BelleLathe class. More...
#include <BelleLathe.h>
Public Member Functions | |
| BelleLathe (const G4String &pName) | |
| Constructor for "nominal" BelleLathe whose parameters are to be set by a G4VPVParamaterisation later. | |
| BelleLathe (const G4String &pName, double phi0, double dphi, int n, double *z, double *rin, double *rout) | |
| explicit constructor | |
| BelleLathe (const G4String &pName, double, double, const std::vector< zr_t > &) | |
| explicit constructor | |
| virtual | ~BelleLathe () |
| Destructor. | |
| void | ComputeDimensions (G4VPVParameterisation *p, const G4int n, const G4VPhysicalVolume *pRep) |
| compute the dimensions | |
| G4bool | CalculateExtent (const EAxis pAxis, const G4VoxelLimits &pVoxelLimit, const G4AffineTransform &pTransform, G4double &pMin, G4double &pMax) const |
| calculate the extent of the volume | |
| EInside | Inside (const G4ThreeVector &p) const |
| Return whether point inside/outside/on surface, using tolerance. | |
| G4ThreeVector | SurfaceNormal (const G4ThreeVector &p) const |
| Calculate side nearest to p, and return normal. | |
| G4double | DistanceToIn (const G4ThreeVector &p, const G4ThreeVector &v) const |
| Calculate distance to shape from outside - return kInfinity if no intersection. | |
| G4double | DistanceToIn (const G4ThreeVector &p) const |
| Calculate exact shortest distance to any boundary from outside. | |
| G4double | DistanceToOut (const G4ThreeVector &p, const G4ThreeVector &v, const G4bool calcNorm=false, G4bool *validNorm=0, G4ThreeVector *n=0) const |
| Calculate distance to surface of shape from inside. | |
| G4double | DistanceToOut (const G4ThreeVector &p) const |
| Calculate exact shortest distance to any boundary from inside. | |
| G4GeometryType | GetEntityType () const |
| Get entity type. | |
| G4ThreeVector | GetPointOnSurface () const |
| Get point on surface. | |
| G4double | GetCubicVolume () |
| Get cubic volume. | |
| G4double | GetSurfaceArea () |
| Get surface area. | |
| G4VSolid * | Clone () const |
| Make a clone of the object. | |
| void | BoundingLimits (G4ThreeVector &pMin, G4ThreeVector &pMax) const |
| Two vectors define an axis-parallel bounding box for the shape. | |
| std::ostream & | StreamInfo (std::ostream &os) const |
| Stream object contents to an output stream. | |
| void | DescribeYourselfTo (G4VGraphicsScene &scene) const |
| Visualisation function. | |
| G4Polyhedron * | CreatePolyhedron () const |
| create polyhedron | |
| BelleLathe (__void__ &) | |
| Fake default constructor for usage restricted to direct object persistency for clients requiring preallocation of memory for persistifiable objects. | |
| BelleLathe (const BelleLathe &rhs) | |
| copy constructor | |
| BelleLathe & | operator= (const BelleLathe &rhs) |
| assignment operator | |
Protected Member Functions | |
| bool | insector (double, double) const |
| True if (x,y) is within the shape rotation. | |
| int | wn_poly (const zr_t &) const |
| wn_poly | |
| double | mindist (const zr_t &) const |
| minimal distance | |
| std::vector< double > | linecross (const G4ThreeVector &, const G4ThreeVector &) const |
| calculate all ray solid's surface intersection return ordered vector | |
| void | eartrim () const |
| ear trim | |
| zr_t | normal (const zr_t &, double &) const |
| return normal | |
| void | getvolarea () |
| get volume area | |
| void | Init (const std::vector< zr_t > &, double, double) |
| initialize | |
Private Attributes | |
| std::vector< zr_t > | fcontour |
| vector of zr structs | |
| std::vector< cachezr_t > | fcache |
| vector of cached zr structs | |
| std::vector< double > | fz |
| vector of z values | |
| std::vector< int > | findx |
| vector of indices | |
| std::vector< int > | fseg |
| vector of segments | |
| std::vector< double > | farea |
| vector of area values | |
| std::vector< triangle_t > | ftlist |
| vector of triangle structs | |
| double | fphi |
| starting angle | |
| double | fdphi |
| finishing angle | |
| double | fs0 |
| fs0 | |
| double | fc0 |
| fc0 | |
| double | fs1 |
| fs1 | |
| double | fc1 |
| fc1 | |
| double | fn0x |
| fn0x | |
| double | fn0y |
| fn0y | |
| double | fn1x |
| fn1x | |
| double | fn1y |
| fn1y | |
| double | frmin |
| minimal r value | |
| double | frmax |
| maximal r value | |
| double | fzmin |
| minimal z value | |
| double | fzmax |
| maximal z value | |
| bool | fgtpi |
| greater than pi? | |
| bool | ftwopi |
| bound within +- 2pi? | |
| G4VSolid * | fshape |
| shape | |
| std::vector< G4ThreeVector > | fsurf |
| vector of surfaces | |
BelleLathe class.
Definition at line 67 of file BelleLathe.h.
