Class to store the likelihoods from KLM with additional informations related to the extrapolation. More...

#include <KLMMuidLikelihood.h>

Inheritance diagram for KLMMuidLikelihood:

Collaboration diagram for KLMMuidLikelihood:

[legend]

Public Member Functions
	KLMMuidLikelihood ()
	Constructor.

	~KLMMuidLikelihood ()
	Destructor.

int	getPDGCode () const
	Get the PDG code of the particle hypothesis used during the extrapolation.

int	getCharge () const
	Get the charge of the particle hypothesis used during the extrapolation.

double	getPDFValue (int pdg) const
	Get the normalized PDF. More...

double	getMuonPDFValue () const
	Get the normalized PDF for the muon hypothesis.

double	getPionPDFValue () const
	Get the normalized PDF for the pion hypothesis.

double	getKaonPDFValue () const
	Get the normalized PDF for the kaon hypothesis.

double	getProtonPDFValue () const
	Get the normalized PDF for the proton hypothesis.

double	getDeuteronPDFValue () const
	Get the normalized PDF for the deuteron hypothesis.

double	getElectronPDFValue () const
	Get the normalized PDF for the electron hypothesis.

bool	getJunkPDFValue () const
	Get the junk flag (1 if junk, 0 if not).

double	getLogL (int pdg) const
	Get the log-likelihood. More...

double	getLogL_mu () const
	Get the log-likelihood for the muon hypothesis.

double	getLogL_pi () const
	Get the log-likelihood for the pion hypothesis.

double	getLogL_K () const
	Get the log-likelihood for the kaon hypothesis.

double	getLogL_p () const
	Get the log-likelihood for the proton hypothesis.

double	getLogL_d () const
	Get the log-likelihood for the deuteron hypothesis.

double	getLogL_e () const
	Get the log-likelihood for the electron hypothesis.

double	getChiSquared () const
	Get the chi-squared of the extrapolation.

int	getDegreesOfFreedom () const
	Get the number of degrees of freedom (= 2 times the number of KLM hits) for the chi-squared computation.

unsigned int	getOutcome () const
	Get the outcome of this extrapolation. More...

bool	getIsForward () const
	Return if this extrapolation is in forward or backward B/EKLM.

int	getBarrelExtLayer () const
	Get the outermost BKLM layer crossed in the extrapolation.

int	getEndcapExtLayer () const
	Get the outermost EKLM layer crossed in the extrapolation.

int	getExtLayer () const
	Get the outermost KLM layer crossed in the extrapolation.

int	getBarrelHitLayer () const
	Get the outermost BKLM layer actually crossed by the track.

int	getEndcapHitLayer () const
	Get the outermost EKLM layer actually crossed by the track.

int	getHitLayer () const
	Get the outermost KLM layer actually crossed by the track.

unsigned int	getExtLayerPattern () const
	Get the pattern of the layers crossed in the extrapolation.

unsigned int	getHitLayerPattern () const
	Get the pattern of the layers actually crossed by the track.

unsigned int	getTotalBarrelHits () const
	Get the total number of crossed BKLM layers.

unsigned int	getTotalEndcapHits () const
	Get the total number of crossed EKLM layers.

float	getExtBKLMEfficiencyValue (int layer) const
	Get the efficiency of a given BKLM layer. More...

float	getExtEKLMEfficiencyValue (int layer) const
	Get the efficiency of a given EKLM layer. More...

void	setPDGCode (int pdg)
	Set the PDG code of the particle hypothesis used during the extrapolation. More...

void	setPDFValue (double pdfValue, int pdg)
	Set the normalized PDF. More...

void	setMuonPDFValue (double pdfValue)
	Set the normalized PDF for the muon hypothesis. More...

void	setPionPDFValue (double pdfValue)
	Set the normalized PDF for the pion hypothesis. More...

void	setKaonPDFValue (double pdfValue)
	Set the normalized PDF for the kaon hypothesis. More...

