TOPDigit Class Reference

Class to store TOP digitized hits (output of TOPDigitizer or raw data unpacker) relations to TOPSimHits, MCParticles. More...

#include <TOPDigit.h>

Inheritance diagram for TOPDigit:

Collaboration diagram for TOPDigit:

Public Types
enum	EHitQuality {   c_Junk = 0,   c_Good = 1,   c_CrossTalk = 3,   c_CalPulse = 4,   c_Uncalibrated = 5,   c_Masked = 6 }
	hit quality enumerators More...
enum	EStatusBits {   c_TimeBaseCalibrated = 1,   c_ChannelT0Calibrated = 2,   c_ModuleT0Calibrated = 4,   c_CommonT0Calibrated = 8,   c_FullyCalibrated = c_TimeBaseCalibrated | c_ChannelT0Calibrated | c_ModuleT0Calibrated | c_CommonT0Calibrated,   c_OffsetSubtracted = 16,   c_EventT0Subtracted = 32,   c_BunchOffsetSubtracted = 64 }
	calibration status enumerators
enum	EChargeShare {   c_PrimaryChargeShare = 1,   c_SecondaryChargeShare = 2 }
	charge sharing enumerators More...
enum	EAppendStatus {   c_DontAppend = 0,   c_Append = 1 }
	Enum for return state of addBGDigit function. More...

