BeamabortCreator Class Reference

The creator for the BEAMABORT geometry. More...

#include <BeamabortCreator.h>

Inheritance diagram for BeamabortCreator:

Collaboration diagram for BeamabortCreator:

Public Member Functions
	BeamabortCreator ()
	Constructor.
virtual	~BeamabortCreator ()
	Destructor.
virtual void	create (const GearDir &content, G4LogicalVolume &topVolume, geometry::GeometryTypes type) override
	Creates the ROOT Objects for the BeamPipe geometry. More...
virtual void	createPayloads (const GearDir &content, const IntervalOfValidity &iov) override
	creates DB payload for BeamabortGeo class
virtual void	createFromDB (const std::string &name, G4LogicalVolume &topVolume, geometry::GeometryTypes type) override
	Create the geometry from the Database.
	BELLE2_DEFINE_EXCEPTION (DBNotImplemented, "Cannot create geometry from Database.")
	Exception that will be thrown in createFromDB if member is not yet implemented by creator.

Protected Attributes
BeamabortGeo	m_config
	geometry parameters object

Private Member Functions
BeamabortGeo	createConfiguration (const GearDir &param)
	Reads beamabort geometry parameters from the xml files and createst DB class BeamabortGeo.
void	createGeometry (G4LogicalVolume &topVolume, geometry::GeometryTypes type)
	Create detector geometry. More...

Detailed Description

The creator for the BEAMABORT geometry.

Definition at line 32 of file BeamabortCreator.h.

Member Function Documentation

create()

virtual void create ( const GearDir &  content, G4LogicalVolume &  topVolume, geometry::GeometryTypes  type  )

inlineoverridevirtual

Creates the ROOT Objects for the BeamPipe geometry.

Parameters

content	A reference to the content part of the parameter description, which should to be used to create the ROOT objects.
topVolume	Geant4 logical top volume.
type	Geometry type.

Implements CreatorBase.

Definition at line 67 of file BeamabortCreator.h.

      {
        m_config = createConfiguration(content);

        // override geometry configuration from the DB
        DBStore::Instance().addConstantOverride("BeamabortGeo", new BeamabortGeo(m_config));

        createGeometry(topVolume, type);
      }

createGeometry()

void createGeometry ( G4LogicalVolume &  topVolume, geometry::GeometryTypes  type  )

private

Create detector geometry.

Parameters

topVolume	Geant4 logical top volume.
type	Geometry type.

Definition at line 58 of file BeamabortCreator.cc.

    {
      //get parameters from .xml file
      std::string prep = "Active.";

      B2INFO("BeamabortCreator phase3");
      //Visualization Attributes
      G4VisAttributes* orange = new G4VisAttributes(G4Colour(1, 2, 0));
      orange->SetForceAuxEdgeVisible(true);
      G4VisAttributes* magenta = new G4VisAttributes(G4Colour(1, 0, 1));
      magenta->SetForceAuxEdgeVisible(true);
      //lets get the stepsize parameter with a default value of 5 µm
      double stepSize = m_config.getParameter("stepSize", 5 * CLHEP::um);

      //Lets loop over all the Active nodes
      int phase = m_config.getParameter(prep + "phase");
      //Positioned Diamonds
      std::vector<double> x_pos;
      std::vector<double> y_pos;
      std::vector<double> z_pos;
      std::vector<double> phi;
      std::vector<double> thetaX;
      std::vector<double> thetaY;
      std::vector<double> thetaZ;
      std::vector<double> svdAngle;
      std::vector<double> r;
      std::vector<double> deltaX;
      unsigned int dimz = 0;

      for (double z : m_config.getParArray(prep + "z", {0})) {
        z *= CLHEP::cm;
        z_pos.push_back(z);
        dimz++;
      }

      for (double ThetaZ : m_config.getParArray(prep + "ThetaZ", {0})) {
        thetaZ.push_back(ThetaZ);
      }

      if (thetaZ.size() != dimz) { B2ERROR("Diamond data not consistent (i.e. not same number of all position parmeters)"); return;}

      if (phase == 2 || phase == 3) {

        for (double Phi : m_config.getParArray(prep + "Phi", {0})) {
          phi.push_back(Phi);
        }

        for (double r_dia : m_config.getParArray(prep + "r_dia", {0})) {
          r_dia *= CLHEP::cm;
          r.push_back(r_dia);
        }
        for (double dX : m_config.getParArray(prep + "deltaX", {0})) {
          dX *= CLHEP::cm;
          deltaX.push_back(dX);
        }
        for (double addAngle : m_config.getParArray(prep + "addAngle", {0})) {
          svdAngle.push_back(addAngle);
        }
        if (phi.size() != dimz || r.size() != dimz || deltaX.size() != dimz || svdAngle.size() != dimz) { B2ERROR("Diamond data not consistent (i.e. not same number of all position parmeters)"); return;}
      }
      if (phase == 1) {
        for (double x : m_config.getParArray(prep + "x", {0})) {
          x *= CLHEP::cm;
          x_pos.push_back(x);
        }
        for (double y : m_config.getParArray(prep + "y", {0})) {
          y *= CLHEP::cm;
          y_pos.push_back(y);
        }

        for (double ThetaX : m_config.getParArray(prep + "ThetaX", {0})) {
          thetaX.push_back(ThetaX);
        }
        for (double ThetaY : m_config.getParArray(prep + "ThetaY", {0})) {
          thetaY.push_back(ThetaY);
        }
        if (x_pos.size() != dimz || y_pos.size() != dimz || thetaX.size() != dimz || thetaY.size() != dimz) { B2ERROR("Diamond data not consistent (i.e. not same number of all position parmeters)"); return;}
      }