void	setProtonPDFValue (double pdfValue)
	Set the normalized PDF for the proton hypothesis. More...

void	setDeuteronPDFValue (double pdfValue)
	Set the normalized PDF for the deuteron hypothesis. More...

void	setElectronPDFValue (double pdfValue)
	Set the normalized PDF for the electron hypothesis. More...

void	setJunkPDFValue (bool flag)
	Set the junk flag (1 if junk, 0 if not). More...

void	setLogL (double logL, int pdg)
	Set the log-likelihood. More...

void	setLogL_mu (double logL)
	Set the log-likelihood for the muon hypothesis. More...

void	setLogL_pi (double logL)
	Set the log-likelihood for the pion hypothesis. More...

void	setLogL_K (double logL)
	Set the log-likelihood for the kaon hypothesis. More...

void	setLogL_p (double logL)
	Set the log-likelihood for the proton hypothesis. More...

void	setLogL_d (double logL)
	Set the log-likelihood for the deuteron hypothesis. More...

void	setLogL_e (double logL)
	Set the log-likelihood for the electron hypothesis. More...

void	setChiSquared (double chiSquared)
	Set the chi-squared of the extrapolation. More...

void	setDegreesOfFreedom (int dof)
	Set the number of degrees of freedom (= 2 times the number of KLM hits) for the chi-square computation. More...

void	setOutcome (unsigned int outcome)
	Set the outcome of this extrapolation. More...

void	setIsForward (bool isForward)
	Set if this extrapolation is in forward or backward B/EKLM. More...

void	setBarrelExtLayer (int layer)
	Set the outermost BKLM layer crossed in the extrapolation. More...

void	setEndcapExtLayer (int layer)
	Set the outermost EKLM layer crossed in the extrapolation. More...

void	setExtLayer (int layer)
	Set the outermost EKLM layer crossed in the extrapolation. More...

void	setBarrelHitLayer (int layer)
	Set the outermost BKLM layer actually crossed by the track. More...

void	setEndcapHitLayer (int layer)
	Set the outermost EKLM layer actually crossed by the track. More...

void	setHitLayer (int layer)
	Set the outermost KLM layer actually crossed by the track. More...

void	setExtLayerPattern (unsigned int pattern)
	Set the pattern of the layers crossed in the extrapolation. More...

void	setHitLayerPattern (unsigned int pattern)
	Set the pattern of the layers actually crossed by the track. More...

void	setExtBKLMEfficiencyValue (int layer, float efficiency)
	Set the efficiency of a given BKLM layer. More...

void	setExtEKLMEfficiencyValue (int layer, float efficiency)
	Set the efficiency of a given EKLM layer. More...

void	addRelationTo (const RelationsInterface< BASE > *object, float weight=1.0, const std::string &namedRelation="") const
	Add a relation from this object to another object (with caching). More...

void	addRelationTo (const TObject *object, float weight=1.0, const std::string &namedRelation="") const
	Add a relation from this object to another object (no caching, can be quite slow). More...

void	copyRelations (const RelationsInterface< BASE > *sourceObj)
	Copies all relations of sourceObj (pointing from or to sourceObj) to this object (including weights). More...

template<class TO >
RelationVector< TO >	getRelationsTo (const std::string &name="", const std::string &namedRelation="") const
	Get the relations that point from this object to another store array. More...

template<class FROM >
RelationVector< FROM >	getRelationsFrom (const std::string &name="", const std::string &namedRelation="") const
	Get the relations that point from another store array to this object. More...

template<class T >
RelationVector< T >	getRelationsWith (const std::string &name="", const std::string &namedRelation="") const
	Get the relations between this object and another store array. More...

template<class TO >
TO *	getRelatedTo (const std::string &name="", const std::string &namedRelation="") const
	Get the object to which this object has a relation. More...

template<class FROM >
FROM *	getRelatedFrom (const std::string &name="", const std::string &namedRelation="") const
	Get the object from which this object has a relation. More...

