This class collects all information needed and produced by a specific AbsFitter and is specific to one AbsTrackRep of the Track. More...

Inheritance diagram for AbsFitterInfo:

[legend]

Collaboration diagram for AbsFitterInfo:

[legend]

Public Member Functions
	AbsFitterInfo (const TrackPoint trackPoint, const AbsTrackRep rep)

virtual AbsFitterInfo *	clone () const =0
	Deep copy ctor for polymorphic class.

const TrackPoint *	getTrackPoint () const

const AbsTrackRep *	getRep () const

void	setTrackPoint (const TrackPoint *tp)

virtual void	setRep (const AbsTrackRep *rep)

virtual bool	hasMeasurements () const =0

virtual bool	hasReferenceState () const =0

virtual bool	hasForwardPrediction () const =0

virtual bool	hasBackwardPrediction () const =0

virtual bool	hasPrediction (int direction) const

virtual bool	hasForwardUpdate () const =0

virtual bool	hasBackwardUpdate () const =0

virtual bool	hasUpdate (int direction) const

virtual void	deleteForwardInfo ()=0

virtual void	deleteBackwardInfo ()=0

virtual void	deleteReferenceInfo ()=0

virtual void	deleteMeasurementInfo ()=0

const SharedPlanePtr &	getPlane () const

virtual const MeasuredStateOnPlane &	getFittedState (bool biased=true) const =0

virtual MeasurementOnPlane	getResidual (unsigned int iMeasurement=0, bool biased=true, bool onlyMeasurementErrors=false) const =0

void	setPlane (const SharedPlanePtr &plane)

virtual void	Print (const Option_t *="") const

virtual bool	checkConsistency (const PruneFlags *=nullptr) const =0

Protected Attributes
const TrackPoint *	trackPoint_
	Pointer to TrackPoint where the FitterInfo belongs to.

const AbsTrackRep *	rep_
	No ownership. More...

SharedPlanePtr	sharedPlane_
	No ownership.

Private Member Functions
	AbsFitterInfo (const AbsFitterInfo &)
	Shared ownership. '!' shuts up ROOT.

AbsFitterInfo &	operator= (const AbsFitterInfo &)

Detailed Description

This class collects all information needed and produced by a specific AbsFitter and is specific to one AbsTrackRep of the Track.

Definition at line 42 of file AbsFitterInfo.h.

Member Data Documentation

const AbsTrackRep* rep_

protected

No ownership.

Pointer to AbsTrackRep with respect to which the FitterInfo is defined

Definition at line 92 of file AbsFitterInfo.h.

The documentation for this class was generated from the following files:
