SVDDQMExpressRecoModule Class Reference
Packages » svd | Modules » svd modules

SVD DQM Module for Express Reco. More...

#include <SVDDQMExpressRecoModule.h>

Inheritance diagram for SVDDQMExpressRecoModule:
Inheritance graph
[legend]
Collaboration diagram for SVDDQMExpressRecoModule:
Collaboration graph
[legend]

Public Types

enum  EModulePropFlags {
  c_Input = 1 ,
  c_Output = 2 ,
  c_ParallelProcessingCertified = 4 ,
  c_HistogramManager = 8 ,
  c_InternalSerializer = 16 ,
  c_TerminateInAllProcesses = 32 ,
  c_DontCollectStatistics = 64
}
 Each module can be tagged with property flags, which indicate certain features of the module. More...

typedef ModuleCondition::EAfterConditionPath EAfterConditionPath
 Forward the EAfterConditionPath definition from the ModuleCondition.


Public Member Functions

 SVDDQMExpressRecoModule ()
 Constructor.

 SVDDQMExpressRecoModule (const SVDDQMExpressRecoModule &)=delete
 Copy constructor (disabled)

SVDDQMExpressRecoModule & operator= (const SVDDQMExpressRecoModule &)=delete
 Operator = (disabled)

void initialize () override final
 Module function initialize.

void terminate () override final
 Module function terminate.

void beginRun () override final
 Module function beginRun.

void event () override final
 Module function event.

void defineHisto () override final
 Histogram definitions such as TH1(), TH2(), TNtuple(), TTree().... More...

virtual void endRun () override
 Function to process end_run record.

virtual std::vector< std::string > getFileNames (bool outputFiles)
 Return a list of output filenames for this modules. More...

const std::string & getName () const
 Returns the name of the module. More...

const std::string & getType () const
 Returns the type of the module (i.e. More...

const std::string & getPackage () const
 Returns the package this module is in.

const std::string & getDescription () const
 Returns the description of the module.

void setName (const std::string &name)
 Set the name of the module. More...

void setPropertyFlags (unsigned int propertyFlags)
 Sets the flags for the module properties. More...

LogConfig & getLogConfig ()
 Returns the log system configuration.

void setLogConfig (const LogConfig &logConfig)
 Set the log system configuration.

void setLogLevel (int logLevel)
 Configure the log level.

void setDebugLevel (int debugLevel)
 Configure the debug messaging level.

void setAbortLevel (int abortLevel)
 Configure the abort log level.

void setLogInfo (int logLevel, unsigned int logInfo)
 Configure the printed log information for the given level. More...

void if_value (const std::string &expression, const std::shared_ptr< Path > &path, EAfterConditionPath afterConditionPath=EAfterConditionPath::c_End)
 Add a condition to the module. More...

void if_false (const std::shared_ptr< Path > &path, EAfterConditionPath afterConditionPath=EAfterConditionPath::c_End)
 A simplified version to add a condition to the module. More...

void if_true (const std::shared_ptr< Path > &path, EAfterConditionPath afterConditionPath=EAfterConditionPath::c_End)
 A simplified version to set the condition of the module. More...

bool hasCondition () const
 Returns true if at least one condition was set for the module.

const ModuleCondition * getCondition () const
 Return a pointer to the first condition (or nullptr, if none was set)

const std::vector< ModuleCondition > & getAllConditions () const
 Return all set conditions for this module.

bool evalCondition () const
 If at least one condition was set, it is evaluated and true returned if at least one condition returns true. More...

std::shared_ptr< Path > getConditionPath () const
 Returns the path of the last true condition (if there is at least one, else reaturn a null pointer). More...

Module::EAfterConditionPath getAfterConditionPath () const
 What to do after the conditional path is finished. More...

std::vector< std::shared_ptr< Path > > getAllConditionPaths () const
 Return all condition paths currently set (no matter if the condition is true or not).

bool hasProperties (unsigned int propertyFlags) const
 Returns true if all specified property flags are available in this module. More...

bool hasUnsetForcedParams () const
 Returns true and prints error message if the module has unset parameters which the user has to set in the steering file.

const ModuleParamList & getParamList () const
 Return module param list.

template<typename T >
ModuleParam< T > & getParam (const std::string &name) const
 Returns a reference to a parameter. More...

bool hasReturnValue () const
 Return true if this module has a valid return value set.

int getReturnValue () const
 Return the return value set by this module. More...

std::shared_ptr< PathElement > clone () const override
 Create an independent copy of this module. More...

std::shared_ptr< boost::python::list > getParamInfoListPython () const
 Returns a python list of all parameters. More...


Static Public Member Functions

static void exposePythonAPI ()
 Exposes methods of the Module class to Python.


Protected Member Functions

virtual void def_initialize ()
 Wrappers to make the methods without "def_" prefix callable from Python. More...

virtual void def_beginRun ()
 Wrapper method for the virtual function beginRun() that has the implementation to be used in a call from Python.

virtual void def_event ()
 Wrapper method for the virtual function event() that has the implementation to be used in a call from Python.

virtual void def_endRun ()
 This method can receive that the current run ends as a call from the Python side. More...

virtual void def_terminate ()
 Wrapper method for the virtual function terminate() that has the implementation to be used in a call from Python.

void setDescription (const std::string &description)
 Sets the description of the module. More...

void setType (const std::string &type)
 Set the module type. More...

template<typename T >
void addParam (const std::string &name, T &paramVariable, const std::string &description, const T &defaultValue)
 Adds a new parameter to the module. More...

template<typename T >
void addParam (const std::string &name, T &paramVariable, const std::string &description)
 Adds a new enforced parameter to the module. More...

void setReturnValue (int value)
 Sets the return value for this module as integer. More...

void setReturnValue (bool value)
 Sets the return value for this module as bool. More...

void setParamList (const ModuleParamList &params)
 Replace existing parameter list.


Private Member Functions

std::list< ModulePtr > getModules () const override
 no submodules, return empty list

std::string getPathString () const override
 return the module name.

void setParamPython (const std::string &name, const boost::python::object &pyObj)
 Implements a method for setting boost::python objects. More...

void setParamPythonDict (const boost::python::dict &dictionary)
 Implements a method for reading the parameter values from a boost::python dictionary. More...


Private Attributes

StoreObjPtr< SVDEventInfo > m_svdEventInfo
 SVDEventInfo data object.

bool m_desynchSVDTime = false
 if TRUE: svdTime back in SVD time reference

StoreObjPtr< SoftwareTriggerResult > m_resultStoreObjectPointer
 Store Object for reading the trigger decision.

bool m_skipRejectedEvents = true
 if true skip events rejected by HLT (default)

bool m_additionalPlots = false
 additional plots flag

TList * m_histoList = nullptr
 list of cumulative histograms

int m_expNumber = 0
 experiment number

int m_runNumber = 0
 run number

int m_ShowAllHistos = 0
 Flag to show all histos in DQM, default = 0 (do not show)

float m_CutSVDCharge = 0.0
 cut for accepting strips to hitmap histogram default = 0 ADU

float m_CutSVDClusterCharge = 0.0
 cut for accepting clusters to hitmap histogram, default = 0 ke-

std::string m_histogramDirectoryName
 Name of the histogram directory in ROOT file.

std::string m_storeNoZSSVDShaperDigitsName
 not zero-suppressed SVDShaperDigits StoreArray name

std::string m_storeSVDShaperDigitsName
 SVDShaperDigits StoreArray name.

std::string m_storeSVDClustersName
 SVDClusters StoreArray name.

TH1F * m_nEvents = nullptr
 number of events

TH1F * m_hitMapCountsU = nullptr
 Hitmaps u of Digits.

TH1F * m_hitMapCountsV = nullptr
 Hitmaps v of Digits.

TH1F * m_hitMapClCountsU = nullptr
 Hitmaps u of Clusters.

TH1F * m_hitMapClCountsV = nullptr
 Hitmaps v of Clusters.

TH1F * m_hitMapCountsChip = nullptr
 Hitmaps of digits on chips.

TH1F * m_hitMapClCountsChip = nullptr
 Hitmaps of clusters on chips.

TH1F ** m_firedU = nullptr
 Fired u strips per event.

TH1F ** m_firedV = nullptr
 Fired v strips per event.

TH1F ** m_clustersU = nullptr
 number of u clusters per event

TH1F ** m_clustersV = nullptr
 number of v clusters per event

TH1F ** m_clusterChargeU = nullptr
 u charge of clusters

TH1F ** m_clusterChargeV = nullptr
 v charge of clusters

TH1F * m_clusterChargeUAll = nullptr
 u charge of clusters for all sensors

TH1F * m_clusterChargeVAll = nullptr
 v charge of clusters for all sensors

TH1F * m_clusterChargeU3 = nullptr
 u charge of clusters for layer 3 sensors

TH1F * m_clusterChargeV3 = nullptr
 v charge of clusters for layer 3 sensors

TH1F * m_clusterChargeU456 = nullptr
 u charge of clusters for layer 4,5,6 sensors

TH1F * m_clusterChargeV456 = nullptr
 v charge of clusters for layer 4,5,6 sensors

TH1F ** m_clusterSNRU = nullptr
 u SNR of clusters per sensor

TH1F ** m_clusterSNRV = nullptr
 v SNR of clusters per sensor

TH1F * m_clusterSNRUAll = nullptr
 u SNR of clusters for all sensors

TH1F * m_clusterSNRVAll = nullptr
 v SNR of clusters for all sensors

TH1F * m_clusterSNRU3 = nullptr
 u SNR of clusters for layer 3 sensors

TH1F * m_clusterSNRV3 = nullptr
 v SNR of clusters for layer 3 sensors

TH1F * m_clusterSNRU456 = nullptr
 u SNR of clusters for layer 4,5,6 sensors

TH1F * m_clusterSNRV456 = nullptr
 v SNR of clusters for layer 4,5,6 sensors

TH1F * m_stripMaxBinUAll = nullptr
 u MaxBin of strips for all sensors (offline Zero Suppression)

TH1F * m_stripMaxBinVAll = nullptr
 v MaxBin of strips for all sensors (offline Zero Suppression)

TH1F * m_stripMaxBinU3 = nullptr
 u MaxBin of strips for layer 3 sensors (offline Zero Suppression)

TH1F * m_stripMaxBinV3 = nullptr
 v MaxBin of strips for layer 3 sensors (offline Zero Suppression)

TH1F * m_stripMaxBinU6 = nullptr
 u MaxBin of strips for layer 6 sensors (offline Zero Suppression)

TH1F * m_stripMaxBinV6 = nullptr
 v MaxBin of strips for layer 6 sensors (offline Zero Suppression)

TH1F ** m_stripSignalU = nullptr
 u charge of strips

TH1F ** m_stripSignalV = nullptr
 v charge of strips

TH1F ** m_stripCountU = nullptr
 u strip count

TH1F ** m_stripCountV = nullptr
 v strip count

TH1F ** m_onlineZSstripCountU = nullptr
 u strip count (online Zero Suppression)

TH1F ** m_onlineZSstripCountV = nullptr
 v strip count (online Zero Suppression

TH1F ** m_stripCountGroupId0U = nullptr
 U strip count for cluster time group Id = 0.

TH1F ** m_stripCountGroupId0V = nullptr
 V strip count for cluster time group Id = 0.

