TOPPull Class Reference

Class to store photon pull in respect to PDF used in reconstruction. More...

#include <TOPPull.h>

Inheritance diagram for TOPPull:
Collaboration diagram for TOPPull:

Public Member Functions

 TOPPull ()
 Default constructor.

 TOPPull (int pixelID, float t, float t0, float sigma, float phiCer, float wt)
 Full constructor. More...

int getPixelID () const
 Return pixel ID (e.g. More...

double getTime () const
 Return photon time. More...

double getMeanTime () const
 Return PDF mean. More...

double getSigma () const
 Return PDF width. More...

double getTimeDiff () const
 Return time difference btw. More...

double getPull () const
 Return pull. More...

double getPhiCer () const
 Return Cerenkov azimuthal angle. More...

double getWeight () const
 Return probability of photon belonging to this PDF. More...

bool isSignal () const
 Checks whether it corresponds to signal PDF. More...

void addRelationTo (const RelationsInterface< BASE > *object, float weight=1.0, const std::string &namedRelation="") const
 Add a relation from this object to another object (with caching). More...

void addRelationTo (const TObject *object, float weight=1.0, const std::string &namedRelation="") const
 Add a relation from this object to another object (no caching, can be quite slow). More...

void copyRelations (const RelationsInterface< BASE > *sourceObj)
 Copies all relations of sourceObj (pointing from or to sourceObj) to this object (including weights). More...

template<class TO >
RelationVector< TO > getRelationsTo (const std::string &name="", const std::string &namedRelation="") const
 Get the relations that point from this object to another store array. More...

template<class FROM >
RelationVector< FROM > getRelationsFrom (const std::string &name="", const std::string &namedRelation="") const
 Get the relations that point from another store array to this object. More...

template<class T >
RelationVector< T > getRelationsWith (const std::string &name="", const std::string &namedRelation="") const
 Get the relations between this object and another store array. More...

template<class TO >
TO * getRelatedTo (const std::string &name="", const std::string &namedRelation="") const
 Get the object to which this object has a relation. More...

template<class FROM >
FROM * getRelatedFrom (const std::string &name="", const std::string &namedRelation="") const
 Get the object from which this object has a relation. More...

template<class T >
T * getRelated (const std::string &name="", const std::string &namedRelation="") const
 Get the object to or from which this object has a relation. More...

template<class TO >
std::pair< TO *, float > getRelatedToWithWeight (const std::string &name="", const std::string &namedRelation="") const
 Get first related object & weight of relation pointing to an array. More...

template<class FROM >
std::pair< FROM *, float > getRelatedFromWithWeight (const std::string &name="", const std::string &namedRelation="") const
 Get first related object & weight of relation pointing from an array. More...

template<class T >
std::pair< T *, float > getRelatedWithWeight (const std::string &name="", const std::string &namedRelation="") const
 Get first related object & weight of relation pointing from/to an array. More...

virtual std::string getName () const
 Return a short name that describes this object, e.g. More...

virtual std::string getInfoHTML () const
 Return a short summary of this object's contents in HTML format. More...

std::string getInfo () const
 Return a short summary of this object's contents in raw text format. More...

std::string getArrayName () const
 Get name of array this object is stored in, or "" if not found.

int getArrayIndex () const
 Returns this object's array index (in StoreArray), or -1 if not found.


Protected Member Functions

TClonesArray * getArrayPointer () const
 Returns the pointer to the raw DataStore array holding this object (protected since these arrays are easy to misuse).


Private Member Functions

 ClassDef (TOPPull, 2)
 ClassDef.


Private Attributes

int m_pixelID
 pixel ID (e.g. More...

float m_t
 photon time

float m_t0
 PDF mean time (signal) or minimal PDF mean (background)

float m_sigma
 PDF sigma (signal) or 0 (background)

float m_phiCer
 azimuthal Cerenkov angle

float m_wt
 weight

DataStore::StoreEntrym_cacheDataStoreEntry
 Cache of the data store entry to which this object belongs.

int m_cacheArrayIndex
 Cache of the index in the TClonesArray to which this object belongs.


Detailed Description

Class to store photon pull in respect to PDF used in reconstruction.

Definition at line 33 of file TOPPull.h.

Constructor & Destructor Documentation

◆ TOPPull()

TOPPull ( int  pixelID,
float  t,
float  t0,
float  sigma,
float  phiCer,
float  wt
)
inline

Full constructor.

Parameters
pixelIDpixel ID (e.g. software channel, 1-based)
tphoton time
t0PDF mean time (signal) or minimal PDF mean (background)
sigmaPDF sigma (signal) or 0 (background)
phiCerazimuthal Cerenkov angle of this PDF peak
wtweight - probability of belonging to this PDF peak

Definition at line 51 of file TOPPull.h.

51  { return m_pixelID; }
52

Member Function Documentation

◆ addRelationTo() [1/2]

void addRelationTo ( const RelationsInterface< BASE > *  object,
float  weight = 1.0,
const std::string &  namedRelation = ""
) const
inlineinherited

Add a relation from this object to another object (with caching).

