The SVD ShaperDigit class. More...

#include <SVDShaperDigit.h>

Inheritance diagram for SVDShaperDigit:

[legend]

Collaboration diagram for SVDShaperDigit:

[legend]

Public Types
typedef uint8_t	APVRawSampleType
	Types for array of samples received from DAQ. More...

typedef std::array< APVRawSampleType, c_nAPVSamples >	APVRawSamples
	array of APVRawSamplesType objects

typedef float	APVFloatSampleType
	Types for array of samples for processing.

typedef std::array< APVFloatSampleType, c_nAPVSamples >	APVFloatSamples
	array of APVFloatSampleType objects

enum	EAppendStatus { c_DontAppend = 0, c_Append = 1 }
	Enum for return state of addBGDigit function. More...

Public Member Functions
template<typename T >
	SVDShaperDigit (VxdID sensorID, bool isU, short cellID, T samples[c_nAPVSamples], int8_t FADCTime=0, SVDModeByte mode=SVDModeByte())
	Constructor using c-array of samples. More...

template<typename T >
	SVDShaperDigit (VxdID sensorID, bool isU, short cellID, T samples, int8_t FADCTime=0, SVDModeByte mode=SVDModeByte())
	Constructor using a stl container of samples. More...

	SVDShaperDigit ()
	Default constructor for the ROOT IO.

VxdID	getSensorID () const
	Get the sensor ID. More...

VxdID::baseType	getRawSensorID () const
	Get raw sensor ID. More...

bool	isUStrip () const
	Get strip direction. More...

short int	getCellID () const
	Get strip ID. More...

APVFloatSamples	getSamples () const
	Get array of samples. More...

int	getMaxTimeBin () const
	Get the max bin. More...

int	getMaxADCCounts () const
	Get the ADC counts corresponding to the higher sample amplitude. More...

float	getFADCTime () const
	Get digit FADCTime estimate. More...

SVDModeByte	getModeByte () const
	Get the SVDMOdeByte object containing information on trigger FADCTime and DAQ mode. More...

std::string	toString () const
	Display main parameters in this object.

unsigned int	getUniqueChannelID () const override
	Implementation of base class function. More...

DigitBase::EAppendStatus	addBGDigit (const DigitBase *bg) override
	Implementation of base class function. More...

bool	operator< (const SVDShaperDigit &x) const

bool	passesZS (int nSamples, float cutMinSignal) const
	does the strip pass the ZS cut? More...

void	addRelationTo (const RelationsInterface< BASE > *object, float weight=1.0, const std::string &namedRelation="") const
	Add a relation from this object to another object (with caching). More...

void	addRelationTo (const TObject *object, float weight=1.0, const std::string &namedRelation="") const
	Add a relation from this object to another object (no caching, can be quite slow). More...

void	copyRelations (const RelationsInterface< BASE > *sourceObj)
	Copies all relations of sourceObj (pointing from or to sourceObj) to this object (including weights). More...

template<class TO >
RelationVector< TO >	getRelationsTo (const std::string &name="", const std::string &namedRelation="") const
	Get the relations that point from this object to another store array. More...

template<class FROM >
RelationVector< FROM >	getRelationsFrom (const std::string &name="", const std::string &namedRelation="") const
	Get the relations that point from another store array to this object. More...

template<class T >
RelationVector< T >	getRelationsWith (const std::string &name="", const std::string &namedRelation="") const
	Get the relations between this object and another store array. More...

template<class TO >
TO *	getRelatedTo (const std::string &name="", const std::string &namedRelation="") const
	Get the object to which this object has a relation. More...

template<class FROM >
FROM *	getRelatedFrom (const std::string &name="", const std::string &namedRelation="") const
	Get the object from which this object has a relation. More...

template<class T >
T *	getRelated (const std::string &name="", const std::string &namedRelation="") const
	Get the object to or from which this object has a relation. More...

template<class TO >
std::pair< TO *, float >	getRelatedToWithWeight (const std::string &name="", const std::string &namedRelation="") const
	Get first related object & weight of relation pointing to an array. More...

template<class FROM >
std::pair< FROM *, float >	getRelatedFromWithWeight (const std::string &name="", const std::string &namedRelation="") const
	Get first related object & weight of relation pointing from an array. More...

template<class T >
std::pair< T *, float >	getRelatedWithWeight (const std::string &name="", const std::string &namedRelation="") const
	Get first related object & weight of relation pointing from/to an array. More...

virtual std::string	getName () const
	Return a short name that describes this object, e.g. More...

virtual std::string	getInfoHTML () const
	Return a short summary of this object's contents in HTML format. More...

std::string	getInfo () const
	Return a short summary of this object's contents in raw text format. More...

std::string	getArrayName () const
	Get name of array this object is stored in, or "" if not found.

int	getArrayIndex () const
	Returns this object's array index (in StoreArray), or -1 if not found.