TH1F ** m_strip3CountU = nullptr
 u strip count for 3 samples

TH1F ** m_strip3CountV = nullptr
 v strip count for 3 samples

TH1F ** m_onlineZSstrip3CountU = nullptr
 u strip count (online Zero Suppression) for 3 samples

TH1F ** m_onlineZSstrip3CountV = nullptr
 v strip count (online Zero Suppression for 3 samples

TH1F ** m_strip6CountU = nullptr
 u strip count for 6 samples

TH1F ** m_strip6CountV = nullptr
 v strip count for 3 samples

TH1F ** m_onlineZSstrip6CountU = nullptr
 u strip count (online Zero Suppression) for 6 samples

TH1F ** m_onlineZSstrip6CountV = nullptr
 v strip count (online Zero Suppression for 6 samples

TH1F ** m_clusterSizeU = nullptr
 u size

TH1F ** m_clusterSizeV = nullptr
 v size

TH2F * m_cluster3TimeGroupId = nullptr
 time group id for 3 samples

TH2F * m_cluster6TimeGroupId = nullptr
 time group id for 6 samples

TH1F ** m_clusterTimeU = nullptr
 u time

TH1F ** m_clusterTimeV = nullptr
 v time

TH1F * m_clusterTimeUAll = nullptr
 u time of clusters for all sensors

TH1F * m_clusterTimeVAll = nullptr
 v time of clusters for all sensors

TH1F * m_clusterTimeU3 = nullptr
 u Time of clusters for layer 3 sensors

TH1F * m_clusterTimeV3 = nullptr
 v Time of clusters for layer 3 sensors

TH1F * m_clusterTimeU456 = nullptr
 u Time of clusters for layer 4,5,6 sensors

TH1F * m_clusterTimeV456 = nullptr
 v Time of clusters for layer 4,5,6 sensors

TH1F * m_cluster3TimeU3 = nullptr
 u Time of clusters for layer 3 sensors for 3 samples

TH1F * m_cluster3TimeV3 = nullptr
 v Time of clusters for layer 3 sensors for 3 samples

TH1F * m_cluster3TimeU456 = nullptr
 u Time of clusters for layer 4,5,6 sensors for 3 samples

TH1F * m_cluster3TimeV456 = nullptr
 v Time of clusters for layer 4,5,6 sensors for 3 samples

TH1F * m_cluster6TimeU3 = nullptr
 u Time of clusters for layer 3 sensors for 6 samples

TH1F * m_cluster6TimeV3 = nullptr
 v Time of clusters for layer 3 sensors for 6 samples

TH1F * m_cluster6TimeU456 = nullptr
 u Time of clusters for layer 4,5,6 sensors for 6 samples

TH1F * m_cluster6TimeV456 = nullptr
 v Time of clusters for layer 4,5,6 sensors for 6 samples

TH2F ** m_hitMapU = nullptr
 Hitmaps pixels for u.

TH2F ** m_hitMapV = nullptr
 Hitmaps pixels for v.

TH1F ** m_hitMapUCl = nullptr
 Hitmaps clusters for u.

TH1F ** m_hitMapVCl = nullptr
 Hitmaps clusters for v.

std::string m_name
 The name of the module, saved as a string (user-modifiable)

std::string m_type
 The type of the module, saved as a string.

std::string m_package
 Package this module is found in (may be empty).

std::string m_description
 The description of the module.

unsigned int m_propertyFlags
 The properties of the module as bitwise or (with |) of EModulePropFlags.

LogConfig m_logConfig
 The log system configuration of the module.

ModuleParamList m_moduleParamList
 List storing and managing all parameter of the module.

bool m_hasReturnValue
 True, if the return value is set.

int m_returnValue
 The return value.

std::vector< ModuleCondition > m_conditions
 Module condition, only non-null if set.


Detailed Description

SVD DQM Module for Express Reco.

Definition at line 33 of file SVDDQMExpressRecoModule.h.

Member Enumeration Documentation

◆ EModulePropFlags

enum EModulePropFlags
inherited

Each module can be tagged with property flags, which indicate certain features of the module.

Enumerator
c_Input

This module is an input module (reads data).

c_Output

This module is an output module (writes data).

c_ParallelProcessingCertified

This module can be run in parallel processing mode safely (All I/O must be done through the data store, in particular, the module must not write any files.)

c_HistogramManager

This module is used to manage histograms accumulated by other modules.

c_InternalSerializer

This module is an internal serializer/deserializer for parallel processing.

c_TerminateInAllProcesses

When using parallel processing, call this module's terminate() function in all processes().

This will also ensure that there is exactly one process (single-core if no parallel modules found) or at least one input, one main and one output process.

c_DontCollectStatistics

No statistics is collected for this module.

Definition at line 77 of file Module.h.

Member Function Documentation

◆ clone()

std::shared_ptr< PathElement > clone ( ) const
overridevirtualinherited

Create an independent copy of this module.

Note that parameters are shared, so changing them on a cloned module will also affect the original module.

Implements PathElement.

Definition at line 179 of file Module.cc.

◆ def_endRun()

virtual void def_endRun ( )
inlineprotectedvirtualinherited

This method can receive that the current run ends as a call from the Python side.

For regular C++-Modules that forwards the call to the regular endRun() method.

Reimplemented in PyModule.

Definition at line 439 of file Module.h.

◆ def_initialize()

virtual void def_initialize ( )
inlineprotectedvirtualinherited

Wrappers to make the methods without "def_" prefix callable from Python.

Overridden in PyModule. Wrapper method for the virtual function initialize() that has the implementation to be used in a call from Python.

Reimplemented in PyModule.

Definition at line 420 of file Module.h.

◆ defineHisto()

void defineHisto ( )
finaloverridevirtual

Histogram definitions such as TH1(), TH2(), TNtuple(), TTree()....

are supposed to be placed in this function.

Reimplemented from HistoModule.

Definition at line 79 of file SVDDQMExpressRecoModule.cc.

