The Raw COPPER class ver.1 ( the latest version since May, 2014 ) This class stores data received by COPPER via belle2linkt Data from all detectors except PXD are stored in this class. More...
#include <RawCOPPERFormat_v2.h>
Public Types | |
| enum | { DATA_FORMAT_VERSION = 2 } |
| Format version number. | |
| enum | { POS_NWORDS = 0 , POS_NODE_ID = 6 } |
| enum | { POS_FTSW_ID_OLD = 5 , TEMP_POS_NWORDS_HEADER = 1 , OLD_FTSW_NWORDS_HEADER = 6 } |
Public Member Functions | |
| RawCOPPERFormat_v2 () | |
| Default constructor. | |
| virtual | ~RawCOPPERFormat_v2 () |
| Constructor using existing pointer to raw data buffer. More... | |
| int | Get1stDetectorNwords (int n) OVERRIDE_CPP17 |
| get Detector buffer length of slot A | |
| int | Get2ndDetectorNwords (int n) OVERRIDE_CPP17 |
| get Detector buffer length of slot B | |
| int | Get3rdDetectorNwords (int n) OVERRIDE_CPP17 |
| get Detector buffer length of slot C | |
| int | Get4thDetectorNwords (int n) OVERRIDE_CPP17 |
| get Detector buffer length of slot D | |
| int * | GetRawTrlBufPtr (int n) OVERRIDE_CPP17 |
| get buffer pointer of rawcopper trailer | |
| int | GetExpNo (int n) OVERRIDE_CPP17 |
| get Experimental # from header | |
| unsigned int | GetExpRunSubrun (int n) OVERRIDE_CPP17 |
| get Experimental # from header | |
| int | GetRunNo (int n) OVERRIDE_CPP17 |
| Exp# (10bit) run# (14bit) restart # (8bit) | |
| int | GetSubRunNo (int n) OVERRIDE_CPP17 |
| get run # (14bit) | |
| unsigned int | GetEveNo (int n) OVERRIDE_CPP17 |
| get subrun #(8bit) | |
| int | GetDataType (int n) OVERRIDE_CPP17 |
| get contents of header | |
| int | GetTruncMask (int n) OVERRIDE_CPP17 |
| get contents of header | |
| unsigned int | GetErrorBitFlag (int n) OVERRIDE_CPP17 |
| get contents of header More... | |
| void | AddErrorBitFlag (int n, unsigned int error_bit_flag) OVERRIDE_CPP17 |
| Add Detected Error bitflag. | |
| int | GetPacketCRCError (int n) OVERRIDE_CPP17 |
| check CRC packet Error | |
| int | GetEventCRCError (int n) OVERRIDE_CPP17 |
| check CRC event Error | |
| unsigned int | GetNodeID (int n) OVERRIDE_CPP17 |
| get node-ID from data | |
| virtual int | GetNumFINESSEBlock (int n) OVERRIDE_CPP17 |
| get # of FINNESEs which contains data | |
| int | Get1stFINESSENwords (int n) OVERRIDE_CPP17 |
| get data size of FINESSE slot A buffer | |
| int | Get2ndFINESSENwords (int n) OVERRIDE_CPP17 |
| get data size of FINESSE slot B buffer | |
| int | Get3rdFINESSENwords (int n) OVERRIDE_CPP17 |
| get data size of FINESSE slot C buffer | |
| int | Get4thFINESSENwords (int n) OVERRIDE_CPP17 |
| get data size of FINESSE slot D buffer | |
| unsigned int | GetTTCtimeTRGType (int n) OVERRIDE_CPP17 |
| get b2l block from "FEE b2link header" More... | |
| unsigned int | GetTTUtime (int n) OVERRIDE_CPP17 |
| Check if COPPER Magic words are correct. | |
| int | GetTTCtime (int n) OVERRIDE_CPP17 |
| Get ctime. | |
| int | GetTRGType (int n) OVERRIDE_CPP17 |
| Get trgtype. | |
| void | GetTTTimeVal (int n, struct timeval *tv) OVERRIDE_CPP17 |
| Get timeval. | |
| int | GetMaxNumOfCh (int n) OVERRIDE_CPP17 |
| Get the max number of channels in a readout board. | |
| virtual int | GetDetectorNwords (int n, int finesse_num)=0 |
| set buffer ( delete_flag : m_buffer is freeed( = 0 )/ not freeed( = 1 ) in Destructer ) More... | |
| virtual int * | GetDetectorBuffer (int n, int finesse_num) |
| get Detector buffer | |
| virtual int * | Get1stDetectorBuffer (int n)=0 |
| get Detector buffer of slot A | |
| virtual int * | Get2ndDetectorBuffer (int n)=0 |
| get Detector Buffer of slot B | |
| virtual int * | Get3rdDetectorBuffer (int n)=0 |
