Belle II Software  release-05-02-19
DATCONSVDSpacePoint Class Reference

DATCONSVDSpacePoint typically is build from 1-2 DATCONSimpleSVDClusters. More...

#include <DATCONSVDSpacePoint.h>

Inheritance diagram for DATCONSVDSpacePoint:
Collaboration diagram for DATCONSVDSpacePoint:

Public Member Functions

 DATCONSVDSpacePoint (std::vector< SVDCluster const * > &clusters, VXD::SensorInfoBase const *aSensorInfo=nullptr)
 Constructor DATCONSVDSpacePoint from ONE or TWO DATCONSimpleSVDClusters. More...

 DATCONSVDSpacePoint ()
 Default constructor for the ROOT IO.

 DATCONSVDSpacePoint (B2Vector3< double > &pos, const std::pair< double, double > &normalizedLocal, std::pair< bool, bool > clustersAssigned, VxdID sensorID, Belle2::VXD::SensorInfoBase::SensorType detID)
 Constructor for debugging or other special purposes. More...

bool operator== (const DATCONSVDSpacePoint &b) const
 Compare, if two DATCONSVDSpacePoints are the same one. More...

bool operator!= (const DATCONSVDSpacePoint &b) const
 Comparison for inequality with another DATCONSVDSpacePoint.

double X () const
 return the x-value of the global position of the DATCONSVDSpacePoint

double Y () const
 return the y-value of the global position of the DATCONSVDSpacePoint

double Z () const
 return the z-value of the global position of the DATCONSVDSpacePoint

const B2Vector3< double > & getPosition () const
 return the position vector in global coordinates

Belle2::VXD::SensorInfoBase::SensorType getType () const
 Return SensorType (PXD, SVD, ...) on which the DATCONSVDSpacePoint lives.

VxdID getVxdID () const
 Return the VxdID of the sensor on which the the cluster of the DATCONSVDSpacePoint lives.

double getNormalizedLocalU () const
 Return normalized local coordinates of the cluster in u (0 <= posU <= 1).

double getNormalizedLocalV () const
 Return normalized local coordinates of the cluster in v (0 <= posV <= 1).

std::pair< bool, bool > getIfClustersAssigned () const
 Returns, if u(v)-coordinate is based on cluster information. More...

unsigned short getNClustersAssigned () const
 Returns the number of Clusters assigned to this DATCONSVDSpacePoint.

void setAssignmentState (bool isAssigned) const
 Setter for association with a track.

bool isUOnly () const
 Returns true if the SP is single clustered and the cluster is a u cluster.

bool isVOnly () const
 Returns true if the SP is single clustered and the cluster is a v cluster.

bool isUAndV () const
 Returns true if the SP is not single clustered.

bool getAssignmentState () const
 Getter for status of assignment to a track.

std::vector< SVDClustergetAssignedDATCONSVDClusters ()
 Getter function for the DATCONSVDClusters assigned to this DATCONSVDSpacePoint.

void addRelationTo (const RelationsInterface< BASE > *object, float weight=1.0, const std::string &namedRelation="") const
 Add a relation from this object to another object (with caching). More...

void addRelationTo (const TObject *object, float weight=1.0, const std::string &namedRelation="") const
 Add a relation from this object to another object (no caching, can be quite slow). More...

void copyRelations (const RelationsInterface< BASE > *sourceObj)
 Copies all relations of sourceObj (pointing from or to sourceObj) to this object (including weights). More...

template<class TO >
RelationVector< TO > getRelationsTo (const std::string &name="", const std::string &namedRelation="") const
 Get the relations that point from this object to another store array. More...

template<class FROM >
RelationVector< FROM > getRelationsFrom (const std::string &name="", const std::string &namedRelation="") const
 Get the relations that point from another store array to this object. More...

template<class T >
RelationVector< T > getRelationsWith (const std::string &name="", const std::string &namedRelation="") const
 Get the relations between this object and another store array. More...

template<class TO >
TO * getRelatedTo (const std::string &name="", const std::string &namedRelation="") const
 Get the object to which this object has a relation. More...

template<class FROM >
FROM * getRelatedFrom (const std::string &name="", const std::string &namedRelation="") const
 Get the object from which this object has a relation. More...

template<class T >
T * getRelated (const std::string &name="", const std::string &namedRelation="") const
 Get the object to or from which this object has a relation. More...

