DQMHistAnalysisPXDCMModule Class Reference

DQM Histogram Analysis for PXD Common Modes. More...

#include <DQMHistAnalysisPXDCM.h>

Inheritance diagram for DQMHistAnalysisPXDCMModule:
Collaboration diagram for DQMHistAnalysisPXDCMModule:

Public Types

enum  EParamType {
  c_ParamINT,
  c_ParamFLOAT,
  c_ParamTEXT
}
 The enumeration types for the module parameters. More...

typedef std::map< std::string, EParamTypeParamTypeList
 The type of list of module parameter types.

typedef std::map< std::string, int > IntValueList
 The type of list of integer module parameter.

typedef std::map< std::string, float > FloatValueList
 The type of list of float module parameter.

typedef std::map< std::string, std::string > TextList
 The type of list of string module parameter.

typedef std::map< std::string, TH1 * > HistList
 The type of list of histograms.

typedef std::map< std::string, MonitoringObject * > MonObjList
 The type of list of MonitoringObjects.

enum  EModulePropFlags {
  c_Input = 1,
  c_Output = 2,
  c_ParallelProcessingCertified = 4,
  c_HistogramManager = 8,
  c_InternalSerializer = 16,
  c_TerminateInAllProcesses = 32,
  c_DontCollectStatistics = 64
}
 Each module can be tagged with property flags, which indicate certain features of the module. More...

typedef ModuleCondition::EAfterConditionPath EAfterConditionPath
 Forward the EAfterConditionPath definition from the ModuleCondition.


Public Member Functions

 DQMHistAnalysisPXDCMModule ()
 Constructor.

 ~DQMHistAnalysisPXDCMModule ()
 Destructor.

virtual std::vector< std::string > getFileNames (__attribute__((unused)) bool outputFiles)
 Return a list of output filenames for this modules. More...

virtual void endRun ()
 This method is called if the current run ends. More...

const std::string & getName () const
 Returns the name of the module. More...

const std::string & getType () const
 Returns the type of the module (i.e. More...

const std::string & getPackage () const
 Returns the package this module is in.

const std::string & getDescription () const
 Returns the description of the module.

void setName (const std::string &name)
 Set the name of the module. More...

void setPropertyFlags (unsigned int propertyFlags)
 Sets the flags for the module properties. More...

LogConfiggetLogConfig ()
 Returns the log system configuration.

void setLogConfig (const LogConfig &logConfig)
 Set the log system configuration.

void setLogLevel (int logLevel)
 Configure the log level.

void setDebugLevel (int debugLevel)
 Configure the debug messaging level.

void setAbortLevel (int abortLevel)
 Configure the abort log level.

void setLogInfo (int logLevel, unsigned int logInfo)
 Configure the printed log information for the given level. More...

void if_value (const std::string &expression, const std::shared_ptr< Path > &path, EAfterConditionPath afterConditionPath=EAfterConditionPath::c_End)
 Add a condition to the module. More...

void if_false (const std::shared_ptr< Path > &path, EAfterConditionPath afterConditionPath=EAfterConditionPath::c_End)
 A simplified version to add a condition to the module. More...

void if_true (const std::shared_ptr< Path > &path, EAfterConditionPath afterConditionPath=EAfterConditionPath::c_End)
 A simplified version to set the condition of the module. More...

bool hasCondition () const
 Returns true if at least one condition was set for the module.

const ModuleConditiongetCondition () const
 Return a pointer to the first condition (or nullptr, if none was set)

const std::vector< ModuleCondition > & getAllConditions () const
 Return all set conditions for this module.

bool evalCondition () const
 If at least one condition was set, it is evaluated and true returned if at least one condition returns true. More...

std::shared_ptr< PathgetConditionPath () const
 Returns the path of the last true condition (if there is at least one, else reaturn a null pointer). More...

Module::EAfterConditionPath getAfterConditionPath () const
 What to do after the conditional path is finished. More...

std::vector< std::shared_ptr< Path > > getAllConditionPaths () const
 Return all condition paths currently set (no matter if the condition is true or not).

bool hasProperties (unsigned int propertyFlags) const
 Returns true if all specified property flags are available in this module. More...

bool hasUnsetForcedParams () const
 Returns true and prints error message if the module has unset parameters which the user has to set in the steering file.

const ModuleParamListgetParamList () const
 Return module param list.

template<typename T >
ModuleParam< T > & getParam (const std::string &name) const
 Returns a reference to a parameter. More...

bool hasReturnValue () const
 Return true if this module has a valid return value set.

int getReturnValue () const
 Return the return value set by this module. More...

std::shared_ptr< PathElementclone () const override
 Create an independent copy of this module. More...

std::shared_ptr< boost::python::list > getParamInfoListPython () const
 Returns a python list of all parameters. More...


Static Public Member Functions

static const HistListgetHistList ()
 Get the list of the histograms. More...

static const MonObjListgetMonObjList ()
 Get the list of MonitoringObjects. More...

static TH1 * findHist (const std::string &histname)
 Find histogram. More...

static TH1 * findHist (const std::string &dirname, const std::string &histname)
 Find histogram. More...

static TH1 * findHist (const TDirectory *histdir, const TString &histname)
 Find histogram. More...

static MonitoringObjectfindMonitoringObject (const std::string &objName)
 Find MonitoringObject. More...

static void setIntValue (const std::string &parname, int vint)
 Set the integer value of the parameter. More...

static void setFloatValue (const std::string &parname, float vfloat)
 Set the float value of the parameter. More...

static void setText (const std::string &parname, const std::string &text)
 Set the string value of the parameter. More...

static void addHist (const std::string &dirname, const std::string &histname, TH1 *h)
 Add histogram. More...

static MonitoringObjectgetMonitoringObject (const std::string &histname)
 Get MonitoringObject with given name (new object is created if non-existing) More...

static void resetHist ()
 Clear and reset the list of histograms.

static HistListgetHists ()
 Get the list of histograms. More...

static ParamTypeListgetParNames ()
 Get the list of the names and types of the parameters. More...

static IntValueListgetIntValues ()
 Get the list of integer parameters. More...

static FloatValueListgetFloatValues ()
 Get the list of float parameters. More...

static TextListgetTexts ()
 Get the list of string parameters. More...

static void exposePythonAPI ()
 Exposes methods of the Module class to Python.


Protected Member Functions

virtual void def_initialize ()
 Wrappers to make the methods without "def_" prefix callable from Python. More...

virtual void def_beginRun ()
 Wrapper method for the virtual function beginRun() that has the implementation to be used in a call from Python.

virtual void def_event ()
 Wrapper method for the virtual function event() that has the implementation to be used in a call from Python.

virtual void def_endRun ()
 This method can receive that the current run ends as a call from the Python side. More...

virtual void def_terminate ()
 Wrapper method for the virtual function terminate() that has the implementation to be used in a call from Python.

void setDescription (const std::string &description)
 Sets the description of the module. More...

void setType (const std::string &type)
 Set the module type. More...

template<typename T >
void addParam (const std::string &name, T &paramVariable, const std::string &description, const T &defaultValue)
 Adds a new parameter to the module. More...

template<typename T >
void addParam (const std::string &name, T &paramVariable, const std::string &description)
 Adds a new enforced parameter to the module. More...

void setReturnValue (int value)
 Sets the return value for this module as integer. More...

void setReturnValue (bool value)
 Sets the return value for this module as bool. More...

void setParamList (const ModuleParamList &params)
 Replace existing parameter list.


Private Member Functions

void initialize (void) override final
 Module functions to be called from main process. More...

void beginRun (void) override final
 Module functions to be called from event process.

void event (void) override final
 This method is the core of the module. More...

void terminate (void) override final
 This method is called at the end of the event processing. More...

std::list< ModulePtrgetModules () const override
 no submodules, return empty list

std::string getPathString () const override
 return the module name.

void setParamPython (const std::string &name, const boost::python::object &pyObj)
 Implements a method for setting boost::python objects. More...

void setParamPythonDict (const boost::python::dict &dictionary)
 Implements a method for reading the parameter values from a boost::python dictionary. More...


Private Attributes

std::string m_histogramDirectoryName
 name of histogram directory

std::string m_pvPrefix
 prefix for EPICS PVs

int m_minEntries = 10000
 Update entry intervall.

double m_warnMeanAdhoc {}
 warn level for mean adhoc plot

double m_errorMeanAdhoc {}
 error level for mean adhoc plot

std::vector< VxdIDm_PXDModules
 IDs of all PXD Modules to iterate over.

TH2D * m_hCommonMode = nullptr
 histogram covering all modules

TH2D * m_hCommonModeDelta = nullptr
 histogram covering all modules

TH2D * m_hCommonModeOld = nullptr
 histogram covering all modules

TCanvas * m_cCommonMode = nullptr
 Final Canvas.

TCanvas * m_cCommonModeDelta = nullptr
 Final Canvas.

TLine * m_line1 = nullptr
 Line in the Canvas to guide the eye.

TLine * m_line2 = nullptr
 Line in the Canvas to guide the eye.

MonitoringObjectm_monObj {}
 Line in the Canvas to guide the eye. More...

bool m_useEpics
 flag if to export to EPICS

std::string m_name
 The name of the module, saved as a string (user-modifiable)

std::string m_type
 The type of the module, saved as a string.

std::string m_package
 Package this module is found in (may be empty).

std::string m_description
 The description of the module.

unsigned int m_propertyFlags
 The properties of the module as bitwise or (with |) of EModulePropFlags.

LogConfig m_logConfig
 The log system configuration of the module.

ModuleParamList m_moduleParamList
 List storing and managing all parameter of the module.

bool m_hasReturnValue
 True, if the return value is set.

int m_returnValue
 The return value.

std::vector< ModuleConditionm_conditions
 Module condition, only non-null if set.


Static Private Attributes

static ParamTypeList g_parname
 The list of module parameter types.

static IntValueList g_vint
 The list of integer module parameter.

static FloatValueList g_vfloat
 The list of float module parameter.

static TextList g_text
 The list of string module parameter.

static HistList g_hist
 The list of histograms.

static MonObjList g_monObj
 The list of MonitoringObjects.


Detailed Description

DQM Histogram Analysis for PXD Common Modes.

Definition at line 32 of file DQMHistAnalysisPXDCM.h.

Member Enumeration Documentation

◆ EModulePropFlags

enum EModulePropFlags
inherited

Each module can be tagged with property flags, which indicate certain features of the module.

Enumerator
c_Input

This module is an input module (reads data).

c_Output

This module is an output module (writes data).

c_ParallelProcessingCertified

This module can be run in parallel processing mode safely (All I/O must be done through the data store, in particular, the module must not write any files.)

c_HistogramManager

This module is used to manage histograms accumulated by other modules.

c_InternalSerializer

This module is an internal serializer/deserializer for parallel processing.

c_TerminateInAllProcesses

When using parallel processing, call this module's terminate() function in all processes().

This will also ensure that there is exactly one process (single-core if no parallel modules found) or at least one input, one main and one output process.

c_DontCollectStatistics

No statistics is collected for this module.

Definition at line 79 of file Module.h.

◆ EParamType

enum EParamType
inherited

The enumeration types for the module parameters.

Enumerator
c_ParamINT

The integer type for module parameter.

c_ParamFLOAT

The float type for module parameter.

c_ParamTEXT

The string type for module parameter.

Definition at line 33 of file DQMHistAnalysis.h.

Member Function Documentation

◆ addHist()

void addHist ( const std::string &  dirname,
const std::string &  histname,
TH1 *  h
)
staticinherited

Add histogram.

Parameters
dirnameThe name of the directory.
histnameThe name of the histogram.
hThe TH1 pointer for the histogram.

Definition at line 46 of file DQMHistAnalysis.cc.

◆ clone()

std::shared_ptr< PathElement > clone ( ) const
overridevirtualinherited

Create an independent copy of this module.

Note that parameters are shared, so changing them on a cloned module will also affect the original module.

Implements PathElement.

Definition at line 181 of file Module.cc.

◆ def_endRun()

virtual void def_endRun ( )
inlineprotectedvirtualinherited

This method can receive that the current run ends as a call from the Python side.

For regular C++-Modules that forwards the call to the regular endRun() method.

Reimplemented in PyModule.

Definition at line 441 of file Module.h.

◆ def_initialize()

virtual void def_initialize ( )
inlineprotectedvirtualinherited

Wrappers to make the methods without "def_" prefix callable from Python.

Overridden in PyModule. Wrapper method for the virtual function initialize() that has the implementation to be used in a call from Python.

Reimplemented in PyModule.

Definition at line 422 of file Module.h.

◆ endRun()

virtual void endRun ( )
inlinevirtualinherited

This method is called if the current run ends.

Use this method to store information, which should be aggregated over one run.

This method can be implemented by subclasses.

