CDCRLWireHitPair Class Reference

A pair of oriented wire hits. More...

#include <CDCRLWireHitPair.h>

Inheritance diagram for CDCRLWireHitPair:

Collaboration diagram for CDCRLWireHitPair:

Public Member Functions
	CDCRLWireHitPair ()=default
	Default constructor for ROOT.
	CDCRLWireHitPair (const CDCRLWireHit &fromRLWireHit, const CDCRLWireHit &toRLWireHit, int iCluster=0)
	Constructor taking two oriented wire hits.
CDCRLWireHitPair	reversed () const
	Constructs a oriented wire hit pair that is the reverse of this one.
void	reverse ()
	Reverses the oriented wire hit pair inplace.
CDCRLWireHitPair	getAlias () const
	Returns the aliased version of this oriented wire hit pair.
bool	operator== (const CDCRLWireHitPair &other) const
	Equality comparision based the two oriented wire hits.
bool	operator< (const CDCRLWireHitPair &other) const
	Total ordering relation based on the from oriented wire hit first and the to oriented wire hit second.
WireNeighborKind	getNeighborKind () const
	Getter for the WireNeighborKind of the two underlying wires.
ISuperLayer	getISuperLayer () const
	Getter for the common superlayer id of the pair.
EStereoKind	getStereoKind () const
	Getter for the common stereo type of the superlayer of the pair.
bool	isAxial () const
	Indicator if the underlying wires are axial.
const CDCWire &	getFromWire () const
	Getter for the wire the first oriented wire hit is based on.
const CDCWire &	getToWire () const
	Getter for the wire the second oriented wire hit is based on.
bool	hasWire (const CDCWire &wire) const
	Indicator if any of the two oriented wire hits is based on the given wire.
const CDCWireHit &	getFromWireHit () const
	Getter for the hit wire of the first oriented wire hit.
const CDCWireHit &	getToWireHit () const
	Getter for the hit wire of the second oriented wire hit.
bool	hasWireHit (const CDCWireHit &wirehit) const
	Indicator if any of the two oriented wire hits is based on the given wire hit.
ERightLeft	getFromRLInfo () const
	Getter for the right left passage information of the first oriented wire hit.
ERightLeft	getToRLInfo () const
	Getter for the right left passage information of the second oriented wire hit.
CDCRLWireHit &	getFromRLWireHit ()
	Getter for the first oriented wire hit.
CDCRLWireHit &	getToRLWireHit ()
	Getter for the second oriented wire hit.
const CDCRLWireHit &	getFromRLWireHit () const
	Constant getter for the first oriented wire hit.
const CDCRLWireHit &	getToRLWireHit () const
	Constant getter for the second oriented wire hit.
void	setFromRLWireHit (const CDCRLWireHit &fromRLWireHit)
	Setter for the first oriented wire hit.
void	setToRLWireHit (const CDCRLWireHit &toRLWireHit)
	Setter for the second oriented wire hit.
void	setFromRLInfo (ERightLeft fromRLInfo)
	Setter for the right left passage information of the first oriented wire hit.
void	setToRLInfo (ERightLeft toRLInfo)
	Setter for the right left passage information of the second oriented wire hit.
int	getICluster () const
	Getter for the cluster id.
void	setICluster (int iCluster)
	Setter for the cluster id.

Protected Attributes
CDCRLWireHit	m_fromRLWireHit
	Memory for the reference to the first oriented wire hit.
CDCRLWireHit	m_toRLWireHit
	Memory for the reference to the second oriented wire hit.
int	m_iCluster = -1
	Memory for the cluster id of this facet.

Friends
bool	operator< (const CDCRLWireHitPair &rlWireHitPair, const CDCWireHit &wireHit)
	Defines wire hits and oriented wire hit pair as coaligned on the first wire hit.
bool	operator< (const CDCWireHit &wireHit, const CDCRLWireHitPair &rlWireHitPair)
	Defines wire hits and oriented wire hit pair as coaligned on the first wire hit.

Detailed Description

A pair of oriented wire hits.

Definition at line 27 of file CDCRLWireHitPair.h.

---

The documentation for this class was generated from the following files:

• tracking/trackFindingCDC/eventdata/hits/include/CDCRLWireHitPair.h
• tracking/trackFindingCDC/eventdata/hits/src/CDCRLWireHitPair.cc