| get Detector Buffer of slot C | |
| virtual int * | Get4thDetectorBuffer (int n)=0 |
| get Detector Buffer of slot D | |
| virtual int * | GetRawHdrBufPtr (int n) |
| get buffer pointer of rawcopper header(Currently same as GetBufferPos) | |
| virtual int * | GetFINESSEBuffer (int n, int finesse_num) |
| get FINESSE buffer pointer | |
| virtual int * | Get1stFINESSEBuffer (int n) |
| get FINESSE buffer pointer for slot A | |
| virtual int * | Get2ndFINESSEBuffer (int n) |
| get FINESSE buffer pointer for slot B | |
| virtual int * | Get3rdFINESSEBuffer (int n) |
| get FINESSE buffer pointer for slot C | |
| virtual int * | Get4thFINESSEBuffer (int n) |
| get FINESSE buffer pointer for slot D | |
| virtual int | GetEventCRC16Value (int n, int finesse_num) |
| Get Event CRC16 value. | |
| virtual unsigned int | GetCOPPERCounter (int n)=0 |
| get COPPER counter(not event number) | |
| virtual int | GetOffsetFINESSE (int n, int finesse) |
| get # of offset words | |
| virtual int | GetOffset1stFINESSE (int n)=0 |
| get # of offset words for FINESSE slot A buffer position | |
| virtual int | GetOffset2ndFINESSE (int n) |
| get # of offset words for FINESSE slot B buffer position | |
| virtual int | GetOffset3rdFINESSE (int n) |
| get # of offset words for FINESSE slot C buffer position | |
| virtual int | GetOffset4thFINESSE (int n) |
| get # of offset words for FINESSE slot D buffer position | |
| virtual int | GetFINESSENwords (int n, int finesse)=0 |
| get data size of FINESSE buffer | |
| virtual int * | GetExpRunSubrunBuf (int n)=0 |
| get b2l block from "FEE b2link header" More... | |
| virtual unsigned int | GetB2LFEE32bitEventNumber (int n)=0 |
| get b2l block from "FEE b2link header" | |
| virtual unsigned int | GetMagicDriverHeader (int n)=0 |
| get magic word of COPPER driver header | |
| virtual unsigned int | GetMagicFPGAHeader (int n)=0 |
| get magic word of COPPER FPGA header | |
| virtual unsigned int | GetMagicFPGATrailer (int n)=0 |
| get magic word of COPPER FPGA trailer | |
| virtual unsigned int | GetMagicDriverTrailer (int n)=0 |
| get magic word of COPPER driver trailer | |
| virtual unsigned int | GetTrailerChksum (int n)=0 |
| Get checksum in RawTrailer. | |
| virtual bool | CheckCOPPERMagic (int n)=0 |
| Check if COPPER Magic words are correct. | |
| virtual unsigned int | FillTopBlockRawHeader (unsigned int m_node_id, unsigned int prev_eve32, unsigned int prev_exprunsubrun_no, unsigned int *cur_exprunsubrun_no)=0 |
| should be called by DeSerializerCOPPER.cc and fill contents in RawHeader | |
| virtual unsigned int | GetDriverChkSum (int n)=0 |
| read COPPER driver's checksum value | |
| virtual unsigned int | CalcDriverChkSum (int n)=0 |
| calc COPPER driver's checksum value | |
| virtual void | CheckData (int n, unsigned int prev_evenum, unsigned int *cur_evenum, unsigned int prev_copper_ctr, unsigned int *cur_copper_ctr, unsigned int prev_exprunsubrun_no, unsigned int *cur_exprunsubrun_no)=0 |
| check data contents | |
| virtual void | CheckUtimeCtimeTRGType (int n)=0 |
| check data contents | |
| virtual unsigned int | CalcXORChecksum (int *buf, int nwords) |
| calc XOR checksum | |
| virtual int * | PackDetectorBuf (int *packed_buf_nwords, int *detector_buf_1st, int nwords_1st, int *detector_buf_2nd, int nwords_2nd, int *detector_buf_3rd, int nwords_3rd, int *detector_buf_4th, int nwords_4th, RawCOPPERPackerInfo rawcprpacker_info)=0 |
| Pack data (format ver. = -1 -> Select the latest format version) | |
| virtual int * | PackDetectorBuf (int *packed_buf_nwords, int *const(&detector_buf_ch)[MAX_PCIE40_CH], int const(&nwords_ch)[MAX_PCIE40_CH], RawCOPPERPackerInfo rawcpr_info) |
