GeoConfiguration Class Reference

configuration of the geometry More...

#include <GeoConfiguration.h>

Inheritance diagram for GeoConfiguration:

Collaboration diagram for GeoConfiguration:

Public Member Functions
	GeoConfiguration ()=default
	empty constructor for ROOT
	GeoConfiguration (const std::string &name, double width, double height, double length, const std::string &material)
	Construct new geometry configuration. More...
void	addMaterial (const GeoMaterial &material)
	add a material to the list of materials
void	addComponent (const GeoComponent &component)
	add a component to the list of components
const std::string &	getName () const
	get the name of the detector
double	getGlobalWidth () const
	get the half width of the global volume, that is length in + and - x direction. More...
double	getGlobalHeight () const
	get the half height of the global volume, that is length in + and - y direction. More...
double	getGlobalLength () const
	get the half length of the global volume, that is length in + and - z direction. More...
const std::string &	getGlobalMaterial () const
	get the material of the global volume
const std::vector< GeoMaterial > &	getMaterials () const
	get List of Materials
const std::vector< GeoComponent > &	getComponents () const
	get list of components

Private Member Functions
	ClassDef (GeoConfiguration, 1)
	Add ROOT reflection info.

Private Attributes
std::vector< GeoMaterial >	m_materials
	list of Materials
std::vector< GeoComponent >	m_components
	list of components
std::string	m_name
	name of the detector configuration
double	m_globalWidth {0}
	half width of the global volume
double	m_globalHeight {0}
	half height of the global volume
double	m_globalLength {0}
	half length of the global volume
std::string	m_globalMaterial
	material of the global volume

Detailed Description

configuration of the geometry

Definition at line 23 of file GeoConfiguration.h.

Constructor & Destructor Documentation

GeoConfiguration()

GeoConfiguration ( const std::string &  name, double  width, double  height, double  length, const std::string &  material  )

inline

Construct new geometry configuration.

Parameters

name	name of the detector
width	half width of the global volume
height	half height of the global volume
length	half length of the global volume
material	material of the global volume

Definition at line 34 of file GeoConfiguration.h.

                                                                                                                  : TObject(),
      m_name(name), m_globalWidth(width), m_globalHeight(height), m_globalLength(length), m_globalMaterial(material) {}

Member Function Documentation

getGlobalHeight()

double getGlobalHeight ( ) const

inline

get the half height of the global volume, that is length in + and - y direction.

Will be determined automatically to fit all volumes if set to non-positive value.

Definition at line 47 of file GeoConfiguration.h.

getGlobalLength()

double getGlobalLength ( ) const

inline

get the half length of the global volume, that is length in + and - z direction.

Will be determined automatically to fit all volumes if set to non-positive value.

Definition at line 50 of file GeoConfiguration.h.

getGlobalWidth()

double getGlobalWidth ( ) const

inline

get the half width of the global volume, that is length in + and - x direction.

Will be determined automatically to fit all volumes if set to non-positive value.

Definition at line 44 of file GeoConfiguration.h.

---

The documentation for this class was generated from the following file:

• geometry/dbobjects/include/GeoConfiguration.h
