A class to represent a track segment hit in CDC. More...
#include <SegmentHit.h>
Public Member Functions | |
| TRGCDCSegmentHit (const TRGCDCSegment &) | |
| Constructor. | |
| virtual | ~TRGCDCSegmentHit () |
| Destructor. | |
| virtual void | dump (const std::string &message=std::string(""), const std::string &prefix=std::string("")) const override |
| dumps debug information. | |
| const TRGCDCSegment & | segment (void) const |
| returns a pointer to a track segment. | |
| const TRGSignal & | signal (void) const |
| returns trigger output. Null will returned if no signal. | |
| int | mcLR (void) const |
| returns mc left/right information | |
| virtual const TRGCDCCell & | cell (void) const |
| returns a pointer to a TRGCDCWire. | |
| unsigned | state (void) const |
| returns state. | |
| unsigned | state (unsigned newState) |
| sets state. Meaning of bits are written below. | |
| unsigned | state (unsigned newState) const |
| sets state. Meaning of bits are written below. (tmp) | |
| float | drift (unsigned) const |
| returns drift distance. | |
| float | drift (void) const |
| returns drift distance. | |
| float | dDrift (unsigned) const |
| returns drift distance error. | |
| float | dDrift (void) const |
| returns drift distance error. | |
| const HepGeom::Point3D< double > & | xyPosition (void) const |
| returns position in the middle of wire. z is always zero, however. | |
| HepGeom::Point3D< double > | position (unsigned) const |
| returns left position. z is always zero. | |
| const void * | track (void) const |
| assigns a pointer to a TTrack. | |
| const void * | track (const void *) |
| assigns a pointer to a TTrack. | |
| const void * | track (const void *) const |
| assigns a pointer to a TTrack. (tmp) | |
| unsigned | sequence (void) const |
| returns sequential Length in one segment : this parameter is used in TCurlFinder now. | |
| unsigned | sequence (unsigned) const |
| sets sequential length in one segment : this parameter is used in TCurlFinder now. | |
| unsigned | iCDCHit (void) const |
| returns an index to CDCHit. | |
| unsigned | iCDCSimHit (void) const |
| returns an index to CDCSimHit. | |
| unsigned | iMCParticle (void) const |
| returns an index to MCParticle. | |
| const CDCHit * | hit (void) const |
| Access to CDCHit. | |
| const CDCSimHit * | simHit (void) const |
| Access to CDCSimHit. | |
| const MCParticle * | mcParticle (void) const |
| Access to MCParticle. | |
| void | setDriftTime (double driftTime, unsigned i) |
| Sets drift time. | |
Static Public Member Functions | |
| static void | removeAll (void) |
| destructs all TRGCDCCellHit objects. (Called by TRGCDC) | |
| static void * | operator new (size_t) |
| new operator. | |
| static void | operator delete (void *) |
| delete operator. | |
| static int | sortById (const TRGCDCSegmentHit **a, const TRGCDCSegmentHit **b) |
| Sorting funnction. | |
| static int | sortById (const TRGCDCCellHit **a, const TRGCDCCellHit **b) |
| Sort function. | |
Private Attributes | |
| int | _mcLR |
| mc left/right information | |
| unsigned | _state |
| state, defined above | |
| float | _drift [2] |
| drift distance | |
| float | _driftError [2] |
| drift distance error | |
| const TRGCDCCell & | _cell |
| a pointer to a TRGCDCWire | |
| const HepGeom::Point3D< double > & | _xyPosition |
| position in the middle of wire. z is always zero, however. | |
| const void * | _track |
| a pointer to a TTrack | |
| unsigned | _sequentialLength |
| sequential Length in one segment | |
| unsigned | _iCDCHit |
| Index to CDCHit array. | |
| unsigned | _iCDCSimHit |
| Index to CDCSimHit array. | |
| unsigned | _iMCParticle |
| Index to MCParticle array. | |
Static Private Attributes | |
| static std::vector< TRGCDCSegmentHit * > | _all |
| Keeps all TRGCDCSegmentHit created by new(). | |
A class to represent a track segment hit in CDC.
Definition at line 31 of file SegmentHit.h.