Static Public Member Functions
template<typename T >
static SVDShaperDigit::APVRawSampleType	trimToSampleRange (T x)
	Convert a value to sample range. More...

Static Public Attributes
static const std::size_t	c_nAPVSamples = 6
	Number of APV samples stored.

Protected Member Functions
TClonesArray *	getArrayPointer () const
	Returns the pointer to the raw DataStore array holding this object (protected since these arrays are easy to misuse).

Private Member Functions
	ClassDef (DigitBase, 2)
	ClassDef.

Private Attributes
VxdID::baseType	m_sensorID = 0
	Compressed sensor identifier.

bool	m_isU = false
	True if U, false if V.

short	m_cellID = 0
	Strip coordinate in pitch units.

APVRawSamples	m_samples
	6 APV signals from the strip.

int8_t	m_FADCTime = 0
	digit time estimate from the FADC, in ns

SVDModeByte::baseType	m_mode = SVDModeByte::c_DefaultID
	Mode byte, trigger FADCTime + DAQ mode.

DataStore::StoreEntry *	m_cacheDataStoreEntry
	Cache of the data store entry to which this object belongs.

int	m_cacheArrayIndex
	Cache of the index in the TClonesArray to which this object belongs.

Detailed Description

The SVD ShaperDigit class.

The SVDShaperDigit holds a set of 6 raw APV25 signal samples, zero-padded in 3-sample mode) taken on a strip. It also holds DAQ mode (3 or 6 samples) and trigger time information in an SVDModeByte structure, and time fit from FADC (when available).

Definition at line 46 of file SVDShaperDigit.h.

Member Typedef Documentation

◆ APVRawSampleType

typedef uint8_t APVRawSampleType

Types for array of samples received from DAQ.

An integer type is sufficient for storage, but getters will return array of doubles suitable for computing.

Definition at line 57 of file SVDShaperDigit.h.

Member Enumeration Documentation

◆ EAppendStatus

enum EAppendStatus

inherited

Enum for return state of addBGDigit function.

Enumerator
c_DontAppend	do not append BG digit to digits
c_Append	append BG digit to digits

Definition at line 42 of file DigitBase.h.

Constructor & Destructor Documentation

◆ SVDShaperDigit() [1/2]

SVDShaperDigit	(	VxdID	sensorID,
		bool	isU,
		short	cellID,
		T	samples[c_nAPVSamples],
		int8_t	FADCTime = `0`,
		SVDModeByte	mode = `SVDModeByte()`
	)

inline

Constructor using c-array of samples.

Parameters

sensorID	Sensor VXD ID.
isU	True if u strip, false if v.
cellID	Strip ID.
samples	std::array of 6 APV raw samples.
FADCTime	Time estimate from FADC
mode	SVDModeByte structure, packed trigger time bin and DAQ mode.

Definition at line 75 of file SVDShaperDigit.h.

89 :

90 m_sensorID(sensorID), m_isU(isU), m_cellID(cellID), m_FADCTime(FADCTime),

◆ SVDShaperDigit() [2/2]

SVDShaperDigit	(	VxdID	sensorID,
		bool	isU,
		short	cellID,
		T	samples,
		int8_t	FADCTime = `0`,
		SVDModeByte	mode = `SVDModeByte()`
	)

inline

Constructor using a stl container of samples.

Parameters

sensorID	Sensor VXD ID.
isU	True if u strip, false if v.
cellID	Strip ID.
samples	std::array of 6 APV raw samples.
FADCTime	Time estimate from FADC
mode	SVDModeByte structure, packed trigger time bin and DAQ mode.

Definition at line 96 of file SVDShaperDigit.h.

Member Function Documentation

◆ addBGDigit()

DigitBase::EAppendStatus addBGDigit ( const DigitBase * bg )

inlineoverridevirtual

Implementation of base class function.

