The Class for VXD geometry. More...
#include <SVDGeometryPar.h>
Public Member Functions | |
| SVDGeometryPar () | |
| Default constructor. | |
| const std::vector< VXDRotationSolidPar > & | getRotationSolids () const |
| get SVD halfshell Rotation Solids | |
| std::vector< VXDRotationSolidPar > & | getRotationSolids () |
| get SVD halfshell Rotation Solids | |
| const std::map< int, SVDEndringsPar > & | getEndrings () const |
| get endrings | |
| std::map< int, SVDEndringsPar > & | getEndrings () |
| get endrings | |
| const std::map< int, SVDCoolingPipesPar > & | getCoolingPipes () const |
| get cooling pipes | |
| std::map< int, SVDCoolingPipesPar > & | getCoolingPipes () |
| get cooling pipes | |
| const std::map< int, SVDSupportRibsPar > & | getSupportRibs () const |
| get support ribs | |
| std::map< int, SVDSupportRibsPar > & | getSupportRibs () |
| get support ribs | |
| const SVDSupportRibsPar & | getSupportRibs (int) const |
| get SVD Support Ribs | |
| const SVDEndringsPar & | getEndrings (int) const |
| get SVD Endrings | |
| const SVDCoolingPipesPar & | getCoolingPipes (int) const |
| get SVD Cooling Pipes | |
| bool | getSupportRibsExist (int) const |
| return if SVD Support Ribs exist | |
| bool | getEndringsExist (int) const |
| return if endrings exist | |
| bool | getCoolingPipesExist (int) const |
| return if endrings exist | |
| std::vector< SVDSensorInfoPar * > & | getSensorInfos () |
| get sensorInfos | |
| std::string | getPrefix () const |
| get prefix | |
| void | setPrefix (const std::string &prefix) |
| set prefix | |
| const VXDGlobalPar & | getGlobalParams () const |
| get global parameters | |
| void | setGlobalParams (const VXDGlobalPar &globals) |
| set global parameters | |
| const VXDEnvelopePar & | getEnvelope () const |
| get envelope parameters | |
| void | setEnvelope (const VXDEnvelopePar &envelope) |
| set envelope parameters | |
| const VXDGeoRadiationSensorsPar & | getRadiationSensors () const |
| get radiation sensor parameters | |
| void | setRadiationSensors (const VXDGeoRadiationSensorsPar &diamonds) |
| set radiation sensor parameters | |
| std::map< std::string, VXDAlignmentPar > & | getAlignmentMap () |
| get alignmant map | |
| VXDAlignmentPar | getAlignment (std::string name) const |
| get alignment parameters for component name | |
| const std::vector< VXDHalfShellPar > & | getHalfShells () const |
| get half-shell | |
| std::vector< VXDHalfShellPar > & | getHalfShells () |
| get half-shell | |
| std::map< int, VXDGeoLadderPar > & | getLadderMap () |
| get ladder map | |
| const VXDGeoLadderPar & | getLadder (int layerID) const |
| get ladder for given layer | |
| const VXDGeoSensorPar & | getSensor (std::string sensorTypeID) const |
| get sensor type | |
| const VXDGeoComponentPar & | getComponent (std::string name) const |
| get component | |
| const std::map< std::string, VXDGeoSensorPar > & | getSensorMap () const |
| get sensor map | |
| std::map< std::string, VXDGeoSensorPar > & | getSensorMap () |
| get sensor map | |
| const std::map< std::string, VXDGeoComponentPar > & | getComponentMap () const |
| get component maps | |
| std::map< std::string, VXDGeoComponentPar > & | getComponentMap () |
| get component maps | |
| int | getSensitiveChipID (std::string name) const |
| get Bkg sensitive chip Id | |
| std::map< std::string, int > & | getSensitiveChipIdMap () |
| get sensitive chip id map | |
| const std::vector< std::string > & | getComponentInsertOder () const |
| get component insert order | |
| std::vector< std::string > & | getComponentInsertOder () |
| get component insert order | |
Private Member Functions | |
| ClassDef (SVDGeometryPar, 5) | |
| ClassDef, must be the last term before the closing {}. | |
Private Attributes | |
| std::vector< SVDSensorInfoPar * > | m_SensorInfo |
| Vector of pointers to SensorInfo objects. | |
| std::vector< VXDRotationSolidPar > | m_halfShell |
| SVD Half Shell parameters. | |
| std::map< int, SVDEndringsPar > | m_endrings |
| SVD Endrings parameters. | |
| std::map< int, SVDCoolingPipesPar > | m_coolingPipes |
| SVD Cooling Pipes parameters. | |
| std::map< int, SVDSupportRibsPar > | m_supportRibs |
| SVD SupportRibs parameters. | |
| std::string | m_prefix {""} |
| Prefix to prepend to all volume names. | |
| VXDGlobalPar | m_globals |
| Container for a few general parameters. | |
| std::map< std::string, VXDAlignmentPar > | m_alignment |
| Alignment parameters for all components. | |
| VXDEnvelopePar | m_envelope |
| Envelope parameters. | |
| std::vector< VXDHalfShellPar > | m_halfShells |
| Cache for half shells | |
| std::map< std::string, VXDGeoComponentPar > | m_componentCache |
| Cache of all previously created components. | |
| std::vector< std::string > | m_componentInsertOrder |
| Vector remembering the order of insertions into component cache. | |
| std::map< std::string, VXDGeoSensorPar > | m_sensorMap |
| Map containing Information about all defined sensor types. | |
| VXDGeoRadiationSensorsPar | m_radiationsensors |
| Diamond radiation sensors. | |
| std::map< int, VXDGeoLadderPar > | m_ladders |
| Parameters of the detector ladders. | |
| std::map< std::string, int > | m_sensitiveIDCache |
| Cache of all Bkg sensitive chip Ids. | |
The Class for VXD geometry.
Definition at line 29 of file SVDGeometryPar.h.
