MaterialScan2D Class Reference

Base class to create a Material Scan of the detector geometry. More...

#include <MaterialScan.h>

Inheritance diagram for MaterialScan2D:

Collaboration diagram for MaterialScan2D:

Classes
struct	ScanParams
	Helper struct to Store Parameters of a Scan. More...

Public Member Functions
	MaterialScan2D (TFile *rootFile, const std::string &name, const std::string &axisLabel, const ScanParams &params)
	Constructor. More...
bool	createNext (G4ThreeVector &origin, G4ThreeVector &direction) override
	Get the origin and direction for the next scan particle. More...
int	getNRays () const override
	Return the number of rays in this scan.
void	UserSteppingAction (const G4Step *step) override
	Record the material budget for each step of the particles.
std::string	getName () const
	Return the name of the scan.

Protected Member Functions
virtual void	getRay (G4ThreeVector &origin, G4ThreeVector &direction)=0
	Get the origin and direction for the next scan particle. More...
TH2D *	getHistogram (const std::string &name)
	get histogram for a given name, create if needed. More...
void	fillValue (const std::string &name, double value)
	Fill the recorded material budget into the corresponding histogram. More...
bool	checkStep (const G4Step *step)
	check for stuck tracks by looking at the step length

Protected Attributes
ScanParams	m_params
	Parameters for the scan.
double	m_curU
	Current value of the parametetr u.
double	m_stepU
	Stepsize for the parameter u.
double	m_curV
	Current value of the parametetr v.
double	m_stepV
	Stepsize for the parameter v.
double	m_curDepth
	Tracklength of the current Ray.
std::map< std::string, std::unique_ptr< TH2D > >	m_regions
	Map holding pointers to all created histograms.
TFile *	m_rootFile
	Pointer to the root file for the histograms.
std::string	m_name
	Name of the scan, will be prefixed to all histogram names.
std::string	m_axisLabel
	Labels for the coordinate axes.

Private Attributes
int	m_zeroSteps {0}
	Count the number of steps with (almost) zero length.

Static Private Attributes
static constexpr double	c_zeroTolerance = 1e-6
	maximum Step length to be considered zero
static constexpr int	c_maxZeroStepsNudge = 10
	maximum number of consecutive zero steps before nudging the track along
static constexpr int	c_maxZeroStepsKill = 20
	maximum number of consecutive zero steps before killing the track

Detailed Description

Base class to create a Material Scan of the detector geometry.

This class is used to record the Material budget encountered by a particle and provide origin and directions of all particles used for the scan.

Definition at line 80 of file MaterialScan.h.

Constructor & Destructor Documentation

MaterialScan2D()

MaterialScan2D	(	TFile *	rootFile,
		const std::string &	name,
		const std::string &	axisLabel,
		const ScanParams &	params
	)

Constructor.

Parameters

rootFile	Pointer to the ROOTFile where the histograms will be stored.
name	Prefix to preprend to all Histograms
axisLabel	Labels for the histogram axes, separated by semicolon
params	Parameters for the scan

Definition at line 78 of file MaterialScan.cc.

                                                                                                                          :
  MaterialScanBase(rootFile, name, axisLabel), m_params(params), m_curDepth(0)
{
  //Sort the parameters accordingly
  if (m_params.minU > m_params.maxU) std::swap(m_params.minU, m_params.maxU);
  if (m_params.minV > m_params.maxV) std::swap(m_params.minV, m_params.maxV);
  //Calculate step size of the parameters
  m_stepU = (m_params.maxU - m_params.minU) / m_params.nU;
  m_stepV = (m_params.maxV - m_params.minV) / m_params.nV;
  //Set Start values
  m_curU  = m_params.minU - m_stepU / 2.;
  m_curV  = m_params.minV + m_stepV / 2.;
  //Convert max depth to G4 units
  m_params.maxDepth /= Unit::mm;
  //Sort the list of ignored materials so that we can use binary search
  std::sort(m_params.ignoredMaterials.begin(), m_params.ignoredMaterials.end());
}

Member Function Documentation

createNext()

bool createNext ( G4ThreeVector &  origin, G4ThreeVector &  direction  )

overridevirtual

Get the origin and direction for the next scan particle.

Parameters

[out]	origin	Origin of the next scan particle
[out]	direction	Direction of the next scan particle

Returns

false if the scan is finished

Implements MaterialScanBase.

Definition at line 97 of file MaterialScan.cc.

fillValue()

void fillValue ( const std::string &  name, double  value  )

protected

Fill the recorded material budget into the corresponding histogram.

Parameters

name	Name of the histogram
value	Value to store

Definition at line 138 of file MaterialScan.cc.

getHistogram()

TH2D * getHistogram ( const std::string &  name )

protected

get histogram for a given name, create if needed.

Parameters

name	Name of the histogram

Definition at line 125 of file MaterialScan.cc.

getRay()

virtual void getRay ( G4ThreeVector &  origin, G4ThreeVector &  direction  )

protectedpure virtual

Get the origin and direction for the next scan particle.

To be overridden by descendents

Parameters

[out]	origin	Origin of the next scan particle
[out]	direction	Direction of the next scan particle

Implemented in MaterialScanPlanar, and MaterialScanSpherical.

---

The documentation for this class was generated from the following files:

• simulation/modules/include/MaterialScan.h
• simulation/modules/src/MaterialScan.cc