80 {
81  auto gTools = VXD::GeoCache::getInstance().getGeoTools();
82  if (gTools->getNumberOfLayers() == 0) {
83  B2FATAL("Missing geometry for VXD, check steering file.");
84  }
85  if (gTools->getNumberOfSVDLayers() == 0) {
86  B2WARNING("Missing geometry for SVD, SVD-DQM is skipped.");
87  return;
88  }
89
90  // Create a separate histogram directories and cd into it.
91  TDirectory* oldDir = gDirectory;
92  if (m_histogramDirectoryName != "") {
93  oldDir->mkdir(m_histogramDirectoryName.c_str());// do not use return value with ->cd(), its ZERO if dir already exists
94  oldDir->cd(m_histogramDirectoryName.c_str());
95  }
96
97  // basic constants presets:
98  int nSVDSensors = gTools->getNumberOfSVDSensors();
99  int nSVDChips = gTools->getTotalSVDChips();
100
101  // number of events counter
102  m_nEvents = new TH1F("SVDDQM_nEvents", "SVD Number of Events", 1, -0.5, 0.5);
103  m_nEvents->GetYaxis()->SetTitle("N events");
104  m_histoList->Add(m_nEvents);
105
106  // Create basic histograms:
107  // basic counters per sensor:
108  m_hitMapCountsU = new TH1F("SVDDQM_StripCountsU", "SVD Integrated Number of ZS5 Fired U-Strips per sensor",
109  nSVDSensors, 0, nSVDSensors);
110  m_hitMapCountsU->GetXaxis()->SetTitle("Sensor ID");
111  m_hitMapCountsU->GetYaxis()->SetTitle("counts");
112  m_histoList->Add(m_hitMapCountsU);
113  m_hitMapCountsV = new TH1F("SVDDQM_StripCountsV", "SVD Integrated Number of ZS5 Fired V-Strips per sensor",
114  nSVDSensors, 0, nSVDSensors);
115  m_hitMapCountsV->GetXaxis()->SetTitle("Sensor ID");
116  m_hitMapCountsV->GetYaxis()->SetTitle("counts");
117  m_histoList->Add(m_hitMapCountsV);
118  m_hitMapClCountsU = new TH1F("SVDDQM_ClusterCountsU", "SVD Integrated Number of U-Clusters per sensor",
119  nSVDSensors, 0, nSVDSensors);
120  m_hitMapClCountsU->GetXaxis()->SetTitle("Sensor ID");
121  m_hitMapClCountsU->GetYaxis()->SetTitle("counts");
122  m_histoList->Add(m_hitMapClCountsU);
123  m_hitMapClCountsV = new TH1F("SVDDQM_ClusterCountsV", "SVD Integrated Number of V-Clusters per sensor",
124  nSVDSensors, 0, nSVDSensors);
125  m_hitMapClCountsV->GetXaxis()->SetTitle("Sensor ID");
126  m_hitMapClCountsV->GetYaxis()->SetTitle("counts");
127  m_histoList->Add(m_hitMapClCountsV);
128  for (int i = 0; i < nSVDSensors; i++) {
129  VxdID id = gTools->getSensorIDFromSVDIndex(i);
130  int iLayer = id.getLayerNumber();
131  int iLadder = id.getLadderNumber();
132  int iSensor = id.getSensorNumber();
133  TString AxisTicks = Form("%i_%i_%i", iLayer, iLadder, iSensor);
134  m_hitMapCountsU->GetXaxis()->SetBinLabel(i + 1, AxisTicks.Data());
135  m_hitMapCountsV->GetXaxis()->SetBinLabel(i + 1, AxisTicks.Data());
136  m_hitMapClCountsU->GetXaxis()->SetBinLabel(i + 1, AxisTicks.Data());
137  m_hitMapClCountsV->GetXaxis()->SetBinLabel(i + 1, AxisTicks.Data());
138  }
139
140  // basic counters per chip:
141  m_hitMapCountsChip = new TH1F("SVDDQM_StripCountsChip", "SVD Integrated Number of ZS5 Fired Strips per chip",
142  nSVDChips, 0, nSVDChips);
143  m_hitMapCountsChip->GetXaxis()->SetTitle("Chip ID");
144  m_hitMapCountsChip->GetYaxis()->SetTitle("counts");
145  m_histoList->Add(m_hitMapCountsChip);
146  m_hitMapClCountsChip = new TH1F("SVDDQM_ClusterCountsChip", "SVD Integrated Number of Clusters per chip",
147  nSVDChips, 0, nSVDChips);
148  m_hitMapClCountsChip->GetXaxis()->SetTitle("Chip ID");
149  m_hitMapClCountsChip->GetYaxis()->SetTitle("counts");
150  m_histoList->Add(m_hitMapClCountsChip);
151
152  if (m_additionalPlots) {
153  m_firedU = new TH1F*[nSVDSensors];
154  m_firedV = new TH1F*[nSVDSensors];
155  m_clustersU = new TH1F*[nSVDSensors];
156  m_clustersV = new TH1F*[nSVDSensors];
157  m_stripSignalU = new TH1F*[nSVDSensors];
158  m_stripSignalV = new TH1F*[nSVDSensors];
159  }
160
161  m_clusterChargeU = new TH1F*[nSVDSensors];
162  m_clusterChargeV = new TH1F*[nSVDSensors];
163  m_clusterSNRU = new TH1F*[nSVDSensors];
164  m_clusterSNRV = new TH1F*[nSVDSensors];
165
166  m_stripCountU = new TH1F*[nSVDSensors];
167  m_stripCountV = new TH1F*[nSVDSensors];
168  m_strip3CountU = new TH1F*[nSVDSensors];
169  m_strip3CountV = new TH1F*[nSVDSensors];
170  m_strip6CountU = new TH1F*[nSVDSensors];
171  m_strip6CountV = new TH1F*[nSVDSensors];
172
173  m_stripCountGroupId0U = new TH1F*[nSVDSensors];
174  m_stripCountGroupId0V = new TH1F*[nSVDSensors];
175
176  m_onlineZSstripCountU = new TH1F*[nSVDSensors];
177  m_onlineZSstripCountV = new TH1F*[nSVDSensors];
178  m_onlineZSstrip3CountU = new TH1F*[nSVDSensors];
179  m_onlineZSstrip3CountV = new TH1F*[nSVDSensors];
180  m_onlineZSstrip6CountU = new TH1F*[nSVDSensors];
181  m_onlineZSstrip6CountV = new TH1F*[nSVDSensors];
182
183  m_clusterSizeU = new TH1F*[nSVDSensors];
184  m_clusterSizeV = new TH1F*[nSVDSensors];
185  m_clusterTimeU = new TH1F*[nSVDSensors];
186  m_clusterTimeV = new TH1F*[nSVDSensors];
187
188  int ChargeBins = 80;
189  float ChargeMax = 80;
190  int SNRBins = 50;
191  float SNRMax = 100;
192  int TimeBins = 300;
193  float TimeMin = -150;
194  float TimeMax = 150;
195
196  int GroupIdBins = 21;
197  float GroupIdMin = -1.5;
198  float GroupIdMax = 19.5;
199
200  int MaxBinBins = 6;
201  int MaxBinMax = 6;
202
203  TString refFrame = "in FTSW reference";
204  if (m_desynchSVDTime)
205  refFrame = "in SVD reference";
206
207
208  //----------------------------------------------------------------
209  // Charge of clusters for all sensors
210  //----------------------------------------------------------------
211  string name = str(format("SVDDQM_ClusterChargeUAll"));
212  string title = str(format("SVD U-Cluster Charge for all sensors"));
213  m_clusterChargeUAll = new TH1F(name.c_str(), title.c_str(), ChargeBins, 0, ChargeMax);
214  m_clusterChargeUAll->GetXaxis()->SetTitle("cluster charge [ke-]");
215  m_clusterChargeUAll->GetYaxis()->SetTitle("count");
216  m_histoList->Add(m_clusterChargeUAll);
217  name = str(format("SVDDQM_ClusterChargeVAll"));
218  title = str(format("SVD V-Cluster Charge for all sensors"));
219  m_clusterChargeVAll = new TH1F(name.c_str(), title.c_str(), ChargeBins, 0, ChargeMax);
220  m_clusterChargeVAll->GetXaxis()->SetTitle("cluster charge [ke-]");
221  m_clusterChargeVAll->GetYaxis()->SetTitle("count");
222  m_histoList->Add(m_clusterChargeVAll);
223  //----------------------------------------------------------------
224  // Charge of clusters for L3/L456 sensors
225  //----------------------------------------------------------------
226  name = str(format("SVDDQM_ClusterChargeU3"));
227  title = str(format("SVD U-Cluster Charge for layer 3 sensors"));
228  m_clusterChargeU3 = new TH1F(name.c_str(), title.c_str(), ChargeBins, 0, ChargeMax);
229  m_clusterChargeU3->GetXaxis()->SetTitle("cluster charge [ke-]");
230  m_clusterChargeU3->GetYaxis()->SetTitle("count");
231  m_histoList->Add(m_clusterChargeU3);
232  name = str(format("SVDDQM_ClusterChargeV3"));
233  title = str(format("SVD V-Cluster Charge for layer 3 sensors"));
234  m_clusterChargeV3 = new TH1F(name.c_str(), title.c_str(), ChargeBins, 0, ChargeMax);
235  m_clusterChargeV3->GetXaxis()->SetTitle("cluster charge [ke-]");
236  m_clusterChargeV3->GetYaxis()->SetTitle("count");
237  m_histoList->Add(m_clusterChargeV3);
238
239  name = str(format("SVDDQM_ClusterChargeU456"));
240  title = str(format("SVD U-Cluster Charge for layers 4,5,6 sensors"));
241  m_clusterChargeU456 = new TH1F(name.c_str(), title.c_str(), ChargeBins, 0, ChargeMax);
242  m_clusterChargeU456->GetXaxis()->SetTitle("cluster charge [ke-]");
243  m_clusterChargeU456->GetYaxis()->SetTitle("count");
244  m_histoList->Add(m_clusterChargeU456);
245
246  name = str(format("SVDDQM_ClusterChargeV456"));
247  title = str(format("SVD V-Cluster Charge for layers 4,5,6 sensors"));
248  m_clusterChargeV456 = new TH1F(name.c_str(), title.c_str(), ChargeBins, 0, ChargeMax);
249  m_clusterChargeV456->GetXaxis()->SetTitle("cluster charge [ke-]");
250  m_clusterChargeV456->GetYaxis()->SetTitle("count");
251  m_histoList->Add(m_clusterChargeV456);
252
253  //----------------------------------------------------------------
254  // SNR of clusters for all sensors
255  //----------------------------------------------------------------
256  name = str(format("SVDDQM_ClusterSNRUAll"));
257  title = str(format("SVD U-Cluster SNR for all sensors"));
258  m_clusterSNRUAll = new TH1F(name.c_str(), title.c_str(), SNRBins, 0, SNRMax); // max = ~ 60
259  m_clusterSNRUAll->GetXaxis()->SetTitle("cluster SNR");
260  m_clusterSNRUAll->GetYaxis()->SetTitle("count");
261  m_histoList->Add(m_clusterSNRUAll);
262  name = str(format("SVDDQM_ClusterSNRVAll"));
263  title = str(format("SVD V-Cluster SNR for all sensors"));
264  m_clusterSNRVAll = new TH1F(name.c_str(), title.c_str(), SNRBins, 0, SNRMax);
265  m_clusterSNRVAll->GetXaxis()->SetTitle("cluster SNR");
266  m_clusterSNRVAll->GetYaxis()->SetTitle("count");
267  m_histoList->Add(m_clusterSNRVAll);
268  //----------------------------------------------------------------
269  // SNR of clusters for L3/L456 sensors
270  //----------------------------------------------------------------
271  name = str(format("SVDDQM_ClusterSNRU3"));
272  title = str(format("SVD U-Cluster SNR for layer 3 sensors"));
273  m_clusterSNRU3 = new TH1F(name.c_str(), title.c_str(), SNRBins, 0, SNRMax);
274  m_clusterSNRU3->GetXaxis()->SetTitle("cluster SNR");
275  m_clusterSNRU3->GetYaxis()->SetTitle("count");
276  m_histoList->Add(m_clusterSNRU3);
277  name = str(format("SVDDQM_ClusterSNRV3"));
278  title = str(format("SVD V-Cluster SNR for layer 3 sensors"));
279  m_clusterSNRV3 = new TH1F(name.c_str(), title.c_str(), SNRBins, 0, SNRMax);
280  m_clusterSNRV3->GetXaxis()->SetTitle("cluster SNR");
281  m_clusterSNRV3->GetYaxis()->SetTitle("count");
282  m_histoList->Add(m_clusterSNRV3);
283
284  name = str(format("SVDDQM_ClusterSNRU456"));
285  title = str(format("SVD U-Cluster SNR for layers 4,5,6 sensors"));
286  m_clusterSNRU456 = new TH1F(name.c_str(), title.c_str(), SNRBins, 0, SNRMax);
287  m_clusterSNRU456->GetXaxis()->SetTitle("cluster SNR");
288  m_clusterSNRU456->GetYaxis()->SetTitle("count");
289  m_histoList->Add(m_clusterSNRU456);
290  name = str(format("SVDDQM_ClusterSNRV456"));
