| DirectedNodeNetworkContainer () |
| | Standard constructor.
|
| |
|
| ~DirectedNodeNetworkContainer () |
| | Destructor.
|
| |
| DirectedNodeNetwork< Belle2::ActiveSector< StaticSectorType, Belle2::TrackNode >, Belle2::VoidMetaInfo > & | accessActiveSectorNetwork () |
| | ************************* PUBLIC MEMBER FUNCTIONS ************************* More...
|
| |
|
std::deque< Belle2::ActiveSector< StaticSectorType, Belle2::TrackNode > > & | accessActiveSectors () |
| | Returns reference to the actual ActiveSectors stored in this container, intended for read and write access.
|
| |
|
std::deque< Belle2::TrackNode > & | accessTrackNodes () |
| | Returns reference to the actual trackNodes stored in this container, intended for read and write access.
|
| |
|
DirectedNodeNetwork< Belle2::TrackNode, Belle2::VoidMetaInfo > & | accessHitNetwork () |
| | Returns reference to the HitNetwork stored in this container, intended for read and write access.
|
| |
|
DirectedNodeNetwork< Belle2::Segment< Belle2::TrackNode >, Belle2::CACell > & | accessSegmentNetwork () |
| | Returns reference to the SegmentNetwork stored in this container, intended for read and write access.
|
| |
|
std::deque< Belle2::Segment< Belle2::TrackNode > > & | accessSegments () |
| | Returns reference to the actual segments stored in this container, intended for read and write access.
|
| |
|
int | sizeActiveSectors () |
| | Returns number of activeSectors found.
|
| |
|
int | sizeTrackNodes () |
| | Returns number of trackNodes found.
|
| |
|
int | sizeSegments () |
| | Returns number of segments found.
|
| |
|
int | get_trackNodesCollected () |
| | Returns number of trackNodes collected.
|
| |
|
int | get_activeSectorConnections () |
| | Returns number of activeSectors connections made.
|
| |
|
int | get_trackNodeConnections () |
| | Returns number of trackNodes connections made.
|
| |
|
int | get_segmentConnections () |
| | Returns number of segments connections made.
|
| |
|
int | get_activeSectorAddedConnections () |
| | Returns number of added activeSectors connections made.
|
| |
|
int | get_trackNodeAddedConnections () |
| | Returns number of added trackNodes connections made.
|
| |
|
int | get_segmentAddedConnections () |
| | Returns number of added segments connections made.
|
| |
|
int | get_collectedPaths () |
| | Returns number of paths found.
|
| |
|
void | set_trackNodesCollected (int in) |
| | Sets number of trackNodes collected.
|
| |
|
void | set_activeSectorConnections (int in) |
| | Sets number of activeSectors connections made.
|
| |
|
void | set_trackNodeConnections (int in) |
| | Sets number of trackNodes connections made.
|
| |
|
void | set_segmentConnections (int in) |
| | Sets number of segments connections made.
|
| |
|
void | set_activeSectorAddedConnections (int in) |
| | Sets number of added activeSectors connections made.
|
| |
|
void | set_trackNodeAddedConnections (int in) |
| | Sets number of added trackNodes connections made.
|
| |
|
void | set_segmentAddedConnections (int in) |
| | Sets number of added segments connections made.
|
| |
|
void | set_collectedPaths (int in) |
| | Sets number of paths found.
|
| |
| void | clear () |
| | Clear directed node network container Called to clear the directed node network container if the segment network size grows to large. More...
|
| |
|
void | setVirtualInteractionPoint (B2Vector3D &pos, B2Vector3D &posError) |
| | Passes parameters for creating a virtual interaction point.
|
| |
|
Belle2::TrackNode * | getVirtualInteractionPoint () |
| | Returns reference to the Virtual interactionPoint stored here.
|
| |
| void | addRelationTo (const RelationsInterface< BASE > *object, float weight=1.0, const std::string &namedRelation="") const |
| | Add a relation from this object to another object (with caching). More...
|
| |
| void | addRelationTo (const TObject *object, float weight=1.0, const std::string &namedRelation="") const |
| | Add a relation from this object to another object (no caching, can be quite slow). More...
|
| |
| void | copyRelations (const RelationsInterface< BASE > *sourceObj) |
| | Copies all relations of sourceObj (pointing from or to sourceObj) to this object (including weights). More...
|
| |
| template<class TO > |
| RelationVector< TO > | getRelationsTo (const std::string &name="", const std::string &namedRelation="") const |
| | Get the relations that point from this object to another store array. More...
|
| |
| template<class FROM > |
| RelationVector< FROM > | getRelationsFrom (const std::string &name="", const std::string &namedRelation="") const |
| | Get the relations that point from another store array to this object. More...
|
| |
| template<class T > |
| RelationVector< T > | getRelationsWith (const std::string &name="", const std::string &namedRelation="") const |
| | Get the relations between this object and another store array. More...