| Pack data for PCIe40 data-format. | |
| virtual void | CompareHeaderValue (int n, const unsigned int(&input_val)[MAX_PCIE40_CH], std::vector< std::vector< unsigned int > > &result) |
| Compare value from different channels and make a statistics table. | |
| virtual void | GetNodeName (int n, char *node_name, int bufsize) |
| Get hostname of a node from the RawCOPPER header. | |
| virtual void | GetNodeName (char *node_name, unsigned int node_id, int bufsize) |
| Get hostname of a node from an argument. | |
| virtual bool | CheckOnlineRemovedDataBit (int n, int finesse_num) |
| Check if COPPER Magic words are correct. | |
| virtual void | SetBuffer (int *bufin, int nwords, int delete_flag, int num_events, int num_nodes) |
| set buffer ( delete_flag : m_buffer is freeed( = 0 )/ not freeed( = 1 ) in Destructer ) | |
| virtual int | TotalBufNwords () |
| Get total length of m_buffer. | |
| virtual int | GetBufferPos (int n) |
| get position of data block in word | |
| virtual int * | GetBuffer (int n) |
| get nth buffer pointer | |
| virtual int * | GetWholeBuffer () |
| get pointer to buffer(m_buffer) | |
| virtual int | GetNumEntries () |
| get # of data blocks = (# of nodes)*(# of events) | |
| virtual int | GetNumNodes () |
| get # of data sources(e.g. # of COPPER boards) in m_buffer | |
| virtual int | GetNumEvents () |
| get # of events in m_buffer | |
| virtual int | GetPreAllocFlag () |
| get malloc_flag | |
| virtual int | GetBlockNwords (int n) |
| get size of a data block | |
| virtual int | CheckFTSWID (int n) |
| get FTSW ID to check whether this data block is FTSW data or not | |
| virtual int | CheckTLUID (int n) |
| get FTSW ID to check whether this data block is FTSW data or not | |
| virtual void | CopyBlock (int n, int *buf_to) |
| Copy one datablock to buffer. | |
| virtual void | PrintData (int *buf, int nwords) |
| print data | |
Public Attributes | |
| RawHeader_v2 | tmp_header |
| header ( not recorded ) | |
| RawTrailer_v2 | tmp_trailer |
| trailer ( not recorded ) | |
Protected Attributes | |
| int | m_nwords |
| number of words of buffer | |
| int | m_num_nodes |
| number of nodes in this object | |
| int | m_num_events |
| number of events in this object | |
| int * | m_buffer |
| Buffer. | |
| int | m_use_prealloc_buf |
| not recorded More... | |
The Raw COPPER class ver.1 ( the latest version since May, 2014 ) This class stores data received by COPPER via belle2linkt Data from all detectors except PXD are stored in this class.
Definition at line 36 of file RawCOPPERFormat_v2.h.
|
virtual |
Constructor using existing pointer to raw data buffer.
Destructor
Definition at line 25 of file RawCOPPERFormat_v2.cc.
|
pure virtualinherited |
set buffer ( delete_flag : m_buffer is freeed( = 0 )/ not freeed( = 1 ) in Destructer )
get Detector buffer length
Implemented in RawCOPPERFormat_v0, PreRawCOPPERFormat_v2, PreRawCOPPERFormat_v1, PreRawCOPPERFormat_latest, PostRawCOPPERFormat_v2, PostRawCOPPERFormat_v1, and PostRawCOPPERFormat_latest.
|
pure virtualinherited |
get b2l block from "FEE b2link header"
get b2l block from "FEE b2link header"
Implemented in RawCOPPERFormat_v0, PreRawCOPPERFormat_v2, PreRawCOPPERFormat_v1, PreRawCOPPERFormat_latest, PostRawCOPPERFormat_v2, PostRawCOPPERFormat_v1, and PostRawCOPPERFormat_latest.
|
protectedinherited |
not recorded
flag for deleting m_buffer in destructer( 0:delete, 1: not delete) When using pre-allocated buffer, the buffer should be reused and not deleted in the destructer
Definition at line 102 of file RawDataBlockFormat.h.