291  title = str(format("SVD V-Cluster SNR for layers 4,5,6 sensors"));
292  m_clusterSNRV456 = new TH1F(name.c_str(), title.c_str(), SNRBins, 0, SNRMax);
293  m_clusterSNRV456->GetXaxis()->SetTitle("cluster SNR");
294  m_clusterSNRV456->GetYaxis()->SetTitle("count");
295  m_histoList->Add(m_clusterSNRV456);
296  //----------------------------------------------------------------
297  // Cluster time distribution for all sensors
298  //----------------------------------------------------------------
299  TString Name = "SVDDQM_ClusterTimeUAll";
300  TString Title = Form("SVD U-Cluster Time %s for all sensors", refFrame.Data());
301  m_clusterTimeUAll = new TH1F(Name.Data(), Title.Data(), TimeBins, TimeMin, TimeMax);
302  m_clusterTimeUAll->GetXaxis()->SetTitle("cluster time (ns)");
303  m_clusterTimeUAll->GetYaxis()->SetTitle("count");
304  m_histoList->Add(m_clusterTimeUAll);
305  Name = "SVDDQM_ClusterTimeVAll";
306  Title = Form("SVD V-Cluster Time %s for all sensors", refFrame.Data());
307  m_clusterTimeVAll = new TH1F(Name.Data(), Title.Data(), TimeBins, TimeMin, TimeMax);
308  m_clusterTimeVAll->GetXaxis()->SetTitle("cluster time (ns)");
309  m_clusterTimeVAll->GetYaxis()->SetTitle("count");
310  m_histoList->Add(m_clusterTimeVAll);
311  //----------------------------------------------------------------
312  // Time of clusters for L3/L456 sensors
313  //----------------------------------------------------------------
314  Name = "SVDDQM_ClusterTimeU3";
315  Title = Form("SVD U-Cluster Time %s for layer 3 sensors", refFrame.Data());
316  m_clusterTimeU3 = new TH1F(Name.Data(), Title.Data(), TimeBins, TimeMin, TimeMax);
317  m_clusterTimeU3->GetXaxis()->SetTitle("cluster time (ns)");
318  m_clusterTimeU3->GetYaxis()->SetTitle("count");
319  m_histoList->Add(m_clusterTimeU3);
320  name = str(format("SVDDQM_ClusterTimeV3"));
321  Title = Form("SVD V-Cluster Time %s for layer 3 sensors", refFrame.Data());
322  m_clusterTimeV3 = new TH1F(name.c_str(), Title.Data(), TimeBins, TimeMin, TimeMax);
323  m_clusterTimeV3->GetXaxis()->SetTitle("cluster time (ns)");
324  m_clusterTimeV3->GetYaxis()->SetTitle("count");
325  m_histoList->Add(m_clusterTimeV3);
326
327  name = str(format("SVDDQM_ClusterTimeU456"));
328  Title = Form("SVD U-Cluster Time %s for layers 4,5,6 sensors", refFrame.Data());
329  m_clusterTimeU456 = new TH1F(name.c_str(), Title.Data(), TimeBins, TimeMin, TimeMax);
330  m_clusterTimeU456->GetXaxis()->SetTitle("cluster time (ns)");
331  m_clusterTimeU456->GetYaxis()->SetTitle("count");
332  m_histoList->Add(m_clusterTimeU456);
333  name = str(format("SVDDQM_ClusterTimeV456"));
334  Title = Form("SVD V-Cluster Time %s for layers 4,5,6 sensors", refFrame.Data());
335  m_clusterTimeV456 = new TH1F(name.c_str(), Title.Data(), TimeBins, TimeMin, TimeMax);
336  m_clusterTimeV456->GetXaxis()->SetTitle("cluster time (ns)");
337  m_clusterTimeV456->GetYaxis()->SetTitle("count");
338  m_histoList->Add(m_clusterTimeV456);
339
340  //----------------------------------------------------------------
341  // Time of clusters for L3/L456 sensors for 3 samples
342  //----------------------------------------------------------------
343  Name = "SVDDQM_Cluster3TimeU3";
344  Title = Form("SVD U-Cluster Time %s for layer 3 sensors for 3 samples", refFrame.Data());
345  m_cluster3TimeU3 = new TH1F(Name.Data(), Title.Data(), TimeBins, TimeMin, TimeMax);
346  m_cluster3TimeU3->GetXaxis()->SetTitle("cluster time (ns)");
347  m_cluster3TimeU3->GetYaxis()->SetTitle("count");
348  m_histoList->Add(m_cluster3TimeU3);
349  name = str(format("SVDDQM_Cluster3TimeV3"));
350  Title = Form("SVD V-Cluster Time %s for layer 3 sensors for 3 samples", refFrame.Data());
351  m_cluster3TimeV3 = new TH1F(name.c_str(), Title.Data(), TimeBins, TimeMin, TimeMax);
352  m_cluster3TimeV3->GetXaxis()->SetTitle("cluster time (ns)");
353  m_cluster3TimeV3->GetYaxis()->SetTitle("count");
354  m_histoList->Add(m_cluster3TimeV3);
355
356  name = str(format("SVDDQM_Cluster3TimeU456"));
357  Title = Form("SVD U-Cluster Time %s for layers 4,5,6 sensors for 3 samples", refFrame.Data());
358  m_cluster3TimeU456 = new TH1F(name.c_str(), Title.Data(), TimeBins, TimeMin, TimeMax);
359  m_cluster3TimeU456->GetXaxis()->SetTitle("cluster time (ns)");
360  m_cluster3TimeU456->GetYaxis()->SetTitle("count");
361  m_histoList->Add(m_cluster3TimeU456);
362  name = str(format("SVDDQM_Cluster3TimeV456"));
363  Title = Form("SVD V-Cluster Time %s for layers 4,5,6 sensors for 3 samples", refFrame.Data());
364  m_cluster3TimeV456 = new TH1F(name.c_str(), Title.Data(), TimeBins, TimeMin, TimeMax);
365  m_cluster3TimeV456->GetXaxis()->SetTitle("cluster time (ns)");
366  m_cluster3TimeV456->GetYaxis()->SetTitle("count");
367  m_histoList->Add(m_cluster3TimeV456);
368
369  //----------------------------------------------------------------
370  // Time of clusters for L3/L456 sensors for 6 samples
371  //----------------------------------------------------------------
372  Name = "SVDDQM_Cluster6TimeU3";
373  Title = Form("SVD U-Cluster Time %s for layer 3 sensors for 6 samples", refFrame.Data());
374  m_cluster6TimeU3 = new TH1F(Name.Data(), Title.Data(), TimeBins, TimeMin, TimeMax);
375  m_cluster6TimeU3->GetXaxis()->SetTitle("cluster time (ns)");
376  m_cluster6TimeU3->GetYaxis()->SetTitle("count");
377  m_histoList->Add(m_cluster6TimeU3);
378  name = str(format("SVDDQM_Cluster6TimeV3"));
379  Title = Form("SVD V-Cluster Time %s for layer 3 sensors for 6 samples", refFrame.Data());
380  m_cluster6TimeV3 = new TH1F(name.c_str(), Title.Data(), TimeBins, TimeMin, TimeMax);
381  m_cluster6TimeV3->GetXaxis()->SetTitle("cluster time (ns)");
382  m_cluster6TimeV3->GetYaxis()->SetTitle("count");
383  m_histoList->Add(m_cluster6TimeV3);
384
385  name = str(format("SVDDQM_Cluster6TimeU456"));
386  Title = Form("SVD U-Cluster Time %s for layers 4,5,6 sensors for 6 samples", refFrame.Data());
387  m_cluster6TimeU456 = new TH1F(name.c_str(), Title.Data(), TimeBins, TimeMin, TimeMax);
388  m_cluster6TimeU456->GetXaxis()->SetTitle("cluster time (ns)");
389  m_cluster6TimeU456->GetYaxis()->SetTitle("count");
390  m_histoList->Add(m_cluster6TimeU456);
391  name = str(format("SVDDQM_Cluster6TimeV456"));
392  Title = Form("SVD V-Cluster Time %s for layers 4,5,6 sensors for 6 samples", refFrame.Data());
393  m_cluster6TimeV456 = new TH1F(name.c_str(), Title.Data(), TimeBins, TimeMin, TimeMax);
394  m_cluster6TimeV456->GetXaxis()->SetTitle("cluster time (ns)");
395  m_cluster6TimeV456->GetYaxis()->SetTitle("count");
396  m_histoList->Add(m_cluster6TimeV456);
397
398
399  //----------------------------------------------------------------
400  // Cluster time group Id vs cluster time for 3-6 samples
401  //----------------------------------------------------------------
402  Name = "SVDDQM_Cluster3TimeGroupId";
403  Title = Form("SVD cluster Time GourpId %s vs cluster time for 3 samples", refFrame.Data());
404  m_cluster3TimeGroupId = new TH2F(Name.Data(), Title.Data(), TimeBins, TimeMin, TimeMax, GroupIdBins, GroupIdMin, GroupIdMax);
405  m_cluster3TimeGroupId->GetXaxis()->SetTitle("cluster time (ns)");
406  m_cluster3TimeGroupId->GetYaxis()->SetTitle("cluster group id");
407  m_histoList->Add(m_cluster3TimeGroupId);
408  Name = "SVDDQM_Cluster6TimeGroupId";
409  Title = Form("SVD cluster Time GourpId %s vs cluster time for 6 samples", refFrame.Data());
410  m_cluster6TimeGroupId = new TH2F(Name.Data(), Title.Data(), TimeBins, TimeMin, TimeMax, GroupIdBins, GroupIdMin, GroupIdMax);
411  m_cluster6TimeGroupId->GetXaxis()->SetTitle("cluster time (ns)");
412  m_cluster6TimeGroupId->GetYaxis()->SetTitle("cluster group id");
413  m_histoList->Add(m_cluster6TimeGroupId);
414
415  //----------------------------------------------------------------
416  // MaxBin of strips for all sensors (offline ZS)
417  //----------------------------------------------------------------
418  name = str(format("SVDDQM_StripMaxBinUAll"));
419  title = str(format("SVD U-Strip MaxBin for all sensors"));
420  m_stripMaxBinUAll = new TH1F(name.c_str(), title.c_str(), MaxBinBins, 0, MaxBinMax);
421  m_stripMaxBinUAll->GetXaxis()->SetTitle("max bin");
422  m_stripMaxBinUAll->GetYaxis()->SetTitle("count");
423  m_histoList->Add(m_stripMaxBinUAll);
424  name = str(format("SVDDQM_StripMaxBinVAll"));
425  title = str(format("SVD V-Strip MaxBin for all sensors"));
426  m_stripMaxBinVAll = new TH1F(name.c_str(), title.c_str(), MaxBinBins, 0, MaxBinMax);
427  m_stripMaxBinVAll->GetXaxis()->SetTitle("max bin");
428  m_stripMaxBinVAll->GetYaxis()->SetTitle("count");
429  m_histoList->Add(m_stripMaxBinVAll);
430
431  name = str(format("SVDDQM_StripMaxBinU3"));
432  title = str(format("SVD U-Strip MaxBin for layer 3 sensors"));
433  m_stripMaxBinU3 = new TH1F(name.c_str(), title.c_str(), MaxBinBins, 0, MaxBinMax);
434  m_stripMaxBinU3->GetXaxis()->SetTitle("max bin");
435  m_stripMaxBinU3->GetYaxis()->SetTitle("count");
436  m_histoList->Add(m_stripMaxBinU3);
437  name = str(format("SVDDQM_StripMaxBinV3"));
438  title = str(format("SVD V-Strip MaxBin for layer 3 sensors"));
439  m_stripMaxBinV3 = new TH1F(name.c_str(), title.c_str(), MaxBinBins, 0, MaxBinMax);
440  m_stripMaxBinV3->GetXaxis()->SetTitle("max bin");
441  m_stripMaxBinV3->GetYaxis()->SetTitle("count");
442  m_histoList->Add(m_stripMaxBinV3);
443
444  name = str(format("SVDDQM_StripMaxBinU6"));
445  title = str(format("SVD U-Strip MaxBin for layer 6 sensors"));
446  m_stripMaxBinU6 = new TH1F(name.c_str(), title.c_str(), MaxBinBins, 0, MaxBinMax);
447  m_stripMaxBinU6->GetXaxis()->SetTitle("max bin");
448  m_stripMaxBinU6->GetYaxis()->SetTitle("count");
449  m_histoList->Add(m_stripMaxBinU6);
450  name = str(format("SVDDQM_StripMaxBinV6"));
451  title = str(format("SVD V-Strip MaxBin for layer 6 sensors"));
452  m_stripMaxBinV6 = new TH1F(name.c_str(), title.c_str(), MaxBinBins, 0, MaxBinMax);
453  m_stripMaxBinV6->GetXaxis()->SetTitle("max bin");
454  m_stripMaxBinV6->GetYaxis()->SetTitle("count");
455  m_histoList->Add(m_stripMaxBinV6);
456
457  for (int i = 0; i < nSVDSensors; i++) {
458  VxdID id = gTools->getSensorIDFromSVDIndex(i);
459  int iLayer = id.getLayerNumber();
460  int iLadder = id.getLadderNumber();
461  int iSensor = id.getSensorNumber();