Reimplemented in DQMHistAnalysisPXDTrackChargeModule, DQMHistOutputToEPICSModule, DQMHistAnalysisRooFitExampleModule, DQMHistAnalysisPXDChargeModule, PyModule, DQMHistComparitorModule, TrackSetEvaluatorHopfieldNNDEVModule, DQMHistAnalysisInputRootFileModule, AlignDQMModule, SVDUnpackerDQMModule, DQMHistAnalysisPXDERModule, vxdDigitMaskingModule, DQMHistAnalysisEpicsExampleModule, DQMHistAnalysisPXDFitsModule, DQMHistAnalysisExampleFlagsModule, TRGCDCT3DUnpackerModule, TRGCDCTSFUnpackerModule, TRGGRLUnpackerModule, TRGCDCETFUnpackerModule, TOPUnpackerModule, FindletModule< AFindlet >, FindletModule< FacetCreator >, FindletModule< TrackFinderAutomaton >, FindletModule< CKFToCDCFromEclFindlet >, FindletModule< CKFToCDCFindlet >, FindletModule< CKFToSVDSeedFindlet >, FindletModule< AxialTrackCreatorMCTruth >, FindletModule< AxialStraightTrackFinder >, FindletModule< SegmentLinker >, FindletModule< TrackCreatorSegmentTripleAutomaton >, FindletModule< TrackCreatorSegmentPairAutomaton >, FindletModule< SegmentCreatorFacetAutomaton >, FindletModule< SegmentOrienter >, FindletModule< SegmentFinderFacetAutomaton >, FindletModule< CKFToSVDFindlet >, FindletModule< TrackFinderSegmentTripleAutomaton >, FindletModule< TrackRejecter >, FindletModule< SegmentCreatorMCTruth >, FindletModule< HitBasedT0Extractor >, FindletModule< TrackFinderCosmics >, FindletModule< SuperClusterCreator >, FindletModule< AsicBackgroundLibraryCreator >, FindletModule< TrackExporter >, FindletModule< ClusterPreparer >, FindletModule< CosmicsTrackMergerFindlet >, FindletModule< AxialTrackFinderHough >, FindletModule< TrackFinderSegmentPairAutomaton >, FindletModule< TrackLinker >, FindletModule< TrackOrienter >, FindletModule< TrackFinder >, FindletModule< AxialTrackFinderLegendre >, FindletModule< AxialTrackCreatorSegmentHough >, FindletModule< MonopoleAxialTrackFinderLegendre >, FindletModule< ClusterRefiner< BridgingWireHitRelationFilter > >, FindletModule< SegmentPairCreator >, FindletModule< HitReclaimer >, FindletModule< CKFToPXDFindlet >, FindletModule< TrackQualityEstimator >, FindletModule< StereoHitFinder >, FindletModule< TrackCreatorSingleSegments >, FindletModule< TrackFlightTimeAdjuster >, FindletModule< SegmentFitter >, FindletModule< SegmentRejecter >, FindletModule< WireHitPreparer >, FindletModule< SegmentTripleCreator >, FindletModule< SegmentTrackCombiner >, FindletModule< MCVXDCDCTrackMergerFindlet >, FindletModule< MonopoleStereoHitFinder >, FindletModule< TrackCombiner >, FindletModule< AxialSegmentPairCreator >, FindletModule< WireHitBackgroundDetector >, FindletModule< ClusterBackgroundDetector >, FindletModule< CDCTrackingEventLevelMdstInfoFillerFindlet >, FindletModule< MonopoleStereoHitFinderQuadratic >, FindletModule< TrackQualityAsserter >, FindletModule< WireHitCreator >, ECLWaveformFitModule, B2BIIConvertMdstModule, TOPTimeBaseCalibratorModule, TOPTBCComparatorModule, ECLChargedPIDModule, SVDBackgroundModule, ARICHNtupleModule, ECLDigitizerModule, BeamBkgTagSetterModule, TOPGainEfficiencyCalculatorModule, ECLShowerShapeModule, KLMClustersReconstructorModule, OpticalGunModule, ParticleKinematicFitterModule, PXDBackgroundModule, CDCDedxValidationModule, ARICHDigitizerModule, TOPDQMModule, CDCDQMModule, KLMDQMModule, TOPLaserHitSelectorModule, TOPModuleT0CalibratorModule, DQMHistAnalysisTRGGDLModule, BKLMDigitAnalyzerModule, TOPChannelT0CalibratorModule, TOPCommonT0CalibratorModule, KLMUnpackerModule, TOPRawDigitConverterModule, TOPReconstructorModule, ARICHFillHitsModule, DQMHistAnalysisCDCMonObjModule, DQMHistAnalysisKLMModule, KLMReconstructorModule, CDCCRTestModule, KLMDigitizerModule, ECLDigitizerPureCsIModule, EKLMDataCheckerModule, ARICHReconstructorModule, ECLLocalRunCalibratorModule, KLMPackerModule, MdstPIDModule, FullSimModule, ARICHDQMModule, DQMHistAnalysisARICHModule, ECLCRFinderModule, TOPAlignerModule, TOPPDFDebuggerModule, ARICHPackerModule, BelleMCOutputModule, BeamBkgMixerModule, CDCPackerModule, TOPBackgroundModule, TOPPDFCheckerModule, ARICHRelateModule, BeamBkgHitRateMonitorModule, CsIDigitizerModule, DQMHistAnalysisMiraBelleModule, ARICHUnpackerModule, CDCUnpackerModule, ARICHMCParticlesModule, ARICHRateCalModule, CDCCosmicAnalysisModule, ECLShowerCorrectorModule, SVDCoGTimeEstimatorModule, SVDUnpackerModule, SVDROIFinderAnalysisModule, ECLDataAnalysisModule, EclDisplayModule, TOPDoublePulseGeneratorModule, TOPWaveformQualityPlotterModule, BGOverlayExecutorModule, ECLChargedPIDDataAnalysisValidationModule, ECLDigitCalibratorModule, ECLSplitterN1Module, EvtGenDecayModule, EKLMADCModule, SVDROIFinderModule, TRGGDLUnpackerModule, ARICHRawUnpackerModule, NtuplePhase1_v6Module, ECLDQMModule, TOPCalPulseGeneratorModule, TOPNtupleModule, TOPPackerModule, TOPWaveformFeatureExtractorModule, TrackFinderMCTruthRecoTracksModule, VXDTFTrainingDataCollectorModule, BeamBkgGeneratorModule, EventInfoPrinterModule, BKLMSimHistogrammerModule, KLMClusterEfficiencyModule, PXDPerformanceModule, TOPInterimFENtupleModule, TOPMCTrackMakerModule, VXDSimpleClusterizerModule, BGOverlayInputModule, TpcDigitizerModule, PIDNtupleModule, SPTCvirtualIPRemoverModule, arichBtestModule, ReprocessorModule, CsIStudyModule, ECLChargedPIDDataAnalysisModule, OverrideGenerationFlagsModule, MCMatcherKLMClustersModule, PrintDataModule, SPTCmomentumSeedRetrieverModule, TrackFinderVXDAnalizerModule, TRGGRLMatchModule, DQMHistAnalysisARICHMonObjModule, ECLLocalMaximumFinderModule, CDCDedxDQMModule, FANGSDigitizerModule, CDCRecoTrackFilterModule, ECLClusterPSDModule, SVDLocalCalibrationsMonitorModule, TOPTriggerDigitizerModule, ExtModule, MCTrackCandClassifierModule, MuidModule, HLTDQM2ZMQModule, DQMHistAnalysisECLModule, IPDQMExpressRecoModule, BKLMTrackingModule, TOPCosmicT0FinderModule, HitXPModule, TRGCDCT3DConverterModule, DQMHistAnalysisMonObjModule, ECLBackgroundModule, EventT0DQMModule, SVDDataFormatCheckModule, TRGTOPDQMModule, BgoStudyModule, CsiStudy_v2Module, MicrotpcStudyModule, PlumeDigitizerModule, DQMHistAnalysisCDCDedxModule, DQMHistAnalysisHLTMonObjModule, PXDClustersFromTracksModule, SVDPackerModule, SVDClusterEvaluationTrueInfoModule, TOPXTalkChargeShareSetterModule, SecMapTrainerVXDTFModule, AnalysisPhase1StudyModule, DosiStudyModule, He3tubeStudyModule, ECLCovarianceMatrixModule, ECLDQMEXTENDEDModule, ECLFinalizerModule, ECLSplitterN2Module, MCMatcherECLClustersModule, BKLMAnaModule, SVDHotStripFinderModule, SVDPerformanceModule, SecMapTrainerBaseModule, NoKickCutsEvalModule, TRGECLRawdataAnalysisModule, TRGTOPUnpackerModule, BgoDigitizerModule, CsiDigitizer_v2Module, DosiDigitizerModule, TPCStudyModule, PinDigitizerModule, HLTDs2ZMQModule, DQMHistAnalysisInputPVSrvModule, ECLShowerCalibratorModule, SVDLatencyCalibrationModule, SVDOccupancyAnalysisModule, TOPLaserCalibratorModule, PXDROIFinderModule, KlongValidationModule, TrackingPerformanceEvaluationModule, MCMatcherTRGECLModule, BeamabortStudyModule, ClawStudyModule, ClawsStudyModule, PindiodeStudyModule, QcsmonitorStudyModule, ECLHitDebugModule, SVDClusterCalibrationsMonitorModule, TOPChannelT0MCModule, EffPlotsModule, CurlTaggerModule, BeamDigitizerModule, He3DigitizerModule, ECLUnpackerModule, StatisticsSummaryModule, DataWriterModule, SVDB4CommissioningPlotsModule, SVDClusterEvaluationModule, SVDClusterFilterModule, SVDShaperDigitsFromTracksModule, SVD3SamplesEmulatorModule, RT2SPTCConverterModule, SVDROIDQMModule, TRGGDLModule, EventKinematicsModule, ClawDigitizerModule, ClawsDigitizerModule, DQMHistSnapshotsModule, ECLPackerModule, PrintEventRateModule, SVDCoGTimeCalibrationsMonitorModule, V0findingPerformanceEvaluationModule, TRGECLModule, CosmicsAlignmentValidationModule, FANGSStudyModule, QcsmonitorDigitizerModule, SectorMapBootstrapModule, CsiModule, DQMHistDeltaHistoModule, RandomBarrierModule, TRGGRLModule, GenfitVisModule, CDCTriggerNeuroDQMModule, TRGECLFAMModule, TRGGRLProjectsModule, B2BIIMdstInputModule, DQMHistAnalysisTOPModule, SubEventModule, TRGCDCModule, DQMHistAnalysisSVDOnMiraBelleModule, TRGCDCTSStreamModule, Convert2RawDetModule, DQMHistAnalysisOutputMonObjModule, TRGECLQAMModule, TRGECLTimingCalModule, MCV0MatcherModule, DQMHistAnalysisInputModule, cdcDQM7Module, SwitchDataStoreModule, PhysicsObjectsMiraBelleModule, HistoModule, TRGGRLDQMModule, KLMTriggerModule, DQMHistAnalysisEventT0Module, DQMHistAnalysisInputSrvModule, SeqRootOutputModule, TRGGDLDQMModule, DQMHistAnalysisSVDGeneralModule, PhysicsObjectsMiraBelleDst2Module, PhysicsObjectsMiraBelleDstModule, TxModule, B2BIIMCParticlesMonitorModule, DQMHistAnalysisOutputNSMModule, DQMHistAnalysisPlotOnlyModule, DQMHistAnalysisSVDEfficiencyModule, RxModule, Root2BinaryModule, DQMHistAnalysisExampleModule, DQMHistAnalysisOutputRelayMsgModule, svdDumpModule, TRGECLDQMModule, DQMHistAnalysisOutputFileModule, TRGCDCT2DDQMModule, DQMHistAnalysisOutputModule, SeqRootInputModule, TRGCDCT3DDQMModule, TRGGDLSummaryModule, HistoManagerModule, TRGCDCTSFDQMModule, TRGGDLDSTModule, PhysicsObjectsDQMModule, CalibrationCollectorModule, ARICHBackgroundModule, TRGECLUnpackerModule, EvReductionModule, Raw2DsModule, RawInputModule, StorageDeserializerModule, BeamabortModule, BgoModule, CaveModule, ClawModule, CLAWSModule, DosiModule, FANGSModule, He3tubeModule, MicrotpcModule, Ph1bpipeModule, Ph1sustrModule, PindiodeModule, PlumeModule, QcsmonitorModule, SrsensorModule, SerializerModule, FastRbuf2DsModule, Ds2SampleModule, DeSerializerPXDModule, Rbuf2RbufModule, GenRawSendModule, Rbuf2DsModule, TxSocketModule, Ds2RawModule, Ds2RawFileModule, DqmHistoManagerModule, Ds2RbufModule, StorageSerializerModule, GetEventFromSocketModule, ReceiveEventModule, ElapsedTimeModule, MonitorDataCOPPERModule, Root2RawModule, RxSocketModule, CertifyParallelModule, SeqRootMergerModule, DAQPerfModule, MonitorDataModule, TrackAnaModule, and PartialSeqRootReaderModule.

