ZMQHistoServerToRawOutput Class Reference

Same as ZMQHistoServerToZMQOutput just send uncompressed to a raw output. More...

#include <ZMQHistogramConnection.h>

Inheritance diagram for ZMQHistoServerToRawOutput:

Collaboration diagram for ZMQHistoServerToRawOutput:

Public Types
using	ReactorFunction = std::function< void(void)>
	Typedef of a function which will be called if a connection has a message.

Public Member Functions
	ZMQHistoServerToRawOutput (const std::string &outputAddress, const std::shared_ptr< ZMQParent > &parent)
	Create a new raw output with the given address.
void	mergeAndSend (const std::map< std::string, HistogramMapping > &storedMessages, const std::optional< unsigned int > &experiment, const std::optional< unsigned int > &run, EMessageTypes messageType)
	Merge the histograms and send them via the connection. Stop/Terminate messages are not sent.
void	clear ()
	Nothing to do on clear.
std::string	getMonitoringJSON () const final
	The monitoring JSON is just passed from the ZMQRawOutput.
void	handleIncomingData ()
	The input data handling is passed from the ZMQRawOutput.
bool	isReady () const override
	The is ready is passed from the ZMQRawOutput.
std::vector< zmq::socket_t * >	getSockets () const final
	The sockets are passed from ZMQRawOutput.
std::string	getEndPoint () const
	Return the connection string.
template<class AClass >
void	log (const std::string &key, const AClass &value)
	Store a value under a certain key. Different types of values can be stored, namely long, double or string. Mixtures are not allowed for a given key.
void	increment (const std::string &key)
	Increment the value with the given key (only numerical values). If not present, set to 1.
void	decrement (const std::string &key)
	Decrement the value with the given key (only numerical values). If not present, set to -1.
template<size_t MAX_SIZE = 100>
void	average (const std::string &key, double value)
	Instead of storeing the double value directly under the given key, store the average of the last MAX_SIZE values.
template<size_t AVERAGE_SIZE = 2000>
void	timeit (const std::string &key)
	Measure the rate of calls with the same key every AVERAGE_SIZE calls (and also display the last time AVERAGE_SIZE was reached under <key>_last_measurement)
void	logTime (const std::string &key)
	Store the current time as a string under the given key.

Static Public Member Functions
static bool	poll (const std::map< const ZMQConnection *, ReactorFunction > &connectionList, int timeout)
	Poll on the given connections and call the attached function if a messages comes in. More...
static bool	hasMessage (const ZMQConnection *connection)
	Check if the given connection as an incoming message (right now, no waiting).

Private Attributes
ZMQRawOutput	m_output
	The output connection used for sending the histograms.
std::map< std::string, std::variant< long, double, std::string > >	m_monitoring
	Internal storage of all stored values.
std::unordered_map< std::string, std::tuple< std::vector< double >, size_t > >	m_averages
	Internal storage of the previous values when calculating averages.
std::unordered_map< std::string, std::tuple< unsigned long, std::chrono::system_clock::time_point > >	m_timeCounters
	Internal storage how often the timeit function for a given key was called and when it has last reached MAX_SIZE.

Detailed Description

Same as ZMQHistoServerToZMQOutput just send uncompressed to a raw output.

Can be used to directly send to the legacy HistoServer.

Stop/Terminate messages are not sent.

Definition at line 127 of file ZMQHistogramConnection.h.

Member Function Documentation

poll()

bool poll ( const std::map< const ZMQConnection *, ReactorFunction > &  connectionList, int  timeout  )

staticinherited

Poll on the given connections and call the attached function if a messages comes in.

If after timeout milliseconds still no message is received, return anyways. If timeout is 0, do not wait. If timeout is -1, wait infinitely.

Returns true if a message was received on any socket, false otherwise. Attention: in case of an interrupted system call (e.g. because a signal was received) the function might return anyways with a negative result even before the timeout!

Definition at line 27 of file ZMQConnection.cc.

---

The documentation for this class was generated from the following files:

• daq/hbasf2/connections/include/ZMQHistogramConnection.h
• daq/hbasf2/connections/src/ZMQHistogramConnection.cc
