

Definition at line 331 of file RelationsObject.h.

◆ getRelationsFrom()

RelationVector<FROM> getRelationsFrom	(	const std::string &	name = `""`,
		const std::string &	namedRelation = `""`
	)		const

inlineinherited

Get the relations that point from another store array to this object.

Template Parameters

FROM	The class of objects from which the relations point.

Parameters

name	The name of the store array from which the relations point. If empty the default store array name for class FROM will be used. If the special name "ALL" is given all store arrays containing objects of type FROM are considered.
namedRelation	Additional name for the relation, or "" for the default naming

Returns: A vector of relations.

Definition at line 212 of file RelationsObject.h.

◆ getRelationsTo()

RelationVector<TO> getRelationsTo	(	const std::string &	name = `""`,
		const std::string &	namedRelation = `""`
	)		const

inlineinherited

Get the relations that point from this object to another store array.

Template Parameters

TO	The class of objects to which the relations point.

Parameters

name	The name of the store array to which the relations point. If empty the default store array name for class TO will be used. If the special name "ALL" is given all store arrays containing objects of type TO are considered.
namedRelation	Additional name for the relation, or "" for the default naming

Returns: A vector of relations.

Definition at line 197 of file RelationsObject.h.

◆ getRelationsWith()

RelationVector<T> getRelationsWith	(	const std::string &	name = `""`,
		const std::string &	namedRelation = `""`
	)		const

inlineinherited

Get the relations between this object and another store array.

Relations in both directions are returned.

Template Parameters

T	The class of objects to or from which the relations point.

Parameters

name	The name of the store array to or from which the relations point. If empty the default store array name for class T will be used. If the special name "ALL" is given all store arrays containing objects of type T are considered.
namedRelation	Additional name for the relation, or "" for the default naming

Returns: A vector of relations.

Definition at line 230 of file RelationsObject.h.

◆ getRevo9Counter()

unsigned short getRevo9Counter ( ) const

inline

Returns 127 MHz clock ticks since last revo9 marker.

Returns: revo9counter

Definition at line 224 of file TOPRecBunch.h.

◆ getTime()

double getTime ( ) const

inline

Returns reconstructed bunch time relative to L1 trigger signal at TOP (time to be subtracted to correct time of digits)

Returns: time relative to L1 trigger signal at TOP minus "look back"

Definition at line 140 of file TOPRecBunch.h.

◆ getUsedTracks()

int getUsedTracks ( ) const

inline

Returns number of tracks used for bunch reconstruction.

Returns: number of tracks

Definition at line 176 of file TOPRecBunch.h.

◆ isFineSearch()

bool isFineSearch ( ) const

inline

Check if fine search is done.

Returns: true on fine search

Definition at line 200 of file TOPRecBunch.h.

◆ isReconstructed()

bool isReconstructed ( ) const

inline

Check if reconstructed return values are valid.

Returns: true on valid

Definition at line 194 of file TOPRecBunch.h.

◆ isSimulated()

bool isSimulated ( ) const

inline

Check if simulated return values are valid.

Returns: true on valid

Definition at line 218 of file TOPRecBunch.h.

◆ setNumTracks()

void setNumTracks	(	int	numTracks,
		int	usedTracks,
		int	nodEdx
	)

inline

Set number of tracks.

Parameters

numTracks	number of tracks in acceptance of TOP
usedTracks	number of tracks used for bunch reconstruction
nodEdx	number of used tracks without dEdx information

Definition at line 84 of file TOPRecBunch.h.

◆ setReconstructed()

void setReconstructed	(	int	bunchNo,
		double	time,
		double	currentOffset,
		double	currentOffsetError,
		double	averageOffset,
		double	averageOffsetError,
		bool	fineSearch
	)

inline

Set reconstructed relative bunch number and time.

Parameters

bunchNo	relative bunch number
time	relative bunch time
currentOffset	current offset
currentOffsetError	uncertainty of current offset
averageOffset	average offset
averageOffsetError	uncertainty of average offset
fineSearch	fine search flag

Definition at line 63 of file TOPRecBunch.h.

◆ setRevo9Counter()

void setRevo9Counter ( unsigned short revo9Counter )

inline

Sets number of global clock tics since last revo9 flag.

Parameters

revo9Counter counter state

Definition at line 95 of file TOPRecBunch.h.

◆ setSimulated()

void setSimulated	(	int	bunchNo,
		double	time
	)

inline

Set simulated relative bunch number and time.

Parameters

bunchNo	relative bunch number
time	relative bunch time

Definition at line 111 of file TOPRecBunch.h.

The documentation for this class was generated from the following file:

top/dataobjects/include/TOPRecBunch.h

Public Member Functions

Protected Member Functions

Private Member Functions

Private Attributes

Detailed Description

Member Function Documentation

◆ addHistogram()

◆ addRelationTo() [1/2]

◆ addRelationTo() [2/2]

◆ copyRelations()

◆ getAbsoluteBunchNo()

◆ getAverageOffset()

◆ getAverageOffsetError()

◆ getBunchNo()

◆ getCurrentOffset()

◆ getCurrentOffsetError()

◆ getHistograms()

◆ getInfo()

◆ getInfoHTML()

◆ getMCBunchNo()

◆ getMCTime()

◆ getName()

◆ getNodEdxTracks()

◆ getNumTracks()

◆ getRelated()

◆ getRelatedFrom()

◆ getRelatedFromWithWeight()

◆ getRelatedTo()

◆ getRelatedToWithWeight()

◆ getRelatedWithWeight()

◆ getRelationsFrom()

◆ getRelationsTo()

◆ getRelationsWith()

◆ getRevo9Counter()

◆ getTime()

◆ getUsedTracks()

◆ isFineSearch()

◆ isReconstructed()

◆ isSimulated()

◆ setNumTracks()

◆ setReconstructed()

◆ setRevo9Counter()

◆ setSimulated()