Definition at line 168 of file Module.h.

◆ evalCondition()

bool evalCondition ( ) const
inherited

If at least one condition was set, it is evaluated and true returned if at least one condition returns true.

If no condition or result value was defined, the method returns false. Otherwise, the condition is evaluated and true returned, if at least one condition returns true. To speed up the evaluation, the condition strings were already parsed in the method if_value().

Returns
True if at least one condition and return value exists and at least one condition expression was evaluated to true.

Definition at line 98 of file Module.cc.

◆ event()

void event ( void  )
finaloverrideprivatevirtual

This method is the core of the module.

This method is called for each event. All processing of the event has to take place in this method.

This method can be implemented by subclasses.

TODO: integration intervalls depend on CM default value, this seems to be agreed =10

TODO level might need adjustment

TODO level might need adjustment

FIXME: absolute numbers or relative numbers and what is the acceptable limit?

FIXME: absolute numbers or relative numbers and what is the acceptable limit?

Reimplemented from Module.

Definition at line 146 of file DQMHistAnalysisPXDCM.cc.

147 {
148  double all_outside = 0.0, all = 0.0;
149  double all_cm = 0.0;
150  bool error_flag = false;
151  bool warn_flag = false;
152  bool error_adhoc_flag = false;
153  bool warn_adhoc_flag = false;
154  bool anyupdate = false;
155  if (!m_cCommonMode) return;
156  m_hCommonMode->Reset(); // dont sum up!!!
157
158  for (unsigned int i = 0; i < m_PXDModules.size(); i++) {
159  std::string name = "PXDDAQCM2_" + (std::string)m_PXDModules[i ];
160  // std::replace( name.begin(), name.end(), '.', '_');
161
162  TH1* hh1 = findHist(name);
163  if (hh1 == NULL) {
164  hh1 = findHist(m_histogramDirectoryName, name);
165  }
166  if (hh1) {
167  double current_full = 0.0;
168  double outside_full = 0.0;
169
170  auto nevent = hh1->GetBinContent(0); // misuse underflow as event counter
171  bool update = nevent - m_hCommonModeOld->GetBinContent(i + 1, 0) > m_minEntries ;
172  anyupdate |= update;
173  if (update) m_hCommonModeOld->SetBinContent(i + 1, 0, nevent);
174  for (int bin = 1; bin <= 63; bin++) { // we ignore CM63!!!
175  double v;
176  v = hh1->GetBinContent(bin);
177  m_hCommonMode->SetBinContent(i + 1, bin, v); // attention, mixing bin nr and index
178  current_full += v;
179  if (nevent < m_minEntries) {
180  m_hCommonModeDelta->SetBinContent(i + 1, bin, v); // attention, mixing bin nr and index
181  } else if (update) {
182  auto old = m_hCommonModeOld->GetBinContent(i + 1, bin); // attention, mixing bin nr and index
183  m_hCommonModeDelta->SetBinContent(i + 1, bin, v - old); // attention, mixing bin nr and index
184  m_hCommonModeOld->SetBinContent(i + 1, bin, v); // attention, mixing bin nr and index
185  }
186  }
187
189  // Attention, Integral uses the bin nr, not the value!
190  outside_full += hh1->Integral(16, 63);
191  // FIXME currently we have to much noise below the line ... thus excluding this to avoid false alarms
192  // outside_full += hh1->Integral(1 /*0*/, 5); /// FIXME we exclude bin 0 as we use it for debugging/timing pixels
193  all_outside += outside_full;
194  all += current_full;
195  double dhpc = hh1->GetBinContent(64);
196  all_cm += dhpc;
197  if (current_full > 1) {
198  error_flag |= (outside_full / current_full > 1e-5);
199  warn_flag |= (outside_full / current_full > 1e-6);
200 // error_flag |= (dhpc / current_full > 1e-5); // DHP Fifo overflow ... might be critical/unrecoverable
201 // warn_flag |= (dhpc / current_full > 1e-6); // DHP Fifo overflow ... might be critical/unrecoverable
202  }
203
204  if (update) {
205  Double_t mean_adhoc = 0.;
206  Double_t entries_adhoc = 0.;
207  Double_t outside_adhoc = 0.;
208  // Attention, Bins
209  for (int cm_y = 0; cm_y < 16; cm_y++) {
210  auto v = m_hCommonModeDelta->GetBinContent(m_hCommonModeDelta->GetBin(i + 1, cm_y + 1));
211  entries_adhoc += v;
212  mean_adhoc += v * (cm_y + 1);
213  }
214  // Attention, Bins
215  for (int cm_y = 16; cm_y < 64; cm_y++) {
216  auto v = m_hCommonModeDelta->GetBinContent(m_hCommonModeDelta->GetBin(i + 1, cm_y + 1));
217  entries_adhoc += v;
218  outside_adhoc += v;
219  }
220  if (entries_adhoc > 0) { // ignore 1.3.2
221  mean_adhoc /= entries_adhoc; // calculate mean
222  warn_adhoc_flag |= entries_adhoc > 1000 && fabs(10.0 - mean_adhoc) > m_warnMeanAdhoc;
223  error_adhoc_flag |= entries_adhoc > 1000 && fabs(10.0 - mean_adhoc) > m_errorMeanAdhoc;
224  m_monObj->setVariable(("cm_" + (std::string)m_PXDModules[i]).c_str(), mean_adhoc);
225 #ifdef _BELLE2_EPICS
226  if (m_useEpics) {
227  auto my = mychid_mean[m_PXDModules[i]];
228  // B2ERROR("Mean "<< name << " " << mean_adhoc << " " << outside_adhoc << " " << entries_adhoc << " " <<warn_adhoc_flag <<error_adhoc_flag );
229  if (my) SEVCHK(ca_put(DBR_DOUBLE, my, (void*)&mean_adhoc), "ca_set failure");
230  }
231 #endif
232  }
233  }
234  }
235  }
236
237  int status = 0;
238  {
239  m_cCommonMode->cd();
240  // not enough Entries
241  if (all < 100.) {
242  m_cCommonMode->Pad()->SetFillColor(kGray);// Magenta or Gray
243  status = 0; // default
244  } else {
246  if (all_outside / all > 1e-5 || /*all_cm / all > 1e-5 ||*/ error_flag) {
247  m_cCommonMode->Pad()->SetFillColor(kRed);// Red
248  status = 4;
249  } else if (all_outside / all > 1e-6 || /*all_cm / all > 1e-6 ||*/ warn_flag) {
250  m_cCommonMode->Pad()->SetFillColor(kYellow);// Yellow
251  status = 3;
252  } else if (all_outside == 0. /*&& all_cm == 0.*/) {
253  m_cCommonMode->Pad()->SetFillColor(kGreen);// Green
254  status = 2;
255  } else { // between 0 and 50 ...
256  m_cCommonMode->Pad()->SetFillColor(kWhite);// White
257  status = 1;
258  }
259  }
260
261  if (m_hCommonMode) {
262  m_hCommonMode->Draw("colz");
263  m_line1->Draw();
264  m_line2->Draw();
265 // m_line3->Draw();
266  }
267
268  auto tt = new TLatex(5.5, 3, "1.3.2 Module is excluded, please ignore");
269  tt->SetTextAngle(90);// Rotated
270  tt->SetTextAlign(12);// Centered
271  tt->Draw();
272
273  m_cCommonMode->Modified();
274  m_cCommonMode->Update();
275  }
276
277  {
278  int status_adhoc = 0;
279  m_cCommonModeDelta->cd();
280  // not enough Entries
281
282  if (all < 100.) { // delta cannot be more than all
283  m_cCommonModeDelta->Pad()->SetFillColor(kGray);// Magenta or Gray
284  status_adhoc = 0; // default
285  } else {
287  if (error_adhoc_flag) {
288  m_cCommonModeDelta->Pad()->SetFillColor(kRed);// Red
289  status_adhoc = 4;
290  } else if (warn_adhoc_flag) {
291  m_cCommonModeDelta->Pad()->SetFillColor(kYellow);// Yellow
292  status_adhoc = 3;
293  } else {
294  m_cCommonModeDelta->Pad()->SetFillColor(kGreen);// Green
295  status_adhoc = 2;
296  /* } else { // between 0 and 50 ...
297  m_cCommonModeDelta->Pad()->SetFillColor(kWhite);// White
298  status_adhoc = 1;*/
299  }
300  }
301 #ifdef _BELLE2_EPICS
302  if (m_useEpics && anyupdate) SEVCHK(ca_put(DBR_INT, mychid[3], (void*)&status_adhoc), "ca_set failure");
303 #endif
304  if (m_hCommonModeDelta) {
305  m_hCommonModeDelta->Draw("colz");
306  m_line1->Draw();
307  m_line2->Draw();
308 // m_line3->Draw();
309  }
310
311  auto tt = new TLatex(5.5, 3, "1.3.2 Module is excluded, please ignore");
312  tt->SetTextAngle(90);// Rotated
313  tt->SetTextAlign(12);// Centered
314  tt->Draw();
315
316  m_cCommonModeDelta->Modified();
317  m_cCommonModeDelta->Update();
318  }
319
320 #ifdef _BELLE2_EPICS
321  if (m_useEpics) {
322  double data = all > 0 ? (all_outside / all) : 0;
323  double data2 = all > 0 ? (all_cm / all) : 0;
324  SEVCHK(ca_put(DBR_DOUBLE, mychid[0], (void*)&data), "ca_set failure");
325  SEVCHK(ca_put(DBR_INT, mychid[1], (void*)&status), "ca_set failure");
326  SEVCHK(ca_put(DBR_DOUBLE, mychid[2], (void*)&data2), "ca_set failure");
327  SEVCHK(ca_pend_io(5.0), "ca_pend_io failure");
328  }
329 #endif
330 }

