KFitBase is a base class for kinematical fitters. More...

#include <KFitBase.h>

Inheritance diagram for KFitBase:

[legend]

Collaboration diagram for KFitBase:

[legend]

Public Member Functions
	KFitBase (void)
	Construct an object with no argument.

virtual	~KFitBase (void)
	Destruct the object.

enum KFitError::ECode	addTrack (const KFitTrack &kp)
	Add a track to the fitter object. More...

enum KFitError::ECode	addTrack (const CLHEP::HepLorentzVector &p, const HepPoint3D &x, const CLHEP::HepSymMatrix &e, const double q)
	Add a track to the fitter object with specifying its momentum, position, error matrix, and charge. More...

enum KFitError::ECode	addParticle (const Particle *particle)
	Add a particle to the fitter. More...

virtual enum KFitError::ECode	setCorrelation (const CLHEP::HepMatrix &c)
	Set a correlation matrix. More...

virtual enum KFitError::ECode	setZeroCorrelation (void)
	Indicate no correlation between tracks. More...

enum KFitError::ECode	setMagneticField (const double mf)
	Change a magnetic field from the default value KFitConst::kDefaultMagneticField. More...

enum KFitError::ECode	getErrorCode (void) const
	Get a code of the last error. More...

int	getTrackCount (void) const
	Get the number of added tracks. More...

virtual int	getNDF (void) const
	Get an NDF of the fit. More...

virtual double	getCHIsq (void) const
	Get a chi-square of the fit. More...

double	getMagneticField (void) const
	Get a magnetic field. More...

virtual double	getTrackCHIsq (const int id) const
	Get a chi-square of the track. More...

const CLHEP::HepLorentzVector	getTrackMomentum (const int id) const
	Get a Lorentz vector of the track. More...

const HepPoint3D	getTrackPosition (const int id) const
	Get a position of the track. More...

const CLHEP::HepSymMatrix	getTrackError (const int id) const
	Get an error matrix of the track. More...

const KFitTrack	getTrack (const int id) const
	Get a specified track object. More...

virtual const CLHEP::HepMatrix	getCorrelation (const int id1, const int id2, const int flag=KFitConst::kAfterFit) const
	Get a correlation matrix between two tracks. More...

bool	isFitted (void) const
	Return false if fit is not performed yet or performed fit is failed; otherwise true. More...

Protected Member Functions
const CLHEP::HepSymMatrix	makeError1 (const CLHEP::HepLorentzVector &p, const CLHEP::HepMatrix &e) const
	Rebuild an error matrix from a Lorentz vector and an error matrix. More...

const CLHEP::HepMatrix	makeError1 (const CLHEP::HepLorentzVector &p1, const CLHEP::HepLorentzVector &p2, const CLHEP::HepMatrix &e) const
	Rebuild an error matrix from a pair of Lorentz vectors and an error matrix. More...

const CLHEP::HepMatrix	makeError2 (const CLHEP::HepLorentzVector &p, const CLHEP::HepMatrix &e) const
	Rebuild an error matrix from a Lorentz vector and an error matrix. More...

const CLHEP::HepSymMatrix	makeError3 (const CLHEP::HepLorentzVector &p, const CLHEP::HepMatrix &e, const bool is_fix_mass) const
	Rebuild an error matrix from a Lorentz vector and an error matrix. More...

const CLHEP::HepMatrix	makeError3 (const CLHEP::HepLorentzVector &p1, const CLHEP::HepLorentzVector &p2, const CLHEP::HepMatrix &e, const bool is_fix_mass1, const bool is_fix_mass2) const
	Rebuild an error matrix from a pair of Lorentz vectors and an error matrix. More...

const CLHEP::HepMatrix	makeError4 (const CLHEP::HepLorentzVector &p, const CLHEP::HepMatrix &e) const
	Rebuild an error matrix from a Lorentz vector and an error matrix. More...

virtual enum KFitError::ECode	prepareInputMatrix (void)=0
	Build grand matrices for minimum search from input-track properties. More...

virtual enum KFitError::ECode	prepareInputSubMatrix (void)=0
	Build sub-matrices for minimum search from input-track properties. More...

