TrackLoader Class Reference

Findlet for loading the seeds from the data store. More...

#include <TrackLoader.h>

Inheritance diagram for TrackLoader:

Collaboration diagram for TrackLoader:

Public Types
using	IOTypes = std::tuple< AIOTypes... >
	Types that should be served to apply on invokation.
using	IOVectors = std::tuple< std::vector< AIOTypes >... >
	Vector types that should be served to apply on invokation.

Public Member Functions
	TrackLoader ()
	Add the subfindlets.
void	exposeParameters (ModuleParamList *moduleParamList, const std::string &prefix) override
	Expose the parameters of the sub findlets.
void	initialize () override
	Create the store arrays.
void	apply (std::vector< RecoTrack * > &seeds) override
	Load in the reco tracks and the hits.
virtual std::string	getDescription ()
	Brief description of the purpose of the concret findlet.
virtual void	apply (ToVector< AIOTypes > &... ioVectors)=0
	Main function executing the algorithm.
void	beginRun () override
	Receive and dispatch signal for the beginning of a new run.
void	beginEvent () override
	Receive and dispatch signal for the start of a new event.
void	endRun () override
	Receive and dispatch signal for the end of the run.
void	terminate () override
	Receive and dispatch Signal for termination of the event processing.

Protected Types
using	ToVector = typename ToVectorImpl< T >::Type
	Short hand for ToRangeImpl.

Protected Member Functions
void	addProcessingSignalListener (ProcessingSignalListener *psl)
	Register a processing signal listener to be notified.
int	getNProcessingSignalListener ()
	Get the number of currently registered listeners.

Private Types
using	Super = TrackFindingCDC::Findlet< RecoTrack * >
	Parent class.

Private Attributes
TrackFitterAndDeleter	m_trackFitter
	Findlet for fitting the tracks.
std::string	m_param_relationRecoTrackStoreArrayName = "RecoTracks"
	StoreArray name of the output Track Store Array.
std::string	m_param_inputRecoTrackStoreArrayName = "RecoTracks"
	StoreArray name of the input Track Store Array.
double	m_param_minimalPtRequirement = 0.0
	Minimal pt requirement.
std::string	m_param_relationCheckForDirectionAsString = "invalid"
	Parameter for the distance given to the framework (can not handle EForwardBackward directly)
TrackFindingCDC::EForwardBackward	m_param_relationCheckForDirection = TrackFindingCDC::EForwardBackward::c_Unknown
	Direction parameter converted from the string parameters.
StoreArray< RecoTrack >	m_inputRecoTracks
	Output Reco Tracks Store Array.
bool	m_noCDChits = false
	Ignore tracks with CDC hits attached.
std::vector< ProcessingSignalListener * >	m_subordinaryProcessingSignalListeners
	References to subordinary signal processing listener contained in this findlet.
bool	m_initialized = false
	Flag to keep track whether initialization happend before.
bool	m_terminated = false
	Flag to keep track whether termination happend before.
std::string	m_initializedAs
	Name of the type during initialisation.

Detailed Description

Findlet for loading the seeds from the data store.

Also, the tracks are fitted and only the fittable tracks are passed on.

If a direction != "invalid" is given, the relations of the tracks to the given store array are checked. If there is a relation with the weight equal to the given direction (meaning there is already a partner for this direction), the track is not passed on.

Definition at line 36 of file TrackLoader.h.

---

The documentation for this class was generated from the following files:

• tracking/ckf/general/findlets/include/TrackLoader.h
• tracking/ckf/general/findlets/src/TrackLoader.cc
