Collaboration diagram for analysis:

Modules
	analysis data objects

	analysis modules

Classes
class	ClusterUtils
	Class to provide momentum-related information from ECLClusters. More...

class	CleoCones
	Class to calculate the Cleo clone variables. More...

class	FoxWolfram
	Class to calculate the Fox-Wolfram moments up to order 8. More...

class	HarmonicMoments
	Class to calculate the Harmonic moments up to order 8 with respect to a given axis. More...

class	KsfwMoments
	Moment-calculation of the k_sfw improved Super-Fox-Wolfram moments. More...

class	SphericityEigenvalues
	Class to calculate the Sphericity tensor eigenvalues and eigenvectors starting from an array of 3-momenta The tensor itself is not stored, only its eigenvalues and eigenvectors are. More...

class	Thrust
	Class to calculate the thrust axis. More...

class	ChargedPidMVAWeights
	Class to contain the payload of MVA weightfiles needed for charged particle identification. More...

class	ParticleWeightingAxis
	Class for handling LookUp tables. More...

class	ParticleWeightingBinLimits
	Just pair of numbers - min and max values of bin border. More...

class	ParticleWeightingKeyMap
	Class for handling KeyMap. More...

class	ParticleWeightingLookUpTable
	Class for handling LookUp tables. More...

class	PIDPriors
	A database class to hold the prior probability for the particle identification. More...

class	PIDPriorsTable
	This class holds the prior distribution for a single particle species. More...

class	DecayDescriptor
	The DecayDescriptor stores information about a decay tree or parts of a decay tree. More...

class	DecayDescriptorParticle
	Represents a particle in the DecayDescriptor. More...

struct	DecayStringDecay
	Holds the information of a decay. More...

struct	DecayStringGrammar< Iterator >
	This class describes the grammar and the syntax elements of decay strings. More...

struct	DecayStringParticle
	Holds the information of a particle in the decay string. More...

class	ParticleListHelper
	Class to help managing creation and adding to ParticleLists. More...

class	ParticleIndexGenerator
	ParticleIndexGenerator is a generator for all the combinations of the particle indices stored in the particle lists. More...

class	ListIndexGenerator
	ListIndexGenerator is a generator for all the combinations of the sublists (FlavorSpecificParticle = 0, SelfConjugatedParticle = 1) of a set of particle lists. More...

class	ParticleGenerator
	ParticleGenerator is a generator for all the particles combined from the given ParticleLists. More...

class	ChargedParticleIdentificatorTest
	Test the MVA-based charged PID. More...

class	eventShapeCoreAlgorithmTest

class	PIDPriorsTest

class	AnalysisConfiguration
	Singleton class keeping configurables of analysis components. More...

class	DecayForest
	Contains several DecayTree objects, which belong all to the same candidate. More...

class	DecayNode
	DecayNode describes the decay of a particle identified by its pdg code, into list of daughters. More...

class	DecayTree< T >
	This is a helper class for the MCDecayFinderModule. More...

class	GenB0Tag
	Class to determine generated decay mode of B0 and B0bar. More...

class	GenBplusTag
	Class to determine generated decay modes of B+ and B-. More...

class	GenBsTag
	Class to determine generated decay mode of Bs0 and Bs0bar. More...

class	GenDTag
	Class to determine generated decay mode of D*, Ds, D0, D+, and their anti-particles. More...

class	GenTauTag
	Class to determine generated decay mode of tau+ and tau-. More...

struct	MCMatching
	Functions to perform Monte Carlo matching for reconstructed Particles. More...

class	ParticleSubset
	Specialised SelectSubset<Particle> that also fixes daughter indices and all ParticleLists. More...

class	PCmsLabTransform
	Class to hold Lorentz transformations from/to CMS and boost vector. More...

class	ReferenceFrame
	Abstract base class of all reference frames. More...

class	RestFrame
	Rest frame of a particle. More...

class	LabFrame
	Lab frame. More...

class	CMSFrame
	CMS frame. More...

class	RotationFrame
	Rotation frame around vector. More...

class	CMSRotationFrame
	Stack frame for cms and Rotation frame. More...

class	UseReferenceFrame< T >
	A template class to apply the reference frame. More...

struct	VariableFormulaConstructor
	Struct to construct new variable function objects from a name or a double value or to apply operations on these variable function objects. More...

