CDCAxialSegmentPair Class Reference

Class representing a pair of reconstructed axial segements in adjacent superlayer. More...

#include <CDCAxialSegmentPair.h>

Collaboration diagram for CDCAxialSegmentPair:

Public Member Functions
	CDCAxialSegmentPair ()
	Default constructor setting the contained segmetns to nullptr.
	CDCAxialSegmentPair (const CDCAxialSegment2D *startSegment, const CDCAxialSegment2D *endSegment)
	Constructor from two segments.
	CDCAxialSegmentPair (const CDCAxialSegment2D *startSegment, const CDCAxialSegment2D *endSegment, const CDCTrajectory2D &trajectory2D)
	Constructor from two segments and an assoziated trajectory.
bool	operator== (CDCAxialSegmentPair const &rhs) const
	Equality comparision based on the pointers to the stored segments.
bool	operator< (CDCAxialSegmentPair const &rhs) const
	Total ordering sheme comparing the segment pointers.
bool	checkSegments () const
	Checks the references to the contained three segment for nullptrs.
ISuperLayer	getStartISuperLayer () const
	Getter for the superlayer id of the start segment.
ISuperLayer	getEndISuperLayer () const
	Getter for the superlayer id of the end segment.
const CDCAxialSegment2D *	getStartSegment () const
	Getter for the start segment.
void	setStartSegment (const CDCAxialSegment2D *startSegment)
	Setter for the start segment.
const CDCAxialSegment2D *	getEndSegment () const
	Getter for the end segment.
void	setEndSegment (const CDCAxialSegment2D *endSegment)
	Setter for the end segment.
void	setSegments (const CDCSegment2D *startSegment, const CDCSegment2D *endSegment)
	Setter for both segments simultaniously.
CDCTrajectory2D &	getTrajectory2D () const
	Getter for the trajectory of the two dimensional trajectory.
void	setTrajectory2D (const CDCTrajectory2D &trajectory2D) const
	Setter for the trajectory of the two dimensional trajectory.
void	clearTrajectory2D () const
	Invalides the currently stored trajectory information.
void	unsetAndForwardMaskedFlag () const
	Unsets the masked flag of the segment pair's automaton cell, of the contained segments and of the contained wire hits.
void	setAndForwardMaskedFlag () const
	Sets the masked flag of the segment pair's automaton cell. Also forward the masked flag to the contained segments and the contained wire hits.
void	receiveMaskedFlag () const
	If one of the contained segments is marked as masked this segment pair is set be masked as well.
EForwardBackward	isCoaligned (const CDCTrajectory2D &trajectory2D) const
	Checks if the last entity in the vector lies greater or lower travel distance than the last entity. More...
AutomatonCell &	getAutomatonCell () const
	Mutable getter for the automaton cell.

Private Attributes
const CDCAxialSegment2D *	m_startSegment
	Reference to the start segment.
const CDCAxialSegment2D *	m_endSegment
	Reference to the end segment.
CDCTrajectory2D	m_trajectory2D
	Reference to the common trajectory.
AutomatonCell	m_automatonCell
	Automaton cell assoziated with the pair of segments.

Friends
bool	operator< (CDCAxialSegmentPair const &segmentPair, const CDCAxialSegment2D *axialSegment)
	Define reconstructed segments and segment triples as coaligned on the start segment.
bool	operator< (const CDCAxialSegment2D *axialSegment, CDCAxialSegmentPair const &segmentPair)
	Define reconstructed segments and segment pairs as coaligned on the start segment.

Detailed Description

Class representing a pair of reconstructed axial segements in adjacent superlayer.

Definition at line 31 of file CDCAxialSegmentPair.h.

Member Function Documentation

isCoaligned()

EForwardBackward isCoaligned

(

const CDCTrajectory2D &

trajectory2D

)

const

Checks if the last entity in the vector lies greater or lower travel distance than the last entity.

Returns:

• EForwardBackward::c_Forward if the last entity lies behind the first.
• EForwardBackward::c_Backward if the last entity lies before the first.

Definition at line 90 of file CDCAxialSegmentPair.cc.

{
  EForwardBackward startIsCoaligned = trajectory2D.isForwardOrBackwardTo(*(getStartSegment()));
  EForwardBackward endIsCoaligned = trajectory2D.isForwardOrBackwardTo(*(getEndSegment()));
  if (startIsCoaligned == EForwardBackward::c_Forward and
      endIsCoaligned == EForwardBackward::c_Forward) {
    return EForwardBackward::c_Forward;
  } else if (startIsCoaligned == EForwardBackward::c_Backward and
             endIsCoaligned == EForwardBackward::c_Backward) {
    return EForwardBackward::c_Backward;
  } else {
    return EForwardBackward::c_Invalid;
  }
}

---

The documentation for this class was generated from the following files:

• tracking/trackFindingCDC/eventdata/tracks/include/CDCAxialSegmentPair.h
• tracking/trackFindingCDC/eventdata/tracks/src/CDCAxialSegmentPair.cc