Addition is always possible, so we always return successful merge. Pile-up method.

Parameters

bg	beam background digit

Returns: append status

Implements DigitBase.

Definition at line 233 of file SVDShaperDigit.h.

◆ addRelationTo() [1/2]

void addRelationTo	(	const RelationsInterface< BASE > *	object,
		float	weight = `1.0`,
		const std::string &	namedRelation = `""`
	)		const

inlineinherited

Add a relation from this object to another object (with caching).

Parameters

object	The object to which the relation should point.
weight	The weight of the relation.
namedRelation	Additional name for the relation, or "" for the default naming

Definition at line 144 of file RelationsObject.h.

◆ addRelationTo() [2/2]

void addRelationTo	(	const TObject *	object,
		float	weight = `1.0`,
		const std::string &	namedRelation = `""`
	)		const

inlineinherited

Add a relation from this object to another object (no caching, can be quite slow).

Parameters

object	The object to which the relation should point.
weight	The weight of the relation.
namedRelation	Additional name for the relation, or "" for the default naming

Definition at line 157 of file RelationsObject.h.

◆ copyRelations()

void copyRelations ( const RelationsInterface< BASE > * sourceObj )

inlineinherited

Copies all relations of sourceObj (pointing from or to sourceObj) to this object (including weights).

Useful if you want to make a complete copy of a StoreArray object to make modifications to it, but retain all information on linked objects.

Note: this only works if sourceObj inherits from the same base (e.g. RelationsObject), and only for related objects that also inherit from the same base.

Definition at line 172 of file RelationsObject.h.

◆ getCellID()

short int getCellID ( ) const

inline

Get strip ID.

Returns: ID of the strip.

Definition at line 132 of file SVDShaperDigit.h.

◆ getFADCTime()

float getFADCTime ( ) const

inline

Get digit FADCTime estimate.

Returns: digit time estimate from FADC

Definition at line 174 of file SVDShaperDigit.h.

◆ getInfo()

std::string getInfo ( ) const

inlineinherited

Return a short summary of this object's contents in raw text format.

Returns the contents of getInfoHTML() while translating line-breaks etc.

Note: : You don't need to implement this function (it's not virtual), getInfoHTML() is enough.

Definition at line 372 of file RelationsObject.h.

◆ getInfoHTML()

virtual std::string getInfoHTML ( ) const

inlinevirtualinherited

Return a short summary of this object's contents in HTML format.

Reimplement this in your own class to provide useful output for display or debugging purposes. For example, you might do something like:

std::stringstream out;
out << "<b>PDG</b>: " << m_pdg << "<br>";
out << "<b>Covariance Matrix</b>: " << HTML::getString(getCovariance5()) << "<br>";
return out.str();

See also: Particle::getInfoHTML() for a more complex example.; HTML for some utility functions.; Use getInfo() to get a raw text version of this output.

Reimplemented in TrackFitResult, TRGSummary, Track, SoftwareTriggerResult, Particle, RecoTrack, MCParticle, Cluster, and PIDLikelihood.

Definition at line 364 of file RelationsObject.h.

◆ getMaxADCCounts()

int getMaxADCCounts ( ) const

inline

Get the ADC counts corresponding to the higher sample amplitude.

Returns: int of the ADC counts corresponding to the higher sample amplitude

Definition at line 162 of file SVDShaperDigit.h.

◆ getMaxTimeBin()

int getMaxTimeBin ( ) const

inline

Get the max bin.

Returns: int time bin corresponding to the higher sample amplitude

Definition at line 150 of file SVDShaperDigit.h.

◆ getModeByte()

SVDModeByte getModeByte ( ) const

inline

Get the SVDMOdeByte object containing information on trigger FADCTime and DAQ mode.

Returns: the SVDModeByte object of the digit

Definition at line 180 of file SVDShaperDigit.h.

◆ getName()

virtual std::string getName ( ) const

inlinevirtualinherited

Return a short name that describes this object, e.g.

pi+ for an MCParticle.

Reimplemented in SpacePoint, Particle, and MCParticle.

Definition at line 346 of file RelationsObject.h.

◆ getRawSensorID()

VxdID::baseType getRawSensorID ( ) const

inline

Get raw sensor ID.

For use in Python

Returns: basetype ID of the sensor.

Definition at line 122 of file SVDShaperDigit.h.