462  VxdID sensorID(iLayer, iLadder, iSensor);
463  SVD::SensorInfo SensorInfo = dynamic_cast<const SVD::SensorInfo&>(VXD::GeoCache::get(sensorID));
464  string sensorDescr = str(format("%1%_%2%_%3%") % iLayer % iLadder % iSensor);
465
466  if (m_additionalPlots) {
467  //----------------------------------------------------------------
468  // Number of fired strips per sensor
469  //----------------------------------------------------------------
470  name = str(format("SVDDQM_%1%_FiredU") % sensorDescr);
471  title = str(format("SVD Sensor %1% Number of Fired U-Strips") % sensorDescr);
472  m_firedU[i] = new TH1F(name.c_str(), title.c_str(), 50, 0, 50);
473  m_firedU[i]->GetXaxis()->SetTitle("# fired strips");
474  m_firedU[i]->GetYaxis()->SetTitle("count");
475  m_histoList->Add(m_firedU[i]);
476  name = str(format("SVDDQM_%1%_FiredV") % sensorDescr);
477  title = str(format("SVD Sensor %1% Number of Fired V-Strips") % sensorDescr);
478  m_firedV[i] = new TH1F(name.c_str(), title.c_str(), 50, 0, 50);
479  m_firedV[i]->GetXaxis()->SetTitle("# fired strips");
480  m_firedV[i]->GetYaxis()->SetTitle("count");
481  m_histoList->Add(m_firedV[i]);
482  //----------------------------------------------------------------
483  // Number of clusters per sensor
484  //----------------------------------------------------------------
485  name = str(format("SVDDQM_%1%_ClustersU") % sensorDescr);
486  title = str(format("SVD Sensor %1% Number of U-Clusters") % sensorDescr);
487  m_clustersU[i] = new TH1F(name.c_str(), title.c_str(), 20, 0, 20);
488  m_clustersU[i]->GetXaxis()->SetTitle("# clusters");
489  m_clustersU[i]->GetYaxis()->SetTitle("count");
490  m_histoList->Add(m_clustersU[i]);
491  name = str(format("SVDDQM_%1%_ClustersV") % sensorDescr);
492  title = str(format("SVD Sensor %1% Number of V-Clusters") % sensorDescr);
493  m_clustersV[i] = new TH1F(name.c_str(), title.c_str(), 20, 0, 20);
494  m_clustersV[i]->GetXaxis()->SetTitle("# clusters");
495  m_clustersV[i]->GetYaxis()->SetTitle("count");
496  m_histoList->Add(m_clustersV[i]);
497  //----------------------------------------------------------------
498  // Charge of strips
499  //----------------------------------------------------------------
500  name = str(format("SVDDQM_%1%_ADCStripU") % sensorDescr);
501  title = str(format("SVD Sensor %1% U-Strip signal in ADC Counts, all 6 APV samples") % sensorDescr);
502  m_stripSignalU[i] = new TH1F(name.c_str(), title.c_str(), 256, -0.5, 255.5);
503  m_stripSignalU[i]->GetXaxis()->SetTitle("signal ADC");
504  m_stripSignalU[i]->GetYaxis()->SetTitle("count");
505  m_histoList->Add(m_stripSignalU[i]);
506  name = str(format("SVDDQM_%1%_ADCStripV") % sensorDescr);
507  title = str(format("SVD Sensor %1% V-Strip signal in ADC Counts, all 6 APV samples") % sensorDescr);
508  m_stripSignalV[i] = new TH1F(name.c_str(), title.c_str(), 256, -0.5, 255.5);
509  m_stripSignalV[i]->GetXaxis()->SetTitle("signal ADC");
510  m_stripSignalV[i]->GetYaxis()->SetTitle("count");
511  m_histoList->Add(m_stripSignalV[i]);
512  }
513
514  //----------------------------------------------------------------
515  // Charge of clusters
516  //----------------------------------------------------------------
517  name = str(format("SVDDQM_%1%_ClusterChargeU") % sensorDescr);
518  title = str(format("SVD Sensor %1% U-Cluster Charge") % sensorDescr);
519  m_clusterChargeU[i] = new TH1F(name.c_str(), title.c_str(), ChargeBins, 0, ChargeMax);
520  m_clusterChargeU[i]->GetXaxis()->SetTitle("cluster charge [ke-]");
521  m_clusterChargeU[i]->GetYaxis()->SetTitle("count");
522  m_histoList->Add(m_clusterChargeU[i]);
523  name = str(format("SVDDQM_%1%_ClusterChargeV") % sensorDescr);
524  title = str(format("SVD Sensor %1% V-Cluster Charge") % sensorDescr);
525  m_clusterChargeV[i] = new TH1F(name.c_str(), title.c_str(), ChargeBins, 0, ChargeMax);
526  m_clusterChargeV[i]->GetXaxis()->SetTitle("cluster charge [ke-]");
527  m_clusterChargeV[i]->GetYaxis()->SetTitle("count");
528  m_histoList->Add(m_clusterChargeV[i]);
529  //----------------------------------------------------------------
530  // SNR of clusters
531  //----------------------------------------------------------------
532  name = str(format("SVDDQM_%1%_ClusterSNRU") % sensorDescr);
533  title = str(format("SVD Sensor %1% U-Cluster SNR") % sensorDescr);
534  m_clusterSNRU[i] = new TH1F(name.c_str(), title.c_str(), SNRBins, 0, SNRMax);
535  m_clusterSNRU[i]->GetXaxis()->SetTitle("cluster SNR");
536  m_clusterSNRU[i]->GetYaxis()->SetTitle("count");
537  m_histoList->Add(m_clusterSNRU[i]);
538  name = str(format("SVDDQM_%1%_ClusterSNRV") % sensorDescr);
539  title = str(format("SVD Sensor %1% V-Cluster SNR") % sensorDescr);
540  m_clusterSNRV[i] = new TH1F(name.c_str(), title.c_str(), SNRBins, 0, SNRMax);
541  m_clusterSNRV[i]->GetXaxis()->SetTitle("cluster SNR");
542  m_clusterSNRV[i]->GetYaxis()->SetTitle("count");
543  m_histoList->Add(m_clusterSNRV[i]);
544
545  //----------------------------------------------------------------
546  // Strips Counts
547  //----------------------------------------------------------------
548  name = str(format("SVDDQM_%1%_StripCountU") % sensorDescr);
549  title = str(format("SVD Sensor %1% Integrated Number of ZS5 Fired U-Strip vs Strip Number") % sensorDescr);
550  m_stripCountU[i] = new TH1F(name.c_str(), title.c_str(), 768, -0.5, 767.5);
551  m_stripCountU[i]->GetXaxis()->SetTitle("cellID");
552  m_stripCountU[i]->GetYaxis()->SetTitle("count");
553  m_histoList->Add(m_stripCountU[i]);
554  name = str(format("SVDDQM_%1%_StripCountV") % sensorDescr);
555  title = str(format("SVD Sensor %1% Integrated Number of ZS5 Fired V-Strip vs Strip Number") % sensorDescr);
556  m_stripCountV[i] = new TH1F(name.c_str(), title.c_str(), 768, -0.5, 767.5);
557  m_stripCountV[i]->GetXaxis()->SetTitle("cellID");
558  m_stripCountV[i]->GetYaxis()->SetTitle("count");
559  m_histoList->Add(m_stripCountV[i]);
560  //----------------------------------------------------------------
561  // Strips Counts with online ZS
562  //----------------------------------------------------------------
563  name = str(format("SVDDQM_%1%_OnlineZSStripCountU") % sensorDescr);
564  title = str(format("SVD Sensor %1% Integrated Number of online-ZS Fired U-Strip vs Strip Number") % sensorDescr);
565  m_onlineZSstripCountU[i] = new TH1F(name.c_str(), title.c_str(), 768, -0.5, 767.5);
566  m_onlineZSstripCountU[i]->GetXaxis()->SetTitle("cellID");
567  m_onlineZSstripCountU[i]->GetYaxis()->SetTitle("count");
568  m_histoList->Add(m_onlineZSstripCountU[i]);
569  name = str(format("SVDDQM_%1%_OnlineZSStripCountV") % sensorDescr);
570  title = str(format("SVD Sensor %1% Integrated Number of online-ZS Fired V-Strip vs Strip Number") % sensorDescr);
571  m_onlineZSstripCountV[i] = new TH1F(name.c_str(), title.c_str(), 768, -0.5, 767.5);
572  m_onlineZSstripCountV[i]->GetXaxis()->SetTitle("cellID");
573  m_onlineZSstripCountV[i]->GetYaxis()->SetTitle("count");
574  m_histoList->Add(m_onlineZSstripCountV[i]);
575
576  //----------------------------------------------------------------
577  // Strips Counts for 3 samples
578  //----------------------------------------------------------------
579  name = str(format("SVDDQM_%1%_Strip3CountU") % sensorDescr);
580  title = str(format("SVD Sensor %1% Integrated Number of ZS5 Fired U-Strip vs Strip Number for 3 samples") % sensorDescr);
581  m_strip3CountU[i] = new TH1F(name.c_str(), title.c_str(), 768, -0.5, 767.5);
582  m_strip3CountU[i]->GetXaxis()->SetTitle("cellID");
583  m_strip3CountU[i]->GetYaxis()->SetTitle("count");
584  m_histoList->Add(m_strip3CountU[i]);
585  name = str(format("SVDDQM_%1%_Strip3CountV") % sensorDescr);
586  title = str(format("SVD Sensor %1% Integrated Number of ZS5 Fired V-Strip vs Strip Number for 3 samples") % sensorDescr);
587  m_strip3CountV[i] = new TH1F(name.c_str(), title.c_str(), 768, -0.5, 767.5);
588  m_strip3CountV[i]->GetXaxis()->SetTitle("cellID");
589  m_strip3CountV[i]->GetYaxis()->SetTitle("count");
590  m_histoList->Add(m_strip3CountV[i]);
591  //----------------------------------------------------------------
592  // Strips Counts with online ZS for 3 samples
593  //----------------------------------------------------------------
594  name = str(format("SVDDQM_%1%_OnlineZSStrip3CountU") % sensorDescr);
595  title = str(format("SVD Sensor %1% Integrated Number of online-ZS Fired U-Strip vs Strip Number for 3 samples") % sensorDescr);
596  m_onlineZSstrip3CountU[i] = new TH1F(name.c_str(), title.c_str(), 768, -0.5, 767.5);
597  m_onlineZSstrip3CountU[i]->GetXaxis()->SetTitle("cellID");
598  m_onlineZSstrip3CountU[i]->GetYaxis()->SetTitle("count");
599  m_histoList->Add(m_onlineZSstrip3CountU[i]);
600  name = str(format("SVDDQM_%1%_OnlineZSStrip3CountV") % sensorDescr);
601  title = str(format("SVD Sensor %1% Integrated Number of online-ZS Fired V-Strip vs Strip Number for 3 samples") % sensorDescr);
602  m_onlineZSstrip3CountV[i] = new TH1F(name.c_str(), title.c_str(), 768, -0.5, 767.5);
603  m_onlineZSstrip3CountV[i]->GetXaxis()->SetTitle("cellID");
604  m_onlineZSstrip3CountV[i]->GetYaxis()->SetTitle("count");
605  m_histoList->Add(m_onlineZSstrip3CountV[i]);
606
607
608  //----------------------------------------------------------------
609  // Strips Counts for 6 samples
610  //----------------------------------------------------------------
611  name = str(format("SVDDQM_%1%_Strip6CountU") % sensorDescr);
612  title = str(format("SVD Sensor %1% Integrated Number of ZS5 Fired U-Strip vs Strip Number for 6 samples") % sensorDescr);
613  m_strip6CountU[i] = new TH1F(name.c_str(), title.c_str(), 768, -0.5, 767.5);
614  m_strip6CountU[i]->GetXaxis()->SetTitle("cellID");
615  m_strip6CountU[i]->GetYaxis()->SetTitle("count");
616  m_histoList->Add(m_strip6CountU[i]);
617  name = str(format("SVDDQM_%1%_Strip6CountV") % sensorDescr);
618  title = str(format("SVD Sensor %1% Integrated Number of ZS5 Fired V-Strip vs Strip Number for 6 samples") % sensorDescr);
619  m_strip6CountV[i] = new TH1F(name.c_str(), title.c_str(), 768, -0.5, 767.5);
620  m_strip6CountV[i]->GetXaxis()->SetTitle("cellID");
621  m_strip6CountV[i]->GetYaxis()->SetTitle("count");