Public Member Functions
	TOPDigit ()
	Default constructor.
	TOPDigit (int moduleID, int pixelID, double rawTime)
	Usefull constructor. More...
void	setModuleID (int moduleID)
	Sets module ID. More...
void	setPixelID (int pixelID)
	Sets pixel ID. More...
void	setChannel (unsigned int channel)
	Sets hardware channel number (0-based) More...
void	setRawTime (double rawTime)
	Sets raw detection time. More...
void	setTime (double time)
	Sets calibrated detection time. More...
void	setTimeError (double timeError)
	Sets calibrated time uncertainty. More...
void	setPulseHeight (int pulseHeight)
	Sets pulse height. More...
void	setPulseWidth (double width)
	Sets pulse width. More...
void	setIntegral (int integral)
	Sets pulse integral. More...
void	setFirstWindow (unsigned window)
	Sets first ASIC window number of the merged waveform this hit is taken from. More...
void	setHitQuality (EHitQuality quality)
	Sets hit quality flag. More...
void	setStatus (unsigned short status)
	Sets calibration status (overwrites previously set bits)
void	addStatus (unsigned short bitmask)
	Add calibration status.
void	removeStatus (unsigned short bitmask)
	Remove calibration status.
void	setPrimaryChargeShare ()
	Sets primary charge share flag.
void	setSecondaryChargeShare ()
	Sets secondary charge share flag.
void	resetChargeShare ()
	Remove charge share flag.
void	subtractT0 (double t0)
	Subtract start time from m_time. More...
EHitQuality	getHitQuality () const
	Returns hit quality. More...
unsigned short	getStatus () const
	Returns calibration status bits. More...
bool	hasStatus (unsigned short bitmask) const
	Returns calibration status. More...
bool	isCalibrated () const
	Returns calibration status. More...
bool	isTimeBaseCalibrated () const
	Returns calibration status. More...
bool	isChannelT0Calibrated () const
	Returns calibration status. More...
bool	isModuleT0Calibrated () const
	Returns calibration status. More...
bool	isCommonT0Calibrated () const
	Returns calibration status. More...
bool	isChargeShare () const
	Returns charge share status. More...
bool	isPrimaryChargeShare () const
	Returns charge share status. More...
bool	isSecondaryChargeShare () const
	Returns charge share status. More...
int	getModuleID () const
	Returns module ID. More...
int	getPixelID () const
	Returns pixel ID (1-based) More...
int	getPixelRow () const
	Returns pixel row number (1-based) More...
int	getPixelCol () const
	Returns pixel column number (1-based) More...
int	getPMTRow () const
	Returns PMT row number (1-based) More...
int	getPMTCol () const
	Returns PMT column number (1-based) More...
int	getPMTNumber () const
	Returns PMT number (1-based) More...
int	getPMTPixelRow () const
	Returns PMT pixel row number (1-based) More...
int	getPMTPixelCol () const
	Returns PMT pixel column number (1-based) More...
int	getPMTPixel () const
	Returns PMT pixel number (1-based) More...
unsigned int	getChannel () const
	Returns hardware channel number. More...
unsigned int	getASICChannel () const
	Returns ASIC channel number. More...
unsigned int	getASICNumber () const
	Returns ASIC number. More...
unsigned int	getCarrierNumber () const
	Returns carrier board number. More...
unsigned int	getBoardstackNumber () const
	Returns boardstack number. More...
double	getRawTime () const
	Returns raw detection time. More...
int	getModulo256Sample () const
	Returns sample number modulo 256. More...
double	getTime () const
	Returns t0-subtracted and calibrated time. More...
double	getTimeError () const
	Returns calibrated time uncertainty. More...
int	getPulseHeight () const
	Returns pulse height. More...
double	getPulseWidth () const
	Returns pulse width. More...
int	getIntegral () const
	Returns pulse integral. More...
unsigned	getFirstWindow () const
	Returns first ASIC window number of the merged waveform this hit is taken from. More...
unsigned int	getUniqueChannelID () const override
	Implementation of the base class function. More...
DigitBase::EAppendStatus	addBGDigit (const DigitBase *bg) override
	Implementation of the base class function. More...
void	addRelationTo (const RelationsInterface< BASE > *object, float weight=1.0, const std::string &namedRelation="") const
	Add a relation from this object to another object (with caching). More...
void	addRelationTo (const TObject *object, float weight=1.0, const std::string &namedRelation="") const
	Add a relation from this object to another object (no caching, can be quite slow). More...
void	copyRelations (const RelationsInterface< BASE > *sourceObj)
	Copies all relations of sourceObj (pointing from or to sourceObj) to this object (including weights). More...
template<class TO >
RelationVector< TO >	getRelationsTo (const std::string &name="", const std::string &namedRelation="") const
	Get the relations that point from this object to another store array. More...
template<class FROM >
RelationVector< FROM >	getRelationsFrom (const std::string &name="", const std::string &namedRelation="") const
	Get the relations that point from another store array to this object. More...
template<class T >
RelationVector< T >	getRelationsWith (const std::string &name="", const std::string &namedRelation="") const
	Get the relations between this object and another store array. More...
template<class TO >
TO *	getRelatedTo (const std::string &name="", const std::string &namedRelation="") const
	Get the object to which this object has a relation. More...
template<class FROM >
FROM *	getRelatedFrom (const std::string &name="", const std::string &namedRelation="") const
	Get the object from which this object has a relation. More...
template<class T >
T *	getRelated (const std::string &name="", const std::string &namedRelation="") const
	Get the object to or from which this object has a relation. More...
template<class TO >
std::pair< TO *, float >	getRelatedToWithWeight (const std::string &name="", const std::string &namedRelation="") const
	Get first related object & weight of relation pointing to an array. More...
template<class FROM >
std::pair< FROM *, float >	getRelatedFromWithWeight (const std::string &name="", const std::string &namedRelation="") const
	Get first related object & weight of relation pointing from an array. More...
template<class T >
std::pair< T *, float >	getRelatedWithWeight (const std::string &name="", const std::string &namedRelation="") const
	Get first related object & weight of relation pointing from/to an array. More...
virtual std::string	getName () const
	Return a short name that describes this object, e.g. More...
virtual std::string	getInfoHTML () const
	Return a short summary of this object's contents in HTML format. More...
std::string	getInfo () const
	Return a short summary of this object's contents in raw text format. More...
std::string	getArrayName () const
	Get name of array this object is stored in, or "" if not found.
int	getArrayIndex () const
	Returns this object's array index (in StoreArray), or -1 if not found.

Static Public Member Functions
static void	setDoubleHitResolution (double time)
	Sets double hit resolution. More...
static void	setPileupTime (double time)
	Sets pile-up time. More...

