Struct for training data of a single MLP for the neuro trigger. More...

#include <CDCTriggerMLPData.h>

Inheritance diagram for CDCTriggerMLPData:

Collaboration diagram for CDCTriggerMLPData:

[legend]

Classes
struct	HeaderSet

struct	NeuroSet
	Struct to keep one set of training data for either training, validation or testing. More...

Public Member Functions
	CDCTriggerMLPData ()
	default constructor.

	~CDCTriggerMLPData ()
	destructor, empty because we don't allocate memory anywhere.

void	addCounters (unsigned nWires)
	add hit counters for a layer with nWires

void	addHit (unsigned iSL, int iTS)
	increase counter for super layer and track segment number in super layer. More...

void	countTrack ()
	increase track counter

template<unsigned inLen, unsigned outLen>
void	addSample (const NeuroSet< inLen, outLen > &dsample)

void	addSample (const std::vector< float > &input, const std::vector< float > &target, const int &expnumber, const int &runnumber, const int &subrunnumber, const int &eventnumber, const int &tracknumber)
	add a pair of input and target

short	getTrackCounter () const
	get track counter

unsigned short	getHitCounter (unsigned iSL, int iTS) const
	get hit counter for super layer and track segment number is super layer. More...

unsigned	nSamples () const
	get number of samples (same for input and target)

const std::vector< float > &	getInput (unsigned i) const
	get input vector of sample i

const std::vector< float > &	getTarget (unsigned i) const
	get target value of sample i

const std::vector< int > &	getevtList () const

const std::vector< int > &	getEvtList () const

const std::vector< int > &	getExpList () const

const std::vector< int > &	getRunList () const

const std::vector< int > &	getSubRunList () const

const std::vector< int > &	getTrackList () const

const int &	getevtnum (unsigned i) const

Private Member Functions
	ClassDef (CDCTriggerMLPData, 3)
	Needed to make the ROOT object storable.

Private Attributes
std::vector< std::vector< float > >	m_inputSamples
	list of input vectors for network training.

std::vector< std::vector< float > >	m_targetSamples
	list of target values for network training.

std::vector< std::vector< unsigned short > >	m_hitCounters
	hit counter of active track segment IDs, used to determine the relevant id range for an MLP.

short	m_trackCounter
	number of tracks used for the hit counter.

std::vector< int >	m_expList
	Vectors for experiment, run, event and tracknumber.

std::vector< int >	m_runList

std::vector< int >	m_subRunList

std::vector< int >	m_evtList
	List for debug purposes to store the event number for every entry of input/target vector.

std::vector< int >	m_trackList

Detailed Description

Struct for training data of a single MLP for the neuro trigger.

Definition at line 27 of file CDCTriggerMLPData.h.

Member Function Documentation

◆ addHit()

void addHit	(	unsigned	iSL,
		int	iTS
	)

increase counter for super layer and track segment number in super layer.

track segment number can be negative. hits in the wrong hemisphere (not in [-nWires/4, nWires/4]) are skipped.

Definition at line 13 of file CDCTriggerMLPData.cc.

 {
   if (iSL < m_hitCounters.size()) {
     int N = m_hitCounters[iSL].size();
     // shift negative indices
     if (iTS < 0) iTS += N;
     // check the range
     //   0, N:        hit is on the track
     //   [0, N/4]:    hit is in quadrant left of the track
     //   [N/4, 3N/4]: hit is in hemisphere opposite of the track (skipped)
     //   [3N/4, N]:   hit is in quadrant right of the track
     if ((0 <= iTS && iTS <= N / 4) || (3 * N / 4 <= iTS && iTS < N)) {
       ++m_hitCounters[iSL][iTS];
     }
   }
 }

◆ getHitCounter()

unsigned short getHitCounter	(	unsigned	iSL,
		int	iTS
	)		const

get hit counter for super layer and track segment number is super layer.

track segment number can be negative.

Returns: counter or 0 (for invalid input)

Definition at line 31 of file CDCTriggerMLPData.cc.

The documentation for this class was generated from the following files:

trg/cdc/dataobjects/include/CDCTriggerMLPData.h
trg/cdc/dataobjects/src/CDCTriggerMLPData.cc