622  m_histoList->Add(m_strip6CountV[i]);
623  //----------------------------------------------------------------
624  // Strips Counts with online ZS for 6 samples
625  //----------------------------------------------------------------
626  name = str(format("SVDDQM_%1%_OnlineZSStrip6CountU") % sensorDescr);
627  title = str(format("SVD Sensor %1% Integrated Number of online-ZS Fired U-Strip vs Strip Number for 6 samples") % sensorDescr);
628  m_onlineZSstrip6CountU[i] = new TH1F(name.c_str(), title.c_str(), 768, -0.5, 767.5);
629  m_onlineZSstrip6CountU[i]->GetXaxis()->SetTitle("cellID");
630  m_onlineZSstrip6CountU[i]->GetYaxis()->SetTitle("count");
631  m_histoList->Add(m_onlineZSstrip6CountU[i]);
632  name = str(format("SVDDQM_%1%_OnlineZSStrip6CountV") % sensorDescr);
633  title = str(format("SVD Sensor %1% Integrated Number of online-ZS Fired V-Strip vs Strip Number for 6 samples") % sensorDescr);
634  m_onlineZSstrip6CountV[i] = new TH1F(name.c_str(), title.c_str(), 768, -0.5, 767.5);
635  m_onlineZSstrip6CountV[i]->GetXaxis()->SetTitle("cellID");
636  m_onlineZSstrip6CountV[i]->GetYaxis()->SetTitle("count");
637  m_histoList->Add(m_onlineZSstrip6CountV[i]);
638
639
640  //----------------------------------------------------------------
641  // Strips Counts for cluster time group id = 0
642  //----------------------------------------------------------------
643  name = str(format("SVDDQM_%1%_StripCountGroupId0U") % sensorDescr);
644  title = str(format("SVD Sensor %1% Integrated NumberFired U-Strip for group Id = 0 vs Strip Number") % sensorDescr);
645  m_stripCountGroupId0U[i] = new TH1F(name.c_str(), title.c_str(), 768, -0.5, 767.5);
646  m_stripCountGroupId0U[i]->GetXaxis()->SetTitle("cellID");
647  m_stripCountGroupId0U[i]->GetYaxis()->SetTitle("count");
648  m_histoList->Add(m_stripCountGroupId0U[i]);
649  name = str(format("SVDDQM_%1%_StripCountGroupId0V") % sensorDescr);
650  title = str(format("SVD Sensor %1% Integrated Number of Fired V-Strip for group Id = 0 vs Strip Number") % sensorDescr);
651  m_stripCountGroupId0V[i] = new TH1F(name.c_str(), title.c_str(), 768, -0.5, 767.5);
652  m_stripCountGroupId0V[i]->GetXaxis()->SetTitle("cellID");
653  m_stripCountGroupId0V[i]->GetYaxis()->SetTitle("count");
654  m_histoList->Add(m_stripCountGroupId0V[i]);
655
656  //----------------------------------------------------------------
657  // Cluster size distribution
658  //----------------------------------------------------------------
659  name = str(format("SVDDQM_%1%_ClusterSizeU") % sensorDescr);
660  title = str(format("SVD Sensor %1% U-Cluster Size") % sensorDescr);
661  m_clusterSizeU[i] = new TH1F(name.c_str(), title.c_str(), 9, 1, 10);
662  m_clusterSizeU[i]->GetXaxis()->SetTitle("cluster size");
663  m_clusterSizeU[i]->GetYaxis()->SetTitle("count");
664  m_histoList->Add(m_clusterSizeU[i]);
665  name = str(format("SVDDQM_%1%_ClusterSizeV") % sensorDescr);
666  title = str(format("SVD Sensor %1% V-Cluster Size") % sensorDescr);
667  m_clusterSizeV[i] = new TH1F(name.c_str(), title.c_str(), 9, 1, 10);
668  m_clusterSizeV[i]->GetXaxis()->SetTitle("cluster size");
669  m_clusterSizeV[i]->GetYaxis()->SetTitle("count");
670  m_histoList->Add(m_clusterSizeV[i]);
671  //----------------------------------------------------------------
672  // Cluster time distribution
673  //----------------------------------------------------------------
674  name = str(format("SVDDQM_%1%_ClusterTimeU") % sensorDescr);
675  Title = Form("SVD Sensor %s U-Cluster Time %s", sensorDescr.c_str(), refFrame.Data());
676  m_clusterTimeU[i] = new TH1F(name.c_str(), Title.Data(), TimeBins, TimeMin, TimeMax);
677  m_clusterTimeU[i]->GetXaxis()->SetTitle("cluster time (ns)");
678  m_clusterTimeU[i]->GetYaxis()->SetTitle("count");
679  m_histoList->Add(m_clusterTimeU[i]);
680  name = str(format("SVDDQM_%1%_ClusterTimeV") % sensorDescr);
681  Title = Form("SVD Sensor %s V-Cluster Time %s", sensorDescr.c_str(), refFrame.Data());
682  m_clusterTimeV[i] = new TH1F(name.c_str(), Title.Data(), TimeBins, TimeMin, TimeMax);
683  m_clusterTimeV[i]->GetXaxis()->SetTitle("cluster time (ns)");
684  m_clusterTimeV[i]->GetYaxis()->SetTitle("count");
685  m_histoList->Add(m_clusterTimeV[i]);
686  }
687
688  for (int i = 0; i < nSVDChips; i++) {
689  VxdID id = gTools->getChipIDFromSVDIndex(i);
690  int iLayer = id.getLayerNumber();
691  int iLadder = id.getLadderNumber();
692  int iSensor = id.getSensorNumber();
693  int iChip = gTools->getSVDChipNumber(id);
694  int IsU = gTools->isSVDSideU(id);
695  TString AxisTicks = Form("%i_%i_%i_u%i", iLayer, iLadder, iSensor, iChip);
696  if (!IsU)
697  AxisTicks = Form("%i_%i_%i_v%i", iLayer, iLadder, iSensor, iChip);
698  m_hitMapCountsChip->GetXaxis()->SetBinLabel(i + 1, AxisTicks.Data());
699  m_hitMapClCountsChip->GetXaxis()->SetBinLabel(i + 1, AxisTicks.Data());
700  }
701
702
703
704  //----------------------------------------------------------------
705  // Additional histograms for out of ExpressReco
706  //----------------------------------------------------------------
707
708  if (m_ShowAllHistos == 1) {
709  TDirectory* dirShowAll = nullptr;
710  dirShowAll = oldDir->mkdir("SVDDQMAll");
711  dirShowAll->cd();
712
713  m_hitMapU = new TH2F*[nSVDSensors];
714  m_hitMapV = new TH2F*[nSVDSensors];
715  m_hitMapUCl = new TH1F*[nSVDSensors];
716  m_hitMapVCl = new TH1F*[nSVDSensors];
717  for (int i = 0; i < nSVDSensors; i++) {
718  VxdID id = gTools->getSensorIDFromSVDIndex(i);
719  int iLayer = id.getLayerNumber();
720  int iLadder = id.getLadderNumber();
721  int iSensor = id.getSensorNumber();
722  VxdID sensorID(iLayer, iLadder, iSensor);
723  SVD::SensorInfo SensorInfo = dynamic_cast<const SVD::SensorInfo&>(VXD::GeoCache::get(sensorID));
724  string sensorDescr = str(format("%1%_%2%_%3%") % iLayer % iLadder % iSensor);
725  //----------------------------------------------------------------
726  // Hitmaps: Number of strips by coordinate
727  //----------------------------------------------------------------
728  name = str(format("SVD_%1%_StripHitmapU") % sensorDescr);
729  title = str(format("SVD Sensor %1% Strip Hitmap in U") % sensorDescr);
730  int nStrips = SensorInfo.getUCells();
731  m_hitMapU[i] = new TH2F(name.c_str(), title.c_str(), nStrips, 0, nStrips, SVDShaperDigit::c_nAPVSamples, 0,
732  SVDShaperDigit::c_nAPVSamples);
733  m_hitMapU[i]->GetXaxis()->SetTitle("u position [pitch units]");
734  m_hitMapU[i]->GetYaxis()->SetTitle("timebin [time units]");
735  m_hitMapU[i]->GetZaxis()->SetTitle("hits");
736  m_histoList->Add(m_hitMapU[i]);
737  name = str(format("SVD_%1%_StripHitmapV") % sensorDescr);
738  title = str(format("SVD Sensor %1% Strip Hitmap in V") % sensorDescr);
739  nStrips = SensorInfo.getVCells();
740  m_hitMapV[i] = new TH2F(name.c_str(), title.c_str(), nStrips, 0, nStrips, SVDShaperDigit::c_nAPVSamples, 0,
741  SVDShaperDigit::c_nAPVSamples);
742  m_hitMapV[i]->GetXaxis()->SetTitle("v position [pitch units]");
743  m_hitMapV[i]->GetYaxis()->SetTitle("timebin [time units]");
744  m_hitMapV[i]->GetZaxis()->SetTitle("hits");
745  m_histoList->Add(m_hitMapV[i]);
746  //----------------------------------------------------------------
747  // Hitmaps: Number of clusters by coordinate
748  //----------------------------------------------------------------
749  name = str(format("SVD_%1%_HitmapClstU") % sensorDescr);
750  title = str(format("SVD Sensor %1% Hitmap Clusters in U") % sensorDescr);
751  nStrips = SensorInfo.getUCells();
752  m_hitMapUCl[i] = new TH1F(name.c_str(), title.c_str(), nStrips, 0, nStrips);
753  m_hitMapUCl[i]->GetXaxis()->SetTitle("u position [pitch units]");
754  m_hitMapUCl[i]->GetYaxis()->SetTitle("hits");
755  m_histoList->Add(m_hitMapUCl[i]);
756  name = str(format("SVD_%1%_HitmapClstV") % sensorDescr);
757  title = str(format("SVD Sensor %1% Hitmap Clusters in V") % sensorDescr);
758  nStrips = SensorInfo.getVCells();
759  m_hitMapVCl[i] = new TH1F(name.c_str(), title.c_str(), nStrips, 0, nStrips);
760  m_hitMapVCl[i]->GetXaxis()->SetTitle("v position [pitch units]");
761  m_hitMapVCl[i]->GetYaxis()->SetTitle("hits");
762  m_histoList->Add(m_hitMapVCl[i]);
763  }
764  }
765
766  oldDir->cd();
767 }
Belle2::SVDDQMExpressRecoModule::m_hitMapUCl
TH1F ** m_hitMapUCl
Hitmaps clusters for u.
Definition: SVDDQMExpressRecoModule.h:266
Belle2::SVDDQMExpressRecoModule::m_clustersV
TH1F ** m_clustersV
number of v clusters per event
Definition: SVDDQMExpressRecoModule.h:124
Belle2::SVDDQMExpressRecoModule::m_onlineZSstrip6CountV
TH1F ** m_onlineZSstrip6CountV
v strip count (online Zero Suppression for 6 samples
Definition: SVDDQMExpressRecoModule.h:209
Belle2::SVDDQMExpressRecoModule::m_clusterSNRVAll
TH1F * m_clusterSNRVAll
v SNR of clusters for all sensors
Definition: SVDDQMExpressRecoModule.h:150
Belle2::SVDDQMExpressRecoModule::m_cluster3TimeV3
TH1F * m_cluster3TimeV3
v Time of clusters for layer 3 sensors for 3 samples
Definition: SVDDQMExpressRecoModule.h:242
Belle2::SVDDQMExpressRecoModule::m_clusterTimeV456
TH1F * m_clusterTimeV456
v Time of clusters for layer 4,5,6 sensors
Definition: SVDDQMExpressRecoModule.h:237
Belle2::SVDDQMExpressRecoModule::m_clusterSNRUAll
TH1F * m_clusterSNRUAll
u SNR of clusters for all sensors
Definition: SVDDQMExpressRecoModule.h:148
Belle2::SVDDQMExpressRecoModule::m_clusterChargeU3
TH1F * m_clusterChargeU3
u charge of clusters for layer 3 sensors
Definition: SVDDQMExpressRecoModule.h:135
Belle2::SVDDQMExpressRecoModule::m_clusterSNRV3
TH1F * m_clusterSNRV3
v SNR of clusters for layer 3 sensors
Definition: SVDDQMExpressRecoModule.h:154
Belle2::SVDDQMExpressRecoModule::m_hitMapCountsV
TH1F * m_hitMapCountsV
Hitmaps v of Digits.
Definition: SVDDQMExpressRecoModule.h:108
Belle2::SVDDQMExpressRecoModule::m_hitMapU
TH2F ** m_hitMapU
Hitmaps pixels for u.
Definition: SVDDQMExpressRecoModule.h:262
Belle2::SVDDQMExpressRecoModule::m_cluster3TimeU3
TH1F * m_cluster3TimeU3
u Time of clusters for layer 3 sensors for 3 samples
Definition: SVDDQMExpressRecoModule.h:240
Belle2::SVDDQMExpressRecoModule::m_stripMaxBinU6
TH1F * m_stripMaxBinU6
u MaxBin of strips for layer 6 sensors (offline Zero Suppression)
Definition: SVDDQMExpressRecoModule.h:169
Belle2::SVDDQMExpressRecoModule::m_clusterTimeUAll