virtual enum KFitError::ECode	prepareCorrelation (void)
	Build a grand correlation matrix from input-track properties. More...

virtual enum KFitError::ECode	prepareOutputMatrix (void)=0
	Build an output error matrix. More...

virtual enum KFitError::ECode	makeCoreMatrix (void)=0
	Build matrices using the kinematical constraint. More...

virtual enum KFitError::ECode	calculateNDF (void)=0
	Calculate an NDF of the fit. More...

enum KFitError::ECode	doFit1 (void)
	Perform a fit (used in MassFitKFit::doFit()). More...

enum KFitError::ECode	doFit2 (void)
	Perform a fit (used in VertexFitKFit::doFit() and MassVertexFitKFit::doFit()). More...

bool	isTrackIDInRange (const int id) const
	Check if the id is in the range. More...

bool	isNonZeroEnergy (const CLHEP::HepLorentzVector &p) const
	Check if the energy is non-zero. More...

Protected Attributes
enum KFitError::ECode	m_ErrorCode
	Error code.

bool	m_FlagFitted
	Flag to indicate if the fit is performed and succeeded.

std::vector< KFitTrack >	m_Tracks
	Container of input tracks.

std::vector< CLHEP::HepMatrix >	m_BeforeCorrelation
	Container of input correlation matrices.

CLHEP::HepSymMatrix	m_V_al_0
	See J.Tanaka Ph.D (2001) p137 for definition.

CLHEP::HepMatrix	m_al_0
	See J.Tanaka Ph.D (2001) p136 for definition.

CLHEP::HepMatrix	m_al_1
	See J.Tanaka Ph.D (2001) p136 for definition.

CLHEP::HepMatrix	m_al_a
	See J.Tanaka Ph.D (2001) p137 for definition.

CLHEP::HepMatrix	m_property
	Container of charges and masses.

CLHEP::HepMatrix	m_D
	See J.Tanaka Ph.D (2001) p137 for definition.

CLHEP::HepMatrix	m_d
	See J.Tanaka Ph.D (2001) p137 for definition.

CLHEP::HepMatrix	m_V_D
	See J.Tanaka Ph.D (2001) p138 for definition.

CLHEP::HepMatrix	m_V_al_1
	See J.Tanaka Ph.D (2001) p138 for definition.

CLHEP::HepMatrix	m_lam
	See J.Tanaka Ph.D (2001) p137 for definition.

CLHEP::HepMatrix	m_E
	See J.Tanaka Ph.D (2001) p137 for definition.

CLHEP::HepMatrix	m_V_E
	See J.Tanaka Ph.D (2001) p138 for definition.

CLHEP::HepMatrix	m_lam0
	See J.Tanaka Ph.D (2001) p138 for definition.

CLHEP::HepMatrix	m_v
	See J.Tanaka Ph.D (2001) p137 for definition.

CLHEP::HepMatrix	m_v_a
	See J.Tanaka Ph.D (2001) p137 for definition.

CLHEP::HepMatrix	m_V_Dt
	See J.Tanaka Ph.D (2001) p138 for definition.

CLHEP::HepMatrix	m_Cov_v_al_1
	See J.Tanaka Ph.D (2001) p137 for definition.

int	m_NDF
	NDF of the fit.

double	m_CHIsq
	chi-square of the fit.

int	m_TrackCount
	Number of tracks.

int	m_NecessaryTrackCount
	Number needed tracks to perform fit.

bool	m_FlagCorrelation
	Flag whether a correlation among tracks exists.

bool	m_FlagOverIteration
	Flag whether the iteration count exceeds the limit.

double	m_MagneticField
	Magnetic field.

Detailed Description

KFitBase is a base class for kinematical fitters.

Definition at line 37 of file KFitBase.h.

Member Function Documentation

◆ addParticle()

enum KFitError::ECode addParticle ( const Particle * particle )

Add a particle to the fitter.

The function gets track parameters from the Particle dataobject and calls addTrack().

Parameters

[in] particle Particle.

Returns: error code (zero if success)

Definition at line 34 of file KFitBase.cc.

◆ addTrack() [1/2]

enum KFitError::ECode addTrack	(	const CLHEP::HepLorentzVector &	p,
		const HepPoint3D &	x,
		const CLHEP::HepSymMatrix &	e,
		const double	q
	)

Add a track to the fitter object with specifying its momentum, position, error matrix, and charge.