Protected Member Functions
TClonesArray *	getArrayPointer () const
	Returns the pointer to the raw DataStore array holding this object (protected since these arrays are easy to misuse).

Private Member Functions
	ClassDefOverride (TOPDigit, 15)
	ClassDef.
	ClassDef (DigitBase, 2)
	ClassDef.

Private Attributes
int	m_moduleID = 0
	module ID (1-based)
int	m_pixelID = 0
	software channel ID (1-based)
unsigned	m_channel = 0
	hardware channel number (0-based)
float	m_rawTime = 0
	raw time expressed in samples (TDC bins)
float	m_time = 0
	calibrated time in [ns], t0-subtracted
float	m_timeError = 0
	time uncertainty (r.m.s) in [ns]
int	m_pulseHeight = 0
	pulse height [ADC counts]
float	m_pulseWidth = 0
	pulse width (FWHM) in [ns]
int	m_integral = 0
	pulse integral [ADC counts]
unsigned short	m_firstWindow = 0
	first ASIC window of the merged waveform
EHitQuality	m_quality = c_Junk
	hit quality
unsigned short	m_status = 0
	calibration status bits
unsigned short	m_chargeShare = 0
	charge sharing flags
DataStore::StoreEntry *	m_cacheDataStoreEntry
	Cache of the data store entry to which this object belongs.
int	m_cacheArrayIndex
	Cache of the index in the TClonesArray to which this object belongs.

Static Private Attributes
static float	s_doubleHitResolution = 0
	double hit resolving time in [ns]
static float	s_pileupTime = 0
	pile-up time in [ns]

Detailed Description

Class to store TOP digitized hits (output of TOPDigitizer or raw data unpacker) relations to TOPSimHits, MCParticles.

Definition at line 34 of file TOPDigit.h.

Member Enumeration Documentation

EAppendStatus

enum EAppendStatus

inherited

Enum for return state of addBGDigit function.

Enumerator
c_DontAppend	do not append BG digit to digits
c_Append	append BG digit to digits

Definition at line 42 of file DigitBase.h.

EChargeShare

enum EChargeShare

charge sharing enumerators

Enumerator
c_PrimaryChargeShare	the largest one among hits sharing the same charge
c_SecondaryChargeShare	others sharing the same charge

Definition at line 69 of file TOPDigit.h.

    {}


EHitQuality

enum EHitQuality

hit quality enumerators

Note: the only allowed place for switching c_Good to c_Masked or c_Uncalibrated is TOPChannelMasker because this information must also be passed to reconstruction

Definition at line 43 of file TOPDigit.h.

Constructor & Destructor Documentation

TOPDigit()

TOPDigit ( int  moduleID, int  pixelID, double  rawTime  )

inline

Usefull constructor.

Parameters

moduleID	module ID (1-based)
pixelID	pixel ID (1-based)
rawTime	raw time expressed in samples (TDC bins)

Definition at line 86 of file TOPDigit.h.

Member Function Documentation

addRelationTo() [1/2]

void addRelationTo ( const RelationsInterface< BASE > *  object, float  weight = 1.0, const std::string &  namedRelation = ""  ) const

inlineinherited

Add a relation from this object to another object (with caching).

Parameters

object	The object to which the relation should point.
weight	The weight of the relation.
namedRelation	Additional name for the relation, or "" for the default naming

Definition at line 144 of file RelationsObject.h.

addRelationTo() [2/2]

void addRelationTo ( const TObject *  object, float  weight = 1.0, const std::string &  namedRelation = ""  ) const

inlineinherited

Add a relation from this object to another object (no caching, can be quite slow).

Parameters

object	The object to which the relation should point.
weight	The weight of the relation.
namedRelation	Additional name for the relation, or "" for the default naming

Definition at line 157 of file RelationsObject.h.

copyRelations()

void copyRelations ( const RelationsInterface< BASE > *  sourceObj )

inlineinherited

Copies all relations of sourceObj (pointing from or to sourceObj) to this object (including weights).

Useful if you want to make a complete copy of a StoreArray object to make modifications to it, but retain all information on linked objects.

Note: this only works if sourceObj inherits from the same base (e.g. RelationsObject), and only for related objects that also inherit from the same base.

Definition at line 172 of file RelationsObject.h.

getASICChannel()

unsigned int getASICChannel ( ) const

inline

Returns ASIC channel number.

Returns

ASIC channel number

Definition at line 346 of file TOPDigit.h.

getASICNumber()

unsigned int getASICNumber ( ) const

inline

Returns ASIC number.

Returns

ASIC number

Definition at line 352 of file TOPDigit.h.

getBoardstackNumber()

unsigned int getBoardstackNumber ( ) const

inline

Returns boardstack number.

Returns

boardstack number

Definition at line 364 of file TOPDigit.h.

getCarrierNumber()

unsigned int getCarrierNumber ( ) const

inline

Returns carrier board number.

Returns

carrier board number

Definition at line 358 of file TOPDigit.h.

getChannel()

unsigned int getChannel ( ) const

inline

Returns hardware channel number.

Returns

hardware channel number

Definition at line 340 of file TOPDigit.h.

getFirstWindow()

unsigned getFirstWindow ( ) const

inline

Returns first ASIC window number of the merged waveform this hit is taken from.

Returns

window number

Definition at line 412 of file TOPDigit.h.

getHitQuality()

EHitQuality getHitQuality ( ) const

inline

Returns hit quality.

Returns

hit quality

Definition at line 211 of file TOPDigit.h.

getInfo()

std::string getInfo ( ) const

inlineinherited

Return a short summary of this object's contents in raw text format.

Returns the contents of getInfoHTML() while translating line-breaks etc.

Note

: You don't need to implement this function (it's not virtual), getInfoHTML() is enough.

Definition at line 372 of file RelationsObject.h.

getInfoHTML()

virtual std::string getInfoHTML ( ) const

inlinevirtualinherited

Return a short summary of this object's contents in HTML format.

Reimplement this in your own class to provide useful output for display or debugging purposes. For example, you might do something like:

std::stringstream out;
out << "<b>PDG</b>: " << m_pdg << "<br>";
out << "<b>Covariance Matrix</b>: " << HTML::getString(getCovariance5()) << "<br>";
return out.str();

See also

Particle::getInfoHTML() for a more complex example.

HTML for some utility functions.

Use getInfo() to get a raw text version of this output.

Reimplemented in TrackFitResult, TRGSummary, Track, SoftwareTriggerResult, Particle, RecoTrack, MCParticle, Cluster, and PIDLikelihood.

Definition at line 364 of file RelationsObject.h.

getIntegral()

int getIntegral ( ) const

inline

Returns pulse integral.

Returns

pulse integral [ADC counts]

Definition at line 406 of file TOPDigit.h.

getModuleID()

int getModuleID ( ) const

inline

Returns module ID.

Returns

module ID

Definition at line 280 of file TOPDigit.h.

getName()

virtual std::string getName ( ) const

inlinevirtualinherited

Return a short name that describes this object, e.g.

pi+ for an MCParticle.

Reimplemented in SpacePoint, Particle, and MCParticle.

Definition at line 346 of file RelationsObject.h.

getPixelCol()

int getPixelCol ( ) const

inline

Returns pixel column number (1-based)

Returns

pixel column number

Definition at line 298 of file TOPDigit.h.

getPixelID()

int getPixelID ( ) const

inline

Returns pixel ID (1-based)

Returns

software channel ID

Definition at line 286 of file TOPDigit.h.

getPixelRow()

int getPixelRow ( ) const

inline

Returns pixel row number (1-based)

Returns

pixel row number

Definition at line 292 of file TOPDigit.h.

getPMTCol()

int getPMTCol ( ) const

inline

Returns PMT column number (1-based)

Returns

PMT column number

Definition at line 310 of file TOPDigit.h.

getPMTNumber()

int getPMTNumber ( ) const

inline

Returns PMT number (1-based)

Returns

PMT number

Definition at line 316 of file TOPDigit.h.

getPMTPixel()

int getPMTPixel ( ) const

inline

Returns PMT pixel number (1-based)

