Particle trajectory as it is seen in xy projection represented as a circle. More...

#include <CDCTrajectory2D.h>

Collaboration diagram for CDCTrajectory2D:

[legend]

Public Member Functions
	CDCTrajectory2D ()
	Default constructor for ROOT compatibility.

	CDCTrajectory2D (const UncertainPerigeeCircle &perigeeCircle)
	Constructs a trajectory from a generalized circle. More...

	CDCTrajectory2D (const Vector2D &localOrigin, const UncertainPerigeeCircle &localPerigeeCircle, double flightTime=NAN)
	Constructs a trajectory from a generalized circle and a start point. More...

	CDCTrajectory2D (const Vector2D &pos2D, double time, const Vector2D &mom2D, double charge, double bZ)
	Construct a trajectory with given start point, transverse momentum at the start point, the given charge and the magnetic field value in z direction.

	CDCTrajectory2D (const Vector2D &pos2D, double time, const Vector2D &mom2D, double charge)
	Construct a trajectory with given start point, transverse momentum at the start point and given charge.

bool	isFitted () const
	Checks if the circle is already set to a valid value.

void	clear ()
	Clears all information from this trajectoy.

void	reverse ()
	Reverses the trajectory in place.

CDCTrajectory2D	reversed () const
	Returns the reverse trajectory as a copy.

std::array< double, 2 >	reconstructBothZ (const WireLine &wireLine, double distance=0.0, double z=0) const
	Gives the two z postions where the given drift circle on the wire line touches the trajectory. More...

double	reconstructZ (const WireLine &wireLine, double distance=0.0, double z=0) const
	Gives the one z postions within the CDC closest to the given z where the given drift circle on the wire line touches the trajectory. More...

std::array< Vector3D, 2 >	reconstructBoth3D (const WireLine &wireLine, double distance=0.0, double z=0) const
	Gives the two three dimensional points where the drift circle touches the wire line. More...

Vector3D	reconstruct3D (const WireLine &wireLine, double distance=0.0, double z=0) const
	Gives the one three dimensional postions within the CDC closest to the given z where the given drift circle on the wire line touches the trajectory. More...

Vector2D	getClosest (const Vector2D &point) const
	Calculates the closest approach on the trajectory to the given point.

ISuperLayer	getNextISuperLayer () const
	Indicates which superlayer the trajectory traverses after the one, where the start point of the trajectory is located.

ISuperLayer	getPreviousISuperLayer () const
	Indicates which superlayer the trajectory traverses before the one, where the start point of the trajectory is located.

ISuperLayer	getNextAxialISuperLayer () const
	Indicates which axial superlayer the trajectory traverses after the one, where the start point of the trajectory is located.

ISuperLayer	getPreviousAxialISuperLayer () const
	Indicates which axial superlayer the trajectory traverses before the one, where the start point of the trajectory is located.

ISuperLayer	getMaximalISuperLayer () const
	Indicates the maximal superlayer the trajectory traverses.

ISuperLayer	getStartISuperLayer () const
	Indicates the superlayer the trajectory starts in.

ISuperLayer	getMinimalISuperLayer () const
	Indicates the minimal superlayer the trajectory traverses.

template<class AHits >
EForwardBackward	isForwardOrBackwardTo (const AHits &hits) const
	Calculates if this trajectory and the hits are coaligned Returns: More...

template<class AFromHits , class AToHits >
double	getArcLength2DGap (const AFromHits &fromHits, const AToHits &toHits) const
	Calculates the perpendicular travel distance from the last position of the fromHits to the first position of the toHits.

template<class AFromHits , class AToHits >
double	getArcLength2DFrontOffset (const AFromHits &fromHits, const AToHits &toHits) const
	Calculates the perpendicular travel distance from the first position of the fromHits to the first position of the toHits.

template<class AFromHits , class AToHits >
double	getArcLength2DBackOffset (const AFromHits &fromHits, const AToHits &toHits) const
	Calculates the perpendicular travel distance from the last position of the fromHits to the last position of the toHits.

template<class AHits >
double	getTotalArcLength2D (const AHits &hits) const
	Calculates the perpendicular travel distance from the first position of the hits to the last position of the hits.

double	calcArcLength2D (const Vector2D &point) const
	Calculate the travel distance from the start position of the trajectory. More...

double	calcArcLength2DBetween (const Vector2D &fromPoint, const Vector2D &toPoint) const
	Calculate the travel distance between the two given positions Returns the travel distance on the trajectory from the first given point to the second given point. More...

double	getArcLength2DPeriod () const
	Getter for the arc length for one round trip around the trajectory.

void	setPosMom2D (const Vector2D &pos2D, const Vector2D &mom2D, double charge)
	Setter for start point and momentum at the start point subjected to the charge sign.