This function internally calls addTrack(const KFitTrack &kp).

Parameters

p	Lorentz vector of the track
x	position of the track
e	(7x7) error matrix of the track
q	charge of the track

Returns: error code (zero if success)

◆ addTrack() [2/2]

enum KFitError::ECode addTrack ( const KFitTrack & kp )

Add a track to the fitter object.

Parameters

kp	object of the track

Returns: error code (zero if success)

Definition at line 34 of file KFitBase.cc.

◆ calculateNDF()

virtual enum KFitError::ECode calculateNDF ( void )

protectedpure virtual

Calculate an NDF of the fit.

Returns: error code (zero if success)

Implemented in VertexFitKFit, RecoilMassKFit, MassVertexFitKFit, MassPointingVertexFitKFit, MassFourCFitKFit, MassFitKFit, and FourCFitKFit.

◆ doFit1()

enum KFitError::ECode doFit1 ( void )

protected

Perform a fit (used in MassFitKFit::doFit()).

Returns: error code (zero if success)

Definition at line 438 of file KFitBase.cc.

◆ doFit2()

enum KFitError::ECode doFit2 ( void )

protected

Perform a fit (used in VertexFitKFit::doFit() and MassVertexFitKFit::doFit()).

Returns: error code (zero if success)

Definition at line 438 of file KFitBase.cc.

◆ getCHIsq()

double getCHIsq ( void ) const

virtual

Get a chi-square of the fit.

Returns: chi-square of the fit

Reimplemented in VertexFitKFit, RecoilMassKFit, MassVertexFitKFit, MassPointingVertexFitKFit, MassFourCFitKFit, MassFitKFit, and FourCFitKFit.

Definition at line 121 of file KFitBase.cc.

◆ getCorrelation()

const HepMatrix getCorrelation	(	const int	id1,
		const int	id2,
		const int	flag = `KFitConst::kAfterFit`
	)		const

virtual

Get a correlation matrix between two tracks.

Parameters

id1	first track id
id2	second track id
flag	KFitConst::kBeforeFit or KFitConst::kAfterFit

Returns: (7x7) correlation matrix

Reimplemented in RecoilMassKFit, MassVertexFitKFit, MassPointingVertexFitKFit, MassFourCFitKFit, MassFitKFit, and FourCFitKFit.

Definition at line 183 of file KFitBase.cc.

◆ getErrorCode()

enum KFitError::ECode getErrorCode ( void ) const

Get a code of the last error.

Returns: the last error code

Definition at line 34 of file KFitBase.cc.

◆ getMagneticField()

double getMagneticField ( void ) const

Get a magnetic field.

Returns: magnetic field

Definition at line 128 of file KFitBase.cc.

◆ getNDF()

int getNDF ( void ) const

virtual

Get an NDF of the fit.

Returns: NDF of the fit

Definition at line 114 of file KFitBase.cc.

◆ getTrack()

const KFitTrack getTrack ( const int id ) const

Get a specified track object.

Parameters

id track id

Returns: specified track object

Definition at line 175 of file KFitBase.cc.

◆ getTrackCHIsq()

double getTrackCHIsq ( const int id ) const

virtual

Get a chi-square of the track.

Parameters

id track id

Returns: chi-square of the track

Reimplemented in VertexFitKFit, RecoilMassKFit, MassVertexFitKFit, MassPointingVertexFitKFit, MassFourCFitKFit, MassFitKFit, and FourCFitKFit.

Definition at line 135 of file KFitBase.cc.

◆ getTrackCount()

int getTrackCount ( void ) const

Get the number of added tracks.

Returns: the number of added tracks

Definition at line 107 of file KFitBase.cc.

◆ getTrackError()

const HepSymMatrix getTrackError ( const int id ) const

Get an error matrix of the track.

Parameters

id track id

Returns: error matrix of the track

Definition at line 168 of file KFitBase.cc.

◆ getTrackMomentum()

const HepLorentzVector getTrackMomentum ( const int id ) const

Get a Lorentz vector of the track.

Parameters

id track id

Returns: Lorentz vector of the track

Definition at line 154 of file KFitBase.cc.

◆ getTrackPosition()

const HepPoint3D getTrackPosition ( const int id ) const

Get a position of the track.

Parameters

id track id

Returns: position of the track

Definition at line 161 of file KFitBase.cc.

◆ isFitted()

bool isFitted ( void ) const

Return false if fit is not performed yet or performed fit is failed; otherwise true.

Returns: see description

Definition at line 727 of file KFitBase.cc.

◆ isNonZeroEnergy()

bool isNonZeroEnergy ( const CLHEP::HepLorentzVector & p ) const

protected

Check if the energy is non-zero.

Parameters

p	Lorentz vector

Returns: true for non-zero energy, false for otherwise

Definition at line 749 of file KFitBase.cc.

◆ isTrackIDInRange()

bool isTrackIDInRange ( const int id ) const

protected

Check if the id is in the range.

Parameters

id track id

Returns: true if the id is in the range, false otherwise

Definition at line 738 of file KFitBase.cc.

◆ makeCoreMatrix()

virtual enum KFitError::ECode makeCoreMatrix ( void )

protectedpure virtual

Build matrices using the kinematical constraint.

Returns: error code (zero if success)

Implemented in VertexFitKFit, RecoilMassKFit, MassVertexFitKFit, MassPointingVertexFitKFit, MassFourCFitKFit, MassFitKFit, and FourCFitKFit.

◆ makeError1() [1/2]

const CLHEP::HepSymMatrix makeError1	(	const CLHEP::HepLorentzVector &	p,
		const CLHEP::HepMatrix &	e
	)		const

protected

Rebuild an error matrix from a Lorentz vector and an error matrix.

Parameters

p	Lorentz vector
e	(6x6) error matrix

Returns: (7x7) error matrix

◆ makeError1() [2/2]

const CLHEP::HepMatrix makeError1	(	const CLHEP::HepLorentzVector &	p1,
		const CLHEP::HepLorentzVector &	p2,
		const CLHEP::HepMatrix &	e
	)		const

protected

Rebuild an error matrix from a pair of Lorentz vectors and an error matrix.

Parameters

p1	first Lorentz vector
p2	second Lorentz vector
e	(6x6) error matrix

Returns: (7x7) error matrix

◆ makeError2()

const HepMatrix makeError2	(	const CLHEP::HepLorentzVector &	p,
		const CLHEP::HepMatrix &	e
	)		const

protected

Rebuild an error matrix from a Lorentz vector and an error matrix.

Parameters

p	Lorentz vector
e	(3x6) error matrix

Returns: (3x7) error matrix

Definition at line 296 of file KFitBase.cc.

◆ makeError3() [1/2]

const CLHEP::HepSymMatrix makeError3	(	const CLHEP::HepLorentzVector &	p,
		const CLHEP::HepMatrix &	e,
		const bool	is_fix_mass
	)		const

protected

Rebuild an error matrix from a Lorentz vector and an error matrix.

Parameters

p	Lorentz vector
e	(7x7) error matrix
is_fix_mass	true to recalculate energy term from other parameters, false to do nothing

Returns: (7x7) error matrix

◆ makeError3() [2/2]

const CLHEP::HepMatrix makeError3	(	const CLHEP::HepLorentzVector &	p1,
		const CLHEP::HepLorentzVector &	p2,
		const CLHEP::HepMatrix &	e,
		const bool	is_fix_mass1,
		const bool	is_fix_mass2
	)		const

protected

Rebuild an error matrix from a pair of Lorentz vectors and an error matrix.

Parameters

p1	first Lorentz vector
p2	second Lorentz vector
e	(7x7) error matrix
is_fix_mass1	true to recalculate energy term from other parameters, false to do nothing
is_fix_mass2	true to recalculate energy term from other parameters, false to do nothing

Returns: (7x7) error matrix

◆ makeError4()

const HepMatrix makeError4	(	const CLHEP::HepLorentzVector &	p,
		const CLHEP::HepMatrix &	e
	)		const

protected

Rebuild an error matrix from a Lorentz vector and an error matrix.

Parameters

p	Lorentz vector
e	(3x7) error matrix

Returns: (7x7) error matrix

Definition at line 438 of file KFitBase.cc.