TH1F * m_clusterTimeUAll
u time of clusters for all sensors
Definition: SVDDQMExpressRecoModule.h:227
Belle2::SVDDQMExpressRecoModule::m_hitMapClCountsU
TH1F * m_hitMapClCountsU
Hitmaps u of Clusters.
Definition: SVDDQMExpressRecoModule.h:110
Belle2::SVDDQMExpressRecoModule::m_hitMapCountsU
TH1F * m_hitMapCountsU
Hitmaps u of Digits.
Definition: SVDDQMExpressRecoModule.h:106
Belle2::SVDDQMExpressRecoModule::m_clusterSNRV
TH1F ** m_clusterSNRV
v SNR of clusters per sensor
Definition: SVDDQMExpressRecoModule.h:146
Belle2::SVDDQMExpressRecoModule::m_clusterChargeV
TH1F ** m_clusterChargeV
v charge of clusters
Definition: SVDDQMExpressRecoModule.h:129
Belle2::SVDDQMExpressRecoModule::m_stripSignalU
TH1F ** m_stripSignalU
u charge of strips
Definition: SVDDQMExpressRecoModule.h:174
Belle2::SVDDQMExpressRecoModule::m_clusterChargeUAll
TH1F * m_clusterChargeUAll
u charge of clusters for all sensors
Definition: SVDDQMExpressRecoModule.h:131
Belle2::SVDDQMExpressRecoModule::m_clusterChargeU456
TH1F * m_clusterChargeU456
u charge of clusters for layer 4,5,6 sensors
Definition: SVDDQMExpressRecoModule.h:139
Belle2::SVDDQMExpressRecoModule::m_clusterTimeV3
TH1F * m_clusterTimeV3
v Time of clusters for layer 3 sensors
Definition: SVDDQMExpressRecoModule.h:233
Belle2::SVDDQMExpressRecoModule::m_clusterSNRU
TH1F ** m_clusterSNRU
u SNR of clusters per sensor
Definition: SVDDQMExpressRecoModule.h:144
Belle2::SVDDQMExpressRecoModule::m_hitMapVCl
TH1F ** m_hitMapVCl
Hitmaps clusters for v.
Definition: SVDDQMExpressRecoModule.h:268
Belle2::SVDDQMExpressRecoModule::m_stripMaxBinV3
TH1F * m_stripMaxBinV3
v MaxBin of strips for layer 3 sensors (offline Zero Suppression)
Definition: SVDDQMExpressRecoModule.h:167
Belle2::SVDDQMExpressRecoModule::m_clusterTimeVAll
TH1F * m_clusterTimeVAll
v time of clusters for all sensors
Definition: SVDDQMExpressRecoModule.h:229
Belle2::SVDDQMExpressRecoModule::m_onlineZSstripCountV
TH1F ** m_onlineZSstripCountV
v strip count (online Zero Suppression
Definition: SVDDQMExpressRecoModule.h:184
Belle2::SVDDQMExpressRecoModule::m_stripSignalV
TH1F ** m_stripSignalV
v charge of strips
Definition: SVDDQMExpressRecoModule.h:176
Belle2::SVDDQMExpressRecoModule::m_strip6CountU
TH1F ** m_strip6CountU
u strip count for 6 samples
Definition: SVDDQMExpressRecoModule.h:203
Belle2::SVDDQMExpressRecoModule::m_cluster6TimeU3
TH1F * m_cluster6TimeU3
u Time of clusters for layer 3 sensors for 6 samples
Definition: SVDDQMExpressRecoModule.h:249
Belle2::SVDDQMExpressRecoModule::m_cluster6TimeGroupId
TH2F * m_cluster6TimeGroupId
time group id for 6 samples
Definition: SVDDQMExpressRecoModule.h:220
Belle2::SVDDQMExpressRecoModule::m_histogramDirectoryName
std::string m_histogramDirectoryName
Name of the histogram directory in ROOT file.
Definition: SVDDQMExpressRecoModule.h:93
Belle2::SVDDQMExpressRecoModule::m_clusterChargeVAll
TH1F * m_clusterChargeVAll
v charge of clusters for all sensors
Definition: SVDDQMExpressRecoModule.h:133
Belle2::SVDDQMExpressRecoModule::m_onlineZSstrip6CountU
TH1F ** m_onlineZSstrip6CountU
u strip count (online Zero Suppression) for 6 samples
Definition: SVDDQMExpressRecoModule.h:207
Belle2::SVDDQMExpressRecoModule::m_clusterSNRU3
TH1F * m_clusterSNRU3
u SNR of clusters for layer 3 sensors
Definition: SVDDQMExpressRecoModule.h:152
Belle2::SVDDQMExpressRecoModule::m_cluster6TimeU456
TH1F * m_cluster6TimeU456
u Time of clusters for layer 4,5,6 sensors for 6 samples
Definition: SVDDQMExpressRecoModule.h:253
Belle2::SVDDQMExpressRecoModule::m_clusterSNRV456
TH1F * m_clusterSNRV456
v SNR of clusters for layer 4,5,6 sensors
Definition: SVDDQMExpressRecoModule.h:158
Belle2::SVDDQMExpressRecoModule::m_stripMaxBinUAll
TH1F * m_stripMaxBinUAll
u MaxBin of strips for all sensors (offline Zero Suppression)
Definition: SVDDQMExpressRecoModule.h:161
Belle2::SVDDQMExpressRecoModule::m_histoList
TList * m_histoList
list of cumulative histograms
Definition: SVDDQMExpressRecoModule.h:76
Belle2::SVDDQMExpressRecoModule::m_clusterChargeU
TH1F ** m_clusterChargeU
u charge of clusters
Definition: SVDDQMExpressRecoModule.h:127
Belle2::SVDDQMExpressRecoModule::m_hitMapCountsChip
TH1F * m_hitMapCountsChip
Hitmaps of digits on chips.
Definition: SVDDQMExpressRecoModule.h:114
Belle2::SVDDQMExpressRecoModule::m_clusterChargeV3
TH1F * m_clusterChargeV3
v charge of clusters for layer 3 sensors
Definition: SVDDQMExpressRecoModule.h:137
Belle2::SVDDQMExpressRecoModule::m_hitMapV
TH2F ** m_hitMapV
Hitmaps pixels for v.
Definition: SVDDQMExpressRecoModule.h:264
Belle2::SVDDQMExpressRecoModule::m_cluster3TimeGroupId
TH2F * m_cluster3TimeGroupId
time group id for 3 samples
Definition: SVDDQMExpressRecoModule.h:217
Belle2::SVDDQMExpressRecoModule::m_strip3CountV
TH1F ** m_strip3CountV
v strip count for 3 samples
Definition: SVDDQMExpressRecoModule.h:195
Belle2::SVDDQMExpressRecoModule::m_stripMaxBinV6
TH1F * m_stripMaxBinV6
v MaxBin of strips for layer 6 sensors (offline Zero Suppression)
Definition: SVDDQMExpressRecoModule.h:171
Belle2::SVDDQMExpressRecoModule::m_stripCountGroupId0V
TH1F ** m_stripCountGroupId0V
V strip count for cluster time group Id = 0.
Definition: SVDDQMExpressRecoModule.h:190
Belle2::SVDDQMExpressRecoModule::m_cluster6TimeV456
TH1F * m_cluster6TimeV456
v Time of clusters for layer 4,5,6 sensors for 6 samples
Definition: SVDDQMExpressRecoModule.h:255
Belle2::SVDDQMExpressRecoModule::m_firedU
TH1F ** m_firedU
Fired u strips per event.
Definition: SVDDQMExpressRecoModule.h:118
Belle2::SVDDQMExpressRecoModule::m_clusterTimeU3
TH1F * m_clusterTimeU3
u Time of clusters for layer 3 sensors
Definition: SVDDQMExpressRecoModule.h:231
Belle2::SVDDQMExpressRecoModule::m_clusterSNRU456
TH1F * m_clusterSNRU456
u SNR of clusters for layer 4,5,6 sensors
Definition: SVDDQMExpressRecoModule.h:156
Belle2::SVDDQMExpressRecoModule::m_onlineZSstripCountU
TH1F ** m_onlineZSstripCountU
u strip count (online Zero Suppression)
Definition: SVDDQMExpressRecoModule.h:182
Belle2::SVDDQMExpressRecoModule::m_ShowAllHistos
int m_ShowAllHistos
Flag to show all histos in DQM, default = 0 (do not show)
Definition: SVDDQMExpressRecoModule.h:84
Belle2::SVDDQMExpressRecoModule::m_additionalPlots
bool m_additionalPlots
additional plots flag
Definition: SVDDQMExpressRecoModule.h:73
Belle2::SVDDQMExpressRecoModule::m_cluster3TimeV456
TH1F * m_cluster3TimeV456
v Time of clusters for layer 4,5,6 sensors for 3 samples
Definition: SVDDQMExpressRecoModule.h:246
Belle2::SVDDQMExpressRecoModule::m_cluster6TimeV3
TH1F * m_cluster6TimeV3
v Time of clusters for layer 3 sensors for 6 samples
Definition: SVDDQMExpressRecoModule.h:251
Belle2::SVDDQMExpressRecoModule::m_stripMaxBinU3
TH1F * m_stripMaxBinU3
u MaxBin of strips for layer 3 sensors (offline Zero Suppression)
Definition: SVDDQMExpressRecoModule.h:165
Belle2::SVDDQMExpressRecoModule::m_desynchSVDTime
bool m_desynchSVDTime
if TRUE: svdTime back in SVD time reference
Definition: SVDDQMExpressRecoModule.h:65
Belle2::SVDDQMExpressRecoModule::m_cluster3TimeU456
TH1F * m_cluster3TimeU456
u Time of clusters for layer 4,5,6 sensors for 3 samples
Definition: SVDDQMExpressRecoModule.h:244
Belle2::SVDDQMExpressRecoModule::m_onlineZSstrip3CountU
TH1F ** m_onlineZSstrip3CountU
u strip count (online Zero Suppression) for 3 samples
Definition: SVDDQMExpressRecoModule.h:197
Belle2::SVDDQMExpressRecoModule::m_onlineZSstrip3CountV
TH1F ** m_onlineZSstrip3CountV
v strip count (online Zero Suppression for 3 samples
Definition: SVDDQMExpressRecoModule.h:199
Belle2::SVDDQMExpressRecoModule::m_stripMaxBinVAll
TH1F * m_stripMaxBinVAll
v MaxBin of strips for all sensors (offline Zero Suppression)
Definition: SVDDQMExpressRecoModule.h:163
Belle2::SVDDQMExpressRecoModule::m_hitMapClCountsChip
TH1F * m_hitMapClCountsChip
Hitmaps of clusters on chips.
Definition: SVDDQMExpressRecoModule.h:116
Belle2::SVDDQMExpressRecoModule::m_clusterTimeU456
TH1F * m_clusterTimeU456
u Time of clusters for layer 4,5,6 sensors
Definition: SVDDQMExpressRecoModule.h:235
Belle2::SVDDQMExpressRecoModule::m_firedV
TH1F ** m_firedV
Fired v strips per event.
Definition: SVDDQMExpressRecoModule.h:120
Belle2::SVDDQMExpressRecoModule::m_clusterChargeV456
TH1F * m_clusterChargeV456
v charge of clusters for layer 4,5,6 sensors
Definition: SVDDQMExpressRecoModule.h:141
Belle2::SVDDQMExpressRecoModule::m_strip6CountV
TH1F ** m_strip6CountV
v strip count for 3 samples
Definition: SVDDQMExpressRecoModule.h:205
Belle2::SVDDQMExpressRecoModule::m_stripCountGroupId0U
TH1F ** m_stripCountGroupId0U
U strip count for cluster time group Id = 0.
Definition: SVDDQMExpressRecoModule.h:187
Belle2::SVDDQMExpressRecoModule::m_hitMapClCountsV
TH1F * m_hitMapClCountsV
Hitmaps v of Clusters.
Definition: SVDDQMExpressRecoModule.h:112
Belle2::SVDDQMExpressRecoModule::m_clustersU
TH1F ** m_clustersU
number of u clusters per event
Definition: SVDDQMExpressRecoModule.h:122
Belle2::SVDDQMExpressRecoModule::m_strip3CountU
TH1F ** m_strip3CountU
u strip count for 3 samples
Definition: SVDDQMExpressRecoModule.h:193
Belle2::SVDShaperDigit::c_nAPVSamples
static const std::size_t c_nAPVSamples
Number of APV samples stored.
Definition: SVDShaperDigit.h:37
Belle2::SVD::SensorInfo
Specific implementation of SensorInfo for SVD Sensors which provides additional sensor specific infor...
Definition: SensorInfo.h:25
Belle2::VXD::GeoCache::getInstance
static GeoCache & getInstance()
Return a reference to the singleton instance.
Definition: GeoCache.cc:214
Belle2::VXD::GeoCache::getGeoTools
const GeoTools * getGeoTools()
Return a raw pointer to a GeoTools object.
Definition: GeoCache.h:147
Belle2::VXD::GeoCache::get
static const SensorInfoBase & get(Belle2::VxdID id)
Return a reference to the SensorInfo of a given SensorID.
Definition: GeoCache.h:139
Belle2::VXD::SensorInfoBase::getVCells
int getVCells() const
Return number of pixel/strips in v direction.
Definition: SensorInfoBase.h:216
Belle2::VXD::SensorInfoBase::getUCells
int getUCells() const
Return number of pixel/strips in u direction.
Definition: SensorInfoBase.h:214
Belle2::VxdID
Class to uniquely identify a any structure of the PXD and SVD.
Definition: VxdID.h:33
Belle2::VxdID::getLayerNumber
baseType getLayerNumber() const
Get the layer id.
Definition: VxdID.h:96