◆ getRelated()

T* getRelated	(	const std::string &	name = `""`,
		const std::string &	namedRelation = `""`
	)		const

inlineinherited

Get the object to or from which this object has a relation.

Template Parameters

T	The class of objects to or from which the relation points.

Parameters

name	The name of the store array to or from which the relation points. If empty the default store array name for class T will be used. If the special name "ALL" is given all store arrays containing objects of type T are considered.
namedRelation	Additional name for the relation, or "" for the default naming

Returns: The first related object or a null pointer.

Definition at line 280 of file RelationsObject.h.

◆ getRelatedFrom()

FROM* getRelatedFrom	(	const std::string &	name = `""`,
		const std::string &	namedRelation = `""`
	)		const

inlineinherited

Get the object from which this object has a relation.

Template Parameters

FROM	The class of objects from which the relation points.

Parameters

name	The name of the store array from which the relation points. If empty the default store array name for class FROM will be used. If the special name "ALL" is given all store arrays containing objects of type FROM are considered.
namedRelation	Additional name for the relation, or "" for the default naming

Returns: The first related object or a null pointer.

Definition at line 265 of file RelationsObject.h.

◆ getRelatedFromWithWeight()

std::pair<FROM*, float> getRelatedFromWithWeight	(	const std::string &	name = `""`,
		const std::string &	namedRelation = `""`
	)		const

inlineinherited

Get first related object & weight of relation pointing from an array.

Template Parameters

FROM	The class of objects from which the relation points.

Parameters

name	The name of the store array from which the relation points. If empty the default store array name for class FROM will be used. If the special name "ALL" is given all store arrays containing objects of type FROM are considered.
namedRelation	Additional name for the relation, or "" for the default naming

Returns: Pair of first related object and the relation weight, or (NULL, 1.0) if none found.

Definition at line 316 of file RelationsObject.h.

◆ getRelatedTo()

TO* getRelatedTo	(	const std::string &	name = `""`,
		const std::string &	namedRelation = `""`
	)		const

inlineinherited

Get the object to which this object has a relation.

Template Parameters

TO	The class of objects to which the relation points.

Parameters

name	The name of the store array to which the relation points. If empty the default store array name for class TO will be used. If the special name "ALL" is given all store arrays containing objects of type TO are considered.
namedRelation	Additional name for the relation, or "" for the default naming

Returns: The first related object or a null pointer.

Definition at line 250 of file RelationsObject.h.

◆ getRelatedToWithWeight()

std::pair<TO*, float> getRelatedToWithWeight	(	const std::string &	name = `""`,
		const std::string &	namedRelation = `""`
	)		const

inlineinherited

Get first related object & weight of relation pointing to an array.

Template Parameters

TO	The class of objects to which the relation points.

Parameters

name	The name of the store array to which the relation points. If empty the default store array name for class TO will be used. If the special name "ALL" is given all store arrays containing objects of type TO are considered.
namedRelation	Additional name for the relation, or "" for the default naming

Returns: Pair of first related object and the relation weight, or (NULL, 1.0) if none found.

Definition at line 299 of file RelationsObject.h.

◆ getRelatedWithWeight()

std::pair<T*, float> getRelatedWithWeight	(	const std::string &	name = `""`,
		const std::string &	namedRelation = `""`
	)		const

inlineinherited

Get first related object & weight of relation pointing from/to an array.

Template Parameters

T	The class of objects to or from which the relation points.

Parameters

name	The name of the store array to or from which the relation points. If empty the default store array name for class T will be used. If the special name "ALL" is given all store arrays containing objects of type T are considered.
namedRelation	Additional name for the relation, or "" for the default naming

Returns: Pair of first related object and the relation weight, or (NULL, 1.0) if none found.

Definition at line 333 of file RelationsObject.h.

◆ getRelationsFrom()

RelationVector<FROM> getRelationsFrom	(	const std::string &	name = `""`,
		const std::string &	namedRelation = `""`
	)		const

inlineinherited

Get the relations that point from another store array to this object.

Template Parameters

FROM	The class of objects from which the relations point.

Parameters

name	The name of the store array from which the relations point. If empty the default store array name for class FROM will be used. If the special name "ALL" is given all store arrays containing objects of type FROM are considered.
namedRelation	Additional name for the relation, or "" for the default naming

Returns: A vector of relations.

Definition at line 214 of file RelationsObject.h.