◆ prepareCorrelation()

enum KFitError::ECode prepareCorrelation ( void )

protectedvirtual

Build a grand correlation matrix from input-track properties.

Returns: error code (zero if success)

Reimplemented in RecoilMassKFit, MassVertexFitKFit, MassPointingVertexFitKFit, MassFourCFitKFit, MassFitKFit, and FourCFitKFit.

Definition at line 438 of file KFitBase.cc.

◆ prepareInputMatrix()

virtual enum KFitError::ECode prepareInputMatrix ( void )

protectedpure virtual

Build grand matrices for minimum search from input-track properties.

Returns: error code (zero if success)

Implemented in VertexFitKFit, RecoilMassKFit, MassVertexFitKFit, MassPointingVertexFitKFit, MassFourCFitKFit, MassFitKFit, and FourCFitKFit.

◆ prepareInputSubMatrix()

virtual enum KFitError::ECode prepareInputSubMatrix ( void )

protectedpure virtual

Build sub-matrices for minimum search from input-track properties.

Returns: error code (zero if success)

Implemented in VertexFitKFit, RecoilMassKFit, MassVertexFitKFit, MassPointingVertexFitKFit, MassFourCFitKFit, MassFitKFit, and FourCFitKFit.

◆ prepareOutputMatrix()

virtual enum KFitError::ECode prepareOutputMatrix ( void )

protectedpure virtual

Build an output error matrix.

Returns: error code (zero if success)

Implemented in VertexFitKFit, RecoilMassKFit, MassVertexFitKFit, MassPointingVertexFitKFit, MassFourCFitKFit, MassFitKFit, and FourCFitKFit.

◆ setCorrelation()

enum KFitError::ECode setCorrelation ( const CLHEP::HepMatrix & c )

virtual

Set a correlation matrix.

Not intended for end user's use.

Parameters

c	(7x7) correlation matrix

Returns: error code (zero if success)

Reimplemented in RecoilMassKFit, MassVertexFitKFit, MassPointingVertexFitKFit, MassFourCFitKFit, MassFitKFit, and FourCFitKFit.

Definition at line 34 of file KFitBase.cc.

◆ setMagneticField()

enum KFitError::ECode setMagneticField ( const double mf )

Change a magnetic field from the default value KFitConst::kDefaultMagneticField.

Parameters

mf	magnetic field to set

Returns: error code (zero if success)

Definition at line 34 of file KFitBase.cc.

◆ setZeroCorrelation()

enum KFitError::ECode setZeroCorrelation ( void )

virtual

Indicate no correlation between tracks.

Not intended for end user's use.

Returns: error code (zero if success)

Reimplemented in RecoilMassKFit, MassVertexFitKFit, MassPointingVertexFitKFit, MassFourCFitKFit, MassFitKFit, and FourCFitKFit.

Definition at line 34 of file KFitBase.cc.

The documentation for this class was generated from the following files:

analysis/VertexFitting/KFit/include/KFitBase.h
analysis/VertexFitting/KFit/src/KFitBase.cc

Public Member Functions

Protected Member Functions

Protected Attributes

Detailed Description

Member Function Documentation

◆ addParticle()

◆ addTrack() [1/2]

◆ addTrack() [2/2]

◆ calculateNDF()

◆ doFit1()

◆ doFit2()

◆ getCHIsq()

◆ getCorrelation()

◆ getErrorCode()

◆ getMagneticField()

◆ getNDF()

◆ getTrack()

◆ getTrackCHIsq()

◆ getTrackCount()

◆ getTrackError()

◆ getTrackMomentum()

◆ getTrackPosition()

◆ isFitted()

◆ isNonZeroEnergy()

◆ isTrackIDInRange()

◆ makeCoreMatrix()

◆ makeError1() [1/2]

◆ makeError1() [2/2]

◆ makeError2()

◆ makeError3() [1/2]

◆ makeError3() [2/2]

◆ makeError4()

◆ prepareCorrelation()

◆ prepareInputMatrix()

◆ prepareInputSubMatrix()

◆ prepareOutputMatrix()

◆ setCorrelation()

◆ setMagneticField()

◆ setZeroCorrelation()