ESign	getChargeSign () const
	Gets the charge sign of the trajectory.

double	getAbsMom2D (double bZ) const
	Get the estimation for the absolute value of the transvers momentum.

double	getAbsMom2D () const
	Get the estimation for the absolute value of the transvers momentum.

Vector2D	getMom2DAtSupport (const double bZ) const
	Get the momentum at the support point of the trajectory.

Vector2D	getMom2DAtSupport () const
	Get the momentum at the support point of the trajectory.

Vector2D	getFlightDirection2D (const Vector2D &point) const
	Get the unit direction of flight at the given point, where arcLength2D = 0.

Vector2D	getFlightDirection2DAtSupport () const
	Get the unit direction of flight at the support point, where arcLength2D = 0.

bool	isMovingOutward () const
	Indicates if the trajectory is moving outwards or inwards (to or away from the origin) from the start point on.

Vector2D	getPos2DAtArcLength2D (double arcLength2D)
	Getter for the position at a given two dimensional arc length.

Vector2D	getSupport () const
	Get the support point of the trajectory in global coordinates.

Vector2D	getGlobalPerigee () const
	Getter for the closest approach on the trajectory to the global origin.

Vector2D	getGlobalCenter () const
	Getter for the center of the trajectory in global coordinates.

Vector2D	getOuterExit (double factor=1) const
	Calculates the point where the trajectory meets the outer wall of the CDC. More...

Vector2D	getInnerExit () const
	Calculates the point where the trajectory meets the inner wall of the CDC. More...

Vector2D	getExit () const
	Calculates the point where the trajectory leaves the CDC. More...

bool	isCurler (double factor=1) const
	Checks if the trajectory leaves the outer radius of the CDC times the given tolerance factor.

bool	isOriginer (double factor=1) const
	Checks if the trajectory intersects with the inner radius of the CDC time the given tolerance factor.

double	getMaximalCylindricalR () const
	Getter for the maximal distance from the origin.

double	getMinimalCylindricalR () const
	Getter for the minimal distance from the origin - same as absolute value of the impact parameter.

double	getGlobalImpact () const
	Getter for the signed impact parameter of the trajectory.

double	getDist2D (const Vector2D &point) const
	Calculates the distance from the point to the trajectory as seen from the xy projection.

ERightLeft	isRightOrLeft (const Vector2D &point) const
	Checks if the given point is to the right or to the left of the trajectory.

double	getCurvature () const
	Getter for the curvature as seen from the xy projection.

double	getLocalCovariance (EPerigeeParameter iRow, EPerigeeParameter iCol) const
	Getter for an individual element of the covariance matrix of the local helix parameters.

double	getLocalVariance (EPerigeeParameter i) const
	Getter for an individual diagonal element of the covariance matrix of the local helix parameters.

PerigeeCircle	getGlobalCircle () const
	Getter for the circle in global coordinates.

void	setGlobalCircle (const UncertainPerigeeCircle &perigeeCircle)
	Setter for the generalized circle that describes the trajectory.

const UncertainPerigeeCircle &	getLocalCircle () const
	Getter for the cirlce in local coordinates.

double	getPValue () const
	Getter for p-value.

double	getChi2 () const
	Getter for the chi2 value of the circle fit.

void	setChi2 (const double chi2)
	Setter for the chi square value of the circle fit.

size_t	getNDF () const
	Getter for the number of degrees of freedom of the circle fit.

void	setNDF (std::size_t ndf)
	Setter for the number of degrees of freedom of the circle fit.

void	setLocalCircle (const UncertainPerigeeCircle &localPerigeeCircle)
	Setter for the generalized circle that describes the trajectory.

const Vector2D &	getLocalOrigin () const
	Getter for the origin of the local coordinate system.

double	setLocalOrigin (const Vector2D &localOrigin)
	Setter for the origin of the local coordinate system. More...

double	getFlightTime () const
	Getter for the time when the particle reached the support point position.

void	setFlightTime (double flightTime)
	Setter for the time when the particle reached the support point position.