Returns

PMT pixel

Definition at line 334 of file TOPDigit.h.

getPMTPixelCol()

int getPMTPixelCol ( ) const

inline

Returns PMT pixel column number (1-based)

Returns

PMT pixel column number

Definition at line 328 of file TOPDigit.h.

getPMTPixelRow()

int getPMTPixelRow ( ) const

inline

Returns PMT pixel row number (1-based)

Returns

PMT pixel row number

Definition at line 322 of file TOPDigit.h.

getPMTRow()

int getPMTRow ( ) const

inline

Returns PMT row number (1-based)

Returns

PMT row number

Definition at line 304 of file TOPDigit.h.

getPulseHeight()

int getPulseHeight ( ) const

inline

Returns pulse height.

Returns

pulse height [ADC counts]

Definition at line 394 of file TOPDigit.h.

getPulseWidth()

double getPulseWidth ( ) const

inline

Returns pulse width.

Returns

pulse width (FWHM) in [ns]

Definition at line 400 of file TOPDigit.h.

getRawTime()

double getRawTime ( ) const

inline

Returns raw detection time.

Returns

time expressed in samples (TDC bins)

Definition at line 370 of file TOPDigit.h.

getRelated()

T* getRelated ( const std::string &  name = "", const std::string &  namedRelation = ""  ) const

inlineinherited

Get the object to or from which this object has a relation.

Template Parameters

T	The class of objects to or from which the relation points.

Parameters

name	The name of the store array to or from which the relation points. If empty the default store array name for class T will be used. If the special name "ALL" is given all store arrays containing objects of type T are considered.
namedRelation	Additional name for the relation, or "" for the default naming

Returns

The first related object or a null pointer.

Definition at line 280 of file RelationsObject.h.

getRelatedFrom()

FROM* getRelatedFrom ( const std::string &  name = "", const std::string &  namedRelation = ""  ) const

inlineinherited

Get the object from which this object has a relation.

Template Parameters

FROM	The class of objects from which the relation points.

Parameters

name	The name of the store array from which the relation points. If empty the default store array name for class FROM will be used. If the special name "ALL" is given all store arrays containing objects of type FROM are considered.
namedRelation	Additional name for the relation, or "" for the default naming

Returns

The first related object or a null pointer.

Definition at line 265 of file RelationsObject.h.

getRelatedFromWithWeight()

std::pair<FROM*, float> getRelatedFromWithWeight ( const std::string &  name = "", const std::string &  namedRelation = ""  ) const

inlineinherited

Get first related object & weight of relation pointing from an array.

Template Parameters

FROM	The class of objects from which the relation points.

Parameters

name	The name of the store array from which the relation points. If empty the default store array name for class FROM will be used. If the special name "ALL" is given all store arrays containing objects of type FROM are considered.
namedRelation	Additional name for the relation, or "" for the default naming

Returns

Pair of first related object and the relation weight, or (NULL, 1.0) if none found.

Definition at line 316 of file RelationsObject.h.

getRelatedTo()

TO* getRelatedTo ( const std::string &  name = "", const std::string &  namedRelation = ""  ) const

inlineinherited

Get the object to which this object has a relation.

Template Parameters

TO	The class of objects to which the relation points.

Parameters

name	The name of the store array to which the relation points. If empty the default store array name for class TO will be used. If the special name "ALL" is given all store arrays containing objects of type TO are considered.
namedRelation	Additional name for the relation, or "" for the default naming

Returns

The first related object or a null pointer.

Definition at line 250 of file RelationsObject.h.

getRelatedToWithWeight()

std::pair<TO*, float> getRelatedToWithWeight ( const std::string &  name = "", const std::string &  namedRelation = ""  ) const

inlineinherited

Get first related object & weight of relation pointing to an array.

Template Parameters

TO	The class of objects to which the relation points.

Parameters

name	The name of the store array to which the relation points. If empty the default store array name for class TO will be used. If the special name "ALL" is given all store arrays containing objects of type TO are considered.
namedRelation	Additional name for the relation, or "" for the default naming

Returns

Pair of first related object and the relation weight, or (NULL, 1.0) if none found.