template<class T >
T *	getRelated (const std::string &name="", const std::string &namedRelation="") const
	Get the object to or from which this object has a relation. More...

template<class TO >
std::pair< TO *, float >	getRelatedToWithWeight (const std::string &name="", const std::string &namedRelation="") const
	Get first related object & weight of relation pointing to an array. More...

template<class FROM >
std::pair< FROM *, float >	getRelatedFromWithWeight (const std::string &name="", const std::string &namedRelation="") const
	Get first related object & weight of relation pointing from an array. More...

template<class T >
std::pair< T *, float >	getRelatedWithWeight (const std::string &name="", const std::string &namedRelation="") const
	Get first related object & weight of relation pointing from/to an array. More...

virtual std::string	getName () const
	Return a short name that describes this object, e.g. More...

virtual std::string	getInfoHTML () const
	Return a short summary of this object's contents in HTML format. More...

std::string	getInfo () const
	Return a short summary of this object's contents in raw text format. More...

std::string	getArrayName () const
	Get name of array this object is stored in, or "" if not found.

int	getArrayIndex () const
	Returns this object's array index (in StoreArray), or -1 if not found.

Protected Member Functions
TClonesArray *	getArrayPointer () const
	Returns the pointer to the raw DataStore array holding this object (protected since these arrays are easy to misuse).

Private Member Functions
	ClassDef (RelationsInterface, 0)
	defines interface for accessing relations of objects in StoreArray.

Private Attributes
int	m_PDGCode
	PDG code of the particle hypothesis used during the extrapolation.

float	m_PDFValue [Const::ChargedStable::c_SetSize]
	Array of normalized PDFs.

bool	m_JunkPDFValue
	Junk flag (1 if junk, 0 if not).

float	m_LogL [Const::ChargedStable::c_SetSize]
	Array of log-likelihoods.

float	m_ChiSquared
	Chi-squared of the extrapolation.

int	m_DegreesOfFreedom
	Number of degrees of freedom (= 2 times the number of KLM hits) for the chi-squared computation.

unsigned int	m_Outcome
	Outcome of this extrapolation.

bool	m_IsForward
	Flag to determine if this extrapolation is in forward or backward B/EKLM.

int	m_BarrelExtLayer
	Outermost BKLM layer crossed in the extrapolation.

int	m_EndcapExtLayer
	Outermost EKLM layer crossed in the extrapolation.

int	m_ExtLayer
	Outermost KLM layer crossed in the extrapolation.

int	m_BarrelHitLayer
	Outermost BKLM layer actually crossed by the track.

int	m_EndcapHitLayer
	Outermost EKLM layer actually crossed by the track.

int	m_HitLayer
	Outermost KLM layer actually crossed by the track.

unsigned int	m_ExtLayerPattern
	Pattern of the layers crossed in the extrapolation (bits 0..14 = BKLM layers 1..15, bits 15..28 = EKLM layers 1..14).

unsigned int	m_HitLayerPattern
	Pattern of the layers actually crossed by the track (bits 0..14 = BKLM layers 1..15, bits 15..28 = EKLM layers 1..14).

float	m_ExtBKLMEfficiencyValue [BKLMElementNumbers::getMaximalLayerNumber()]
	Array of BKLM layer efficiencies.

float	m_ExtEKLMEfficiencyValue [EKLMElementNumbers::getMaximalLayerNumber()]
	Array of EKLM layer efficiencies.

DataStore::StoreEntry *	m_cacheDataStoreEntry
	Cache of the data store entry to which this object belongs.

int	m_cacheArrayIndex
	Cache of the index in the TClonesArray to which this object belongs.

Detailed Description

Class to store the likelihoods from KLM with additional informations related to the extrapolation.

Definition at line 38 of file KLMMuidLikelihood.h.

Member Function Documentation

◆ addRelationTo() [1/2]

void addRelationTo	(	const RelationsInterface< BASE > *	object,
		float	weight = `1.0`,
		const std::string &	namedRelation = `""`
	)		const

inlineinherited

Add a relation from this object to another object (with caching).