template<class TO >
std::pair< TO *, float > getRelatedToWithWeight (const std::string &name="", const std::string &namedRelation="") const
 Get first related object & weight of relation pointing to an array. More...

template<class FROM >
std::pair< FROM *, float > getRelatedFromWithWeight (const std::string &name="", const std::string &namedRelation="") const
 Get first related object & weight of relation pointing from an array. More...

template<class T >
std::pair< T *, float > getRelatedWithWeight (const std::string &name="", const std::string &namedRelation="") const
 Get first related object & weight of relation pointing from/to an array. More...

virtual std::string getName () const
 Return a short name that describes this object, e.g. More...

virtual std::string getInfoHTML () const
 Return a short summary of this object's contents in HTML format. More...

std::string getInfo () const
 Return a short summary of this object's contents in raw text format. More...

std::string getArrayName () const
 Get name of array this object is stored in, or "" if not found.

int getArrayIndex () const
 Returns this object's array index (in StoreArray), or -1 if not found.


Static Public Member Functions

static B2Vector3< double > getGlobalCoordinates (const std::pair< double, double > &hitLocal, VxdID vxdID, const VXD::SensorInfoBase *aSensorInfo=nullptr)
 converts a local hit on a given sensor into global coordinates. More...

static std::pair< double, double > convertLocalToNormalizedCoordinates (const std::pair< double, double > &hitLocal, VxdID vxdID, const VXD::SensorInfoBase *aSensorInfo=nullptr)
 converts a local hit into sensor-independent relative coordinates. More...

static std::pair< double, double > convertNormalizedToLocalCoordinates (const std::pair< double, double > &hitNormalized, Belle2::VxdID vxdID, const Belle2::VXD::SensorInfoBase *aSensorInfo=nullptr)
 converts a hit in sensor-independent relative coordinates into local coordinate of given sensor. More...

static double getUWedged (const std::pair< double, double > &hitLocalUnwedged, VxdID vxdID, const VXD::SensorInfoBase *aSensorInfo=nullptr)
 takes a general uCoordinate, and transforms it to corrected uCoordinate for wedged sensors. More...

static double getUUnwedged (const std::pair< double, double > &hitLocalWedged, VxdID::baseType vxdID, const VXD::SensorInfoBase *aSensorInfo=nullptr)
 takes a wedged uCoordinate, and transforms it to general uCoordinate. More...

static void boundaryEnforce (double &value, const double &otherValue, double lower=0, double higher=1, unsigned int side=0, VxdID vxdID=VxdID())
 Enforce. More...


Protected Member Functions

TClonesArray * getArrayPointer () const
 Returns the pointer to the raw DataStore array holding this object (protected since these arrays are easy to misuse).


Protected Attributes

B2Vector3< double > m_position
 Global position vector. More...

std::pair< double, double > m_normalizedLocal
 Local position vector normalized to sensor size (0 <= x <= 1). More...

std::pair< bool, bool > m_clustersAssigned {false, false}
 The bool value is true, when correct information of the coordinate exists. More...

std::vector< SVDClusterm_assignedDATCONSVDClusters
 Vector containing the DATCONSVDClusters assigned to this DATCONSVDSpacePoint.

VxdID::baseType m_vxdID
 Stores the VxdID.

VXD::SensorInfoBase::SensorType m_sensorType
 Stores the SensorType using the scheme of SensorInfoBase. More...

bool m_isAssigned {false}
 Stores whether this DATCONSVDSpacePoint is connected to a track. More...


Private Member Functions

 ClassDef (RelationsInterface, 0)
 defines interface for accessing relations of objects in StoreArray.


Private Attributes

DataStore::StoreEntrym_cacheDataStoreEntry
 Cache of the data store entry to which this object belongs.

int m_cacheArrayIndex
 Cache of the index in the TClonesArray to which this object belongs.


Friends

std::ostream & operator<< (std::ostream &out, const DATCONSVDSpacePoint &aSP)
 overloaded '<<' stream operator. More...


Detailed Description

DATCONSVDSpacePoint typically is build from 1-2 DATCONSimpleSVDClusters.

It stores a global space point and some extra infos, such as a flag if it is already assigned.

For SVD only:
If relations to its attached Clusters are set, these have got the following meaning:

  • relationweights code the type of the cluster. +1 for u and -1 for v clusters.