Definition at line 299 of file RelationsObject.h.

getRelatedWithWeight()

std::pair<T*, float> getRelatedWithWeight ( const std::string &  name = "", const std::string &  namedRelation = ""  ) const

inlineinherited

Get first related object & weight of relation pointing from/to an array.

Template Parameters

T	The class of objects to or from which the relation points.

Parameters

name	The name of the store array to or from which the relation points. If empty the default store array name for class T will be used. If the special name "ALL" is given all store arrays containing objects of type T are considered.
namedRelation	Additional name for the relation, or "" for the default naming

Returns

Pair of first related object and the relation weight, or (NULL, 1.0) if none found.

Definition at line 333 of file RelationsObject.h.

getRelationsFrom()

RelationVector<FROM> getRelationsFrom ( const std::string &  name = "", const std::string &  namedRelation = ""  ) const

inlineinherited

Get the relations that point from another store array to this object.

Template Parameters

FROM	The class of objects from which the relations point.

Parameters

name	The name of the store array from which the relations point. If empty the default store array name for class FROM will be used. If the special name "ALL" is given all store arrays containing objects of type FROM are considered.
namedRelation	Additional name for the relation, or "" for the default naming

Returns

A vector of relations.

Definition at line 214 of file RelationsObject.h.

getRelationsTo()

RelationVector<TO> getRelationsTo ( const std::string &  name = "", const std::string &  namedRelation = ""  ) const

inlineinherited

Get the relations that point from this object to another store array.

Template Parameters

TO	The class of objects to which the relations point.

Parameters

name	The name of the store array to which the relations point. If empty the default store array name for class TO will be used. If the special name "ALL" is given all store arrays containing objects of type TO are considered.
namedRelation	Additional name for the relation, or "" for the default naming

Returns

A vector of relations.

Definition at line 199 of file RelationsObject.h.

getRelationsWith()

RelationVector<T> getRelationsWith ( const std::string &  name = "", const std::string &  namedRelation = ""  ) const

inlineinherited

Get the relations between this object and another store array.

Relations in both directions are returned.

Template Parameters

T	The class of objects to or from which the relations point.

Parameters

name	The name of the store array to or from which the relations point. If empty the default store array name for class T will be used. If the special name "ALL" is given all store arrays containing objects of type T are considered.
namedRelation	Additional name for the relation, or "" for the default naming

Returns

A vector of relations.

Definition at line 232 of file RelationsObject.h.

getStatus()

unsigned short getStatus ( ) const

inline

Returns calibration status bits.

Returns

status bits

Definition at line 217 of file TOPDigit.h.

getTime()

double getTime ( ) const

inline

Returns t0-subtracted and calibrated time.

Returns

time in [ns]

Definition at line 382 of file TOPDigit.h.

getTimeError()

double getTimeError ( ) const

inline

Returns calibrated time uncertainty.

Returns

uncertainty (r.m.s.) in [ns]

Definition at line 388 of file TOPDigit.h.

getUniqueChannelID()

unsigned int getUniqueChannelID ( ) const

inlineoverridevirtual

Implementation of the base class function.

Enables BG overlay module to identify uniquely the physical channel of this Digit.

Returns

unique channel ID, composed of pixel ID (1-512) and module ID (1-16)

Implements DigitBase.

Definition at line 419 of file TOPDigit.h.

hasStatus()

bool hasStatus ( unsigned short  bitmask ) const

inline

Returns calibration status.

Returns

calibration status

Definition at line 223 of file TOPDigit.h.

isCalibrated()

bool isCalibrated ( ) const

inline

Returns calibration status.

Returns

true, if fully calibrated

Definition at line 232 of file TOPDigit.h.

isChannelT0Calibrated()

bool isChannelT0Calibrated ( ) const

inline

Returns calibration status.

Returns

true, if channel T0 calibrated

Definition at line 244 of file TOPDigit.h.

isChargeShare()

bool isChargeShare ( ) const

inline

Returns charge share status.

Returns

true, if digit is sharing charge with some other digits

Definition at line 262 of file TOPDigit.h.

isCommonT0Calibrated()

bool isCommonT0Calibrated ( ) const

inline

Returns calibration status.

Returns

true, if common T0 calibrated

Definition at line 256 of file TOPDigit.h.

isModuleT0Calibrated()

bool isModuleT0Calibrated ( ) const

inline

Returns calibration status.

Returns

true, if module T0 calibrated

Definition at line 250 of file TOPDigit.h.

isPrimaryChargeShare()

bool isPrimaryChargeShare ( ) const

inline

Returns charge share status.

Returns

true, if digit is the primary one among those sharing the same charge

Definition at line 268 of file TOPDigit.h.

isSecondaryChargeShare()

bool isSecondaryChargeShare ( ) const

inline

Returns charge share status.

Returns

true, if digit is not the primary one among those sharing the same charge

Definition at line 274 of file TOPDigit.h.

isTimeBaseCalibrated()

bool isTimeBaseCalibrated ( ) const

inline

Returns calibration status.

Returns

true, if time base calibrated

Definition at line 238 of file TOPDigit.h.

setChannel()

void setChannel ( unsigned int  channel )

inline

Sets hardware channel number (0-based)

Parameters

channel

hardware channel number

Definition at line 121 of file TOPDigit.h.

setDoubleHitResolution()

static void setDoubleHitResolution ( double  time )

inlinestatic

Sets double hit resolution.

Parameters

time	double hit resolving time in [ns]

Definition at line 97 of file TOPDigit.h.

setFirstWindow()

void setFirstWindow ( unsigned  window )

inline

Sets first ASIC window number of the merged waveform this hit is taken from.

Parameters

window

ASIC window number

Definition at line 163 of file TOPDigit.h.

setHitQuality()

void setHitQuality ( EHitQuality  quality )

inline

Sets hit quality flag.

Parameters

quality

hit quality

Definition at line 169 of file TOPDigit.h.

setIntegral()

void setIntegral ( int  integral )

inline

Sets pulse integral.

Parameters

integral

pulse integral [ADC counts]

Definition at line 157 of file TOPDigit.h.

setModuleID()

void setModuleID ( int  moduleID )

inline

Sets module ID.

Parameters

moduleID

module ID (1-based)

Definition at line 109 of file TOPDigit.h.

setPileupTime()

static void setPileupTime ( double  time )

inlinestatic

Sets pile-up time.

Parameters

time	pile-up time in [ns]

Definition at line 103 of file TOPDigit.h.

setPixelID()

void setPixelID ( int  pixelID )

inline

Sets pixel ID.

Parameters

pixelID

pixel ID (1-based)

Definition at line 115 of file TOPDigit.h.

setPulseHeight()

void setPulseHeight ( int  pulseHeight )

inline

Sets pulse height.

Parameters

pulseHeight

pulse height [ADC counts]

Definition at line 145 of file TOPDigit.h.

setPulseWidth()

void setPulseWidth ( double  width )

inline

Sets pulse width.

Parameters

width

pulse width (FWHM) in [ns]

Definition at line 151 of file TOPDigit.h.

setRawTime()

void setRawTime ( double  rawTime )

inline

Sets raw detection time.

Parameters

rawTime

raw time expressed in samples (TDC bins)

Definition at line 127 of file TOPDigit.h.

setTime()

void setTime ( double  time )

inline

Sets calibrated detection time.

Parameters

time	time in [ns]

Definition at line 133 of file TOPDigit.h.

setTimeError()

void setTimeError ( double  timeError )

inline

Sets calibrated time uncertainty.

Parameters

timeError

uncertainty (r.m.s.) in [ns]

Definition at line 139 of file TOPDigit.h.

subtractT0()

void subtractT0 ( double  t0 )

inline

Subtract start time from m_time.

Parameters

t0	start time in [ns]

Definition at line 205 of file TOPDigit.h.

---

The documentation for this class was generated from the following files:

• top/dataobjects/include/TOPDigit.h
• top/dataobjects/src/TOPDigit.cc