Parameters
objectThe object to which the relation should point.
weightThe weight of the relation.
namedRelationAdditional name for the relation, or "" for the default naming

Definition at line 144 of file RelationsObject.h.

◆ addRelationTo() [2/2]

void addRelationTo ( const TObject *  object,
float  weight = 1.0,
const std::string &  namedRelation = ""
) const
inlineinherited

Add a relation from this object to another object (no caching, can be quite slow).

Parameters
objectThe object to which the relation should point.
weightThe weight of the relation.
namedRelationAdditional name for the relation, or "" for the default naming

Definition at line 157 of file RelationsObject.h.

◆ copyRelations()

void copyRelations ( const RelationsInterface< BASE > *  sourceObj)
inlineinherited

Copies all relations of sourceObj (pointing from or to sourceObj) to this object (including weights).

Useful if you want to make a complete copy of a StoreArray object to make modifications to it, but retain all information on linked objects.

Note: this only works if sourceObj inherits from the same base (e.g. RelationsObject), and only for related objects that also inherit from the same base.

Definition at line 172 of file RelationsObject.h.

◆ getInfo()

std::string getInfo ( ) const
inlineinherited

Return a short summary of this object's contents in raw text format.

Returns the contents of getInfoHTML() while translating line-breaks etc.

Note
: You don't need to implement this function (it's not virtual), getInfoHTML() is enough.

Definition at line 372 of file RelationsObject.h.

◆ getInfoHTML()

virtual std::string getInfoHTML ( ) const
inlinevirtualinherited

Return a short summary of this object's contents in HTML format.

Reimplement this in your own class to provide useful output for display or debugging purposes. For example, you might do something like:

std::stringstream out;
out << "<b>PDG</b>: " << m_pdg << "<br>";
out << "<b>Covariance Matrix</b>: " << HTML::getString(getCovariance5()) << "<br>";
return out.str();
See also
Particle::getInfoHTML() for a more complex example.
HTML for some utility functions.
Use getInfo() to get a raw text version of this output.

Reimplemented in TrackFitResult, TRGSummary, Track, SoftwareTriggerResult, Particle, RecoTrack, MCParticle, Cluster, and PIDLikelihood.

Definition at line 364 of file RelationsObject.h.

◆ getMeanTime()

double getMeanTime ( ) const
inline

Return PDF mean.

Returns
PDF mean time

Definition at line 71 of file TOPPull.h.

◆ getName()

virtual std::string getName ( ) const
inlinevirtualinherited

Return a short name that describes this object, e.g.

pi+ for an MCParticle.

Reimplemented in SpacePoint, Particle, and MCParticle.

Definition at line 346 of file RelationsObject.h.

◆ getPhiCer()

double getPhiCer ( ) const
inline

Return Cerenkov azimuthal angle.

Returns
azimuthal angle

Definition at line 95 of file TOPPull.h.

◆ getPixelID()

int getPixelID ( ) const
inline

Return pixel ID (e.g.

software channel, 1-based) of detected photon

Returns
pixel ID

Definition at line 59 of file TOPPull.h.

◆ getPull()

double getPull ( ) const
inline

Return pull.

Returns
pull

Definition at line 89 of file TOPPull.h.

◆ getRelated()

T* getRelated ( const std::string &  name = "",
const std::string &  namedRelation = ""
) const
inlineinherited

Get the object to or from which this object has a relation.

Template Parameters
TThe class of objects to or from which the relation points.
Parameters
nameThe name of the store array to or from which the relation points. If empty the default store array name for class T will be used. If the special name "ALL" is given all store arrays containing objects of type T are considered.
namedRelationAdditional name for the relation, or "" for the default naming
Returns
The first related object or a null pointer.

Definition at line 280 of file RelationsObject.h.

◆ getRelatedFrom()

FROM* getRelatedFrom ( const std::string &  name = "",
const std::string &  namedRelation = ""
) const
inlineinherited

Get the object from which this object has a relation.

Template Parameters
FROMThe class of objects from which the relation points.
Parameters
nameThe name of the store array from which the relation points. If empty the default store array name for class FROM will be used. If the special name "ALL" is given all store arrays containing objects of type FROM are considered.
namedRelationAdditional name for the relation, or "" for the default naming
Returns
The first related object or a null pointer.

Definition at line 265 of file RelationsObject.h.

◆ getRelatedFromWithWeight()

std::pair<FROM*, float> getRelatedFromWithWeight ( const std::string &  name = "",
const std::string &  namedRelation = ""
) const
inlineinherited

Get first related object & weight of relation pointing from an array.

Template Parameters
FROMThe class of objects from which the relation points.
Parameters
nameThe name of the store array from which the relation points. If empty the default store array name for class FROM will be used. If the special name "ALL" is given all store arrays containing objects of type FROM are considered.
namedRelationAdditional name for the relation, or "" for the default naming
Returns
Pair of first related object and the relation weight, or (NULL, 1.0) if none found.