Definition at line 51 of file DATCONSVDSpacePoint.h.

Constructor & Destructor Documentation

◆ DATCONSVDSpacePoint() [1/2]

DATCONSVDSpacePoint ( std::vector< SVDCluster const * > &  clusters,
VXD::SensorInfoBase const *  aSensorInfo = nullptr
)
explicit

Constructor DATCONSVDSpacePoint from ONE or TWO DATCONSimpleSVDClusters.

Parameters
clusterscontainer carrying pointers to DATCONSVDCluster (1 or 2 (u+v), must not be nullptr).
aSensorInfoSensorInfoBase for testing purposes, usually derived from first cluster.

Definition at line 17 of file DATCONSVDSpacePoint.cc.

19 {
20  //---The following contains only sanity checks without effect, if nobody gave buggy information---
21  //We have 1 or two SVD Clusters.
22  B2ASSERT("You have to insert 1 or two SVD Clusters, but gave: " << clusters.size(), ((clusters.size() == 1)
23  || (clusters.size() == 2)));
24
25  //No cluster pointer is a nullptr.
26  for (auto && cluster : clusters) {
27  B2ASSERT("An (DATCON)SVDCluster Pointer is a nullptr!", cluster != nullptr);
28  }
29
30  //In case of 2 clusters, they are compatible with each other.
31  if (clusters.size() == 2) {
32  B2ASSERT("Clusters are on different Sensors.", clusters[0]->getSensorID() == clusters[1]->getSensorID());
33  B2ASSERT("Clusters are of same direction type.", clusters[0]->isUCluster() != clusters[1]->isUCluster());
34  }
35  //---End sanity checks---
36
37  m_vxdID = clusters[0]->getSensorID();
38
39  //We need some handle to translate IDs to local and global coordinates.
40  if (aSensorInfo == NULL) {
42  }
43
44  m_sensorType = aSensorInfo->getType();
45
46  // retrieve position and sigma-values
47  double uCoord = 0; // 0 = center of Sensor
48  double vCoord = 0; // 0 = center of Sensor
50
51  const SVDCluster* vCluster(NULL), *uCluster(NULL);
52  for (const SVDCluster* aCluster : clusters) {
53  m_assignedDATCONSVDClusters.push_back(*aCluster);
54  if (aCluster->isUCluster() == true) {
55  m_clustersAssigned.first = true;
56  uCoord = aCluster->getPosition();
57  uCluster = aCluster;
58  } else {
59  m_clustersAssigned.second = true;
60  vCoord = aCluster->getPosition();
61  vCluster = aCluster;
62  }
63  }
64
65  if (aSensorInfo->getBackwardWidth() > aSensorInfo->getForwardWidth() &&
66  vCluster != NULL && uCluster != NULL) // is a WedgeSensor and we do have a vCluster
67  uCoord = uCluster->getPosition(vCoord);
68
69  m_position = aSensorInfo->pointToGlobal(TVector3(uCoord, vCoord, 0));
70  m_normalizedLocal = convertLocalToNormalizedCoordinates({ uCoord, vCoord } , m_vxdID, aSensorInfo);
71
72 }

◆ DATCONSVDSpacePoint() [2/2]

DATCONSVDSpacePoint ( B2Vector3< double > &  pos,
const std::pair< double, double > &  normalizedLocal,
std::pair< bool, bool >  clustersAssigned,
VxdID  sensorID,
Belle2::VXD::SensorInfoBase::SensorType  detID
)
inline

Constructor for debugging or other special purposes.

Parameters
posglobal DATCONSVDSpacePoint position.
normalizedLocalcoordinates (element: [0;1]) of SP on given sensorID (.first "=" u, .second "=" v).
clustersAssignedstates, if u (.first) or v (.second) is assigned.
sensorIDVxdID of sensor the DATCONSVDSpacePoint shall be on.
detIDSensorType detector-type (PXD, SVD, ...) to be used.

Definition at line 76 of file DATCONSVDSpacePoint.h.

79  { return out << aSP.getName();}
80

Member Function Documentation

◆ addRelationTo() [1/2]

void addRelationTo ( const RelationsInterface< BASE > *  object,
float  weight = 1.0,
const std::string &  namedRelation = ""
) const
inlineinherited

Add a relation from this object to another object (with caching).

Parameters
objectThe object to which the relation should point.
weightThe weight of the relation.
namedRelationAdditional name for the relation, or "" for the default naming

Definition at line 144 of file RelationsObject.h.

◆ addRelationTo() [2/2]

void addRelationTo ( const TObject *  object,
float  weight = 1.0,
const std::string &  namedRelation = ""
) const
inlineinherited

Add a relation from this object to another object (no caching, can be quite slow).

Parameters
objectThe object to which the relation should point.
weightThe weight of the relation.
namedRelationAdditional name for the relation, or "" for the default naming

Definition at line 157 of file RelationsObject.h.

◆ boundaryEnforce()

static void boundaryEnforce ( double &  value,
const double &  otherValue,
double  lower = 0,
double  higher = 1,
unsigned int  side = 0,
VxdID  vxdID = VxdID()
)
inlinestatic

Enforce.

Parameters
valuein the range [
lower

Definition at line 244 of file DATCONSVDSpacePoint.h.

◆ convertLocalToNormalizedCoordinates()

std::pair< double, double > convertLocalToNormalizedCoordinates ( const std::pair< double, double > &  hitLocal,
VxdID  vxdID,
const VXD::SensorInfoBase aSensorInfo = nullptr
)
static

converts a local hit into sensor-independent relative coordinates.

first parameter is the local hit (as provided by DATCONSVDSpacePoint::getUWedged(...) and Cluster::getV!) stored as a pair of doubles. second parameter is the coded vxdID, which carries the sensorID. third parameter, a sensorInfo can be passed for testing purposes. If no sensorInfo is passed, the member gets its own pointer to it.

ATTENTION: this function assumes, that for wedged sensors, the uCoordinate is already adapted to the vCoordinate! The normalized coordinates are independent of wedged-sensor-issues

Definition at line 75 of file DATCONSVDSpacePoint.cc.

◆ convertNormalizedToLocalCoordinates()

std::pair< double, double > convertNormalizedToLocalCoordinates ( const std::pair< double, double > &  hitNormalized,
Belle2::VxdID  vxdID,
const Belle2::VXD::SensorInfoBase aSensorInfo = nullptr
)
static

converts a hit in sensor-independent relative coordinates into local coordinate of given sensor.

first parameter is the hit in sensor-independent normalized ! coordinates stored as a pair of floats. second parameter is the coded vxdID, which carries the sensorID. third parameter, a sensorInfo can be passed for testing purposes. If no sensorInfo is passed, the member gets its own pointer to it.

Definition at line 104 of file DATCONSVDSpacePoint.cc.

◆ copyRelations()

void copyRelations ( const RelationsInterface< BASE > *  sourceObj)
inlineinherited

Copies all relations of sourceObj (pointing from or to sourceObj) to this object (including weights).

Useful if you want to make a complete copy of a StoreArray object to make modifications to it, but retain all information on linked objects.

Note: this only works if sourceObj inherits from the same base (e.g. RelationsObject), and only for related objects that also inherit from the same base.

Definition at line 172 of file RelationsObject.h.

◆ getGlobalCoordinates()

B2Vector3< double > getGlobalCoordinates ( const std::pair< double, double > &  hitLocal,
VxdID  vxdID,
const VXD::SensorInfoBase aSensorInfo = nullptr
)
static

converts a local hit on a given sensor into global coordinates.

so this practically does what sensorInfo::pointToGlobal is doing, the difference is, that you do not need to have the sensorInfo beforehand (it will be retrieved using the VxdID) first parameter is the local hit (as provided by getU and getV!) stored as a pair of doubles. second parameter is the coded vxdID, which carries the sensorID. third parameter, a sensorInfo can be passed for testing purposes. If no sensorInfo is passed, the member gets its own pointer to it.

ATTENTION: this function assumes, that for wedged sensors, the uCoordinate is already adapted to the vCoordinate!

Definition at line 130 of file DATCONSVDSpacePoint.cc.

◆ getIfClustersAssigned()

std::pair<bool, bool> getIfClustersAssigned ( ) const
inline

Returns, if u(v)-coordinate is based on cluster information.

.first is true, if u-cluster information is present
.second is true, if v-cluster information is present.

Definition at line 138 of file DATCONSVDSpacePoint.h.

◆ getInfo()

std::string getInfo ( ) const
inlineinherited

Return a short summary of this object's contents in raw text format.