Parameters

object	The object to which the relation should point.
weight	The weight of the relation.
namedRelation	Additional name for the relation, or "" for the default naming

Definition at line 144 of file RelationsObject.h.

◆ addRelationTo() [2/2]

void addRelationTo	(	const TObject *	object,
		float	weight = `1.0`,
		const std::string &	namedRelation = `""`
	)		const

inlineinherited

Add a relation from this object to another object (no caching, can be quite slow).

Parameters

object	The object to which the relation should point.
weight	The weight of the relation.
namedRelation	Additional name for the relation, or "" for the default naming

Definition at line 157 of file RelationsObject.h.

◆ copyRelations()

void copyRelations ( const RelationsInterface< BASE > * sourceObj )

inlineinherited

Copies all relations of sourceObj (pointing from or to sourceObj) to this object (including weights).

Useful if you want to make a complete copy of a StoreArray object to make modifications to it, but retain all information on linked objects.

Note: this only works if sourceObj inherits from the same base (e.g. RelationsObject), and only for related objects that also inherit from the same base.

Definition at line 172 of file RelationsObject.h.

◆ getExtBKLMEfficiencyValue()

float getExtBKLMEfficiencyValue ( int layer ) const

inline

Get the efficiency of a given BKLM layer.

Parameters

[in] layer BKLM layer.

Definition at line 299 of file KLMMuidLikelihood.h.

301 {

302 return m_ExtEKLMEfficiencyValue[layer];

◆ getExtEKLMEfficiencyValue()

float getExtEKLMEfficiencyValue ( int layer ) const

inline

Get the efficiency of a given EKLM layer.

Parameters

[in] layer EKLM layer

Definition at line 308 of file KLMMuidLikelihood.h.

◆ getInfo()

std::string getInfo ( ) const

inlineinherited

Return a short summary of this object's contents in raw text format.

Returns the contents of getInfoHTML() while translating line-breaks etc.

Note: : You don't need to implement this function (it's not virtual), getInfoHTML() is enough.

Definition at line 372 of file RelationsObject.h.

◆ getInfoHTML()

virtual std::string getInfoHTML ( ) const

inlinevirtualinherited

Return a short summary of this object's contents in HTML format.

Reimplement this in your own class to provide useful output for display or debugging purposes. For example, you might do something like:

std::stringstream out;
out << "<b>PDG</b>: " << m_pdg << "<br>";
out << "<b>Covariance Matrix</b>: " << HTML::getString(getCovariance5()) << "<br>";
return out.str();

See also: Particle::getInfoHTML() for a more complex example.; HTML for some utility functions.; Use getInfo() to get a raw text version of this output.

Reimplemented in TrackFitResult, TRGSummary, Track, SoftwareTriggerResult, Particle, RecoTrack, MCParticle, Cluster, and PIDLikelihood.

Definition at line 364 of file RelationsObject.h.

◆ getLogL()

double getLogL ( int pdg ) const

inline

Get the log-likelihood.

Parameters

[in] pdg PDG code of the hypothesis.

Definition at line 134 of file KLMMuidLikelihood.h.

◆ getName()

virtual std::string getName ( ) const

inlinevirtualinherited

Return a short name that describes this object, e.g.

pi+ for an MCParticle.

Reimplemented in SpacePoint, Particle, and MCParticle.

Definition at line 346 of file RelationsObject.h.

◆ getOutcome()

unsigned int getOutcome ( ) const

inline

Get the outcome of this extrapolation.

All the possible outcome values are defined in MuidElementNumbers (see enum Outcome and calculateExtrapolationOutcome).

Definition at line 208 of file KLMMuidLikelihood.h.

◆ getPDFValue()

double getPDFValue ( int pdg ) const

inline

Get the normalized PDF.

Parameters

[in] pdg PDG code of the hypothesis.

