DQM Histogram Analysis for PXD Efficiency. More...

#include <DQMHistAnalysisPXDEff.h>

Inheritance diagram for DQMHistAnalysisPXDEffModule:

[legend]

Collaboration diagram for DQMHistAnalysisPXDEffModule:

[legend]

Public Types
typedef std::map< std::string, HistObject >	HistList
	The type of list of histograms.

typedef std::map< std::string, MonitoringObject * >	MonObjList
	The type of list of MonitoringObjects.

typedef std::map< std::string, HistDelta * >	DeltaList
	The type of list of delta settings and histograms.

typedef std::map< std::string, bool >	CanvasUpdatedList
	The type of list of canvas updated status.

enum	EModulePropFlags { c_Input = 1 , c_Output = 2 , c_ParallelProcessingCertified = 4 , c_HistogramManager = 8 , c_InternalSerializer = 16 , c_TerminateInAllProcesses = 32 , c_DontCollectStatistics = 64 }
	Each module can be tagged with property flags, which indicate certain features of the module. More...

typedef ModuleCondition::EAfterConditionPath	EAfterConditionPath
	Forward the EAfterConditionPath definition from the ModuleCondition.

Public Member Functions
	DQMHistAnalysisPXDEffModule ()
	Constructor.

	~DQMHistAnalysisPXDEffModule ()
	Destructor.

void	initialize (void) override final
	Initializer.

void	beginRun (void) override final
	Called when entering a new run.

void	event (void) override final
	This method is called for each event. More...

void	terminate (void) override final
	This method is called at the end of the event processing.

void	setRunType (std::string &t)
	Set the Run Type. More...

void	setEventProcessed (int e)
	Set the number of processed events. More...

TCanvas *	findCanvas (TString cname)
	Find canvas by name. More...

TH1 *	findHistInCanvas (const std::string &hname)
	Find histogram in corresponding canvas. More...

double	getSigma68 (TH1 *h) const
	Helper function to compute half of the central interval covering 68% of a distribution. More...

TH1 *	getDelta (const std::string &fullname, int n=0, bool onlyIfUpdated=true)
	Get Delta histogram. More...

TH1 *	getDelta (const std::string &dirname, const std::string &histname, int n=0, bool onlyIfUpdated=true)
	Get Delta histogram. More...

void	addDeltaPar (const std::string &dirname, const std::string &histname, HistDelta::EDeltaType t, int p, unsigned int a=1)
	Add Delta histogram parameters. More...

bool	hasDeltaPar (const std::string &dirname, const std::string &histname)
	Check if Delta histogram parameters exist for histogram. More...

void	UpdateCanvas (std::string name, bool updated=true)
	Mark canvas as updated (or not) More...

void	UpdateCanvas (TCanvas *canvas, bool updated=true)
	Mark canvas as updated (or not) More...

void	ExtractRunType (std::vector< TH1 * > &hs)
	Extract Run Type from histogram title, called from input module.

void	ExtractEvent (std::vector< TH1 * > &hs)
	Extract event processed from daq histogram, called from input module.

int	registerEpicsPV (std::string pvname, std::string keyname="", bool update_pvs=true)
	EPICS related Functions. More...

void	setEpicsPV (std::string keyname, double value)
	Write value to a EPICS PV. More...

void	setEpicsPV (std::string keyname, int value)
	Write value to a EPICS PV. More...

void	setEpicsPV (int index, double value)
	Write value to a EPICS PV. More...

void	setEpicsPV (int index, int value)
	Write value to a EPICS PV. More...

void	setEpicsStringPV (std::string keyname, std::string value)
	Write string to a EPICS PV. More...

void	setEpicsStringPV (int index, std::string value)
	Write string to a EPICS PV. More...

double	getEpicsPV (std::string keyname)
	Read value from a EPICS PV. More...

double	getEpicsPV (int index)
	Read value from a EPICS PV. More...

std::string	getEpicsStringPV (std::string keyname, bool &status)
	Read value from a EPICS PV. More...

std::string	getEpicsStringPV (int index, bool &status)
	Read value from a EPICS PV. More...

void	updateEpicsPVs (float timeout)
	Update all EPICS PV (flush to network) More...

chid	getEpicsPVChID (std::string keyname)
	Get EPICS PV Channel Id. More...

chid	getEpicsPVChID (int index)
	Get EPICS PV Channel Id. More...

bool	requestLimitsFromEpicsPVs (chid id, double &lowerAlarm, double &lowerWarn, double &upperWarn, double &upperAlarm)
	Get Alarm Limits from EPICS PV. More...

bool	requestLimitsFromEpicsPVs (std::string keyname, double &lowerAlarm, double &lowerWarn, double &upperWarn, double &upperAlarm)
	Get Alarm Limits from EPICS PV. More...

bool	requestLimitsFromEpicsPVs (int index, double &lowerAlarm, double &lowerWarn, double &upperWarn, double &upperAlarm)
	Get Alarm Limits from EPICS PV. More...

void	setUseEpics (bool flag)
	Setter for EPICS usage. More...

void	setUseEpicsReadOnly (bool flag)
	Setter EPICS flag in read only mode. More...

bool	getUseEpics (void)
	Getter for EPICS usage. More...

bool	getUseEpicsReadOnly (void)
	Getter EPICS flag in read only mode. More...

void	cleanupEpicsPVs (void)
	Unsubscribe from EPICS PVs on terminate.

std::string &	getPVPrefix (void)
	get global Prefix for EPICS PVs More...

void	setPVPrefix (std::string &prefix)
	set global Prefix for EPICS PVs More...

std::vector< std::string >	StringSplit (const std::string &s, const char delim)
	Helper function for string token split. More...

virtual std::vector< std::string >	getFileNames (bool outputFiles)
	Return a list of output filenames for this modules. More...

virtual void	endRun ()
	This method is called if the current run ends. More...

const std::string &	getName () const
	Returns the name of the module. More...

const std::string &	getType () const
	Returns the type of the module (i.e. More...

const std::string &	getPackage () const
	Returns the package this module is in.

const std::string &	getDescription () const
	Returns the description of the module.

void	setName (const std::string &name)
	Set the name of the module. More...

void	setPropertyFlags (unsigned int propertyFlags)
	Sets the flags for the module properties. More...

LogConfig &	getLogConfig ()
	Returns the log system configuration.

void	setLogConfig (const LogConfig &logConfig)
	Set the log system configuration.

void	setLogLevel (int logLevel)
	Configure the log level.

void	setDebugLevel (int debugLevel)
	Configure the debug messaging level.

void	setAbortLevel (int abortLevel)
	Configure the abort log level.

void	setLogInfo (int logLevel, unsigned int logInfo)
	Configure the printed log information for the given level. More...

void	if_value (const std::string &expression, const std::shared_ptr< Path > &path, EAfterConditionPath afterConditionPath=EAfterConditionPath::c_End)
	Add a condition to the module. More...

void	if_false (const std::shared_ptr< Path > &path, EAfterConditionPath afterConditionPath=EAfterConditionPath::c_End)
	A simplified version to add a condition to the module. More...

void	if_true (const std::shared_ptr< Path > &path, EAfterConditionPath afterConditionPath=EAfterConditionPath::c_End)
	A simplified version to set the condition of the module. More...

bool	hasCondition () const
	Returns true if at least one condition was set for the module.

const ModuleCondition *	getCondition () const
	Return a pointer to the first condition (or nullptr, if none was set)

const std::vector< ModuleCondition > &	getAllConditions () const
	Return all set conditions for this module.

bool	evalCondition () const
	If at least one condition was set, it is evaluated and true returned if at least one condition returns true. More...

std::shared_ptr< Path >	getConditionPath () const
	Returns the path of the last true condition (if there is at least one, else reaturn a null pointer). More...

