The RaveKinematicVertexFitter class is part of the RaveInterface together with RaveSetup. More...

#include <RaveKinematicVertexFitter.h>

Collaboration diagram for RaveKinematicVertexFitter:

[legend]

Public Member Functions
	RaveKinematicVertexFitter ()
	The default constructor checks if RaveSetup was initialized and will set the attributes of RaveKinematicVertexFitter.

	~RaveKinematicVertexFitter ()
	Destructor.

void	addTrack (const Particle *aParticlePtr)
	add a track (in the format of a Belle2::Particle) to set of tracks that should be fitted to a vertex

void	addMother (const Particle *aMotherParticlePtr)
	All daughters of the argument of this function will be used as input for the vertex fit. More...

void	setMother (const Particle *aMotherParticlePtr)
	Set Mother particle for Vertex/momentum update. More...

int	fit ()
	do the kinematic vertex fit with all tracks previously added with the addTrack or addMother function. More...

TVector3	getPos ()
	get the position of the fitted vertex. More...

double	getPValue ()
	get the p value of the fitted vertex. More...

double	getNdf ()
	get the number of degrees of freedom (NDF) of the fitted vertex. More...

double	getChi2 ()
	get the χ² of the fitted vertex.

TMatrixDSym	getCov ()
	get the covariance matrix (7x7). More...

TMatrixDSym	getVertexErrorMatrix ()
	get the covariance matrix (3x3) of the of the fitted vertex position. More...

void	useBeamSpot (bool beamSpot=true)
	Overwrite the global option in ReveSetup that tells the fitter if beam spot info should be used or not. More...

Particle *	getMother ()
	returns a pointer to the mother particle

void	updateMother ()
	update the mother particle

void	updateDaughters ()
	update the Daughters particles

void	clearTracks ()
	Delete all information of previously added tracks and fitted results.

void	setMassConstFit (bool isConstFit=true)
	Set mass constrained fit

void	setVertFit (bool isVertFit=true)
	Set vertex fit: set false in case of mass fit only.

void	Print () const
	Print all attributes of this object to terminal.

Protected Attributes
bool	m_useBeamSpot
	flag determines if the beam spot will be used or not. More...

Particle *	m_motherParticlePtr
	pointer to the mother particle who's daughters will be used in the fit. More...

std::string	m_raveAlgorithm
	Algorithm used by rave (kalman, avr, ...)

rave::KinematicTree	m_fittedResult
	the output of the kinematic fit

std::vector< rave::Track >	m_raveTracks
	holds the tracks that were added to a RaveVertexFitter object in the format used by Rave

std::vector< rave::Vertex >	m_raveVertices
	holds the fitted vertices after fit() was called in the format used by Rave

std::vector< rave::KinematicParticle >	m_inputParticles
	input particles for vertex fit in rave format

rave::KinematicParticle	m_fittedParticle
	Particle fit output.

std::vector< Particle * >	m_belleDaughters
	Belle Particle pointers input.

bool	m_massConstFit
	flag determines if the mass fit is performed

bool	m_vertFit
	flag determines if the vertex fit is performed

double	m_fittedNdf
	Ndf of the vertex fit.

double	m_fittedPValue
	Pvalue of the fit result.

double	m_fittedChi2
	chi^2 of the vertex fit

TVector3	m_fittedPos
	Fitted vertex position.

TLorentzVector	m_fitted4Vector
	4 momentum of the mother particle after the fit

TMatrixFSym	m_fitted7Cov
	7x7 errror matrix of the mother particle after the fit

Private Member Functions
TMatrixDSym	ErrorMatrixMassToEnergy (const TLorentzVector &p4, const TMatrixDSym &MassErr)
	Convert the error matrix from P-M to P-E. More...

TMatrixDSym	ErrorMatrixEnergyToMass (const TLorentzVector &p4, const TMatrixDSym &EnergyErr)
	Convert the error matrix from P-E to P-M. More...

IOIntercept::InterceptorScopeGuard< IOIntercept::OutputToLogMessages >	captureOutput ()
	Start capturing the output of rave and divert it to log messages. More...

Detailed Description

The RaveKinematicVertexFitter class is part of the RaveInterface together with RaveSetup.

To fit a vertex the user adds tracks (different formats are supported). Then calls the fit() function where the name of the fitting method and parameters can be passed as a string. RaveKinematicVertexFitter provides the getters to extract the results produced by Rave.