◆ evalCondition()

bool evalCondition ( ) const
inherited

If at least one condition was set, it is evaluated and true returned if at least one condition returns true.

If no condition or result value was defined, the method returns false. Otherwise, the condition is evaluated and true returned, if at least one condition returns true. To speed up the evaluation, the condition strings were already parsed in the method if_value().

Returns
True if at least one condition and return value exists and at least one condition expression was evaluated to true.

Definition at line 96 of file Module.cc.

◆ getAfterConditionPath()

Module::EAfterConditionPath getAfterConditionPath ( ) const
inherited

What to do after the conditional path is finished.

(defaults to c_End if no condition is set)

Definition at line 133 of file Module.cc.

◆ getConditionPath()

std::shared_ptr< Path > getConditionPath ( ) const
inherited

Returns the path of the last true condition (if there is at least one, else reaturn a null pointer).


Definition at line 113 of file Module.cc.

◆ getFileNames()

virtual std::vector<std::string> getFileNames ( bool  outputFiles)
inlinevirtualinherited

Return a list of output filenames for this modules.

This will be called when basf2 is run with "--dry-run" if the module has set either the c_Input or c_Output properties.

If the parameter outputFiles is false (for modules with c_Input) the list of input filenames should be returned (if any). If outputFiles is true (for modules with c_Output) the list of output files should be returned (if any).

If a module has sat both properties this member is called twice, once for each property.

The module should return the actual list of requested input or produced output filenames (including handling of input/output overrides) so that the grid system can handle input/output files correctly.

This function should return the same value when called multiple times. This is especially important when taking the input/output overrides from Environment as they get consumed when obtained so the finalized list of output files should be stored for subsequent calls.

Reimplemented in RootOutputModule, StorageRootOutputModule, and RootInputModule.

Definition at line 134 of file Module.h.

◆ getName()

const std::string& getName ( ) const
inlineinherited

Returns the name of the module.

This can be changed via e.g. set_name() in the steering file to give more useful names if there is more than one module of the same type.

For identifying the type of a module, using getType() (or type() in Python) is recommended.

Definition at line 187 of file Module.h.

◆ getParamInfoListPython()

std::shared_ptr< boost::python::list > getParamInfoListPython ( ) const
inherited

Returns a python list of all parameters.

Each item in the list consists of the name of the parameter, a string describing its type, a python list of all default values and the description of the parameter.

Returns
A python list containing the parameters of this parameter list.

Definition at line 279 of file Module.cc.

◆ getReturnValue()

int getReturnValue ( ) const
inlineinherited

Return the return value set by this module.

This value is only meaningful if hasReturnValue() is true

Definition at line 381 of file Module.h.

◆ getType()

const std::string & getType ( ) const
inherited

Returns the type of the module (i.e.

class name minus 'Module')

Definition at line 41 of file Module.cc.

◆ hasProperties()

bool hasProperties ( unsigned int  propertyFlags) const
inherited

Returns true if all specified property flags are available in this module.

Parameters
propertyFlagsOred EModulePropFlags which should be compared with the module flags.

Definition at line 160 of file Module.cc.

◆ if_false()

void if_false ( const std::shared_ptr< Path > &  path,
EAfterConditionPath  afterConditionPath = EAfterConditionPath::c_End
)
inherited

A simplified version to add a condition to the module.

Please note that successive calls of this function will add more than one condition to the module. If more than one condition results in true, only the last of them will be used.

Please be careful: Avoid creating cyclic paths, e.g. by linking a condition to a path which is processed before the path where this module is located in.

It is equivalent to the if_value() method, using the expression "<1". This method is meant to be used together with the setReturnValue(bool value) method.

Parameters
pathShared pointer to the Path which will be executed if the return value is false.
afterConditionPathWhat to do after executing 'path'.

Definition at line 85 of file Module.cc.

◆ if_true()

void if_true ( const std::shared_ptr< Path > &  path,
EAfterConditionPath  afterConditionPath = EAfterConditionPath::c_End
)
inherited

A simplified version to set the condition of the module.

Please note that successive calls of this function will add more than one condition to the module. If more than one condition results in true, only the last of them will be used.

Please be careful: Avoid creating cyclic paths, e.g. by linking a condition to a path which is processed before the path where this module is located in.

It is equivalent to the if_value() method, using the expression ">=1". This method is meant to be used together with the setReturnValue(bool value) method.

Parameters
pathShared pointer to the Path which will be executed if the return value is true.
afterConditionPathWhat to do after executing 'path'.

Definition at line 90 of file Module.cc.

◆ if_value()

void if_value ( const std::string &  expression,
const std::shared_ptr< Path > &  path,
EAfterConditionPath  afterConditionPath = EAfterConditionPath::c_End
)
inherited

Add a condition to the module.

Please note that successive calls of this function will add more than one condition to the module. If more than one condition results in true, only the last of them will be used.

See https://confluence.desy.de/display/BI/Software+ModCondTut or ModuleCondition for a description of the syntax.

Please be careful: Avoid creating cyclic paths, e.g. by linking a condition to a path which is processed before the path where this module is located in.

Parameters
expressionThe expression of the condition.
pathShared pointer to the Path which will be executed if the condition is evaluated to true.
afterConditionPathWhat to do after executing 'path'.

Definition at line 79 of file Module.cc.

◆ setDescription()

void setDescription ( const std::string &  description)
protectedinherited

Sets the description of the module.

Parameters
descriptionA description of the module.

Definition at line 214 of file Module.cc.

◆ setLogInfo()

void setLogInfo ( int  logLevel,
unsigned int  logInfo
)
inherited

Configure the printed log information for the given level.

Parameters
logLevelThe log level (one of LogConfig::ELogLevel)
logInfoWhat kind of info should be printed? ORed combination of LogConfig::ELogInfo flags.

Definition at line 73 of file Module.cc.

◆ setName()

void setName ( const std::string &  name)
inlineinherited

Set the name of the module.

Note
The module name is set when using the REG_MODULE macro, but the module can be renamed before calling process() using the set_name() function in your steering file.
Parameters
nameThe name of the module

Definition at line 214 of file Module.h.

◆ setParamPython()

void setParamPython ( const std::string &  name,
const boost::python::object &  pyObj
)
privateinherited

Implements a method for setting boost::python objects.

The method supports the following types: list, dict, int, double, string, bool The conversion of the python object to the C++ type and the final storage of the parameter value is done in the ModuleParam class.

Parameters
nameThe unique name of the parameter.
pyObjThe object which should be converted and stored as the parameter value.

Definition at line 234 of file Module.cc.

◆ setParamPythonDict()

void setParamPythonDict ( const boost::python::dict &  dictionary)
privateinherited

Implements a method for reading the parameter values from a boost::python dictionary.

The key of the dictionary has to be the name of the parameter and the value has to be of one of the supported parameter types.

Parameters
dictionaryThe python dictionary from which the parameter values are read.

Definition at line 249 of file Module.cc.

◆ setPropertyFlags()

void setPropertyFlags ( unsigned int  propertyFlags)
inherited

Sets the flags for the module properties.

Parameters
propertyFlagsbitwise OR of EModulePropFlags

Definition at line 208 of file Module.cc.

◆ setReturnValue() [1/2]

void setReturnValue ( bool  value)
protectedinherited

Sets the return value for this module as bool.

The bool value is saved as an integer with the convention 1 meaning true and 0 meaning false. The value can be used in the steering file to divide the analysis chain into several paths.

Parameters
valueThe value of the return value.

Definition at line 227 of file Module.cc.

◆ setReturnValue() [2/2]

void setReturnValue ( int  value)
protectedinherited

Sets the return value for this module as integer.

The value can be used in the steering file to divide the analysis chain into several paths.

Parameters
valueThe value of the return value.

Definition at line 220 of file Module.cc.

◆ setType()

void setType ( const std::string &  type)
protectedinherited

Set the module type.

Only for use by internal modules (which don't use the normal REG_MODULE mechanism).

Definition at line 48 of file Module.cc.

The documentation for this class was generated from the following files:
