TrackQualityAsserter Class Reference

This module applies configurable correction functions to all found tracks. More...

#include <TrackQualityAsserter.h>

Inheritance diagram for TrackQualityAsserter:

Collaboration diagram for TrackQualityAsserter:

Public Types
using	IOTypes = std::tuple< AIOTypes... >
	Types that should be served to apply on invokation.
using	IOVectors = std::tuple< std::vector< AIOTypes >... >
	Vector types that should be served to apply on invokation.

Public Member Functions
	TrackQualityAsserter ()
	Constructor setting up the default parameters.
std::string	getDescription () override
	Get the description of the findlet.
void	exposeParameters (ModuleParamList *moduleParamList, const std::string &prefix) final
	Expose the parameters to a module.
void	apply (std::vector< CDCTrack > &tracks) final
	Main function to clean up the tracks.
virtual void	apply (ToVector< AIOTypes > &... ioVectors)=0
	Main function executing the algorithm.
void	initialize () override
	Receive and dispatch signal before the start of the event processing.
void	beginRun () override
	Receive and dispatch signal for the beginning of a new run.
void	beginEvent () override
	Receive and dispatch signal for the start of a new event.
void	endRun () override
	Receive and dispatch signal for the end of the run.
void	terminate () override
	Receive and dispatch Signal for termination of the event processing.

Protected Types
using	ToVector = typename ToVectorImpl< T >::Type
	Short hand for ToRangeImpl.

Protected Member Functions
void	addProcessingSignalListener (ProcessingSignalListener *psl)
	Register a processing signal listener to be notified.
int	getNProcessingSignalListener ()
	Get the number of currently registered listeners.

Private Types
using	Super = Findlet< CDCTrack & >
	Type of the base class.

Private Attributes
std::vector< std::string >	m_param_corrections
	Parameter : The corrections to use.
bool	m_param_onlyNotFittedTracks = false
	Parameter : Flag to use the corrections only for not fitted tracks.
std::vector< ProcessingSignalListener * >	m_subordinaryProcessingSignalListeners
	References to subordinary signal processing listener contained in this findlet.
bool	m_initialized = false
	Flag to keep track whether initialization happend before.
bool	m_terminated = false
	Flag to keep track whether termination happend before.
std::string	m_initializedAs
	Name of the type during initialisation.

Detailed Description

This module applies configurable correction functions to all found tracks.

Typical correction functions include:

• Removal of hits after long breaks
• Removal of hits on the wrong side of the detector
• Splitting of curling tracks into two halves
• etc.

See the TrackQualityTools for details on the specific functions.

Mainly the corrections are applied to remove fakes and to make the tracks fitable with genfit (which fails mainly for low-momentum tracks). WARNING: Not all of the correction functions work well and the finding efficiency may be reduced strongly even when applying the correctly working functions! Handle with care ;-)

Definition at line 41 of file TrackQualityAsserter.h.

---

The documentation for this class was generated from the following files:

• tracking/trackFindingCDC/findlets/minimal/include/TrackQualityAsserter.h
• tracking/trackFindingCDC/findlets/minimal/src/TrackQualityAsserter.cc