      //create beamabort package
      G4double dx_opa = 12. / 2. * CLHEP::mm;
      G4double dy_opa = 18. / 2. * CLHEP::mm;
      G4double dz_opa = 3.1 / 2. * CLHEP::mm;
      G4VSolid* s_pa = new G4Box("s_opa", dx_opa, dy_opa, dz_opa);
      G4double dx_ipa = 6. / 2. * CLHEP::mm;
      G4double dy_ipa = 6. / 2. * CLHEP::mm;
      G4double dz_ipa = 5.6 / 2. * CLHEP::mm;
      G4VSolid* s_ipa = new G4Box("s_ipa", dx_ipa, dy_ipa, dz_ipa);
      s_pa = new G4SubtractionSolid("s_pa", s_pa, s_ipa, 0, G4ThreeVector(0., 4.0, 0.));
      G4LogicalVolume* l_pa = new G4LogicalVolume(s_pa, G4Material::GetMaterial("Al6061"), "l_pa");
      l_pa->SetVisAttributes(magenta);
      G4Transform3D transform;
      for (unsigned int i = 0; i < dimz; i++) {
        B2INFO("DIA-" << i << "RotateZ3D phi: " << phi[i]);

        if (phase == 1) {
          transform = G4Translate3D(x_pos[i], y_pos[i], z_pos[i]) * G4RotateX3D(thetaX[i]) *
                      G4RotateY3D(thetaY[i]) * G4RotateZ3D(thetaZ[i]);
        } else if (phase == 2 || phase == 3) {
          transform = G4Translate3D(deltaX[i], 0, 0) * G4RotateZ3D(phi[i]) *
                      G4Translate3D(r[i], 0, z_pos[i]) * G4RotateX3D(-M_PI / 2 - thetaZ[i]) *
                      G4RotateZ3D(svdAngle[i]) * G4RotateY3D(M_PI / 2);
        }
        new G4PVPlacement(transform, l_pa, TString::Format("p_dia_pa_%d", i).Data(), &topVolume, false, 0);
        B2INFO("DIA-" << i << " placed at: " << transform.getTranslation() << " mm ");
      }

      //create beamabort volumes
      G4double dx_ba = 4.5 / 2. * CLHEP::mm;
      G4double dy_ba = 4.5 / 2. * CLHEP::mm;
      G4double dz_ba = 0.5 / 2. * CLHEP::mm;
      G4Box* s_BEAMABORT = new G4Box("s_BEAMABORT", dx_ba, dy_ba, dz_ba);
      G4LogicalVolume* l_BEAMABORT = new G4LogicalVolume(s_BEAMABORT, geometry::Materials::get("Diamond"), "l_BEAMABORT");
      l_BEAMABORT->SetVisAttributes(orange);

      //Lets limit the Geant4 stepsize inside the volume
      l_BEAMABORT->SetUserLimits(new G4UserLimits(stepSize));
      l_BEAMABORT->SetVisAttributes(orange);

      // make the volume sensitive if the beam background study flag is enabled
      if (m_config.getParameter("BeamBackgroundStudy")) l_BEAMABORT->SetSensitiveDetector(new SensitiveDetector());

      for (unsigned int i = 0; i < dimz; i++) {

        if (phase == 1)
          transform = G4Translate3D(x_pos[i], y_pos[i],
                                    z_pos[i]) * G4RotateX3D(thetaX[i]) * G4RotateY3D(thetaY[i]) * G4RotateZ3D(thetaZ[i]);
        if (phase == 2 || phase == 3)
          transform = G4Translate3D(deltaX[i], 0, 0) * G4RotateZ3D(phi[i]) *
                      G4Translate3D(r[i], 0, z_pos[i]) * G4RotateX3D(-M_PI / 2 - thetaZ[i]) *
                      G4RotateZ3D(svdAngle[i]) * G4RotateY3D(M_PI / 2) * G4Translate3D(0, 4.2, 0);

        new G4PVPlacement(transform, l_BEAMABORT, TString::Format("p_dia_%d", i).Data(), &topVolume, false, i);

        B2INFO("DIA-sensitive volume-" << i << " placed at: " << transform.getTranslation() << " mm "
               << "  at phi angle = " << phi[i] << "   at theta angle = "
               << thetaZ[i]);
        B2INFO("DIA-sensitive volume-" << i << " G4RotateZ3D of: phi= " << phi[i] << "  G4RotateX3D = "
               << (-M_PI / 2 - thetaZ[i]));
      }
    }

---

The documentation for this class was generated from the following files:

• beast/beamabort/geometry/include/BeamabortCreator.h
• beast/beamabort/geometry/src/BeamabortCreator.cc