Definition at line 69 of file KLMMuidLikelihood.h.

◆ getRelated()

T* getRelated	(	const std::string &	name = `""`,
		const std::string &	namedRelation = `""`
	)		const

inlineinherited

Get the object to or from which this object has a relation.

Template Parameters

T	The class of objects to or from which the relation points.

Parameters

name	The name of the store array to or from which the relation points. If empty the default store array name for class T will be used. If the special name "ALL" is given all store arrays containing objects of type T are considered.
namedRelation	Additional name for the relation, or "" for the default naming

Returns: The first related object or a null pointer.

Definition at line 280 of file RelationsObject.h.

◆ getRelatedFrom()

FROM* getRelatedFrom	(	const std::string &	name = `""`,
		const std::string &	namedRelation = `""`
	)		const

inlineinherited

Get the object from which this object has a relation.

Template Parameters

FROM	The class of objects from which the relation points.

Parameters

name	The name of the store array from which the relation points. If empty the default store array name for class FROM will be used. If the special name "ALL" is given all store arrays containing objects of type FROM are considered.
namedRelation	Additional name for the relation, or "" for the default naming

Returns: The first related object or a null pointer.

Definition at line 265 of file RelationsObject.h.

◆ getRelatedFromWithWeight()

std::pair<FROM*, float> getRelatedFromWithWeight	(	const std::string &	name = `""`,
		const std::string &	namedRelation = `""`
	)		const

inlineinherited

Get first related object & weight of relation pointing from an array.

Template Parameters

FROM	The class of objects from which the relation points.

Parameters

name	The name of the store array from which the relation points. If empty the default store array name for class FROM will be used. If the special name "ALL" is given all store arrays containing objects of type FROM are considered.
namedRelation	Additional name for the relation, or "" for the default naming

Returns: Pair of first related object and the relation weight, or (NULL, 1.0) if none found.

Definition at line 316 of file RelationsObject.h.

◆ getRelatedTo()

TO* getRelatedTo	(	const std::string &	name = `""`,
		const std::string &	namedRelation = `""`
	)		const

inlineinherited

Get the object to which this object has a relation.

Template Parameters

TO	The class of objects to which the relation points.

Parameters

name	The name of the store array to which the relation points. If empty the default store array name for class TO will be used. If the special name "ALL" is given all store arrays containing objects of type TO are considered.
namedRelation	Additional name for the relation, or "" for the default naming

Returns: The first related object or a null pointer.

Definition at line 250 of file RelationsObject.h.

◆ getRelatedToWithWeight()

std::pair<TO*, float> getRelatedToWithWeight	(	const std::string &	name = `""`,
		const std::string &	namedRelation = `""`
	)		const

inlineinherited

Get first related object & weight of relation pointing to an array.

Template Parameters

TO	The class of objects to which the relation points.

Parameters

name	The name of the store array to which the relation points. If empty the default store array name for class TO will be used. If the special name "ALL" is given all store arrays containing objects of type TO are considered.
namedRelation	Additional name for the relation, or "" for the default naming

Returns: Pair of first related object and the relation weight, or (NULL, 1.0) if none found.

Definition at line 299 of file RelationsObject.h.

◆ getRelatedWithWeight()

std::pair<T*, float> getRelatedWithWeight	(	const std::string &	name = `""`,
		const std::string &	namedRelation = `""`
	)		const

inlineinherited

Get first related object & weight of relation pointing from/to an array.

Template Parameters

T	The class of objects to or from which the relation points.

Parameters

name	The name of the store array to or from which the relation points. If empty the default store array name for class T will be used. If the special name "ALL" is given all store arrays containing objects of type T are considered.
namedRelation	Additional name for the relation, or "" for the default naming

Returns: Pair of first related object and the relation weight, or (NULL, 1.0) if none found.

Definition at line 333 of file RelationsObject.h.

