AWESOMEGeometryCreator Class Reference

The creator for the AWESOME detector geometry. More...

#include <AWESOMEGeometryCreator.h>

Inheritance diagram for AWESOMEGeometryCreator:

Collaboration diagram for AWESOMEGeometryCreator:

Public Member Functions
	AWESOMEGeometryCreator ()
	Default constructor.
	AWESOMEGeometryCreator (AWESOMEGeometryCreator &)=delete
	Copy constructor, deleted.
AWESOMEGeometryCreator &	operator= (AWESOMEGeometryCreator &)=delete
	Assignment operator, deleted.
virtual	~AWESOMEGeometryCreator ()
	Default destructor.
void	create (const GearDir &content, G4LogicalVolume &topVolume, geometry::GeometryTypes)
	Create the AWESOME detector geometry in the world volume. More...
	BELLE2_DEFINE_EXCEPTION (DBNotImplemented, "Cannot create geometry from Database.")
	Exception that will be thrown in createFromDB if member is not yet implemented by creator.
virtual void	createFromDB (const std::string &name, G4LogicalVolume &topVolume, GeometryTypes type)
	Function to create the geometry from the Database. More...
virtual void	createPayloads (const GearDir &content, const IntervalOfValidity &iov)
	Function to create the geometry database. More...

Private Attributes
AWESOMESensitiveDetector *	m_sensitiveDetector
	The AWESOME sensitive detector.

Detailed Description

The creator for the AWESOME detector geometry.

Definition at line 26 of file AWESOMEGeometryCreator.h.

Member Function Documentation

create()

void create ( const GearDir &  content, G4LogicalVolume &  topVolume, geometry::GeometryTypes    )

virtual

Create the AWESOME detector geometry in the world volume.

Parameters

content	Gearbox path to the detector geometry.
topVolume	Geant4 world volume.

Implements CreatorBase.

Definition at line 43 of file AWESOMEGeometryCreator.cc.

{
  /* Let's get the stepsize parameter with a default value of 5 µm. */
  double stepSize = content.getLength("stepSize", 5 * Unit::um);
  /* Now get the array. Notice that the default framework unit is cm,
   * so the values will be automatically converted. */
  B2INFO("Contents of bar:");
  for (double value : content.getArray("bar")) {
    B2INFO(LogVar("Value", value));
  }
  /* Let's loop over all the Active nodes. */
  for (const GearDir& activeParams : content.getNodes("Active")) {
    /* Lets create a Box with dimensions taken from the parameters.
     * WARNING: Geant4 is in mm so you have to convert the parameters. */
    G4Box* activeShape = new G4Box("ActiveBox",
                                   activeParams.getLength("width") / Unit::mm / 2.0,
                                   activeParams.getLength("length") / Unit::mm / 2.0,
                                   activeParams.getLength("height") / Unit::mm / 2.0
                                  );
    std::string material = activeParams.getString("Material");
    G4LogicalVolume* active = new G4LogicalVolume(activeShape,  geometry::Materials::get(material),
                                                  "ActiveVolume", 0, m_sensitiveDetector);
    /* setColor is an utility function which allows to easily set the color for visualization. */
    geometry::setColor(*active, "#006699");
    /* Le's limit the Geant4 stepsize inside the volume. */
    active->SetUserLimits(new G4UserLimits(stepSize));
    /* And finally place the volume in the world one. */
    new G4PVPlacement(G4Translate3D(0, 0, activeParams.getLength("z") / Unit::mm),
                      active, "ActivePlacement", &topVolume, false, 1);
  }
}

createFromDB()

void createFromDB ( const std::string &  name, G4LogicalVolume &  topVolume, GeometryTypes  type  )

virtualinherited

Function to create the geometry from the Database.

Parameters

name	name of the component in the database, could be used to disambiguate multiple components created with the same creator
topVolume	Top volume in which the geometry has to be placed
type	Type of geometry to be build

Reimplemented in MyDBCreator, and GeoMagneticField.

Definition at line 17 of file CreatorBase.cc.

    {
      //Do nothing but raise exception that we don't do anything
      throw DBNotImplemented();
    }

createPayloads()

void createPayloads ( const GearDir &  content, const IntervalOfValidity &  iov  )

virtualinherited

Function to create the geometry database.

This function should be implemented to convert Gearbox parameters to one ore more database payloads

Parameters

content	GearDir pointing to the parameters which should be used for construction
iov	interval of validity to use when generating payloads

Reimplemented in MyDBCreator, and GeoMagneticField.

Definition at line 24 of file CreatorBase.cc.

---

The documentation for this class was generated from the following files:

• online_book/awesome/geometry/include/AWESOMEGeometryCreator.h
• online_book/awesome/geometry/src/AWESOMEGeometryCreator.cc
