Clusterizend Class Reference

Clustering module. More...

#include <Clusterizend.h>

Collaboration diagram for Clusterizend:

Public Member Functions
	Clusterizend (const clusterer_params &params)
clusterer_params	getParams ()
void	setPlaneShape (std::vector< ushort > planeShape)
void	setNewPlane (c3array &houghmap_plain)
	Next event initialization: set a new hough space for clustering and track finding.
bool	has_before (cell_index entry, ushort dim)
	Clustering logic. More...
cell_index	before (cell_index entry, ushort dim)
bool	has_after (cell_index entry, ushort dim)
cell_index	after (cell_index entry, ushort dim)
void	blockcheck (std::vector< cell_index > *neighbors, cell_index elem, ushort dim)
std::vector< cell_index >	regionQuery (cell_index entry)
std::vector< SimpleCluster >	dbscan ()
void	expandCluster (std::vector< cell_index > &N, SimpleCluster &C)
std::vector< cell_index >	getCandidates ()
template<class T >
std::string	printVector (std::vector< T > vecX)
template<class T >
std::string	printCells (std::vector< T > vecX)

Private Attributes
clusterer_params	m_params
	Clusterizend.
std::vector< ushort >	m_planeShape
std::vector< ushort >	m_valmax
ushort	m_dimsize
boost::array< c3index, 3 >	m_c3shape = {{ 40, 384, 9 }}
c3array *	m_houghVals {0}
c3array	m_houghVisit = c3array(m_c3shape)

Detailed Description

Clustering module.

Definition at line 114 of file Clusterizend.h.

Member Function Documentation

getCandidates()

vector< cell_index > getCandidates

(

)

all candidiates TODO: select

Definition at line 152 of file Clusterizend.cc.

{
  vector<cell_index> candidates;
  for (c3index iom = 0; iom < 40; iom++) {
    for (c3index iph = 0; iph < 384; iph++) {
      for (c3index ith = 0; ith < 9; ith++) {
        if ((*m_houghVals)[iom][iph][ith] > m_params.minweight) {
          cell_index elem = {iom, iph, ith};
          candidates.push_back(elem);
        }
      }
    }
  }
  return candidates;
}

has_before()

bool has_before	(	cell_index	entry,
		ushort	dim
	)

Clustering logic.

Get neighboring cells before and after a cell in track space before and after is defined along the track parameter axes given by dim.

Definition at line 17 of file Clusterizend.cc.

---

The documentation for this class was generated from the following files:

• trg/cdc/include/Clusterizend.h
• trg/cdc/src/Clusterizend.cc
