CDCCKFResultStorer Class Reference

Store resutling tracks and relations on the dataStore. More...

#include <CDCCKFResultStorer.h>

Inheritance diagram for CDCCKFResultStorer:

Collaboration diagram for CDCCKFResultStorer:

Public Types
using	IOTypes = std::tuple< AIOTypes... >
	Types that should be served to apply on invokation.
using	IOVectors = std::tuple< std::vector< AIOTypes >... >
	Vector types that should be served to apply on invokation.

Public Member Functions
void	exposeParameters (ModuleParamList *moduleParamList, const std::string &prefix) override
	Expose the parameters of the sub findlets.
void	apply (const std::vector< CDCCKFResult > &results) override
	Do the track/hit finding/merging.
void	initialize () override
	Register the store arrays.
virtual std::string	getDescription ()
	Brief description of the purpose of the concret findlet.
virtual void	apply (ToVector< AIOTypes > &... ioVectors)=0
	Main function executing the algorithm.
void	beginRun () override
	Receive and dispatch signal for the beginning of a new run.
void	beginEvent () override
	Receive and dispatch signal for the start of a new event.
void	endRun () override
	Receive and dispatch signal for the end of the run.
void	terminate () override
	Receive and dispatch Signal for termination of the event processing.

Protected Types
using	ToVector = typename ToVectorImpl< T >::Type
	Short hand for ToRangeImpl.

Protected Member Functions
void	addProcessingSignalListener (ProcessingSignalListener *psl)
	Register a processing signal listener to be notified.
int	getNProcessingSignalListener ()
	Get the number of currently registered listeners.

Private Types
using	Super = TrackFindingCDC::Findlet< const CDCCKFResult >
	Parent class.

Private Attributes
std::string	m_param_writeOutDirectionAsString = "both"
	Parameter for the distance given to the framework (can not handle EForwardBackward directly)
TrackFindingCDC::EForwardBackward	m_param_writeOutDirection = TrackFindingCDC::EForwardBackward::c_Unknown
	Direction parameter converted from the string parameters.
bool	m_param_exportTracks = true
	Export the tracks or not.
bool	m_param_exportAllTracks = false
	Export all tracks, even if they did not reach the center of the CDC.
std::string	m_param_outputRecoTrackStoreArrayName = "CKFRecoTracks"
	StoreArray name of the output Track Store Array.
std::string	m_param_outputRelationRecoTrackStoreArrayName = "RecoTracks"
	StoreArray name of the tracks, the output reco tracks should be related to.
std::string	m_param_trackFindingDirectionAsString = "forward"
	Parameter for the direction of the CKF.
TrackFindingCDC::EForwardBackward	m_param_trackFindingDirection = TrackFindingCDC::EForwardBackward::c_Unknown
	Direction parameter converted from the string parameters.
bool	m_param_setTakenFlag = true
	Set flag that hit is taken.
RecoHitInformation::OriginTrackFinder	m_trackFinderType = RecoHitInformation::c_SVDtoCDCCKF
	What was used to seed the CKF (typically c_SVDtoCDCCKF, c_ECLtoCDCCKF)
std::string	m_seedComponentString = "SVD"
	Where does the seed track for the CKF come from (typically SVD, ECL)
StoreArray< RecoTrack >	m_outputRecoTracks
	Output Reco Tracks Store Array.
std::vector< ProcessingSignalListener * >	m_subordinaryProcessingSignalListeners
	References to subordinary signal processing listener contained in this findlet.
bool	m_initialized = false
	Flag to keep track whether initialization happend before.
bool	m_terminated = false
	Flag to keep track whether termination happend before.
std::string	m_initializedAs
	Name of the type during initialisation.

Detailed Description

Store resutling tracks and relations on the dataStore.

Definition at line 28 of file CDCCKFResultStorer.h.

---

The documentation for this class was generated from the following files:

• tracking/ckf/cdc/findlets/include/CDCCKFResultStorer.h
• tracking/ckf/cdc/findlets/src/CDCCKFResultStorer.cc