Private Member Functions
ISuperLayer	getISuperLayerAfter (ISuperLayer iSuperLayer, bool movingOutward) const
	Returns which superlayer is traversed after the current one following the trajectory outward or inward as indicated by the boolean input.

ISuperLayer	getISuperLayerAfterStart (bool movingOutward) const
	Returns which superlayer is traversed after the current one following the trajectory outward or inward as indicated by the boolean input.

ISuperLayer	getISuperLayerAfterStart (EForwardBackward forwardBackwardInfo) const
	Indicates which superlayer is traversed after the current one following the trajectory forward or backward as indicated by the input.

ISuperLayer	getAxialISuperLayerAfterStart (EForwardBackward forwardBackwardInfo) const
	Indicates which axial superlayer is traversed after the one, where the start point of the trajectory is located considering if you want to follow the trajectory in the forward or backward direction.

Private Attributes
Vector2D	m_localOrigin
	Memory for local coordinate origin of the circle representing the trajectory in global coordinates.

UncertainPerigeeCircle	m_localPerigeeCircle
	Memory for the generalized circle describing the trajectory in coordinates from the local origin.

double	m_flightTime = NAN
	Memory for the estimation of the time at which the particle arrived at the support point.

Detailed Description

Particle trajectory as it is seen in xy projection represented as a circle.

Definition at line 36 of file CDCTrajectory2D.h.

Constructor & Destructor Documentation

◆ CDCTrajectory2D() [1/2]

CDCTrajectory2D ( const UncertainPerigeeCircle & perigeeCircle )

explicit

Constructs a trajectory from a generalized circle.

Constructs a trajectory which is described by the given line or circle. The start point is set to the closest approach to the origin.

Definition at line 43 of file CDCTrajectory2D.cc.

   : m_localOrigin(0.0, 0.0)
   , m_localPerigeeCircle(perigeeCircle)
 {
 }

◆ CDCTrajectory2D() [2/2]

CDCTrajectory2D	(	const Vector2D &	localOrigin,
		const UncertainPerigeeCircle &	localPerigeeCircle,
		double	flightTime = `NAN`
	)

Constructs a trajectory from a generalized circle and a start point.

Constructs a trajectory which is described by the given line or circle and starts in the given point. The point is taken to be the closest approach to the circle.

Definition at line 49 of file CDCTrajectory2D.cc.

Member Function Documentation

◆ calcArcLength2D()

double calcArcLength2D ( const Vector2D & point ) const

inline

Calculate the travel distance from the start position of the trajectory.

Returns the travel distance on the trajectory from the start point to
the given point. This is subjected to a discontinuity at the far point
of the circle. Hence the value return is in the range from -pi*radius to pi*radius
If you have a heavily curling track you have care about the feasibility of this
calculation.

Definition at line 260 of file CDCTrajectory2D.h.

       {
         return getLocalCircle()->arcLengthBetween(Vector2D(0.0, 0.0), point - getLocalOrigin());
       }

◆ calcArcLength2DBetween()

double calcArcLength2DBetween	(	const Vector2D &	fromPoint,
		const Vector2D &	toPoint
	)		const

inline

Calculate the travel distance between the two given positions Returns the travel distance on the trajectory from the first given point to
the second given point.

This is subjected to a discontinuity at the far point
of the circle. Hence the value return is in the range from -pi*radius to pi*radius
If you have a heavily curling track you have care about the feasibility of this
calculation.

Definition at line 273 of file CDCTrajectory2D.h.

◆ getExit()

Vector2D getExit ( ) const

Calculates the point where the trajectory leaves the CDC.

This method returns the first point in forward flight direction from the start point of the trajectory where it meets either the radius of the inner most layer or the outer radius of the outer most wall. If the trajectory does not leave the CDC by the inner or outer wall this will return Vector2D(nan,nan).

Definition at line 334 of file CDCTrajectory2D.cc.

◆ getInnerExit()

Vector2D getInnerExit ( ) const

Calculates the point where the trajectory meets the inner wall of the CDC.

This method returns the first point in forward flight direction from the start point of the trajectory where it meets the inner radius of the inner most layer. If the trajectory does not meet the CDC by the inner wall this will return Vector2D(nan,nan)

Definition at line 294 of file CDCTrajectory2D.cc.

◆ getOuterExit()

Vector2D getOuterExit ( double factor = 1 ) const

Calculates the point where the trajectory meets the outer wall of the CDC.