Returns the contents of getInfoHTML() while translating line-breaks etc.

Note
: You don't need to implement this function (it's not virtual), getInfoHTML() is enough.

Definition at line 372 of file RelationsObject.h.

◆ getInfoHTML()

virtual std::string getInfoHTML ( ) const
inlinevirtualinherited

Return a short summary of this object's contents in HTML format.

Reimplement this in your own class to provide useful output for display or debugging purposes. For example, you might do something like:

std::stringstream out;
out << "<b>PDG</b>: " << m_pdg << "<br>";
out << "<b>Covariance Matrix</b>: " << HTML::getString(getCovariance5()) << "<br>";
return out.str();
See also
Particle::getInfoHTML() for a more complex example.
HTML for some utility functions.
Use getInfo() to get a raw text version of this output.

Reimplemented in TrackFitResult, TRGSummary, Track, SoftwareTriggerResult, Particle, RecoTrack, MCParticle, Cluster, and PIDLikelihood.

Definition at line 364 of file RelationsObject.h.

◆ getName()

virtual std::string getName ( ) const
inlinevirtualinherited

Return a short name that describes this object, e.g.

pi+ for an MCParticle.

Reimplemented in SpacePoint, Particle, and MCParticle.

Definition at line 346 of file RelationsObject.h.

◆ getRelated()

T* getRelated ( const std::string &  name = "",
const std::string &  namedRelation = ""
) const
inlineinherited

Get the object to or from which this object has a relation.

Template Parameters
TThe class of objects to or from which the relation points.
Parameters
nameThe name of the store array to or from which the relation points. If empty the default store array name for class T will be used. If the special name "ALL" is given all store arrays containing objects of type T are considered.
namedRelationAdditional name for the relation, or "" for the default naming
Returns
The first related object or a null pointer.

Definition at line 280 of file RelationsObject.h.

◆ getRelatedFrom()

FROM* getRelatedFrom ( const std::string &  name = "",
const std::string &  namedRelation = ""
) const
inlineinherited

Get the object from which this object has a relation.

Template Parameters
FROMThe class of objects from which the relation points.
Parameters
nameThe name of the store array from which the relation points. If empty the default store array name for class FROM will be used. If the special name "ALL" is given all store arrays containing objects of type FROM are considered.
namedRelationAdditional name for the relation, or "" for the default naming
Returns
The first related object or a null pointer.

Definition at line 265 of file RelationsObject.h.

◆ getRelatedFromWithWeight()

std::pair<FROM*, float> getRelatedFromWithWeight ( const std::string &  name = "",
const std::string &  namedRelation = ""
) const
inlineinherited

Get first related object & weight of relation pointing from an array.

Template Parameters
FROMThe class of objects from which the relation points.
Parameters
nameThe name of the store array from which the relation points. If empty the default store array name for class FROM will be used. If the special name "ALL" is given all store arrays containing objects of type FROM are considered.
namedRelationAdditional name for the relation, or "" for the default naming
Returns
Pair of first related object and the relation weight, or (NULL, 1.0) if none found.

Definition at line 316 of file RelationsObject.h.

◆ getRelatedTo()

TO* getRelatedTo ( const std::string &  name = "",
const std::string &  namedRelation = ""
) const
inlineinherited

Get the object to which this object has a relation.

Template Parameters
TOThe class of objects to which the relation points.
Parameters
nameThe name of the store array to which the relation points. If empty the default store array name for class TO will be used. If the special name "ALL" is given all store arrays containing objects of type TO are considered.
namedRelationAdditional name for the relation, or "" for the default naming
Returns
The first related object or a null pointer.

Definition at line 250 of file RelationsObject.h.

◆ getRelatedToWithWeight()

std::pair<TO*, float> getRelatedToWithWeight ( const std::string &  name = "",
const std::string &  namedRelation = ""
) const
inlineinherited

Get first related object & weight of relation pointing to an array.

Template Parameters
TOThe class of objects to which the relation points.
Parameters
nameThe name of the store array to which the relation points. If empty the default store array name for class TO will be used. If the special name "ALL" is given all store arrays containing objects of type TO are considered.
namedRelationAdditional name for the relation, or "" for the default naming
Returns
Pair of first related object and the relation weight, or (NULL, 1.0) if none found.

