SVDChargeSimulationCalibrations Class Reference

This class defines the dbobject and the methods to access SVD simulation calibrations; coupling constants and Geant4 electron weight. More...

#include <SVDChargeSimulationCalibrations.h>

Collaboration diagram for SVDChargeSimulationCalibrations:

Public Types
typedef SVDCalibrationsBase< SVDCalibrationsScalar< SVDChargeSimCal > >	t_payload
	typedef of the SVDChargeSimulationCalibrations payload

Public Member Functions
	SVDChargeSimulationCalibrations ()
	Constructor, no input argument is required.
float	getCouplingConstant (const VxdID &sensorID, const bool &isU, const std::string &couplingName) const
	Return coupling constant. More...
float	getElectronWeight (const VxdID &sensorID, const bool &isU) const
	Return Geant4 electron weight. More...
TString	getUniqueID ()
	returns the unique ID of the payload
bool	isValid ()
	returns true if the m_aDBObtPtr is valid in the requested IoV

Static Public Attributes
static std::string	name = std::string("SVDChargeSimulationCalibrations")
	name of the SVDChargeSimulationCalibrations payload

Private Attributes
DBObjPtr< t_payload >	m_aDBObjPtr
	the SVDChargeSimulationCalibrations payload

Detailed Description

This class defines the dbobject and the methods to access SVD simulation calibrations; coupling constants and Geant4 electron weight.

Definition at line 26 of file SVDChargeSimulationCalibrations.h.

Member Function Documentation

getCouplingConstant()

float getCouplingConstant ( const VxdID &  sensorID, const bool &  isU, const std::string &  couplingName  ) const

inline

Return coupling constant.

Input:

Parameters

sensorID	identitiy of the sensor for which the calibration is required
isU	sensor side, true for p (u) side, false for n (v) side
couplingName	coupling name, specify which coupling to return. Possible values are: "C0" | Coupling from readout implant to its readout channel "C1" | Coupling from first neighbour implant (floating) to readout channel "C2" | Coupling from second neighbour implant (readout) to readout channel "C3" | Coupling from third neighbour implant (floating) to readout channel "APVCoupling" | Coupling between two adjacent channels done at APV level after charge sharing Output: float corresponding to a given coupling constant.

Definition at line 53 of file SVDChargeSimulationCalibrations.h.

    {
      float coupling_constant = 0;
      try {
        coupling_constant = m_aDBObjPtr->getReference(sensorID.getLayerNumber(), sensorID.getLadderNumber(),
                                                      sensorID.getSensorNumber(), m_aDBObjPtr->sideIndex(isU), 0).couplingConstant.at(couplingName);
      } catch (const std::out_of_range& oor) {
        B2ERROR("Cannot find coupling constant " << couplingName << " in database.");
      }
      return coupling_constant;
    }

getElectronWeight()

float getElectronWeight ( const VxdID &  sensorID, const bool &  isU  ) const

inline

Return Geant4 electron weight.

Input:

Parameters

sensorID	identitiy of the sensor for which the calibration is required
isU	sensor side, true for p (u) side, false for n (v) side

Output: float corresponding to a Geant4-electron to real-electron weight.

Definition at line 72 of file SVDChargeSimulationCalibrations.h.

---

The documentation for this class was generated from the following files:

• svd/calibration/include/SVDChargeSimulationCalibrations.h
• svd/calibration/src/SVDChargeSimulationCalibrations.cc