Definition at line 52 of file RaveKinematicVertexFitter.h.

Member Function Documentation

◆ addMother()

void addMother ( const Particle * aMotherParticlePtr )

All daughters of the argument of this function will be used as input for the vertex fit.

Writes back the result directly to the mother particle

Definition at line 107 of file RaveKinematicVertexFitter.cc.

 {
   vector<Particle*> daughters = aMotherParticlePtr->getDaughters();

   int nDaughters = daughters.size();
   for (int i = 0; i not_eq nDaughters; ++i) {
     addTrack(daughters[i]);
   }

   //store input pointer so fit results can be written to the mother particle after the fit
   auto* tmp = const_cast<Particle*>(aMotherParticlePtr);
   m_motherParticlePtr = tmp;

 }

◆ captureOutput()

IOIntercept::InterceptorScopeGuard< IOIntercept::OutputToLogMessages > captureOutput ( )

private

Start capturing the output of rave and divert it to log messages.

Capturing will finish as soon as the returned object goes out of scope

Definition at line 48 of file RaveKinematicVertexFitter.cc.

◆ ErrorMatrixEnergyToMass()

TMatrixDSym ErrorMatrixEnergyToMass	(	const TLorentzVector &	p4,
		const TMatrixDSym &	EnergyErr
	)

private

Convert the error matrix from P-E to P-M.

It Requires an input error matrit in the form X,P,E

Definition at line 485 of file RaveKinematicVertexFitter.cc.

◆ ErrorMatrixMassToEnergy()

TMatrixDSym ErrorMatrixMassToEnergy	(	const TLorentzVector &	p4,
		const TMatrixDSym &	MassErr
	)

private

Convert the error matrix from P-M to P-E.

It Requires an input error matrit in the form X,P,M

Definition at line 455 of file RaveKinematicVertexFitter.cc.

◆ fit()

int fit ( )

do the kinematic vertex fit with all tracks previously added with the addTrack or addMother function.

The return value is 1 if a vertex is successfully found. Return value 0 means the fit was not successful. -1 means not enough tracks were added

Definition at line 131 of file RaveKinematicVertexFitter.cc.

◆ getCov()

TMatrixDSym getCov ( )

get the covariance matrix (7x7).

Definition at line 433 of file RaveKinematicVertexFitter.cc.

◆ getNdf()

double getNdf ( )

get the number of degrees of freedom (NDF) of the fitted vertex.

Definition at line 423 of file RaveKinematicVertexFitter.cc.

◆ getPos()

TVector3 getPos ( )

get the position of the fitted vertex.

Definition at line 413 of file RaveKinematicVertexFitter.cc.

◆ getPValue()

double getPValue ( )

get the p value of the fitted vertex.

Definition at line 418 of file RaveKinematicVertexFitter.cc.

◆ getVertexErrorMatrix()

TMatrixDSym getVertexErrorMatrix ( )

get the covariance matrix (3x3) of the of the fitted vertex position.

Definition at line 438 of file RaveKinematicVertexFitter.cc.

◆ setMother()

void setMother ( const Particle * aMotherParticlePtr )

Set Mother particle for Vertex/momentum update.

Not to be used with addMother

Definition at line 123 of file RaveKinematicVertexFitter.cc.

◆ useBeamSpot()

void useBeamSpot ( bool beamSpot = true )

inline

Overwrite the global option in ReveSetup that tells the fitter if beam spot info should be used or not.

The beam spot pos and cov must still be set in the RaveSetup class if you what to use it

Definition at line 93 of file RaveKinematicVertexFitter.h.

                {
           m_useBeamSpot = false;
         }
       }

       Particle* getMother();

       void updateMother();


Member Data Documentation

◆ m_motherParticlePtr

Particle* m_motherParticlePtr

protected

pointer to the mother particle who's daughters will be used in the fit.

the fit result will be written back to the mother particle

Definition at line 144 of file RaveKinematicVertexFitter.h.

◆ m_useBeamSpot

bool m_useBeamSpot

protected

flag determines if the beam spot will be used or not.

Overwrites the global flag in RaveSetup

Definition at line 141 of file RaveKinematicVertexFitter.h.

The documentation for this class was generated from the following files:

analysis/VertexFitting/RaveInterface/include/RaveKinematicVertexFitter.h
analysis/VertexFitting/RaveInterface/src/RaveKinematicVertexFitter.cc