Definition at line 299 of file RelationsObject.h.

◆ getRelatedWithWeight()

std::pair<T*, float> getRelatedWithWeight ( const std::string &  name = "",
const std::string &  namedRelation = ""
) const
inlineinherited

Get first related object & weight of relation pointing from/to an array.

Template Parameters
TThe class of objects to or from which the relation points.
Parameters
nameThe name of the store array to or from which the relation points. If empty the default store array name for class T will be used. If the special name "ALL" is given all store arrays containing objects of type T are considered.
namedRelationAdditional name for the relation, or "" for the default naming
Returns
Pair of first related object and the relation weight, or (NULL, 1.0) if none found.

Definition at line 333 of file RelationsObject.h.

◆ getRelationsFrom()

RelationVector<FROM> getRelationsFrom ( const std::string &  name = "",
const std::string &  namedRelation = ""
) const
inlineinherited

Get the relations that point from another store array to this object.

Template Parameters
FROMThe class of objects from which the relations point.
Parameters
nameThe name of the store array from which the relations point. If empty the default store array name for class FROM will be used. If the special name "ALL" is given all store arrays containing objects of type FROM are considered.
namedRelationAdditional name for the relation, or "" for the default naming
Returns
A vector of relations.

Definition at line 214 of file RelationsObject.h.

◆ getRelationsTo()

RelationVector<TO> getRelationsTo ( const std::string &  name = "",
const std::string &  namedRelation = ""
) const
inlineinherited

Get the relations that point from this object to another store array.

Template Parameters
TOThe class of objects to which the relations point.
Parameters
nameThe name of the store array to which the relations point. If empty the default store array name for class TO will be used. If the special name "ALL" is given all store arrays containing objects of type TO are considered.
namedRelationAdditional name for the relation, or "" for the default naming
Returns
A vector of relations.

Definition at line 199 of file RelationsObject.h.

◆ getRelationsWith()

RelationVector<T> getRelationsWith ( const std::string &  name = "",
const std::string &  namedRelation = ""
) const
inlineinherited

Get the relations between this object and another store array.

Relations in both directions are returned.

Template Parameters
TThe class of objects to or from which the relations point.
Parameters
nameThe name of the store array to or from which the relations point. If empty the default store array name for class T will be used. If the special name "ALL" is given all store arrays containing objects of type T are considered.
namedRelationAdditional name for the relation, or "" for the default naming
Returns
A vector of relations.

Definition at line 232 of file RelationsObject.h.

◆ getUUnwedged()

static double getUUnwedged ( const std::pair< double, double > &  hitLocalWedged,
VxdID::baseType  vxdID,
const VXD::SensorInfoBase aSensorInfo = nullptr
)
inlinestatic

takes a wedged uCoordinate, and transforms it to general uCoordinate.

Use this if you want to "unwedge" your u-coordinate. The returned value shall be like the value delivered by a uCluster without information of v (== aCluster.getPosition() ). This is only relevant for wedged/slanted sensors because of their trapezoidal shape, for rectangular shapes, the value does not change

Definition at line 225 of file DATCONSVDSpacePoint.h.

◆ getUWedged()

static double getUWedged ( const std::pair< double, double > &  hitLocalUnwedged,
VxdID  vxdID,
const VXD::SensorInfoBase aSensorInfo = nullptr
)
inlinestatic

takes a general uCoordinate, and transforms it to corrected uCoordinate for wedged sensors.

Use this if you want to add the information of the vCluster to the local uPosition. The returned value is now dependent of vCluster and valid only for this cluster! This is only relevant for wedged/slanted sensors because of their trapezoidal shape, for rectangular shapes, the value does not change

function kept only for backward compatibility with VXDTF1

Definition at line 212 of file DATCONSVDSpacePoint.h.

◆ operator==()

bool operator== ( const DATCONSVDSpacePoint b) const
inline

Compare, if two DATCONSVDSpacePoints are the same one.

As DATCONSVDSpacePoints should live in the DataStore and comparing positions doesn't guarantee, that different underlying clusters are used, we compare here only the indices of the DATCONSVDSpacePoint within their StoreArray --> DATCONSVDSpacePoints are equal, if the share the index.

Definition at line 95 of file DATCONSVDSpacePoint.h.