Macros
#define	MAKE_DEPRECATED(name, make_fatal, version, description) static DeprecateProxy VARMANAGER_MAKE_UNIQUE(_deprecateproxy)(std::string(name), bool(make_fatal), std::string(version), std::string(description));
	Registers a variable as deprecated.

Typedefs
typedef std::map< int, ParticleWeightingBinLimits * >	BinMap
	Map of keys with bin limits.

typedef std::pair< std::vector< int >, int >	MultiDimBin
	Multidimensional bin: first element contains combination of bin IDs from 1D axis, second elements contain ID ("key") associated with this combination.

typedef std::map< std::string, ParticleWeightingBinLimits * >	NDBin
	N-dim bin: pairs of bin limits with name of the axis variable.

typedef std::map< std::string, double >	WeightInfo
	Weight information: a line from the weight lookup table.

typedef std::map< int, WeightInfo >	WeightMap
	Weight map: the whole lookup table

typedef boost::variant< boost::recursive_wrapper< DecayStringDecay >, DecayStringParticle >	DecayString
	The DecayStringElement can be either a DecayStringDecay or a vector of mother particles. More...

Functions
void	addContinuumSuppression (const Particle *particle, const std::string &maskName)
	Adds continuum suppression variables.

double	legendre (const double z, const int i)
	Legendre polynomials.

	TEST_F (ChargedParticleIdentificatorTest, TestDBRep)
	Test correct storage of weightfiles in the database representation inner structure.

	TEST_F (eventShapeCoreAlgorithmTest, Thrust)
	Test the calculation of a thrust axis.

	TEST_F (eventShapeCoreAlgorithmTest, CleoCones)
	Test the calculation of the CleoClones variables.

	TEST_F (eventShapeCoreAlgorithmTest, FoxWolfram)
	Test the calculation of the Fox-Wolfram moments.

	TEST_F (eventShapeCoreAlgorithmTest, HarmonicMoments)
	Test the calculation of the Harmonic moments.

	TEST_F (eventShapeCoreAlgorithmTest, Sphericity)
	Test the calculation of the Sphericity eigenvalues and eigenvectors.

	TEST_F (PIDPriorsTest, PIDPriorsTableTest)
	Test of the PIDPriorsTable class.

	TEST_F (PIDPriorsTest, PIDPriorTest)
	Test the PIDPriors dbobject.

bool	operator== (const DecayNode &node1, const DecayNode &node2)
	Compare two Decay Nodes: They are equal if All daughter decay nodes are equal or one of the daughter lists is empty (which means "inclusive") More...

bool	operator!= (const DecayNode &node1, const DecayNode &node2)
	Not equal: See operator==.

	CleoCones (const std::vector< TVector3 > &p3_cms_all, const std::vector< TVector3 > &p3_cms_roe, const TVector3 &thrustB, bool calc_CleoCones_with_all, bool calc_CleoCones_with_roe)
	Constructor.

	KsfwMoments (double Hso0_max, std::vector< std::pair< TVector3, int >> p3_cms_q_sigA, std::vector< std::pair< TVector3, int >> p3_cms_q_sigB, std::vector< std::pair< TVector3, int >> p3_cms_q_roe, const TLorentzVector &p_cms_missA, const TLorentzVector &p_cms_missB, double et[2])
	Constructor.

void	registerList (const std::string &listname, bool save=true)
	Register a list by name. More...

void	registerList (const DecayDescriptor &decay, bool save=true)
	Register a list using a decay descriptor. More...

void	create ()
	Create the list objects. More...

void	init (const std::vector< unsigned int > &_sizes)
	Initialises the generator to produce combinations with the given sizes of each particle list. More...

bool	loadNext ()
	Loads the next combination. More...

const std::vector< unsigned int > &	getCurrentIndices () const
	Returns theindices of the current loaded combination.

void	init (unsigned int _numberOfLists)
	Initialises the generator to produce the given type of sublist. More...

bool	loadNext ()
	Loads the next combination. More...

const std::vector< ParticleList::EParticleType > &	getCurrentIndices () const
	Returns the type of the sublist of the current loaded combination.

	ParticleGenerator (const std::string &decayString, const std::string &cutParameter="")
	Initialises the generator to produce the given type of sublist. More...

	ParticleGenerator (const DecayDescriptor &decaydescriptor, const std::string &cutParameter="")
	Initialises the generator to produce the given type of sublist. More...

void	init ()
	Initialises the generator to produce the given type of sublist.

void	initIndicesToUniqueIDMap ()
	In the case input daughter particle lists collide (two or more lists contain copies of Particles) the Particle's Store Array index can not be longer used as its unique identifier, which is needed to check for uniqueness of accpeted combinations. More...

void	fillIndicesToUniqueIDMap (const std::vector< int > &listA, const std::vector< int > &listB, int &uniqueID)
	Assigns unique IDs to all particles in list A, which do not have the unique ID already assigned. More...

void	fillIndicesToUniqueIDMap (const std::vector< int > &listA, int &uniqueID)
	Assigns unique IDs to all particles in list A, which do not have the unique ID already assigned.

bool	loadNext (bool loadAntiParticle=true)
	Loads the next combination. More...

bool	loadNextParticle (bool useAntiParticle)
	Loads the next combination. More...

bool	loadNextSelfConjugatedParticle ()
	Loads the next combination. More...

Particle	createCurrentParticle () const
	Create current particle object.

Particle	getCurrentParticle () const
	Returns the particle.

bool	currentCombinationHasDifferentSources ()
	Check that all FS particles of a combination differ. More...

bool	currentCombinationIsUnique ()
	Check that the combination is unique. More...

bool	inputListsCollide (const std::pair< unsigned, unsigned > &pair) const
	True if the pair of input lists collide. More...

bool	currentCombinationIsECLCRUnique ()
	Check that: if the current combination has at least two particles from an ECL source, then they are from different connected regions or from the same connected region but have the same hypothesis. More...

int	getUniqueID (int index) const
	Returns the unique ID assigned to Particle with given index from the IndicesToUniqueID map. More...

bool	find_decay (const DecayNode &to_find) const
	Check if the decay node contains the given decay tree. More...

std::string	print_node (unsigned int indent=0) const
	Output a single node. More...

Detailed Description

Typedef Documentation

◆ DecayString

typedef boost::variant< boost::recursive_wrapper<DecayStringDecay>, DecayStringParticle > DecayString

The DecayStringElement can be either a DecayStringDecay or a vector of mother particles.

User documentation is located at analysis/doc/DecayDescriptor.rst Please modify in accordingly to introduced changes.

Definition at line 23 of file DecayString.h.

Function Documentation

◆ create()

void create ( )

Create the list objects.

Warning: This function should be called in Every event

Definition at line 40 of file ParticleListHelper.cc.

   {
     m_list.create();
     m_list->initialize(m_pdg, m_list.getName());
     if (m_antiList) {
       m_antiList->create();
       (*m_antiList)->initialize(-m_pdg, m_antiList->getName());
       m_list->bindAntiParticleList(**m_antiList);
     }
   }

◆ currentCombinationHasDifferentSources()

bool currentCombinationHasDifferentSources ( )

private

Check that all FS particles of a combination differ.

The comparison is made at the MDST objects level. If for example a kaon and a pion Particle's are created from the same MSDT Track object, then these two Particles have the same source and the function will return false.

Returns: true if all FS particles of a combination differ

Definition at line 473 of file ParticleCombiner.cc.

   {
     std::vector<Particle*> stack = m_particles;
     static std::vector<int> sources; // stack for particle sources
     sources.clear();

     // recursively check all daughters and daughters of daughters
     while (!stack.empty()) {
       Particle* p = stack.back();
       stack.pop_back();
       const std::vector<int>& daughters = p->getDaughterIndices();

       if (daughters.empty()) {
         int source = p->getMdstSource();
         for (int i : sources) {
           if (source == i) return false;
         }
         sources.push_back(source);
       } else {
         for (int daughter : daughters) stack.push_back(m_particleArray[daughter]);
       }
     }
     return true;
   }

◆ currentCombinationIsECLCRUnique()

bool currentCombinationIsECLCRUnique ( )

private

Check that: if the current combination has at least two particles from an ECL source, then they are from different connected regions or from the same connected region but have the same hypothesis.

Returns: true if indices not found in the stack; if true indices pushed to stack

Definition at line 521 of file ParticleCombiner.cc.

◆ currentCombinationIsUnique()

bool currentCombinationIsUnique ( )

private

Check that the combination is unique.

Especially in the case of reconstructing self conjugated decays we get combinations like M -> A B and M -> B A. These two particles are the same and hence only one combination of the two should be kept. This function takes care of this. It keeps track of all combinations that were already accepted (ordered set of unique IDs of daughter particles) and if the current combination is already found in the set it is discarded. The unique ID of daughter particles are either their StoreArray indices (if input lists do not collide) or specially set unique IDs during initialization phase (if input lists collide).

Returns: true if indices not found in the stack; if true indices pushed to stack

Definition at line 499 of file ParticleCombiner.cc.

◆ fillIndicesToUniqueIDMap()

void fillIndicesToUniqueIDMap	(	const std::vector< int > &	listA,
		const std::vector< int > &	listB,
		int &	uniqueID
	)

private

Assigns unique IDs to all particles in list A, which do not have the unique ID already assigned.

The same unique ID is assigned to copies of particles from list A found in the list B. This function has to be executed first.

Definition at line 285 of file ParticleCombiner.cc.

◆ find_decay()

bool find_decay ( const DecayNode & to_find ) const

Check if the decay node contains the given decay tree.

Parameters

to_find DecayNode object describing the decay

Definition at line 19 of file DecayNode.cc.

   {
     if (to_find == (*this))
       return true;
     for (const auto& node : daughters) {
       if (node.find_decay(to_find))
         return true;
     }
     return false;
   }

◆ getUniqueID()

int getUniqueID ( int index ) const

Returns the unique ID assigned to Particle with given index from the IndicesToUniqueID map.

If the Particle's index is not found in the map -1 is returned instead. If the map was never filled (inputListsCollide is false) 0 is returned.

Needed only for tests.

Definition at line 573 of file ParticleCombiner.cc.

◆ init() [1/2]

void init ( const std::vector< unsigned int > & _sizes )

Initialises the generator to produce combinations with the given sizes of each particle list.

Parameters

_sizes the sizes of the particle lists to combine

Definition at line 26 of file ParticleCombiner.cc.

◆ init() [2/2]

void init ( unsigned int _numberOfLists )

Initialises the generator to produce the given type of sublist.

Parameters

_numberOfLists Number of Particle Lists which shall be combined

Definition at line 78 of file ParticleCombiner.cc.

◆ initIndicesToUniqueIDMap()

void initIndicesToUniqueIDMap ( )

private

In the case input daughter particle lists collide (two or more lists contain copies of Particles) the Particle's Store Array index can not be longer used as its unique identifier, which is needed to check for uniqueness of accpeted combinations.

Instead unique identifier is created for all particles in the input particle lists and use those when checking for uniqueness of current combination.

Definition at line 233 of file ParticleCombiner.cc.

◆ inputListsCollide()

bool inputListsCollide ( const std::pair< unsigned, unsigned > & pair ) const

True if the pair of input lists collide.

Needed only for tests.

Definition at line 512 of file ParticleCombiner.cc.

◆ loadNext() [1/3]

bool loadNext ( )

Loads the next combination.

Returns false if there is no next combination

Definition at line 49 of file ParticleCombiner.cc.

◆ loadNext() [2/3]

bool loadNext ( )

Loads the next combination.

Returns false if there is no next combination

Definition at line 88 of file ParticleCombiner.cc.

◆ loadNext() [3/3]

bool loadNext ( bool loadAntiParticle = true )

Loads the next combination.

Returns false if there is no next combination

Three cases are distinguished: First, particles matching the flavor specified in the decay string are used to form combinations. Secondly, the anti-particles of flavored particles are used, but only if requested. Lastly, self-conjugated particles are handled specifically.

Definition at line 324 of file ParticleCombiner.cc.

◆ loadNextParticle()

bool loadNextParticle ( bool useAntiParticle )

private

Loads the next combination.

Returns false if there is no next combination

Definition at line 361 of file ParticleCombiner.cc.

◆ loadNextSelfConjugatedParticle()

bool loadNextSelfConjugatedParticle ( )

private

Loads the next combination.

Returns false if there is no next combination

Definition at line 405 of file ParticleCombiner.cc.

◆ operator==()

bool operator==	(	const DecayNode &	node1,
		const DecayNode &	node2
	)

Compare two Decay Nodes: They are equal if All daughter decay nodes are equal or one of the daughter lists is empty (which means "inclusive")

In particular the order of the daughter particles matter! 423 (--> 421 13) is not the same as 423 (--> 13 421)

Parameters

node1	first node
node2	second node

Definition at line 48 of file DecayNode.cc.

◆ ParticleGenerator() [1/2]

ParticleGenerator	(	const DecayDescriptor &	decaydescriptor,
		const std::string &	cutParameter = `""`
	)

explicit

Initialises the generator to produce the given type of sublist.

Parameters

decaydescriptor
cutParameter

Definition at line 165 of file ParticleCombiner.cc.

◆ ParticleGenerator() [2/2]

ParticleGenerator	(	const std::string &	decayString,
		const std::string &	cutParameter = `""`
	)

explicit

Initialises the generator to produce the given type of sublist.

Parameters

decayString
cutParameter

Definition at line 108 of file ParticleCombiner.cc.

◆ print_node()

std::string print_node ( unsigned int indent = 0 ) const

Output a single node.

Used by to_string to convert tree into a string

Parameters

indent -ion level

Definition at line 30 of file DecayNode.cc.

◆ registerList() [1/2]

void registerList	(	const DecayDescriptor &	decay,
		bool	save = `true`
	)

Register a list using a decay descriptor.

Warning: should be called in initialize

Parameters

decay	decay descriptor to use for the list name
save	if true the list will be saved in the output file

Definition at line 27 of file ParticleListHelper.cc.

◆ registerList() [2/2]

void registerList	(	const std::string &	listname,
		bool	save = `true`
	)

Register a list by name.

Warning: should be called in initialize

Parameters

listname	full list name in the form '{particlename}:{label}'
save	if true the list will be saved in the output file

Definition at line 18 of file ParticleListHelper.cc.

Modules

Classes

Macros

Typedefs

Functions

Detailed Description

Typedef Documentation

◆ DecayString

Function Documentation

◆ create()

◆ currentCombinationHasDifferentSources()

◆ currentCombinationIsECLCRUnique()

◆ currentCombinationIsUnique()

◆ fillIndicesToUniqueIDMap()

◆ find_decay()

◆ getUniqueID()

◆ init() [1/2]

◆ init() [2/2]

◆ initIndicesToUniqueIDMap()

◆ inputListsCollide()

◆ loadNext() [1/3]

◆ loadNext() [2/3]

◆ loadNext() [3/3]

◆ loadNextParticle()

◆ loadNextSelfConjugatedParticle()

◆ operator==()

◆ ParticleGenerator() [1/2]

◆ ParticleGenerator() [2/2]

◆ print_node()

◆ registerList() [1/2]

◆ registerList() [2/2]
