A class to represent a digitized signal. Unit is nano second. More...
#include <Clock.h>
Public Member Functions | |
| TRGClock (const std::string &name, double offset, double frequency) | |
| Constructor. "offset" is in unit of ns. "frequency" is in unit of MHz. | |
| TRGClock (const std::string &name, const TRGClock &, unsigned multiplicationFactor, unsigned divisionFactor=1) | |
| Constructor with clock source. | |
| virtual | ~TRGClock () |
| Destructor. | |
| const std::string & | name (void) const |
| returns name. | |
| int | position (double timing) const |
| returns clock position. | |
| int | positionInSourceClock (double timing) const |
| returns clock position in the source clock. | |
| double | absoluteTime (int clockPosition) const |
| returns absolute time of clock position | |
| double | overShoot (double timing) const |
| returns over shoot. | |
| int | unit (double period) const |
| returns min # of clocks to cover given time period. | |
| double | offset (void) const |
| returns offset of the clock zero position in nano second. | |
| double | frequency (void) const |
| returns frequency in MHz. | |
| double | phase (double timing) const |
| returns phase of given timing in degree (0 to 360). | |
| const TRGSignalVector & | clockCounter (void) const |
| returns the clock counter. | |
| void | dump (const std::string &message="", const std::string &pre="") const |
| dumps contents. More... | |
| int | min (void) const |
| returns min. clock point. | |
| int | max (void) const |
| returns max. clock point. | |
| double | minTiming (void) const |
| returns min. timing. | |
| double | maxTiming (void) const |
| returns max. timing. | |
| TRGTime | minTRGTime (bool edge) const |
| returns min. TRGtime with clock. | |
| TRGTime | maxTRGTime (bool edge) const |
| returns max. TRGtime with clock. | |
Private Attributes | |
| const std::string | _name |
| Name. | |
| const TRGClock * | _source |
| Clock source. | |
| const unsigned | _multi |
| Multiplication factor. | |
| const unsigned | _div |
| Division factor. | |
| const double | _offset |
| Clock offset in nano second. | |
| const double | _frequency |
| Frequency in MHz. | |
| const double | _cycle |
| Clock cycle in nano second. | |
| int | _min |
| Clock min. count. | |
| int | _max |
| Clock max. count. | |
| TRGSignalVector * | _clockCounter |
| Clock counter. | |
A class to represent a digitized signal. Unit is nano second.