Friends And Related Function Documentation

◆ operator<<

std::ostream& operator<< ( std::ostream &  out,
const DATCONSVDSpacePoint aSP
)
friend

overloaded '<<' stream operator.

Print secID to stream by converting it to string

Definition at line 87 of file DATCONSVDSpacePoint.h.

Member Data Documentation

◆ m_clustersAssigned

std::pair<bool, bool> m_clustersAssigned {false, false}
protected

The bool value is true, when correct information of the coordinate exists.

.first is true, if this DATCONSVDSpacePoint has a UCluster (only relevant for SVD, PXD always true), .second is true, if this DATCONSVDSpacePoint has a VCluster (only relevant for SVD, PXD always true),

Definition at line 287 of file DATCONSVDSpacePoint.h.

◆ m_isAssigned

bool m_isAssigned {false}
mutableprotected

Stores whether this DATCONSVDSpacePoint is connected to a track.

We assume, that const for DATCONSVDSpacePoint means, things like position et cetera remain constant. The assignment status is therefore a mutable on purpose and DATCONSVDSpacePoints can be const during tracking.

Definition at line 308 of file DATCONSVDSpacePoint.h.

◆ m_normalizedLocal

std::pair<double, double> m_normalizedLocal
protected

Local position vector normalized to sensor size (0 <= x <= 1).

.first: u, .second: v

Definition at line 280 of file DATCONSVDSpacePoint.h.

◆ m_position

B2Vector3<double> m_position
protected

Global position vector.

[0]: x, [1] : y, [2] : z

Definition at line 274 of file DATCONSVDSpacePoint.h.

◆ m_sensorType

VXD::SensorInfoBase::SensorType m_sensorType
protected

Stores the SensorType using the scheme of SensorInfoBase.

Currently there are the following types possible:
PXD, SVD, TEL, VXD

Definition at line 300 of file DATCONSVDSpacePoint.h.


The documentation for this class was generated from the following files:
Belle2::DATCONSVDSpacePoint::m_assignedDATCONSVDClusters
std::vector< SVDCluster > m_assignedDATCONSVDClusters
Vector containing the DATCONSVDClusters assigned to this DATCONSVDSpacePoint.
Definition: DATCONSVDSpacePoint.h:290
Belle2::VXD::GeoCache::getInstance
static GeoCache & getInstance()
Return a reference to the singleton instance.
Definition: GeoCache.cc:215
Belle2::HTML::getString
std::string getString(const TMatrixFBase &matrix, int precision=2, bool color=true)
get HTML table representing a matrix.
Definition: HTML.cc:18
Belle2::DATCONSVDSpacePoint::m_sensorType
VXD::SensorInfoBase::SensorType m_sensorType
Stores the SensorType using the scheme of SensorInfoBase.
Definition: DATCONSVDSpacePoint.h:300
Belle2::DATCONSVDSpacePoint::m_vxdID
VxdID::baseType m_vxdID
Stores the VxdID.
Definition: DATCONSVDSpacePoint.h:293
Belle2::DATCONSVDSpacePoint::m_normalizedLocal
std::pair< double, double > m_normalizedLocal
Local position vector normalized to sensor size (0 <= x <= 1).
Definition: DATCONSVDSpacePoint.h:280
Belle2::DATCONSVDSpacePoint::convertLocalToNormalizedCoordinates
static std::pair< double, double > convertLocalToNormalizedCoordinates(const std::pair< double, double > &hitLocal, VxdID vxdID, const VXD::SensorInfoBase *aSensorInfo=nullptr)
converts a local hit into sensor-independent relative coordinates.
Definition: DATCONSVDSpacePoint.cc:75
Belle2::SVDCluster
The SVD Cluster class This class stores all information about reconstructed SVD clusters.
Definition: SVDCluster.h:38
Belle2::VXD::GeoCache::getSensorInfo
const SensorInfoBase & getSensorInfo(Belle2::VxdID id) const
Return a referecne to the SensorInfo of a given SensorID.
Definition: GeoCache.cc:68
Belle2::DATCONSVDSpacePoint::m_position
B2Vector3< double > m_position
Global position vector.
Definition: DATCONSVDSpacePoint.h:274
Belle2::DATCONSVDSpacePoint::m_clustersAssigned
std::pair< bool, bool > m_clustersAssigned
The bool value is true, when correct information of the coordinate exists.
Definition: DATCONSVDSpacePoint.h:287
