BooleanNode which has three AbstractExpressionNodes nodes and two ComparisonOperator. More...

#include <CutNodes.h>

Inheritance diagram for TernaryRelationalNode< AVariableManager >:

Collaboration diagram for TernaryRelationalNode< AVariableManager >:

Public Types
typedef AVariableManager::Var	Var
	Template argument dependent Variable type definition.

Public Member Functions
bool	check (const Object *p) const override

void	print () const override
	Print node.

std::string	decompile () const override
	Decompile Node back to a string. More...

	~TernaryRelationalNode ()
	Destructor.

Private Types
typedef AbstractBooleanNode< AVariableManager >::Object	Object
	Template argument dependent Particle type definition.

Private Member Functions
	TernaryRelationalNode (Nodetuple left_node, Nodetuple center_node, Nodetuple right_node, ComparisonOperator lc_coperator, ComparisonOperator cr_coperator)
	Constructor. More...

Private Attributes
std::unique_ptr< const AbstractExpressionNode< AVariableManager > >	m_left_enode
	left expression of the ternary relational expression

std::unique_ptr< const AbstractExpressionNode< AVariableManager > >	m_center_enode
	center expression of the ternary relational expression

std::unique_ptr< const AbstractExpressionNode< AVariableManager > >	m_right_enode
	right expression of the ternary relational expression

const ComparisonOperator	m_lc_coperator
	comparison operator to be applied to the evaluations of the left and center expression

const ComparisonOperator	m_cr_coperator
	comparison operator to be applied to the evaluations of the center and right expressions

Friends
class	NodeFactory

Detailed Description

template<class AVariableManager>
class Belle2::TernaryRelationalNode< AVariableManager >

BooleanNode which has three AbstractExpressionNodes nodes and two ComparisonOperator.

This allows Ranges in the Cutstring e.g 2.0 < var < 4.3 Check() evaluates the children nodes and compares both sides with the specified operator.

Definition at line 523 of file CutNodes.h.

Constructor & Destructor Documentation

◆ TernaryRelationalNode()

TernaryRelationalNode	(	Nodetuple	left_node,
		Nodetuple	center_node,
		Nodetuple	right_node,
		ComparisonOperator	lc_coperator,
		ComparisonOperator	cr_coperator
	)

inlineexplicitprivate

Constructor.

Parameters

left_node	(const boost::python::tuple&): tuple containing an expression node
center_node	(const boost::python::tuple&): tuple containing an expression node
right_node	(const boost::python::tuple&): tuple containing an expression node
lc_coperator	(ComparisonOperator): comparison operator enum value specifying the comparison between left and center expression
cr_coperator	(ComparisonOperator): comparison operator enum value specifiying the comparison between center and right expression

Definition at line 628 of file CutNodes.h.

Member Function Documentation

◆ check()

bool check ( const Object * p ) const

inlineoverridevirtual

Parameters

p	pointer to the object, that should be checked. Checking is done sequentially. At first the left-center condition is checked. If it evaluates to false we can directly return false. If it true we have to check to center-right condition.

Implements AbstractBooleanNode< AVariableManager >.

Definition at line 535 of file CutNodes.h.

◆ decompile()

std::string decompile ( ) const

inlineoverridevirtual

Decompile Node back to a string.

decompile(compile) should give the same result.

Implements AbstractBooleanNode< AVariableManager >.

Definition at line 603 of file CutNodes.h.

The documentation for this class was generated from the following file:

framework/utilities/include/CutNodes.h