◆ findHist() [1/3]

TH1 * findHist ( const std::string &  dirname,
const std::string &  histname
)
staticinherited

Find histogram.

Parameters
dirnameThe name of the directory.
histnameThe name of the histogram.
Returns
The found histogram, or nullptr if not found.

Definition at line 130 of file DQMHistAnalysis.cc.

◆ findHist() [2/3]

TH1 * findHist ( const std::string &  histname)
staticinherited

Find histogram.

Parameters
histnameThe name of the histogram.
Returns
The found histogram, or nullptr if not found.

Definition at line 83 of file DQMHistAnalysis.cc.

◆ findHist() [3/3]

TH1 * findHist ( const TDirectory *  histdir,
const TString &  histname
)
staticinherited

Find histogram.

Parameters
histdirThe TDirectory of the directory.
histnameThe name of the histogram.
Returns
The found histogram, or nullptr if not found.

Definition at line 139 of file DQMHistAnalysis.cc.

◆ findMonitoringObject()

MonitoringObject * findMonitoringObject ( const std::string &  objName)
staticinherited

Find MonitoringObject.

Parameters
objNameThe name of the MonitoringObject.
Returns
The found MonitoringObject, or nullptr if not found.

Definition at line 153 of file DQMHistAnalysis.cc.

◆ getAfterConditionPath()

Module::EAfterConditionPath getAfterConditionPath ( ) const
inherited

What to do after the conditional path is finished.

(defaults to c_End if no condition is set)

Definition at line 135 of file Module.cc.

◆ getConditionPath()

std::shared_ptr< Path > getConditionPath ( ) const
inherited

Returns the path of the last true condition (if there is at least one, else reaturn a null pointer).


Definition at line 115 of file Module.cc.

◆ getFileNames()

virtual std::vector<std::string> getFileNames ( __attribute__((unused)) bool  outputFiles)
inlinevirtualinherited

Return a list of output filenames for this modules.

This will be called when basf2 is run with "--dry-run" if the module has set either the c_Input or c_Output properties.

If the parameter outputFiles is false (for modules with c_Input) the list of input filenames should be returned (if any). If outputFiles is true (for modules with c_Output) the list of output files should be returned (if any).

If a module has sat both properties this member is called twice, once for each property.

The module should return the actual list of requested input or produced output filenames (including handling of input/output overrides) so that the grid system can handle input/output files correctly.

This function should return the same value when called multiple times. This is especially important when taking the input/output overrides from Environment as they get consumed when obtained so the finalized list of output files should be stored for subsequent calls.

Definition at line 136 of file Module.h.

◆ getFloatValues()

static FloatValueList& getFloatValues ( )
inlinestaticinherited

Get the list of float parameters.