This method returns the first point in forward flight direction from the start point of the trajectory where it meets the outer radius of the outer most layer. If the trajectory does not meet the CDC by the outer wall this will return Vector2D(nan,nan) The factor can be used to virtually resize the CDC.

Definition at line 314 of file CDCTrajectory2D.cc.

◆ isForwardOrBackwardTo()

EForwardBackward isForwardOrBackwardTo ( const AHits & hits ) const

inline

Calculates if this trajectory and the hits are coaligned Returns:

EForwardBackward::c_Forward if the last entity lies behind the first.
EForwardBackward::c_Backward if the last entity lies before the first.

Definition at line 200 of file CDCTrajectory2D.h.

◆ reconstruct3D()

Vector3D reconstruct3D	(	const WireLine &	wireLine,
		double	distance = `0.0`,
		double	z = `0`
	)		const

Gives the one three dimensional postions within the CDC closest to the given z where the given drift circle on the wire line touches the trajectory.

This method makes the reconstruction of the z coordinate possible by using the skewness
stereo layer of the stereo wires. The point is determined such that it is at the (signed) distance to the wire line.

Parameters

wireLine	The geometrical wire line on which the hit is located-
distance	The desired distance from the wire line a.k.a. drift length
z	The expected value of z to which to closest solution should be selected.

Definition at line 162 of file CDCTrajectory2D.cc.

◆ reconstructBoth3D()

std::array< Vector3D, 2 > reconstructBoth3D	(	const WireLine &	wireLine,
		double	distance = `0.0`,
		double	z = `0`
	)		const

Gives the two three dimensional points where the drift circle touches the wire line.

Only works for the skew stereo wires.

Parameters

wireLine	The geometrical wire line on which the hit is located-
distance	The desired distance from the wire line a.k.a. drift length
z	The expected value of z to which to closest solution should be selected.

Definition at line 149 of file CDCTrajectory2D.cc.

◆ reconstructBothZ()

std::array< double, 2 > reconstructBothZ	(	const WireLine &	wireLine,
		double	distance = `0.0`,
		double	z = `0`
	)		const

Gives the two z postions where the given drift circle on the wire line touches the trajectory.

Only works for the skew stereo wires

Parameters

wireLine	The geometrical wire line on which the hit is located-
distance	The desired distance from the wire line a.k.a. drift length
z	The expected value of z to which to closest solution should be selected.

Definition at line 109 of file CDCTrajectory2D.cc.

◆ reconstructZ()

double reconstructZ	(	const WireLine &	wireLine,
		double	distance = `0.0`,
		double	z = `0`
	)		const

Gives the one z postions within the CDC closest to the given z where the given drift circle on the wire line touches the trajectory.

Only works for the skew stereo wires.

Parameters

wireLine	The geometrical wire line on which the hit is located-
distance	The desired distance from the wire line a.k.a. drift length
z	The expected value of z to which to closest solution should be selected.

Definition at line 132 of file CDCTrajectory2D.cc.

◆ setLocalOrigin()

double setLocalOrigin ( const Vector2D & localOrigin )

Setter for the origin of the local coordinate system.

This sets the origin point the local circle representation is subjected. The local circle is also changed such that the set of points in global space is not changed on repositioning the local parameterisation. It also implicitly sets up a new reference position for all travel distances.
To be able to keep track how the travel distances have to be shifted by this change
the setter returns the value by which the coordinate s parameter was moved ( passively ).
The relation "old traveldistance - return value == new traveldistance" holds.
(if they are not to far away from the reference points, up to the discontinuity at the
far point on the circle)

Parameters

localOrigin New local reference point in the global coordinate system

Returns: Travel distance from the old to the new origin point

Definition at line 355 of file CDCTrajectory2D.cc.

The documentation for this class was generated from the following files:

tracking/trackFindingCDC/eventdata/trajectories/include/CDCTrajectory2D.h
tracking/trackFindingCDC/eventdata/trajectories/src/CDCTrajectory2D.cc

Public Member Functions

Private Member Functions

Private Attributes

Detailed Description

Constructor & Destructor Documentation

◆ CDCTrajectory2D() [1/2]

◆ CDCTrajectory2D() [2/2]

Member Function Documentation

◆ calcArcLength2D()

◆ calcArcLength2DBetween()

◆ getExit()

◆ getInnerExit()

◆ getOuterExit()

◆ isForwardOrBackwardTo()

◆ reconstruct3D()

◆ reconstructBoth3D()

◆ reconstructBothZ()

◆ reconstructZ()

◆ setLocalOrigin()