◆ getRelationsFrom()

RelationVector<FROM> getRelationsFrom	(	const std::string &	name = `""`,
		const std::string &	namedRelation = `""`
	)		const

inlineinherited

Get the relations that point from another store array to this object.

Template Parameters

FROM	The class of objects from which the relations point.

Parameters

name	The name of the store array from which the relations point. If empty the default store array name for class FROM will be used. If the special name "ALL" is given all store arrays containing objects of type FROM are considered.
namedRelation	Additional name for the relation, or "" for the default naming

Returns: A vector of relations.

Definition at line 214 of file RelationsObject.h.

◆ getRelationsTo()

RelationVector<TO> getRelationsTo	(	const std::string &	name = `""`,
		const std::string &	namedRelation = `""`
	)		const

inlineinherited

Get the relations that point from this object to another store array.

Template Parameters

TO	The class of objects to which the relations point.

Parameters

name	The name of the store array to which the relations point. If empty the default store array name for class TO will be used. If the special name "ALL" is given all store arrays containing objects of type TO are considered.
namedRelation	Additional name for the relation, or "" for the default naming

Returns: A vector of relations.

Definition at line 199 of file RelationsObject.h.

◆ getRelationsWith()

RelationVector<T> getRelationsWith	(	const std::string &	name = `""`,
		const std::string &	namedRelation = `""`
	)		const

inlineinherited

Get the relations between this object and another store array.

Relations in both directions are returned.

Template Parameters

T	The class of objects to or from which the relations point.

Parameters

name	The name of the store array to or from which the relations point. If empty the default store array name for class T will be used. If the special name "ALL" is given all store arrays containing objects of type T are considered.
namedRelation	Additional name for the relation, or "" for the default naming

Returns: A vector of relations.

Definition at line 232 of file RelationsObject.h.

◆ setBarrelExtLayer()

void setBarrelExtLayer ( int layer )

inline

Set the outermost BKLM layer crossed in the extrapolation.

Parameters

[in] layer Outermost BKLM layer.

Definition at line 501 of file KLMMuidLikelihood.h.

◆ setBarrelHitLayer()

void setBarrelHitLayer ( int layer )

inline

Set the outermost BKLM layer actually crossed by the track.

Parameters

[in] layer Outermost BKLM layer.

Definition at line 528 of file KLMMuidLikelihood.h.

◆ setChiSquared()

void setChiSquared ( double chiSquared )

inline

Set the chi-squared of the extrapolation.

Parameters

[in] chiSquared Chi-squared of the extrapolation.

Definition at line 463 of file KLMMuidLikelihood.h.

◆ setDegreesOfFreedom()

void setDegreesOfFreedom ( int dof )

inline

Set the number of degrees of freedom (= 2 times the number of KLM hits) for the chi-square computation.

Parameters

[in] dof Number of degrees of freedom.

Definition at line 472 of file KLMMuidLikelihood.h.

◆ setDeuteronPDFValue()

void setDeuteronPDFValue ( double pdfValue )

inline

Set the normalized PDF for the deuteron hypothesis.

Parameters

[in] pdfValue Normalized PDF.

Definition at line 372 of file KLMMuidLikelihood.h.

◆ setElectronPDFValue()

void setElectronPDFValue ( double pdfValue )

inline

Set the normalized PDF for the electron hypothesis.

Parameters

[in] pdfValue Normalized PDF.

Definition at line 381 of file KLMMuidLikelihood.h.

◆ setEndcapExtLayer()

void setEndcapExtLayer ( int layer )

inline

Set the outermost EKLM layer crossed in the extrapolation.

Parameters

[in] layer Outermost EKLM layer.

Definition at line 510 of file KLMMuidLikelihood.h.

◆ setEndcapHitLayer()

void setEndcapHitLayer ( int layer )

inline

Set the outermost EKLM layer actually crossed by the track.

Parameters

[in] layer Outermost EKLM layer.

Definition at line 537 of file KLMMuidLikelihood.h.

