SingleMatchSelector< ACollectorItem, ACollectionItem, AComparer > Class Template Reference

Selector to remove all relations in the list, which share the same collection item - except one in case the useOnlySingleBestCandidate is set to false (then, only the one with the heightest weight is used). More...

#include <SingleMatchSelector.h>

Inheritance diagram for SingleMatchSelector< ACollectorItem, ACollectionItem, AComparer >:

Collaboration diagram for SingleMatchSelector< ACollectorItem, ACollectionItem, AComparer >:

Public Types
using	WeightedRelationItem = WeightedRelation< ACollectorItem, const ACollectionItem >
	Shortcut class name for a weighted relation between a collector item and a collection item.
using	Super = Findlet< WeightedRelation< ACollectorItem, const ACollectionItem > >
	The parent class.
using	IOTypes = std::tuple< AIOTypes... >
	Types that should be served to apply on invokation.
using	IOVectors = std::tuple< std::vector< AIOTypes >... >
	Vector types that should be served to apply on invokation.

Public Member Functions
void	exposeParameters (ModuleParamList *moduleParamList, const std::string &prefix) override
	Expose the useOnlySingleBestCandidate parameter to the module.
void	apply (std::vector< WeightedRelationItem > &weightedRelations) override
	Main function of this class doing the relation selection.
void	setUseOnlySingleBestCandidate (bool useOnlySingleBestCandidate)
	Set the UseOnlySingleBestCandidate parameter (mostly for tests).
virtual std::string	getDescription ()
	Brief description of the purpose of the concret findlet.
virtual void	apply (ToVector< AIOTypes > &... ioVectors)=0
	Main function executing the algorithm.
void	initialize () override
	Receive and dispatch signal before the start of the event processing.
void	beginRun () override
	Receive and dispatch signal for the beginning of a new run.
void	beginEvent () override
	Receive and dispatch signal for the start of a new event.
void	endRun () override
	Receive and dispatch signal for the end of the run.
void	terminate () override
	Receive and dispatch Signal for termination of the event processing.

Protected Types
using	ToVector = typename ToVectorImpl< T >::Type
	Short hand for ToRangeImpl.

Protected Member Functions
void	addProcessingSignalListener (ProcessingSignalListener *psl)
	Register a processing signal listener to be notified.
int	getNProcessingSignalListener ()
	Get the number of currently registered listeners.

Private Attributes
bool	m_param_useOnlySingleBestCandidate = true
	Whether to output only those relations, where the relation from collectio to collector items is injective or to output always the best relation for a given collection item.
std::vector< ProcessingSignalListener * >	m_subordinaryProcessingSignalListeners
	References to subordinary signal processing listener contained in this findlet.
bool	m_initialized = false
	Flag to keep track whether initialization happend before.
bool	m_terminated = false
	Flag to keep track whether termination happend before.
std::string	m_initializedAs
	Name of the type during initialisation.

Detailed Description

template<class ACollectorItem, class ACollectionItem, class AComparer = std::less<const ACollectionItem*>>
class Belle2::TrackFindingCDC::SingleMatchSelector< ACollectorItem, ACollectionItem, AComparer >

Selector to remove all relations in the list, which share the same collection item - except one in case the useOnlySingleBestCandidate is set to false (then, only the one with the heightest weight is used).

This means the function will output a list of weighted relations, where the relations from collection to collector items are injective (but not in the other way round: a collector can have multiple matched collection items, but one collection item only one matched collector item).

Most likely, the full stack is used as follows:

• match two lists of elements (Collectors and Collections) resulting in a list of weighted relations among those
• select only some relations using a certain criteria (this is where the difference between Collector and Collections comes into place)
• add the found relations by absorbing the collection items into the collector items.

Please note that the CollectionItems are therefore const whereas the CollectorItems are not. All the passed WeightedRelations lists must be sorted.

Definition at line 44 of file SingleMatchSelector.h.

---

The documentation for this class was generated from the following file:

• tracking/trackFindingCDC/collectors/selectors/include/SingleMatchSelector.h