Returns
The list of float parameters.

Definition at line 199 of file DQMHistAnalysis.h.

◆ getHistList()

const DQMHistAnalysisModule::HistList & getHistList ( )
staticinherited

Get the list of the histograms.

Returns
The list of the histograms.

Definition at line 72 of file DQMHistAnalysis.cc.

◆ getHists()

static HistList& getHists ( )
inlinestaticinherited

Get the list of histograms.

Returns
The list of histograms.

Definition at line 184 of file DQMHistAnalysis.h.

◆ getIntValues()

static IntValueList& getIntValues ( )
inlinestaticinherited

Get the list of integer parameters.

Returns
The list of integer parameters.

Definition at line 194 of file DQMHistAnalysis.h.

◆ getMonitoringObject()

MonitoringObject * getMonitoringObject ( const std::string &  histname)
staticinherited

Get MonitoringObject with given name (new object is created if non-existing)

Parameters
objNamename of MonitoringObject to get

Definition at line 55 of file DQMHistAnalysis.cc.

◆ getMonObjList()

const DQMHistAnalysisModule::MonObjList & getMonObjList ( )
staticinherited

Get the list of MonitoringObjects.

Returns
The list of the MonitoringObjects.

Definition at line 77 of file DQMHistAnalysis.cc.

◆ getName()

const std::string& getName ( ) const
inlineinherited

Returns the name of the module.

This can be changed via e.g. set_name() in the steering file to give more useful names if there is more than one module of the same type.

For identifying the type of a module, using getType() (or type() in Python) is recommended.

Definition at line 189 of file Module.h.

◆ getParamInfoListPython()

std::shared_ptr< boost::python::list > getParamInfoListPython ( ) const
inherited

Returns a python list of all parameters.

Each item in the list consists of the name of the parameter, a string describing its type, a python list of all default values and the description of the parameter.

Returns
A python list containing the parameters of this parameter list.

Definition at line 281 of file Module.cc.

◆ getParNames()

static ParamTypeList& getParNames ( )
inlinestaticinherited

Get the list of the names and types of the parameters.

Returns
The list of the names and types of the parameters.

Definition at line 189 of file DQMHistAnalysis.h.

◆ getReturnValue()

int getReturnValue ( ) const
inlineinherited

Return the return value set by this module.

This value is only meaningful if hasReturnValue() is true

Definition at line 383 of file Module.h.

◆ getTexts()

static TextList& getTexts ( )
inlinestaticinherited

Get the list of string parameters.

Returns
The list of string parameters.

Definition at line 204 of file DQMHistAnalysis.h.

◆ getType()

const std::string & getType ( ) const
inherited

Returns the type of the module (i.e.

class name minus 'Module')

Definition at line 43 of file Module.cc.

◆ hasProperties()

bool hasProperties ( unsigned int  propertyFlags) const
inherited

Returns true if all specified property flags are available in this module.

Parameters
propertyFlagsOred EModulePropFlags which should be compared with the module flags.

Definition at line 162 of file Module.cc.

◆ if_false()

void if_false ( const std::shared_ptr< Path > &  path,
EAfterConditionPath  afterConditionPath = EAfterConditionPath::c_End
)
inherited

A simplified version to add a condition to the module.

Please note that successive calls of this function will add more than one condition to the module. If more than one condition results in true, only the last of them will be used.

Please be careful: Avoid creating cyclic paths, e.g. by linking a condition to a path which is processed before the path where this module is located in.

It is equivalent to the if_value() method, using the expression "<1". This method is meant to be used together with the setReturnValue(bool value) method.

Parameters
pathShared pointer to the Path which will be executed if the return value is false.
afterConditionPathWhat to do after executing 'path'.

Definition at line 87 of file Module.cc.

◆ if_true()

void if_true ( const std::shared_ptr< Path > &  path,
EAfterConditionPath  afterConditionPath = EAfterConditionPath::c_End
)
inherited

A simplified version to set the condition of the module.

Please note that successive calls of this function will add more than one condition to the module. If more than one condition results in true, only the last of them will be used.

Please be careful: Avoid creating cyclic paths, e.g. by linking a condition to a path which is processed before the path where this module is located in.

It is equivalent to the if_value() method, using the expression ">=1". This method is meant to be used together with the setReturnValue(bool value) method.

Parameters
pathShared pointer to the Path which will be executed if the return value is true.
afterConditionPathWhat to do after executing 'path'.

Definition at line 92 of file Module.cc.

◆ if_value()

void if_value ( const std::string &  expression,
const std::shared_ptr< Path > &  path,
EAfterConditionPath  afterConditionPath = EAfterConditionPath::c_End
)
inherited

Add a condition to the module.

Please note that successive calls of this function will add more than one condition to the module. If more than one condition results in true, only the last of them will be used.

See https://confluence.desy.de/display/BI/Software+ModCondTut or ModuleCondition for a description of the syntax.

Please be careful: Avoid creating cyclic paths, e.g. by linking a condition to a path which is processed before the path where this module is located in.

Parameters
expressionThe expression of the condition.
pathShared pointer to the Path which will be executed if the condition is evaluated to true.
afterConditionPathWhat to do after executing 'path'.

Definition at line 81 of file Module.cc.

◆ initialize()

void initialize ( void  )
finaloverrideprivatevirtual

Module functions to be called from main process.

FIXME were to put the lines depends ...

Reimplemented from Module.

Definition at line 51 of file DQMHistAnalysisPXDCM.cc.

◆ setDescription()

void setDescription ( const std::string &  description)
protectedinherited

Sets the description of the module.

Parameters
descriptionA description of the module.

Definition at line 216 of file Module.cc.

◆ setFloatValue()

void setFloatValue ( const std::string &  parname,
float  vfloat
)
staticinherited

Set the float value of the parameter.

Parameters
parnameThe name of the parameter.
vfloatThe value to be set.

Definition at line 181 of file DQMHistAnalysis.cc.

◆ setIntValue()

void setIntValue ( const std::string &  parname,
int  vint
)
staticinherited

Set the integer value of the parameter.

Parameters
parnameThe name of the parameter.
vintThe value to be set.

Definition at line 169 of file DQMHistAnalysis.cc.

◆ setLogInfo()

void setLogInfo ( int  logLevel,
unsigned int  logInfo
)
inherited

Configure the printed log information for the given level.

Parameters
logLevelThe log level (one of LogConfig::ELogLevel)
logInfoWhat kind of info should be printed? ORed combination of LogConfig::ELogInfo flags.