◆ setExtBKLMEfficiencyValue()

void setExtBKLMEfficiencyValue	(	int	layer,
		float	efficiency
	)

inline

Set the efficiency of a given BKLM layer.

Parameters

[in]	layer	BKLM layer.
[in]	efficiency	Efficiency of the given layer.

Definition at line 574 of file KLMMuidLikelihood.h.

◆ setExtEKLMEfficiencyValue()

void setExtEKLMEfficiencyValue	(	int	layer,
		float	efficiency
	)

inline

Set the efficiency of a given EKLM layer.

Parameters

[in]	layer	EKLM layer.
[in]	efficiency	Efficiency of the given layer.

Definition at line 584 of file KLMMuidLikelihood.h.

◆ setExtLayer()

void setExtLayer ( int layer )

inline

Set the outermost EKLM layer crossed in the extrapolation.

Parameters

[in] layer Outermost KLM layer.

Definition at line 519 of file KLMMuidLikelihood.h.

◆ setExtLayerPattern()

void setExtLayerPattern ( unsigned int pattern )

inline

Set the pattern of the layers crossed in the extrapolation.

Parameters

[in] pattern Pattern of the extrapolation.

Definition at line 555 of file KLMMuidLikelihood.h.

◆ setHitLayer()

void setHitLayer ( int layer )

inline

Set the outermost KLM layer actually crossed by the track.

Parameters

[in] layer Outermost KLM layer.

Definition at line 546 of file KLMMuidLikelihood.h.

◆ setHitLayerPattern()

void setHitLayerPattern ( unsigned int pattern )

inline

Set the pattern of the layers actually crossed by the track.

Parameters

[in] pattern Pattern of the layers actually crossed.

Definition at line 564 of file KLMMuidLikelihood.h.

◆ setIsForward()

void setIsForward ( bool isForward )

inline

Set if this extrapolation is in forward or backward B/EKLM.

Parameters

[in] isForward True for forward, false for backward.

Definition at line 492 of file KLMMuidLikelihood.h.

◆ setJunkPDFValue()

void setJunkPDFValue ( bool flag )

inline

Set the junk flag (1 if junk, 0 if not).

Parameters

[in] flag 1 if junk, 0 if not.

Definition at line 390 of file KLMMuidLikelihood.h.

◆ setKaonPDFValue()

void setKaonPDFValue ( double pdfValue )

inline

Set the normalized PDF for the kaon hypothesis.

Parameters

[in] pdfValue Normalized PDF.

Definition at line 354 of file KLMMuidLikelihood.h.

◆ setLogL()

void setLogL	(	double	logL,
		int	pdg
	)

inline

Set the log-likelihood.

Parameters

[in]	logL	Log-likelihood.
[in]	pdg	PDG code of the hypothesis.

Definition at line 400 of file KLMMuidLikelihood.h.

◆ setLogL_d()

void setLogL_d ( double logL )

inline

Set the log-likelihood for the deuteron hypothesis.

Parameters

[in] logL Log-likelihood.

Definition at line 445 of file KLMMuidLikelihood.h.

◆ setLogL_e()

void setLogL_e ( double logL )

inline

Set the log-likelihood for the electron hypothesis.

Parameters

[in] logL Log-likelihood.

Definition at line 454 of file KLMMuidLikelihood.h.

◆ setLogL_K()

void setLogL_K ( double logL )

inline

Set the log-likelihood for the kaon hypothesis.

Parameters

[in] logL Log-likelihood.

Definition at line 427 of file KLMMuidLikelihood.h.

◆ setLogL_mu()

void setLogL_mu ( double logL )

inline

Set the log-likelihood for the muon hypothesis.

Parameters

[in] logL Log-likelihood.

Definition at line 409 of file KLMMuidLikelihood.h.

◆ setLogL_p()

void setLogL_p ( double logL )

inline

Set the log-likelihood for the proton hypothesis.

Parameters

[in] logL Log-likelihood.