|
| |
| template<class TO > |
| TO * | getRelatedTo (const std::string &name="", const std::string &namedRelation="") const |
| | Get the object to which this object has a relation. More...
|
| |
| template<class FROM > |
| FROM * | getRelatedFrom (const std::string &name="", const std::string &namedRelation="") const |
| | Get the object from which this object has a relation. More...
|
| |
| template<class T > |
| T * | getRelated (const std::string &name="", const std::string &namedRelation="") const |
| | Get the object to or from which this object has a relation. More...
|
| |
| template<class TO > |
| std::pair< TO *, float > | getRelatedToWithWeight (const std::string &name="", const std::string &namedRelation="") const |
| | Get first related object & weight of relation pointing to an array. More...
|
| |
| template<class FROM > |
| std::pair< FROM *, float > | getRelatedFromWithWeight (const std::string &name="", const std::string &namedRelation="") const |
| | Get first related object & weight of relation pointing from an array. More...
|
| |
| template<class T > |
| std::pair< T *, float > | getRelatedWithWeight (const std::string &name="", const std::string &namedRelation="") const |
| | Get first related object & weight of relation pointing from/to an array. More...
|
| |
| virtual std::string | getName () const |
| | Return a short name that describes this object, e.g. More...
|
| |
| virtual std::string | getInfoHTML () const |
| | Return a short summary of this object's contents in HTML format. More...
|
| |
| std::string | getInfo () const |
| | Return a short summary of this object's contents in raw text format. More...
|
| |
|
std::string | getArrayName () const |
| | Get name of array this object is stored in, or "" if not found.
|
| |
|
int | getArrayIndex () const |
| | Returns this object's array index (in StoreArray), or -1 if not found.
|
| |
|
| ClassDef(DirectedNodeNetworkContainer, 10) protected int | m_activeSectorConnections = 0 |
| | Making the Class a ROOT class last member changed: added metaInfo for DirectedNodeNetwork. More...
|
| |
|
int | m_trackNodeConnections = 0 |
| | Number of trackNodes connections made.
|
| |
|
int | m_segmentConnections = 0 |
| | Number of segments connections made.
|
| |
|
int | m_activeSectorAddedConnections = 0 |
| | Number of added activeSectors connections made.
|
| |
|
int | m_trackNodeAddedConnections = 0 |
| | Number of added trackNodes connections made.
|
| |
|
int | m_segmentAddedConnections = 0 |
| | Number of added segments connections made.
|
| |
|
int | m_collectedPaths = 0 |
| | Number of paths found.
|
| |
| DirectedNodeNetwork< ActiveSector< StaticSectorType, TrackNode >, Belle2::VoidMetaInfo > | m_ActiveSectorNetwork |
| | ************************* DATA MEMBERS ************************* More...
|
| |
|
std::deque< ActiveSector< StaticSectorType, TrackNode > > | m_activeSectors |
| | Stores the actual ActiveSectors, since the ActiveSectorNetwork does only keep references.
|
| |
|
DirectedNodeNetwork< TrackNode, Belle2::VoidMetaInfo > | m_HitNetwork |
| | Stores the full network of TrackNode< SpaacePoint>, which were accepted by activated two-hit-filters of the assigned sectorMap.
|
| |
|
std::deque< TrackNode > | m_trackNodes |
| | Stores the actual trackNodes, since the SegmentNetwork does only keep references.
|
| |
|
DirectedNodeNetwork< Segment< TrackNode >, Belle2::CACell > | m_SegmentNetwork |
| | Stores the full network of Segments, which were accepted by activated three-hit-filters of the assigned sectorMap.
|
| |
|
std::deque< Segment< TrackNode > > | m_segments |
| | Stores the actual Segments, since the SegmentNetwork does only keep references.
|
| |
|
Belle2::TrackNode * | m_VirtualInteractionPoint |
| | Stores a SpacePoint representing the virtual interaction point if set, NULL if not.
|
| |
|
SpacePoint * | m_VIPSpacePoint |
| | Stores the SpacePoint needed for the virtual IP.
|
| |
|
DataStore::StoreEntry * | m_cacheDataStoreEntry |
| | Cache of the data store entry to which this object belongs.
|
| |
|
int | m_cacheArrayIndex |
| | Cache of the index in the TClonesArray to which this object belongs.
|
| |
The Container stores the output produced by the SegmentNetworkProducerModule.
Is coupled to an assigned static sectorMap, which influences the structure of the DirectedNodeNetworks stored in this container. Is intended to be filled event-wise and not to be stored in root-files.
WARNING: all data members which are followed by "//!" will not be streamed by root (so no I/O for them)
TODO: create constructor for vIPs in SpacePoint. What about activeSectors for vIP? -> solution dependent of treatment in static sectorMap.
Definition at line 50 of file DirectedNodeNetworkContainer.h.