◆ getRelationsTo()

RelationVector<TO> getRelationsTo	(	const std::string &	name = `""`,
		const std::string &	namedRelation = `""`
	)		const

inlineinherited

Get the relations that point from this object to another store array.

Template Parameters

TO	The class of objects to which the relations point.

Parameters

name	The name of the store array to which the relations point. If empty the default store array name for class TO will be used. If the special name "ALL" is given all store arrays containing objects of type TO are considered.
namedRelation	Additional name for the relation, or "" for the default naming

Returns: A vector of relations.

Definition at line 199 of file RelationsObject.h.

◆ getRelationsWith()

RelationVector<T> getRelationsWith	(	const std::string &	name = `""`,
		const std::string &	namedRelation = `""`
	)		const

inlineinherited

Get the relations between this object and another store array.

Relations in both directions are returned.

Template Parameters

T	The class of objects to or from which the relations point.

Parameters

name	The name of the store array to or from which the relations point. If empty the default store array name for class T will be used. If the special name "ALL" is given all store arrays containing objects of type T are considered.
namedRelation	Additional name for the relation, or "" for the default naming

Returns: A vector of relations.

Definition at line 232 of file RelationsObject.h.

◆ getSamples()

APVFloatSamples getSamples ( ) const

inline

Get array of samples.

Returns: std::array of 6 APV25 samples.

Definition at line 137 of file SVDShaperDigit.h.

◆ getSensorID()

VxdID getSensorID ( ) const

inline

Get the sensor ID.

Returns: ID of the sensor.

Definition at line 116 of file SVDShaperDigit.h.

◆ getUniqueChannelID()

unsigned int getUniqueChannelID ( ) const

inlineoverridevirtual

Implementation of base class function.

Enables BG overlay module to identify uniquely the physical channel of this Digit.

Returns: unique channel ID, composed of VxdID (1 - 16), strip side (17), and strip number (18-28)

Implements DigitBase.

Definition at line 223 of file SVDShaperDigit.h.

◆ isUStrip()

bool isUStrip ( ) const

inline

Get strip direction.

Returns: true if u, false if v.

Definition at line 127 of file SVDShaperDigit.h.

◆ operator<()

bool operator< ( const SVDShaperDigit & x ) const

inline

Parameters

Definition at line 253 of file SVDShaperDigit.h.

◆ passesZS()

bool passesZS	(	int	nSamples,
		float	cutMinSignal
	)		const

inline

does the strip pass the ZS cut?

Parameters

nSamples	min number of samples above threshold
cutMinSignal	SN threshold

Returns: true if the strip have st least nSamples above threshold, false otherwise

Definition at line 269 of file SVDShaperDigit.h.

◆ trimToSampleRange()

static SVDShaperDigit::APVRawSampleType trimToSampleRange ( T x )

inlinestatic

Convert a value to sample range.

Parameters

value to be converted

Returns: APVRawSampleType representation of x

Definition at line 188 of file SVDShaperDigit.h.

The documentation for this class was generated from the following file:

svd/dataobjects/include/SVDShaperDigit.h

Public Types

Public Member Functions

Static Public Member Functions

Static Public Attributes

Protected Member Functions

Private Member Functions

Private Attributes

Detailed Description

Member Typedef Documentation

◆ APVRawSampleType

Member Enumeration Documentation

◆ EAppendStatus

Constructor & Destructor Documentation

◆ SVDShaperDigit() [1/2]

◆ SVDShaperDigit() [2/2]

Member Function Documentation

◆ addBGDigit()

◆ addRelationTo() [1/2]

◆ addRelationTo() [2/2]

◆ copyRelations()

◆ getCellID()

◆ getFADCTime()

◆ getInfo()

◆ getInfoHTML()

◆ getMaxADCCounts()

◆ getMaxTimeBin()

◆ getModeByte()

◆ getName()

◆ getRawSensorID()

◆ getRelated()

◆ getRelatedFrom()

◆ getRelatedFromWithWeight()

◆ getRelatedTo()

◆ getRelatedToWithWeight()

◆ getRelatedWithWeight()

◆ getRelationsFrom()

◆ getRelationsTo()

◆ getRelationsWith()

◆ getSamples()

◆ getSensorID()

◆ getUniqueChannelID()

◆ isUStrip()

◆ operator<()

◆ passesZS()

◆ trimToSampleRange()