Definition at line 436 of file KLMMuidLikelihood.h.

◆ setLogL_pi()

void setLogL_pi ( double logL )

inline

Set the log-likelihood for the pion hypothesis.

Parameters

[in] logL Log-likelihood.

Definition at line 418 of file KLMMuidLikelihood.h.

◆ setMuonPDFValue()

void setMuonPDFValue ( double pdfValue )

inline

Set the normalized PDF for the muon hypothesis.

Parameters

[in] pdfValue Normalized PDF.

Definition at line 336 of file KLMMuidLikelihood.h.

◆ setOutcome()

void setOutcome ( unsigned int outcome )

inline

Set the outcome of this extrapolation.

All the possible outcome values are defined in MuidElementNumbers (see enum Outcome and calculateExtrapolationOutcome).

Parameters

[in] outcome Outcome of this extrapolation.

Definition at line 483 of file KLMMuidLikelihood.h.

◆ setPDFValue()

void setPDFValue	(	double	pdfValue,
		int	pdg
	)

inline

Set the normalized PDF.

Parameters

[in]	pdfValue	Normalized PDF.
[in]	pdg	PDG code of the particle hypothesis.

Definition at line 327 of file KLMMuidLikelihood.h.

◆ setPDGCode()

void setPDGCode ( int pdg )

inline

Set the PDG code of the particle hypothesis used during the extrapolation.

Parameters

[in] pdg PDG code of the particle hypothesis.

Definition at line 317 of file KLMMuidLikelihood.h.

◆ setPionPDFValue()

void setPionPDFValue ( double pdfValue )

inline

Set the normalized PDF for the pion hypothesis.

Parameters

[in] pdfValue Normalized PDF.

Definition at line 345 of file KLMMuidLikelihood.h.

◆ setProtonPDFValue()

void setProtonPDFValue ( double pdfValue )

inline

Set the normalized PDF for the proton hypothesis.

Parameters

[in] pdfValue Normalized PDF.

Definition at line 363 of file KLMMuidLikelihood.h.

The documentation for this class was generated from the following files:

klm/dataobjects/include/KLMMuidLikelihood.h
klm/dataobjects/src/KLMMuidLikelihood.cc

Public Member Functions

Protected Member Functions

Private Member Functions

Private Attributes

Detailed Description

Member Function Documentation

◆ addRelationTo() [1/2]

◆ addRelationTo() [2/2]

◆ copyRelations()

◆ getExtBKLMEfficiencyValue()

◆ getExtEKLMEfficiencyValue()

◆ getInfo()

◆ getInfoHTML()

◆ getLogL()

◆ getName()

◆ getOutcome()

◆ getPDFValue()

◆ getRelated()

◆ getRelatedFrom()

◆ getRelatedFromWithWeight()

◆ getRelatedTo()

◆ getRelatedToWithWeight()

◆ getRelatedWithWeight()

◆ getRelationsFrom()

◆ getRelationsTo()

◆ getRelationsWith()

◆ setBarrelExtLayer()

◆ setBarrelHitLayer()

◆ setChiSquared()

◆ setDegreesOfFreedom()

◆ setDeuteronPDFValue()

◆ setElectronPDFValue()

◆ setEndcapExtLayer()

◆ setEndcapHitLayer()

◆ setExtBKLMEfficiencyValue()

◆ setExtEKLMEfficiencyValue()

◆ setExtLayer()

◆ setExtLayerPattern()

◆ setHitLayer()

◆ setHitLayerPattern()

◆ setIsForward()

◆ setJunkPDFValue()

◆ setKaonPDFValue()

◆ setLogL()

◆ setLogL_d()

◆ setLogL_e()

◆ setLogL_K()

◆ setLogL_mu()

◆ setLogL_p()

◆ setLogL_pi()

◆ setMuonPDFValue()

◆ setOutcome()

◆ setPDFValue()

◆ setPDGCode()

◆ setPionPDFValue()

◆ setProtonPDFValue()
