A class to represent a reconstructed charged track in TRGCDC. More...
#include <TRGCDCTrack.h>
Public Types | |
| enum | EDebugValueType { fit2D = 1 << 3 , find3D = 1 << 4 , fit3D = 1 << 5 , any = fit2D | find3D | fit3D } |
| Enum for returnValue types. | |
Public Member Functions | |
| TRGCDCTrack () | |
| Constructor. | |
| TRGCDCTrack (const TRGCDCCircle &) | |
| Constructor from a Circle. | |
| virtual | ~TRGCDCTrack () |
| Destructor. | |
| const TRGCDCHelix & | helix (void) const |
| returns helix parameter. | |
| void | setHelix (const TRGCDCHelix &helix) |
| Set helix parameter. | |
| int | approach (TRGCDCLink &, bool sagCorrection=false) const |
| calculates the closest approach to a wire in real space. Results are stored in TLink. Return value is negative if error happened. | |
| virtual const CLHEP::Hep3Vector & | p (void) const override |
| returns momentum vector. | |
| virtual double | pt (void) const override |
| returns Pt. | |
| virtual const CLHEP::Hep3Vector & | x (void) const override |
| returns position vector. | |
| void | set2DFitChi2 (double) |
| Set 2D fit chi2. | |
| double | get2DFitChi2 (void) const |
| Returns 2D fit chi2. | |
| void | set3DFitChi2 (double) |
| Set 3D fit chi2. | |
| double | get3DFitChi2 (void) const |
| Returns 3D fit chi2. | |
| void | setDebugValue (EDebugValueType const &moduleName, bool flag) |
| Set debug value. | |
| int | getDebugValue (EDebugValueType const &moduleName) const |
| Get debug value. | |
| std::vector< HepGeom::Point3D< double > > | perfectPosition (void) const |
| returns perfect position from GEANT. | |
| std::string | name (void) const |
| returns name. | |
| std::string | name (const std::string &newName) |
| sets and returns name. | |
| int | status (void) const |
| returns status. | |
| double | charge (void) const |
| returns charge. | |
| double | charge (double c) |
| sets and returns charge. | |
| virtual void | dump (const std::string &message=std::string(""), const std::string &prefix=std::string("")) const |
| dumps debug information. | |
| const std::vector< TRGCDCLink * > & | links (void) const |
| returns a vector to track segments. | |
| const std::vector< TRGCDCLink * > & | links (unsigned layerId) const |
| returns a vector to track segments. | |
| bool | fitted (void) const |
| returns true if fitted. | |
| void | setFitted (bool fitted) |
| set fit status | |
| void | setTrackID (int trackID) |
| set track ID. | |
| int | getTrackID () |
| get track ID. | |
| virtual unsigned | objectType (void) const |
| returns object type. | |
| const TRGCDCFitter * | fitter (void) const |
| returns a pointer to a default fitter. | |
| const TRGCDCFitter * | fitter (const TRGCDCFitter *) |
| sets a default fitter. | |
| const TRGCDCRelation | relation (void) const |
| returns MC information. More... | |
| const TRGCDCRelation | relation2D (void) const |
| returns MC information for only axial layers. | |
| const TRGCDCRelation | relation3D (void) const |
| returns MC information for only stereo layers. | |
| void | append (TRGCDCLink *) |
| appends a link. | |
| void | append (const std::vector< TRGCDCLink * > &links) |
| appends links. | |
| virtual int | fit (void) |
| fits itself by a default fitter. Error was happened if return value is not zero. | |
| virtual int | approach2D (TRGCDCLink &) const |
| calculate closest approach. Error was happened if return value is not zero. | |
Static Public Member Functions | |
| static std::vector< const TRGCDCTrack * > | list (void) |
| returns a list of TRGCDCTrack's. | |
Private Attributes | |
| TRGCDCHelix | _helix |
| Helix parameter. | |
| CLHEP::Hep3Vector | _p |
| Momentum. | |
| CLHEP::Hep3Vector | _x |
| Position. | |
| double | m_2DFitChi2 |
| 2D fit chi2 | |
| double | m_3DFitChi2 |
| 3D fit chi2 | |
| int | m_debugValue |
| Debugging variable. | |
| std::string | _name |
| Name. | |
| int | _status |
| Status. | |
| double | _charge |
| Charge. | |
| std::vector< TRGCDCLink * > * | _ts |
| Links for each super layer. | |
| std::vector< TRGCDCLink * > | _tsAll |
| Links for all super layers. | |
| const unsigned | _nTs |
| Size of _ts. | |
| const TRGCDCFitter * | _fitter |
| Fitter. | |
| bool | _fitted |
| Fitting status. | |
| int | m_trackID |
| ID of tracks. | |
Static Private Attributes | |
| static std::vector< const TRGCDCTrack * > | _list = vector<const TRGCDCTrack*>() |
| a vector to keep all TRGCDCTrack objects. | |
A class to represent a reconstructed charged track in TRGCDC.
Definition at line 38 of file TRGCDCTrack.h.
