CreatorBase Class Reference

Pure virtual base class for all geometry creators. More...

#include <CreatorBase.h>

Inheritance diagram for CreatorBase:

Public Member Functions
	BELLE2_DEFINE_EXCEPTION (DBNotImplemented, "Cannot create geometry from Database.")
	Exception that will be thrown in createFromDB if member is not yet implemented by creator.
	CreatorBase ()
	Default Constructor.
virtual	~CreatorBase ()
	Default Destructor.
virtual void	create (const GearDir &content, G4LogicalVolume &topVolume, GeometryTypes type)=0
	Function to actually create the geometry, has to be overridden by derived classes. More...
virtual void	createFromDB (const std::string &name, G4LogicalVolume &topVolume, GeometryTypes type)
	Function to create the geometry from the Database. More...
virtual void	createPayloads (const GearDir &content, const IntervalOfValidity &iov)
	Function to create the geometry database. More...

Detailed Description

Pure virtual base class for all geometry creators.

Definition at line 28 of file CreatorBase.h.

Member Function Documentation

create()

virtual void create ( const GearDir &  content, G4LogicalVolume &  topVolume, GeometryTypes  type  )

pure virtual

Function to actually create the geometry, has to be overridden by derived classes.

Parameters

content	GearDir pointing to the parameters which should be used for construction
topVolume	Top volume in which the geometry has to be placed
type	Type of geometry to be build

Implemented in AWESOMEGeometryCreator, MyDBCreator, and GeoMagneticField.

createFromDB()

void createFromDB ( const std::string &  name, G4LogicalVolume &  topVolume, GeometryTypes  type  )

virtual

Function to create the geometry from the Database.

Parameters

name	name of the component in the database, could be used to disambiguate multiple components created with the same creator
topVolume	Top volume in which the geometry has to be placed
type	Type of geometry to be build

Reimplemented in MyDBCreator, and GeoMagneticField.

Definition at line 17 of file CreatorBase.cc.

createPayloads()

void createPayloads ( const GearDir &  content, const IntervalOfValidity &  iov  )

virtual

Function to create the geometry database.

This function should be implemented to convert Gearbox parameters to one ore more database payloads

Parameters

content	GearDir pointing to the parameters which should be used for construction
iov	interval of validity to use when generating payloads

Reimplemented in MyDBCreator, and GeoMagneticField.

Definition at line 24 of file CreatorBase.cc.

---

The documentation for this class was generated from the following files:

• geometry/include/CreatorBase.h
• geometry/src/CreatorBase.cc