Module::EAfterConditionPath	getAfterConditionPath () const
	What to do after the conditional path is finished. More...

std::vector< std::shared_ptr< Path > >	getAllConditionPaths () const
	Return all condition paths currently set (no matter if the condition is true or not).

bool	hasProperties (unsigned int propertyFlags) const
	Returns true if all specified property flags are available in this module. More...

bool	hasUnsetForcedParams () const
	Returns true and prints error message if the module has unset parameters which the user has to set in the steering file.

const ModuleParamList &	getParamList () const
	Return module param list.

template<typename T >
ModuleParam< T > &	getParam (const std::string &name) const
	Returns a reference to a parameter. More...

bool	hasReturnValue () const
	Return true if this module has a valid return value set.

int	getReturnValue () const
	Return the return value set by this module. More...

std::shared_ptr< PathElement >	clone () const override
	Create an independent copy of this module. More...

std::shared_ptr< boost::python::list >	getParamInfoListPython () const
	Returns a python list of all parameters. More...

Static Public Member Functions
static HistList &	getHistList ()
	Get the list of the histograms. More...

static const MonObjList &	getMonObjList ()
	Get the list of MonitoringObjects. More...

static const DeltaList &	getDeltaList ()
	Get the list of the delta histograms. More...

static const CanvasUpdatedList &	getCanvasUpdatedList ()
	Get the list of the canvas update status. More...

static const std::string &	getRunType (void)
	Get the Run Type. More...

static int	getEventProcessed (void)
	Get the number of processed events. More...

static TH1 *	findHist (const std::string &histname, bool onlyIfUpdated=false)
	Get histogram from list (no other search). More...

static TH1 *	findHist (const std::string &dirname, const std::string &histname, bool onlyIfUpdated=false)
	Find histogram. More...

static TH1 *	findHistInFile (TFile *file, const std::string &histname)
	Find histogram in specific TFile (e.g. More...

static MonitoringObject *	findMonitoringObject (const std::string &objName)
	Find MonitoringObject. More...

static bool	addHist (const std::string &dirname, const std::string &histname, TH1 *h)
	Add histogram. More...

static MonitoringObject *	getMonitoringObject (const std::string &histname)
	Get MonitoringObject with given name (new object is created if non-existing) More...

static void	initHistListBeforeEvent (void)
	Reset the list of histograms.

static void	clearHistList (void)
	Clears the list of histograms.

static void	exposePythonAPI ()
	Exposes methods of the Module class to Python.

Protected Member Functions
virtual void	def_initialize ()
	Wrappers to make the methods without "def_" prefix callable from Python. More...

virtual void	def_beginRun ()
	Wrapper method for the virtual function beginRun() that has the implementation to be used in a call from Python.

virtual void	def_event ()
	Wrapper method for the virtual function event() that has the implementation to be used in a call from Python.

virtual void	def_endRun ()
	This method can receive that the current run ends as a call from the Python side. More...

virtual void	def_terminate ()
	Wrapper method for the virtual function terminate() that has the implementation to be used in a call from Python.

void	setDescription (const std::string &description)
	Sets the description of the module. More...

void	setType (const std::string &type)
	Set the module type. More...

template<typename T >
void	addParam (const std::string &name, T &paramVariable, const std::string &description, const T &defaultValue)
	Adds a new parameter to the module. More...

template<typename T >
void	addParam (const std::string &name, T &paramVariable, const std::string &description)
	Adds a new enforced parameter to the module. More...

void	setReturnValue (int value)
	Sets the return value for this module as integer. More...

void	setReturnValue (bool value)
	Sets the return value for this module as bool. More...

void	setParamList (const ModuleParamList &params)
	Replace existing parameter list.

Private Member Functions
std::list< ModulePtr >	getModules () const override
	no submodules, return empty list

std::string	getPathString () const override
	return the module name.

void	setParamPython (const std::string &name, const boost::python::object &pyObj)
	Implements a method for setting boost::python objects. More...

void	setParamPythonDict (const boost::python::dict &dictionary)
	Implements a method for reading the parameter values from a boost::python dictionary. More...

Private Attributes
std::string	m_histogramDirectoryName
	name of histogram directory

int	m_u_bins
	u binning for 2d plots

int	m_v_bins
	v binning for 2d plots

double	m_confidence
	confidence level for error bars

double	m_warnlevel
	warn level for alarm

double	m_errorlevel
	error level for alarm

int	m_minEntries = 1000
	Update entry intervall.

bool	m_perModuleAlarm
	use alarm level per module

bool	m_alarmAdhoc
	generate alarm from adhoc values

std::vector< int >	m_excluded
	Indizes of excluded PXD Modules.

std::vector< VxdID >	m_PXDModules
	IDs of all PXD Modules to iterate over.

std::map< VxdID, TEfficiency * >	m_hEffModules
	Individual efficiency for each module, 2d histogram.

std::map< VxdID, TCanvas * >	m_cEffModules
	Individual efficiency for each module, canvas.

TEfficiency *	m_hEffAll = nullptr
	One bin for each module in the geometry.

TCanvas *	m_cEffAll = nullptr
	Final Canvas.

TH1 *	m_hEffAllLastTotal = nullptr
	TH1, last state, total.

TH1 *	m_hEffAllLastPassed = nullptr
	TH1, last state, passed.

TEfficiency *	m_hEffAllUpdate = nullptr
	Efficiency, last state, updated.

TCanvas *	m_cEffAllUpdate = nullptr
	Final Canvas for Update.

TH2F *	m_hInnerMap {}
	Full Eff Map Inner Layer.

TH2F *	m_hOuterMap {}
	Full Eff Map Outer Layer.

TCanvas *	m_cInnerMap {}
	Full Eff Map Inner Layer.

TCanvas *	m_cOuterMap {}
	Full Eff Map Outer Layer.

TH1F *	m_hWarnLine {}
	TLine object for warning limit.

TH1F *	m_hErrorLine {}
	TLine object for error error.

std::map< VxdID, double >	m_warnlevelmod
	warn level for alarm per module

std::map< VxdID, double >	m_errorlevelmod
	error level for alarm per module

MonitoringObject *	m_monObj {}
	Monitoring Object.

std::string	m_name
	The name of the module, saved as a string (user-modifiable)

std::string	m_type
	The type of the module, saved as a string.

std::string	m_package
	Package this module is found in (may be empty).

std::string	m_description
	The description of the module.

unsigned int	m_propertyFlags
	The properties of the module as bitwise or (with \|) of EModulePropFlags.

LogConfig	m_logConfig
	The log system configuration of the module.

ModuleParamList	m_moduleParamList
	List storing and managing all parameter of the module.

bool	m_hasReturnValue
	True, if the return value is set.

int	m_returnValue
	The return value.

std::vector< ModuleCondition >	m_conditions
	Module condition, only non-null if set.

Static Private Attributes
static HistList	s_histList
	The list of Histograms.

static MonObjList	s_monObjList
	The list of MonitoringObjects.

static DeltaList	s_deltaList
	The list of Delta Histograms and settings.

static CanvasUpdatedList	s_canvasUpdatedList
	The list of canvas updated status.

static int	s_eventProcessed = 0
	Number of Events processed to fill histograms. More...

static std::string	s_runType = ""
	The Run type.

static bool	m_useEpics = false
	Flag if to use EPICS do not set by yourself, use EpicsEnable module to set.

static bool	m_epicsReadOnly
	Flag if to use EPICS in ReadOnly mode (for reading limits) do not set by yourself, use EpicsEnable module to set. More...

static std::string	m_PVPrefix = "TEST:"
	The Prefix for EPICS PVs.

Detailed Description

DQM Histogram Analysis for PXD Efficiency.

Definition at line 29 of file DQMHistAnalysisPXDEff.h.

Member Enumeration Documentation

◆ EModulePropFlags

enum EModulePropFlags

inherited

Each module can be tagged with property flags, which indicate certain features of the module.

Enumerator
c_Input	This module is an input module (reads data).
c_Output	This module is an output module (writes data).
c_ParallelProcessingCertified	This module can be run in parallel processing mode safely (All I/O must be done through the data store, in particular, the module must not write any files.)
c_HistogramManager	This module is used to manage histograms accumulated by other modules.
c_InternalSerializer	This module is an internal serializer/deserializer for parallel processing.
c_TerminateInAllProcesses	When using parallel processing, call this module's terminate() function in all processes(). This will also ensure that there is exactly one process (single-core if no parallel modules found) or at least one input, one main and one output process.
c_DontCollectStatistics	No statistics is collected for this module.

Definition at line 77 of file Module.h.

Member Function Documentation

◆ addDeltaPar()

void addDeltaPar	(	const std::string &	dirname,
		const std::string &	histname,
		HistDelta::EDeltaType	t,
		int	p,
		unsigned int	a = `1`
	)

inherited

Add Delta histogram parameters.

Parameters

dirname	directory
histname	name of histogram
t	type of delta histogramming
p	numerical parameter depnding on type, e.g. number of entries
a	amount of histograms in the past

Definition at line 68 of file DQMHistAnalysis.cc.

◆ addHist()

bool addHist	(	const std::string &	dirname,
		const std::string &	histname,
		TH1 *	h
	)

staticinherited

Add histogram.

Parameters

dirname	The name of the directory.
histname	The name of the histogram.
h	The TH1 pointer for the histogram.

Returns: histogram was updated flag

Definition at line 46 of file DQMHistAnalysis.cc.

◆ clone()

std::shared_ptr< PathElement > clone ( ) const

overridevirtualinherited

Create an independent copy of this module.

Note that parameters are shared, so changing them on a cloned module will also affect the original module.

Implements PathElement.

Definition at line 179 of file Module.cc.

◆ def_endRun()

virtual void def_endRun ( )

inlineprotectedvirtualinherited

This method can receive that the current run ends as a call from the Python side.

For regular C++-Modules that forwards the call to the regular endRun() method.

Reimplemented in PyModule.

Definition at line 439 of file Module.h.

◆ def_initialize()

virtual void def_initialize ( )

inlineprotectedvirtualinherited

Wrappers to make the methods without "def_" prefix callable from Python.

Overridden in PyModule. Wrapper method for the virtual function initialize() that has the implementation to be used in a call from Python.

Reimplemented in PyModule.

Definition at line 420 of file Module.h.

◆ endRun()

virtual void endRun ( void )

inlinevirtualinherited

This method is called if the current run ends.

Use this method to store information, which should be aggregated over one run.

This method can be implemented by subclasses.

Definition at line 166 of file Module.h.

◆ evalCondition()

bool evalCondition ( ) const

inherited

If at least one condition was set, it is evaluated and true returned if at least one condition returns true.

If no condition or result value was defined, the method returns false. Otherwise, the condition is evaluated and true returned, if at least one condition returns true. To speed up the evaluation, the condition strings were already parsed in the method if_value().

Returns: True if at least one condition and return value exists and at least one condition expression was evaluated to true.

Definition at line 96 of file Module.cc.

◆ event()

void event ( void )

finaloverridevirtual

This method is called for each event.

TODO: one value per module, and please change to the "delta" instead of integral

we wont use "white" =1 in this module

Reimplemented from Module.

Definition at line 220 of file DQMHistAnalysisPXDEff.cc.

 {
   //Count how many of each type of histogram there are for the averaging
   //std::map<std::string, int> typeCounter;

   m_hInnerMap->Reset();
   m_hOuterMap->Reset();

   for (unsigned int i = 1; i <= m_PXDModules.size(); i++) {
     VxdID& aPXDModule = m_PXDModules[i - 1];

     TString buff = (std::string)aPXDModule;
     buff.ReplaceAll(".", "_");

     TH1* Hits, *Matches;
     TString locationHits = "track_hits_" + buff;
     if (m_histogramDirectoryName != "") {
       locationHits = m_histogramDirectoryName + "/" + locationHits;
     }
     Hits = (TH1*)findHist(locationHits.Data());
     TString locationMatches = "matched_cluster_" + buff;
     if (m_histogramDirectoryName != "") {
       locationMatches = m_histogramDirectoryName + "/" + locationMatches;
     }
     Matches = (TH1*)findHist(locationMatches.Data());

     // Finding only one of them should only happen in very strange situations...
     if (Hits == nullptr || Matches == nullptr) {
       B2ERROR("Missing histogram for sensor " << aPXDModule);
     } else {
       if (m_cEffModules[aPXDModule] && m_hEffModules[aPXDModule]) {// this check creates them with a nullptr ..bad
         m_hEffModules[aPXDModule]->SetTotalHistogram(*Hits, "f");
         m_hEffModules[aPXDModule]->SetPassedHistogram(*Matches, "f");

         m_cEffModules[aPXDModule]->cd();
         m_hEffModules[aPXDModule]->Paint("colz"); // not Draw, enforce to create GetPaintedHistogram?
         m_cEffModules[aPXDModule]->Modified();
         m_cEffModules[aPXDModule]->Update();

         auto h = m_hEffModules[aPXDModule]->GetPaintedHistogram();
         int s = (2 - aPXDModule.getSensorNumber()) * m_v_bins;
         int l = (aPXDModule.getLadderNumber() - 1) * m_u_bins;
         if (m_hInnerMap && aPXDModule.getLayerNumber() == 1) {
           for (int u = 0; u < m_u_bins; u++) {
             for (int v = 0; v < m_v_bins; v++) {
               auto b = h->GetBin(u + 1, v + 1);
               m_hInnerMap->Fill(u + l, v + s, h->GetBinContent(b));
             }
           }
         }
         if (m_hOuterMap && aPXDModule.getLayerNumber() == 2) {
           for (int u = 0; u < m_u_bins; u++) {
             for (int v = 0; v < m_v_bins; v++) {
               auto b = h->GetBin(u + 1, v + 1);
               m_hOuterMap->Fill(u + l, v + s, h->GetBinContent(b));
             }
           }
         }
       }
     }
   }// Single-Module histos + 2d overview finished

   m_cInnerMap->cd();
   if (m_hInnerMap) m_hInnerMap->Draw("colz");
   m_cInnerMap->Modified();
   m_cInnerMap->Update();
   m_cOuterMap->cd();
   if (m_hOuterMap) m_hOuterMap->Draw("colz");
   m_cOuterMap->Modified();
   m_cOuterMap->Update();
   UpdateCanvas(m_cInnerMap->GetName());
   UpdateCanvas(m_cOuterMap->GetName());

   // Change: We now use one histogram for hits and matches to make
   // sure that we have an atomic update which is otherwise not
   // guaranteed by DQM framework
   TString locationHits = "PXD_Eff_combined";
   if (m_histogramDirectoryName != "") {
     locationHits = m_histogramDirectoryName + "/" + locationHits;
   }
   TH1* Combined = (TH1*)findHist(locationHits.Data());

   double stat_data = 0;
   bool error_flag = false;
   bool warn_flag = false;
   double all = 0.0;

   double imatch = 0.0, ihit = 0.0;
   int ieff = 0;

   std::map <VxdID, bool> updated{}; // init to false, keep track of updated histograms
   for (unsigned int i = 0; i < m_PXDModules.size(); i++) {
     int j = i + 1;

     if (Combined == nullptr) {
       m_hEffAll->SetPassedEvents(j, 0); // order, otherwise it might happen that SetTotalEvents is NOT filling the value!
       m_hEffAll->SetTotalEvents(j, 0);
     } else {
       VxdID& aModule = m_PXDModules[i];
       double nmatch = Combined->GetBinContent(i * 2 + 2);
       double nhit = Combined->GetBinContent(i * 2 + 1);
       if (nmatch > 10 && nhit > 10) { // could be zero, too
         imatch += nmatch;
         ihit +=  nhit;
         ieff++; // only count in modules working
         double var_e = nmatch / nhit; // can never be zero
         // workaround for excluded module
         if (std::find(m_excluded.begin(), m_excluded.end(), i) != m_excluded.end()) continue;

         m_monObj->setVariable(Form("efficiency_%d_%d_%d", aModule.getLayerNumber(), aModule.getLadderNumber(), aModule.getSensorNumber()),
                               var_e);
       }

       all += nhit;
       m_hEffAll->SetPassedEvents(j, 0); // otherwise it might happen that SetTotalEvents is NOT filling the value!
       m_hEffAll->SetTotalEvents(j, nhit);
       m_hEffAll->SetPassedEvents(j, nmatch);

       if (nhit < m_minEntries) {
         // update the first entries directly (short runs)
         m_hEffAllUpdate->SetPassedEvents(j, 0); // otherwise it might happen that SetTotalEvents is NOT filling the value!
         m_hEffAllUpdate->SetTotalEvents(j, nhit);
         m_hEffAllUpdate->SetPassedEvents(j, nmatch);
         m_hEffAllLastTotal->SetBinContent(j, nhit);
         m_hEffAllLastPassed->SetBinContent(j, nmatch);
         updated[aModule] = true;
       } else if (nhit - m_hEffAllLastTotal->GetBinContent(j) > m_minEntries) {
         m_hEffAllUpdate->SetPassedEvents(j, 0); // otherwise it might happen that SetTotalEvents is NOT filling the value!
         m_hEffAllUpdate->SetTotalEvents(j, nhit - m_hEffAllLastTotal->GetBinContent(j));
         m_hEffAllUpdate->SetPassedEvents(j, nmatch - m_hEffAllLastPassed->GetBinContent(j));
         m_hEffAllLastTotal->SetBinContent(j, nhit);
         m_hEffAllLastPassed->SetBinContent(j, nmatch);
         updated[aModule] = true;
       }

       // workaround for excluded module
       if (std::find(m_excluded.begin(), m_excluded.end(), i) != m_excluded.end()) continue;

       // get the errors and check for limits for each bin seperately ...

       if (nhit > 50) {
         error_flag |= (m_hEffAll->GetEfficiency(j) + m_hEffAll->GetEfficiencyErrorUp(j) <
                        m_errorlevelmod[aModule]); // error if upper error value is below limit
         warn_flag |= (m_hEffAll->GetEfficiency(j) + m_hEffAll->GetEfficiencyErrorUp(j) <
                       m_warnlevelmod[aModule]); // (and not only the actual eff value)
         if (m_alarmAdhoc) {
           error_flag |= (m_hEffAllUpdate->GetEfficiency(j) + m_hEffAllUpdate->GetEfficiencyErrorUp(j) <
                          m_errorlevelmod[aModule]); // error if upper error value is below limit
           warn_flag |= (m_hEffAllUpdate->GetEfficiency(j) + m_hEffAllUpdate->GetEfficiencyErrorUp(j) <
                         m_warnlevelmod[aModule]); // (and not only the actual eff value)
         }
       }
     }
   }

   {
     m_cEffAll->cd();
     m_cEffAll->cd(0);
     m_hEffAll->Paint("AP");
     m_cEffAll->Clear();
     m_cEffAll->cd(0);

     auto gr = m_hEffAll->GetPaintedGraph();
     if (gr) {
       double scale_min = 1.0;
       for (int i = 0; i < gr->GetN(); i++) {
         gr->SetPointEXhigh(i, 0.);
         gr->SetPointEXlow(i, 0.);
         // this has to be done first, as it will recalc Min/Max and destroy axis
         Double_t x, y;
         gr->GetPoint(i, x, y);
         gr->SetPoint(i, x - 0.01, y); // workaround for jsroot bug (fixed upstream)
         auto val = y - gr->GetErrorYlow(i); // Error is relative to value
         if (std::find(m_excluded.begin(), m_excluded.end(), i) == m_excluded.end()) {
           // scale update only for included module
           if (scale_min > val) scale_min = val;
         }
       }
       if (scale_min == 1.0) scale_min = 0.0;
       if (scale_min > 0.9) scale_min = 0.9;
       gr->SetMinimum(0);
       gr->SetMaximum(m_PXDModules.size());
       auto ay = gr->GetYaxis();
       if (ay) ay->SetRangeUser(scale_min, 1.0);
       auto ax = gr->GetXaxis();
       if (ax) {
         ax->Set(m_PXDModules.size(), 0, m_PXDModules.size());
         for (unsigned int i = 0; i < m_PXDModules.size(); i++) {
           TString ModuleName = (std::string)m_PXDModules[i];
           ax->SetBinLabel(i + 1, ModuleName);
         }
       }

       gr->SetLineColor(4);
       gr->SetLineWidth(2);
       gr->SetMarkerStyle(8);

       gr->Draw("AP");

       for (auto& it : m_excluded) {
         auto tt = new TLatex(it + 0.5, scale_min, (" " + std::string(m_PXDModules[it]) + " Module is excluded, please ignore").c_str());
         tt->SetTextAngle(90);// Rotated
         tt->SetTextAlign(12);// Centered
         tt->Draw();
       }

       if (all < 100.) {
         m_cEffAll->Pad()->SetFillColor(kGray);// Magenta or Gray
       } else {
         if (error_flag) {
           m_cEffAll->Pad()->SetFillColor(kRed);// Red
         } else if (warn_flag) {
           m_cEffAll->Pad()->SetFillColor(kYellow);// Yellow
         } else {
           m_cEffAll->Pad()->SetFillColor(kGreen);// Green
           //       m_cEffAll->Pad()->SetFillColor(kWhite);// White
         }
       }

       m_cEffAll->Pad()->SetFrameFillColor(kWhite - 1); // White
       m_cEffAll->Pad()->SetFrameFillStyle(1001);// White
       m_cEffAll->Pad()->Modified();
       m_cEffAll->Pad()->Update();
       m_hWarnLine->Draw("same,hist");
       m_hErrorLine->Draw("same,hist");
     }