Definition at line 75 of file Module.cc.

◆ setName()

void setName ( const std::string &  name)
inlineinherited

Set the name of the module.

Note
The module name is set when using the REG_MODULE macro, but the module can be renamed before calling process() using the set_name() function in your steering file.
Parameters
nameThe name of the module

Definition at line 216 of file Module.h.

◆ setParamPython()

void setParamPython ( const std::string &  name,
const boost::python::object &  pyObj
)
privateinherited

Implements a method for setting boost::python objects.

The method supports the following types: list, dict, int, double, string, bool The conversion of the python object to the C++ type and the final storage of the parameter value is done in the ModuleParam class.

Parameters
nameThe unique name of the parameter.
pyObjThe object which should be converted and stored as the parameter value.

Definition at line 236 of file Module.cc.

◆ setParamPythonDict()

void setParamPythonDict ( const boost::python::dict &  dictionary)
privateinherited

Implements a method for reading the parameter values from a boost::python dictionary.

The key of the dictionary has to be the name of the parameter and the value has to be of one of the supported parameter types.

Parameters
dictionaryThe python dictionary from which the parameter values are read.

Definition at line 251 of file Module.cc.

◆ setPropertyFlags()

void setPropertyFlags ( unsigned int  propertyFlags)
inherited

Sets the flags for the module properties.

Parameters
propertyFlagsbitwise OR of EModulePropFlags

Definition at line 210 of file Module.cc.

◆ setReturnValue() [1/2]

void setReturnValue ( bool  value)
protectedinherited

Sets the return value for this module as bool.

The bool value is saved as an integer with the convention 1 meaning true and 0 meaning false. The value can be used in the steering file to divide the analysis chain into several paths.

Parameters
valueThe value of the return value.

Definition at line 229 of file Module.cc.

◆ setReturnValue() [2/2]

void setReturnValue ( int  value)
protectedinherited

Sets the return value for this module as integer.

The value can be used in the steering file to divide the analysis chain into several paths.

Parameters
valueThe value of the return value.

Definition at line 222 of file Module.cc.

◆ setText()

void setText ( const std::string &  parname,
const std::string &  text
)
staticinherited

Set the string value of the parameter.

Parameters
parnameThe name of the parameter.
textThe value to be set.

Definition at line 193 of file DQMHistAnalysis.cc.

◆ setType()

void setType ( const std::string &  type)
protectedinherited

Set the module type.

Only for use by internal modules (which don't use the normal REG_MODULE mechanism).

Definition at line 50 of file Module.cc.

◆ terminate()

void terminate ( void  )
finaloverrideprivatevirtual

This method is called at the end of the event processing.

This method is called only once after the event processing finished. Use this method for cleaning up, closing files, etc.

This method can be implemented by subclasses.

Reimplemented from Module.

Definition at line 332 of file DQMHistAnalysisPXDCM.cc.

Member Data Documentation

◆ m_monObj

MonitoringObject* m_monObj {}
private

Line in the Canvas to guide the eye.

Monitoring Object

Definition at line 84 of file DQMHistAnalysisPXDCM.h.


The documentation for this class was generated from the following files:
prepareAsicCrosstalkSimDB.e
e
aux.
Definition: prepareAsicCrosstalkSimDB.py:53
Belle2::DQMHistAnalysisPXDCMModule::m_warnMeanAdhoc
double m_warnMeanAdhoc
warn level for mean adhoc plot
Definition: DQMHistAnalysisPXDCM.h:59
Belle2::DQMHistAnalysisPXDCMModule::m_minEntries
int m_minEntries
Update entry intervall.
Definition: DQMHistAnalysisPXDCM.h:57
Belle2::DQMHistAnalysisPXDCMModule::m_hCommonModeOld
TH2D * m_hCommonModeOld
histogram covering all modules
Definition: DQMHistAnalysisPXDCM.h:71
Belle2::DQMHistAnalysisPXDCMModule::m_hCommonMode
TH2D * m_hCommonMode
histogram covering all modules
Definition: DQMHistAnalysisPXDCM.h:67
Belle2::DQMHistAnalysisModule::findHist
static TH1 * findHist(const std::string &histname)
Find histogram.
Definition: DQMHistAnalysis.cc:83
Belle2::DQMHistAnalysisPXDCMModule::m_hCommonModeDelta
TH2D * m_hCommonModeDelta
histogram covering all modules
Definition: DQMHistAnalysisPXDCM.h:69
Belle2::DQMHistAnalysisPXDCMModule::m_cCommonMode
TCanvas * m_cCommonMode
Final Canvas.
Definition: DQMHistAnalysisPXDCM.h:73
Belle2::DQMHistAnalysisPXDCMModule::m_errorMeanAdhoc
double m_errorMeanAdhoc
error level for mean adhoc plot
Definition: DQMHistAnalysisPXDCM.h:61
Belle2::DQMHistAnalysisPXDCMModule::m_monObj
MonitoringObject * m_monObj
Line in the Canvas to guide the eye.
Definition: DQMHistAnalysisPXDCM.h:84
Belle2::DQMHistAnalysisPXDCMModule::m_histogramDirectoryName
std::string m_histogramDirectoryName
name of histogram directory
Definition: DQMHistAnalysisPXDCM.h:53
Belle2::MonitoringObject::setVariable
void setVariable(const std::string &var, float val, float upErr=-1., float dwErr=-1)
set value to float variable (new variable is made if not yet existing)
Definition: MonitoringObject.h:134
Belle2::DQMHistAnalysisPXDCMModule::m_useEpics
bool m_useEpics
flag if to export to EPICS
Definition: DQMHistAnalysisPXDCM.h:87
Belle2::DQMHistAnalysisPXDCMModule::m_PXDModules
std::vector< VxdID > m_PXDModules
IDs of all PXD Modules to iterate over.
Definition: DQMHistAnalysisPXDCM.h:64
Belle2::DQMHistAnalysisPXDCMModule::m_line1
TLine * m_line1
Line in the Canvas to guide the eye.
Definition: DQMHistAnalysisPXDCM.h:77
Belle2::DQMHistAnalysisPXDCMModule::m_line2
TLine * m_line2
Line in the Canvas to guide the eye.
Definition: DQMHistAnalysisPXDCM.h:79
Belle2::DQMHistAnalysisPXDCMModule::m_cCommonModeDelta
TCanvas * m_cCommonModeDelta
Final Canvas.
Definition: DQMHistAnalysisPXDCM.h:75