Definition at line 316 of file RelationsObject.h.

◆ getRelatedTo()

TO* getRelatedTo ( const std::string &  name = "",
const std::string &  namedRelation = ""
) const
inlineinherited

Get the object to which this object has a relation.

Template Parameters
TOThe class of objects to which the relation points.
Parameters
nameThe name of the store array to which the relation points. If empty the default store array name for class TO will be used. If the special name "ALL" is given all store arrays containing objects of type TO are considered.
namedRelationAdditional name for the relation, or "" for the default naming
Returns
The first related object or a null pointer.

Definition at line 250 of file RelationsObject.h.

◆ getRelatedToWithWeight()

std::pair<TO*, float> getRelatedToWithWeight ( const std::string &  name = "",
const std::string &  namedRelation = ""
) const
inlineinherited

Get first related object & weight of relation pointing to an array.

Template Parameters
TOThe class of objects to which the relation points.
Parameters
nameThe name of the store array to which the relation points. If empty the default store array name for class TO will be used. If the special name "ALL" is given all store arrays containing objects of type TO are considered.
namedRelationAdditional name for the relation, or "" for the default naming
Returns
Pair of first related object and the relation weight, or (NULL, 1.0) if none found.

Definition at line 299 of file RelationsObject.h.

◆ getRelatedWithWeight()

std::pair<T*, float> getRelatedWithWeight ( const std::string &  name = "",
const std::string &  namedRelation = ""
) const
inlineinherited

Get first related object & weight of relation pointing from/to an array.

Template Parameters
TThe class of objects to or from which the relation points.
Parameters
nameThe name of the store array to or from which the relation points. If empty the default store array name for class T will be used. If the special name "ALL" is given all store arrays containing objects of type T are considered.
namedRelationAdditional name for the relation, or "" for the default naming
Returns
Pair of first related object and the relation weight, or (NULL, 1.0) if none found.

Definition at line 333 of file RelationsObject.h.

◆ getRelationsFrom()

RelationVector<FROM> getRelationsFrom ( const std::string &  name = "",
const std::string &  namedRelation = ""
) const
inlineinherited

Get the relations that point from another store array to this object.

Template Parameters
FROMThe class of objects from which the relations point.
Parameters
nameThe name of the store array from which the relations point. If empty the default store array name for class FROM will be used. If the special name "ALL" is given all store arrays containing objects of type FROM are considered.
namedRelationAdditional name for the relation, or "" for the default naming
Returns
A vector of relations.

Definition at line 214 of file RelationsObject.h.

◆ getRelationsTo()

RelationVector<TO> getRelationsTo ( const std::string &  name = "",
const std::string &  namedRelation = ""
) const
inlineinherited

Get the relations that point from this object to another store array.

Template Parameters
TOThe class of objects to which the relations point.
Parameters
nameThe name of the store array to which the relations point. If empty the default store array name for class TO will be used. If the special name "ALL" is given all store arrays containing objects of type TO are considered.
namedRelationAdditional name for the relation, or "" for the default naming
Returns
A vector of relations.

Definition at line 199 of file RelationsObject.h.

◆ getRelationsWith()

RelationVector<T> getRelationsWith ( const std::string &  name = "",
const std::string &  namedRelation = ""
) const
inlineinherited

Get the relations between this object and another store array.

Relations in both directions are returned.

Template Parameters
TThe class of objects to or from which the relations point.
Parameters
nameThe name of the store array to or from which the relations point. If empty the default store array name for class T will be used. If the special name "ALL" is given all store arrays containing objects of type T are considered.
namedRelationAdditional name for the relation, or "" for the default naming
Returns
A vector of relations.

Definition at line 232 of file RelationsObject.h.

◆ getSigma()

double getSigma ( ) const
inline

Return PDF width.

Returns
sigma

Definition at line 77 of file TOPPull.h.

◆ getTime()

double getTime ( ) const
inline

Return photon time.

Returns
photon time

Definition at line 65 of file TOPPull.h.

◆ getTimeDiff()

double getTimeDiff ( ) const
inline

Return time difference btw.

photon and PDF

Returns
time difference

Definition at line 83 of file TOPPull.h.

◆ getWeight()

double getWeight ( ) const
inline

Return probability of photon belonging to this PDF.

Returns
weight

Definition at line 101 of file TOPPull.h.

◆ isSignal()

bool isSignal ( ) const
inline

Checks whether it corresponds to signal PDF.

Returns
true (signal) or false (background)

Definition at line 107 of file TOPPull.h.

Member Data Documentation

◆ m_pixelID

int m_pixelID
private

pixel ID (e.g.

software channel, 1-based)

Definition at line 110 of file TOPPull.h.


The documentation for this class was generated from the following file:
Belle2::HTML::getString
std::string getString(const TMatrixFBase &matrix, int precision=2, bool color=true)
get HTML table representing a matrix.
Definition: HTML.cc:18
Belle2::TOPPull::m_pixelID
int m_pixelID
pixel ID (e.g.
Definition: TOPPull.h:110