     UpdateCanvas(m_cEffAll->GetName());
     m_cEffAll->Modified();
     m_cEffAll->Update();
   }

   {
     m_cEffAllUpdate->cd();
     m_hEffAllUpdate->Paint("AP");
     m_cEffAllUpdate->Clear();
     m_cEffAllUpdate->cd(0);

     auto gr = m_hEffAllUpdate->GetPaintedGraph();
     auto gr3 = (TGraphAsymmErrors*) m_hEffAll->GetPaintedGraph()->Clone();
     if (gr3) {
       for (int i = 0; i < gr3->GetN(); i++) {
         Double_t x, y;
         gr3->GetPoint(i, x, y);
         gr3->SetPoint(i, x + 0.2, y);
       }
     }

     double scale_min = 1.0;
     if (gr) {
       for (int i = 0; i < gr->GetN(); i++) {
         gr->SetPointEXhigh(i, 0.);
         gr->SetPointEXlow(i, 0.);
         // this has to be done first, as it will recalc Min/Max and destroy axis
         Double_t x, y;
         gr->GetPoint(i, x, y);
         gr->SetPoint(i, x - 0.2, y); // shift a bit if in same plot
         auto val = y - gr->GetErrorYlow(i); // Error is relative to value
         if (std::find(m_excluded.begin(), m_excluded.end(), i) == m_excluded.end()) {
           // skip scale update only for included modules
           if (scale_min > val) scale_min = val;
         }
       }
       if (scale_min == 1.0) scale_min = 0.0;
       if (scale_min > 0.9) scale_min = 0.9;
       gr->SetMinimum(0);
       gr->SetMaximum(m_PXDModules.size());
       auto ay = gr->GetYaxis();
       if (ay) ay->SetRangeUser(scale_min, 1.0);
       auto ax = gr->GetXaxis();
       if (ax) {
         ax->Set(m_PXDModules.size(), 0, m_PXDModules.size());
         for (unsigned int i = 0; i < m_PXDModules.size(); i++) {
           TString ModuleName = (std::string)m_PXDModules[i];
           ax->SetBinLabel(i + 1, ModuleName);
         }
       }
       for (unsigned int i = 0; i < m_PXDModules.size(); i++) {
         if (updated[m_PXDModules[i]]) {
           // we should only write if it was updated!
           Double_t x, y;// we assume that double and Double_t are same!
           gr->GetPoint(i, x, y);
           setEpicsPV((std::string)m_PXDModules[i], y);
         }
       }

       gr->SetLineColor(kBlack);
       gr->SetLineWidth(3);
       gr->SetMarkerStyle(33);
       gr->Draw("AP");
     } else scale_min = 0.0;
     if (gr3) gr3->Draw("P"); // both in one plot

     for (auto& it : m_excluded) {
       auto tt = new TLatex(it + 0.5, scale_min, (" " + std::string(m_PXDModules[it]) + " Module is excluded, please ignore").c_str());
       tt->SetTextSize(0.035);
       tt->SetTextAngle(90);// Rotated
       tt->SetTextAlign(12);// Centered
       tt->Draw();
     }

     if (all < 100.) {
       m_cEffAllUpdate->Pad()->SetFillColor(kGray);// Magenta or Gray
       stat_data = 0.;
     } else {
       if (error_flag) {
         m_cEffAllUpdate->Pad()->SetFillColor(kRed);// Red
         stat_data = 4.;
       } else if (warn_flag) {
         m_cEffAllUpdate->Pad()->SetFillColor(kYellow);// Yellow
         stat_data = 3.;
       } else {
         m_cEffAllUpdate->Pad()->SetFillColor(kGreen);// Green
         stat_data = 2.;
         //       m_cEffAllUpdate->Pad()->SetFillColor(kWhite);// White
       }
     }
     m_cEffAllUpdate->Pad()->SetFrameFillColor(kWhite - 1); // White
     m_cEffAllUpdate->Pad()->SetFrameFillStyle(1001);// White
     m_cEffAllUpdate->Pad()->Modified();
     m_cEffAllUpdate->Pad()->Update();
     m_hWarnLine->Draw("same,hist");
     m_hErrorLine->Draw("same,hist");
   }
   UpdateCanvas(m_cEffAllUpdate->GetName());
   m_cEffAllUpdate->Modified();
   m_cEffAllUpdate->Update();


   double var_efficiency = ihit > 0 ? imatch / ihit : 0.0;
   m_monObj->setVariable("efficiency", var_efficiency);
   m_monObj->setVariable("nmodules", ieff);

   setEpicsPV("Status", stat_data);
   // only update if statistics is reasonable, we dont want "0" drops between runs!
   if (stat_data != 0) setEpicsPV("Overall", var_efficiency);
 }

◆ findCanvas()

TCanvas * findCanvas ( TString cname )

inherited

Find canvas by name.

Parameters

cname Name of the canvas

Returns: The pointer to the canvas, or nullptr if not found.

Definition at line 128 of file DQMHistAnalysis.cc.

◆ findHist() [1/2]

TH1 * findHist	(	const std::string &	dirname,
		const std::string &	histname,
		bool	onlyIfUpdated = `false`
	)

staticinherited

Find histogram.

Parameters

dirname	The name of the directory.
histname	The name of the histogram.
onlyIfUpdated	req only updated hists, return nullptr otherwise

Returns: The found histogram, or nullptr if not found.

Definition at line 156 of file DQMHistAnalysis.cc.

◆ findHist() [2/2]

TH1 * findHist	(	const std::string &	histname,
		bool	onlyIfUpdated = `false`
	)

staticinherited

Get histogram from list (no other search).

Parameters

histname	The name of the histogram (incl dir).
onlyIfUpdated	req only updated hists, return nullptr otherwise

Returns: The found histogram, or nullptr if not found.

Definition at line 142 of file DQMHistAnalysis.cc.

◆ findHistInCanvas()

TH1 * findHistInCanvas ( const std::string & hname )

inherited

Find histogram in corresponding canvas.

Parameters

hname Name of the histogram (dir+name)

Returns: The pointer to the histogram, or nullptr if not found.

Definition at line 164 of file DQMHistAnalysis.cc.

◆ findHistInFile()

TH1 * findHistInFile	(	TFile *	file,
		const std::string &	histname
	)

staticinherited

Find histogram in specific TFile (e.g.

ref file).

Parameters

file	The TFile to search.
histname	The name of the histogram, can incl directory

Returns: The found histogram, or nullptr if not found.

Definition at line 190 of file DQMHistAnalysis.cc.

◆ findMonitoringObject()

MonitoringObject * findMonitoringObject ( const std::string & objName )

staticinherited

Find MonitoringObject.

Parameters

objName The name of the MonitoringObject.

Returns: The found MonitoringObject, or nullptr if not found.

Definition at line 211 of file DQMHistAnalysis.cc.

◆ getAfterConditionPath()

Module::EAfterConditionPath getAfterConditionPath ( ) const

inherited

What to do after the conditional path is finished.

(defaults to c_End if no condition is set)

Definition at line 133 of file Module.cc.

◆ getCanvasUpdatedList()

static const CanvasUpdatedList& getCanvasUpdatedList ( )

inlinestaticinherited

Get the list of the canvas update status.

Returns: The list of the canvases.

Definition at line 143 of file DQMHistAnalysis.h.

◆ getConditionPath()

std::shared_ptr< Path > getConditionPath ( ) const

inherited

Returns the path of the last true condition (if there is at least one, else reaturn a null pointer).

Definition at line 113 of file Module.cc.

◆ getDelta() [1/2]

TH1 * getDelta	(	const std::string &	dirname,
		const std::string &	histname,
		int	n = `0`,
		bool	onlyIfUpdated = `true`
	)

inherited

Get Delta histogram.

Parameters

dirname	directory
histname	name of histogram
n	index of delta histogram, 0 is most recent one
onlyIfUpdated	req only updated deltas, return nullptr otherwise

Returns: delta histogram or nullptr

Definition at line 91 of file DQMHistAnalysis.cc.

◆ getDelta() [2/2]

TH1 * getDelta	(	const std::string &	fullname,
		int	n = `0`,
		bool	onlyIfUpdated = `true`
	)

inherited

Get Delta histogram.

Parameters

fullname	directory+name of histogram
n	index of delta histogram, 0 is most recent one
onlyIfUpdated	req only updated deltas, return nullptr otherwise

Returns: delta histogram or nullptr

Definition at line 102 of file DQMHistAnalysis.cc.

◆ getDeltaList()

static const DeltaList& getDeltaList ( )

inlinestaticinherited

Get the list of the delta histograms.

Returns: The list of the delta histograms.

Definition at line 137 of file DQMHistAnalysis.h.

◆ getEpicsPV() [1/2]

double getEpicsPV ( int index )

inherited

Read value from a EPICS PV.

Parameters

index index of PV

Returns: value or NAN if not existing

Definition at line 426 of file DQMHistAnalysis.cc.

◆ getEpicsPV() [2/2]

double getEpicsPV ( std::string keyname )

inherited

Read value from a EPICS PV.

Parameters

keyname key name (or full PV name) of PV

Returns: value or NAN if not existing

Definition at line 403 of file DQMHistAnalysis.cc.

◆ getEpicsPVChID() [1/2]

chid getEpicsPVChID ( int index )

inherited

Get EPICS PV Channel Id.

Parameters

index index of PV

Returns: Channel ID is written on success, otherwise nullptr

Definition at line 513 of file DQMHistAnalysis.cc.

◆ getEpicsPVChID() [2/2]

chid getEpicsPVChID ( std::string keyname )

inherited

Get EPICS PV Channel Id.

Parameters

keyname key name (or full PV name) of PV

Returns: Channel ID is written on success, otherwise nullptr

Definition at line 499 of file DQMHistAnalysis.cc.

◆ getEpicsStringPV() [1/2]

std::string getEpicsStringPV	(	int	index,
		bool &	status
	)

inherited

Read value from a EPICS PV.

Parameters

index	index of PV
status	return status (true on success)

Returns: string value (empty string if non existing)

Definition at line 474 of file DQMHistAnalysis.cc.

◆ getEpicsStringPV() [2/2]

std::string getEpicsStringPV	(	std::string	keyname,
		bool &	status
	)

inherited

Read value from a EPICS PV.

Parameters

keyname	key name (or full PV name) of PV
status	return status (true on success)

Returns: string value (empty string if non existing)

Definition at line 449 of file DQMHistAnalysis.cc.

◆ getEventProcessed()

static int getEventProcessed ( void )

inlinestaticinherited

Get the number of processed events.

(Attention, asynch histogram updates!)

Returns: Processed events.

Definition at line 155 of file DQMHistAnalysis.h.

◆ getFileNames()

virtual std::vector<std::string> getFileNames ( bool outputFiles )

inlinevirtualinherited

Return a list of output filenames for this modules.

This will be called when basf2 is run with "--dry-run" if the module has set either the c_Input or c_Output properties.

If the parameter outputFiles is false (for modules with c_Input) the list of input filenames should be returned (if any). If outputFiles is true (for modules with c_Output) the list of output files should be returned (if any).

If a module has sat both properties this member is called twice, once for each property.

The module should return the actual list of requested input or produced output filenames (including handling of input/output overrides) so that the grid system can handle input/output files correctly.

This function should return the same value when called multiple times. This is especially important when taking the input/output overrides from Environment as they get consumed when obtained so the finalized list of output files should be stored for subsequent calls.

Reimplemented in RootOutputModule, StorageRootOutputModule, and RootInputModule.

Definition at line 134 of file Module.h.

◆ getHistList()

static HistList& getHistList ( )

inlinestaticinherited

Get the list of the histograms.

Returns: The list of the histograms.

Definition at line 125 of file DQMHistAnalysis.h.

◆ getMonitoringObject()

MonitoringObject * getMonitoringObject ( const std::string & histname )

staticinherited

Get MonitoringObject with given name (new object is created if non-existing)

Parameters

histname name of MonitoringObject to get

Returns: The MonitoringObject

Definition at line 112 of file DQMHistAnalysis.cc.

◆ getMonObjList()

static const MonObjList& getMonObjList ( )

inlinestaticinherited

Get the list of MonitoringObjects.

Returns: The list of the MonitoringObjects.

Definition at line 131 of file DQMHistAnalysis.h.

◆ getName()

const std::string& getName ( ) const

inlineinherited

Returns the name of the module.

This can be changed via e.g. set_name() in the steering file to give more useful names if there is more than one module of the same type.

For identifying the type of a module, using getType() (or type() in Python) is recommended.

Definition at line 187 of file Module.h.

◆ getParamInfoListPython()

std::shared_ptr< boost::python::list > getParamInfoListPython ( ) const

inherited

Returns a python list of all parameters.

Each item in the list consists of the name of the parameter, a string describing its type, a python list of all default values and the description of the parameter.

Returns: A python list containing the parameters of this parameter list.

Definition at line 279 of file Module.cc.

◆ getPVPrefix()

std::string& getPVPrefix ( void )

inlineinherited

get global Prefix for EPICS PVs

Returns: prefix in use

Definition at line 486 of file DQMHistAnalysis.h.

◆ getReturnValue()

int getReturnValue ( ) const

inlineinherited

Return the return value set by this module.

This value is only meaningful if hasReturnValue() is true

Definition at line 381 of file Module.h.

◆ getRunType()

static const std::string& getRunType ( void )

inlinestaticinherited

Get the Run Type.

Returns: Run type string.

Definition at line 149 of file DQMHistAnalysis.h.

◆ getSigma68()

double getSigma68 ( TH1 * h ) const

inherited

Helper function to compute half of the central interval covering 68% of a distribution.

This quantity is an alternative to the standard deviation.

Parameters

h histogram

Returns: Half of the central interval covering 68% of a distribution.

Definition at line 225 of file DQMHistAnalysis.cc.

◆ getType()

const std::string & getType ( ) const

inherited

Returns the type of the module (i.e.

class name minus 'Module')

Definition at line 41 of file Module.cc.

◆ getUseEpics()

bool getUseEpics ( void )

inlineinherited

Getter for EPICS usage.

Returns: flag is in use

Definition at line 469 of file DQMHistAnalysis.h.

◆ getUseEpicsReadOnly()

bool getUseEpicsReadOnly ( void )

inlineinherited

Getter EPICS flag in read only mode.

Returns: flag if read only

Definition at line 475 of file DQMHistAnalysis.h.

◆ hasDeltaPar()

bool hasDeltaPar	(	const std::string &	dirname,
		const std::string &	histname
	)

inherited

Check if Delta histogram parameters exist for histogram.

Parameters

dirname	directory
histname	name of histogram

Returns: true if parameters have been set already

Definition at line 80 of file DQMHistAnalysis.cc.

◆ hasProperties()

bool hasProperties ( unsigned int propertyFlags ) const

inherited

Returns true if all specified property flags are available in this module.

Parameters

propertyFlags Ored EModulePropFlags which should be compared with the module flags.

Definition at line 160 of file Module.cc.

◆ if_false()

void if_false	(	const std::shared_ptr< Path > &	path,
		EAfterConditionPath	afterConditionPath = `EAfterConditionPath::c_End`
	)

inherited

A simplified version to add a condition to the module.

Please note that successive calls of this function will add more than one condition to the module. If more than one condition results in true, only the last of them will be used.

Please be careful: Avoid creating cyclic paths, e.g. by linking a condition to a path which is processed before the path where this module is located in.

It is equivalent to the if_value() method, using the expression "<1". This method is meant to be used together with the setReturnValue(bool value) method.

Parameters

path	Shared pointer to the Path which will be executed if the return value is false.
afterConditionPath	What to do after executing 'path'.

Definition at line 85 of file Module.cc.

◆ if_true()

void if_true	(	const std::shared_ptr< Path > &	path,
		EAfterConditionPath	afterConditionPath = `EAfterConditionPath::c_End`
	)

inherited

A simplified version to set the condition of the module.

Please note that successive calls of this function will add more than one condition to the module. If more than one condition results in true, only the last of them will be used.

Please be careful: Avoid creating cyclic paths, e.g. by linking a condition to a path which is processed before the path where this module is located in.

It is equivalent to the if_value() method, using the expression ">=1". This method is meant to be used together with the setReturnValue(bool value) method.

Parameters

path	Shared pointer to the Path which will be executed if the return value is true.
afterConditionPath	What to do after executing 'path'.

Definition at line 90 of file Module.cc.

◆ if_value()

void if_value	(	const std::string &	expression,
		const std::shared_ptr< Path > &	path,
		EAfterConditionPath	afterConditionPath = `EAfterConditionPath::c_End`
	)

inherited

Add a condition to the module.

Please note that successive calls of this function will add more than one condition to the module. If more than one condition results in true, only the last of them will be used.

See https://confluence.desy.de/display/BI/Software+ModCondTut or ModuleCondition for a description of the syntax.

Please be careful: Avoid creating cyclic paths, e.g. by linking a condition to a path which is processed before the path where this module is located in.

Parameters

expression	The expression of the condition.
path	Shared pointer to the Path which will be executed if the condition is evaluated to true.
afterConditionPath	What to do after executing 'path'.

Definition at line 79 of file Module.cc.

◆ registerEpicsPV()

int registerEpicsPV	(	std::string	pvname,
		std::string	keyname = `""`,
		bool	update_pvs = `true`
	)

inherited

EPICS related Functions.

Register a PV with its name and a key name

If you register large number of PVs at once, consider setting update_pvs = false and explicitly running updateEpicsPVs()

Parameters

pvname	full PV name
keyname	key name for easier access
update_pvs	if true, update all PVs (flush network) after new PV is registered

Returns: an index which can be used to access the PV instead of key name, -1 if failure

Definition at line 294 of file DQMHistAnalysis.cc.

◆ requestLimitsFromEpicsPVs() [1/3]

bool requestLimitsFromEpicsPVs	(	chid	id,
		double &	lowerAlarm,
		double &	lowerWarn,
		double &	upperWarn,
		double &	upperAlarm
	)

inherited

Get Alarm Limits from EPICS PV.

Parameters

id	Channel ID
&lowerAlarm	return low Alarm limit (lolo) if set, not changed otherwise
&lowerWarn	return low Warning limit (low) if set, not changed otherwise
&upperWarn	return upper Warning limit (high) if set, not changed otherwise
&upperAlarm	return upper Alarm limit (hihi) if set, not changed otherwise

Returns: true if limits could be read (even if there are none set)

Definition at line 561 of file DQMHistAnalysis.cc.

◆ requestLimitsFromEpicsPVs() [2/3]

bool requestLimitsFromEpicsPVs	(	int	index,
		double &	lowerAlarm,
		double &	lowerWarn,
		double &	upperWarn,
		double &	upperAlarm
	)

inherited

Get Alarm Limits from EPICS PV.

Parameters

index	index of PV
&lowerAlarm	return low Alarm limit (lolo) if set, not changed otherwise
&lowerWarn	return low Warning limit (low) if set, not changed otherwise
&upperWarn	return upper Warning limit (high) if set, not changed otherwise
&upperAlarm	return upper Alarm limit (hihi) if set, not changed otherwise

Returns: true if limits could be read (even if there are none set)

Definition at line 555 of file DQMHistAnalysis.cc.

◆ requestLimitsFromEpicsPVs() [3/3]

bool requestLimitsFromEpicsPVs	(	std::string	keyname,
		double &	lowerAlarm,
		double &	lowerWarn,
		double &	upperWarn,
		double &	upperAlarm
	)

inherited

Get Alarm Limits from EPICS PV.

Parameters

keyname	key name (or full PV name) of PV
&lowerAlarm	return low Alarm limit (lolo) if set, not changed otherwise
&lowerWarn	return low Warning limit (low) if set, not changed otherwise
&upperWarn	return upper Warning limit (high) if set, not changed otherwise
&upperAlarm	return upper Alarm limit (hihi) if set, not changed otherwise

Returns: true if limits could be read (even if there are none set)

Definition at line 549 of file DQMHistAnalysis.cc.

◆ setDescription()

void setDescription ( const std::string & description )

protectedinherited

Sets the description of the module.

Parameters

description A description of the module.

Definition at line 214 of file Module.cc.

◆ setEpicsPV() [1/4]

void setEpicsPV	(	int	index,
		double	value
	)

inherited

Write value to a EPICS PV.

Parameters

index	index of PV
value	value to write

Definition at line 365 of file DQMHistAnalysis.cc.

◆ setEpicsPV() [2/4]

void setEpicsPV	(	int	index,
		int	value
	)

inherited

Write value to a EPICS PV.

Parameters

index	index of PV
value	value to write

Definition at line 377 of file DQMHistAnalysis.cc.

◆ setEpicsPV() [3/4]

void setEpicsPV	(	std::string	keyname,
		double	value
	)

inherited

Write value to a EPICS PV.

Parameters

keyname	key name (or full PV name) of PV
value	value to write

Definition at line 323 of file DQMHistAnalysis.cc.

◆ setEpicsPV() [4/4]

void setEpicsPV	(	std::string	keyname,
		int	value
	)

inherited

Write value to a EPICS PV.

Parameters

keyname	key name (or full PV name) of PV
value	value to write

Definition at line 335 of file DQMHistAnalysis.cc.

◆ setEpicsStringPV() [1/2]

void setEpicsStringPV	(	int	index,
		std::string	value
	)

inherited

Write string to a EPICS PV.

Parameters

index	index of PV
value	string to write

Definition at line 389 of file DQMHistAnalysis.cc.

◆ setEpicsStringPV() [2/2]

void setEpicsStringPV	(	std::string	keyname,
		std::string	value
	)

inherited

Write string to a EPICS PV.

Parameters

keyname	key name (or full PV name) of PV
value	string to write

Definition at line 347 of file DQMHistAnalysis.cc.

◆ setEventProcessed()

void setEventProcessed ( int e )

inlineinherited

Set the number of processed events.

(Attention, asynch histogram updates!)

e Processed events.

Definition at line 167 of file DQMHistAnalysis.h.

◆ setLogInfo()

void setLogInfo	(	int	logLevel,
		unsigned int	logInfo
	)

inherited

Configure the printed log information for the given level.

Parameters

logLevel	The log level (one of LogConfig::ELogLevel)
logInfo	What kind of info should be printed? ORed combination of LogConfig::ELogInfo flags.

Definition at line 73 of file Module.cc.

◆ setName()

void setName ( const std::string & name )

inlineinherited

Set the name of the module.

Note: The module name is set when using the REG_MODULE macro, but the module can be renamed before calling process() using the set_name() function in your steering file.

Parameters

name	The name of the module

Definition at line 214 of file Module.h.

◆ setParamPython()

void setParamPython	(	const std::string &	name,
		const boost::python::object &	pyObj
	)

privateinherited

Implements a method for setting boost::python objects.

The method supports the following types: list, dict, int, double, string, bool The conversion of the python object to the C++ type and the final storage of the parameter value is done in the ModuleParam class.

Parameters

name	The unique name of the parameter.
pyObj	The object which should be converted and stored as the parameter value.

Definition at line 234 of file Module.cc.

◆ setParamPythonDict()

void setParamPythonDict ( const boost::python::dict & dictionary )

privateinherited

Implements a method for reading the parameter values from a boost::python dictionary.

The key of the dictionary has to be the name of the parameter and the value has to be of one of the supported parameter types.

Parameters

dictionary The python dictionary from which the parameter values are read.

Definition at line 249 of file Module.cc.

◆ setPropertyFlags()

void setPropertyFlags ( unsigned int propertyFlags )

inherited

Sets the flags for the module properties.

Parameters

propertyFlags bitwise OR of EModulePropFlags

Definition at line 208 of file Module.cc.

◆ setPVPrefix()

void setPVPrefix ( std::string & prefix )

inlineinherited

set global Prefix for EPICS PVs

Parameters

prefix Prefix to set

Definition at line 492 of file DQMHistAnalysis.h.

◆ setReturnValue() [1/2]

void setReturnValue ( bool value )

protectedinherited

Sets the return value for this module as bool.

The bool value is saved as an integer with the convention 1 meaning true and 0 meaning false. The value can be used in the steering file to divide the analysis chain into several paths.

Parameters

value The value of the return value.

Definition at line 227 of file Module.cc.

◆ setReturnValue() [2/2]

void setReturnValue ( int value )

protectedinherited

Sets the return value for this module as integer.

The value can be used in the steering file to divide the analysis chain into several paths.

Parameters

value The value of the return value.

Definition at line 220 of file Module.cc.

◆ setRunType()

void setRunType ( std::string & t )

inlineinherited

Set the Run Type.

t Run type string.

Definition at line 161 of file DQMHistAnalysis.h.

◆ setType()

void setType ( const std::string & type )

protectedinherited

Set the module type.

Only for use by internal modules (which don't use the normal REG_MODULE mechanism).

Definition at line 48 of file Module.cc.

◆ setUseEpics()

void setUseEpics ( bool flag )

inlineinherited

Setter for EPICS usage.

Parameters

flag	set in use

Definition at line 457 of file DQMHistAnalysis.h.

◆ setUseEpicsReadOnly()

void setUseEpicsReadOnly ( bool flag )

inlineinherited

Setter EPICS flag in read only mode.

Parameters

flag	set read only

Definition at line 463 of file DQMHistAnalysis.h.

◆ StringSplit()

std::vector< std::string > StringSplit	(	const std::string &	s,
		const char	delim
	)

inherited

Helper function for string token split.

Parameters

s	String to split
delim	delimiter

Returns: vector of strings

Definition at line 234 of file DQMHistAnalysis.cc.

◆ UpdateCanvas() [1/2]

void UpdateCanvas	(	std::string	name,
		bool	updated = `true`
	)

inherited

Mark canvas as updated (or not)

Parameters

name	name of Canvas
updated	was updated

Definition at line 259 of file DQMHistAnalysis.cc.

◆ UpdateCanvas() [2/2]

void UpdateCanvas	(	TCanvas *	canvas,
		bool	updated = `true`
	)

inherited

Mark canvas as updated (or not)

Parameters

canvas	Canvas from which to take the name for update
updated	was updated

Definition at line 264 of file DQMHistAnalysis.cc.

◆ updateEpicsPVs()

void updateEpicsPVs ( float timeout )

inherited

Update all EPICS PV (flush to network)

Parameters

timeout maximum time until timeout in s

Definition at line 527 of file DQMHistAnalysis.cc.

Member Data Documentation

◆ m_epicsReadOnly

bool m_epicsReadOnly

staticprivateinherited

Initial value:

=

false

Flag if to use EPICS in ReadOnly mode (for reading limits) do not set by yourself, use EpicsEnable module to set.

Definition at line 105 of file DQMHistAnalysis.h.

◆ s_eventProcessed

int s_eventProcessed = 0

inlinestaticprivateinherited

Number of Events processed to fill histograms.

Attention: histograms are updates asynchronously Thus the number for a specific histogram may be lower or higher. If you need precise number, you must fill it in the histogram itself (e.g. underflow bin)

Definition at line 88 of file DQMHistAnalysis.h.

The documentation for this class was generated from the following files:

dqm/analysis/modules/include/DQMHistAnalysisPXDEff.h
dqm/analysis/modules/src/DQMHistAnalysisPXDEff.cc
