Geometry parameters of a module (optical components + positioning) More...

#include <TOPGeoModule.h>

Inheritance diagram for TOPGeoModule:

Collaboration diagram for TOPGeoModule:

[legend]

Public Member Functions
	TOPGeoModule ()
	Default constructor.

	TOPGeoModule (int moduleID, double radius, double phi, double backwardZ, const std::string &name="TOPModule")
	Useful constructor. More...

	TOPGeoModule (const TOPGeoModule &module)
	Copy constructor.

TOPGeoModule &	operator= (const TOPGeoModule &module)
	Assignment operator.

	~TOPGeoModule ()
	Destructor.

void	setModuleCNumber (unsigned moduleCNumber)
	Sets module construction number (0 = ideal module = default) More...

void	setBarSegment1 (const TOPGeoBarSegment &bar)
	Sets bar segment No.1 (forward bar) More...

void	setBarSegment2 (const TOPGeoBarSegment &bar)
	Sets bar segment No.2 (backward bar) More...

void	setMirrorSegment (const TOPGeoMirrorSegment &mirror)
	Sets mirror segment. More...

void	setPrism (const TOPGeoPrism &prism)
	Sets prism. More...

void	setPMTArray (const TOPGeoPMTArray &array)
	Sets PMT array. More...

void	setDecoupledPMT (unsigned pmtID)
	Sets PMT as optically decoupled. More...

void	generateDecoupledPMTs (double fraction)
	Generate randomly a fraction of PMT's to be optically decoupled. More...

void	setBrokenGlue (int glueID, double fraction, double angle, const std::string &material)
	Sets glue to be broken (delaminated) More...

void	setPeelOffRegions (double thickness, const std::string &material)
	Sets parameters of the peel-off cookie volumes. More...

void	appendPeelOffRegion (unsigned ID, double fraction, double angle)
	Appends peel-off cookie region. More...

void	setPMTArrayDisplacement (const TOPGeoPMTArrayDisplacement &displ)
	Sets PMT array displacement. More...

void	setModuleDisplacement (const TOPGeoModuleDisplacement &displ)
	Sets module displacement. More...

int	getModuleID () const
	Returns module ID. More...

double	getRadius () const
	Returns radius of the bar central plane in Belle II frame. More...

double	getPhi () const
	Returns module azimuthal angle in Belle II frame. More...

double	getBackwardZ () const
	Returns the z position of prism-bar joint in Belle II frame. More...

unsigned	getModuleCNumber () const
	Returns module construction number (0 = ideal module) More...

const TOPGeoBarSegment &	getBarSegment1 () const
	Returns bar segment No.1 (forward bar) More...

const TOPGeoBarSegment &	getBarSegment2 () const
	Returns bar segment No.2 (backward bar) More...

const TOPGeoMirrorSegment &	getMirrorSegment () const
	Returns mirror segment. More...

const TOPGeoPrism &	getPrism () const
	Returns prism. More...

const TOPGeoPMTArray &	getPMTArray () const
	Returns PMT array. More...

const TOPGeoPMTArrayDisplacement &	getPMTArrayDisplacement () const
	Returns PMT array displacement. More...

const TOPGeoModuleDisplacement &	getModuleDisplacement () const
	Returns module displacement. More...

double	getBarLength () const
	Returns bar length (w/o prism) including glue joints. More...

double	getFullLength () const
	Returns full length (including prism, wavelenght filter and glue joints) More...

double	getForwardZ () const
	Returns the z position of the bar forward end in Belle II frame. More...

double	getBarThickness () const
	Returns average bar thickness (weigthed by segment lengths) More...

double	getBarWidth () const
	Returns average bar width (weigthed by segment lengths) More...

double	getSurfaceReflectivity (double energy) const
	Returns average surface reflectivity at given photon energy (weigthed by segment lengths) More...

double	getSigmaAlpha () const
	Returns average surface roughness parameter (weigthed by segment lengths) More...

double	getZc () const
	Returns z of bar center (w/o prism) in Belle II frame. More...

double	getInnerRadius () const
	Returns inner surface radius in Belle II frame. More...

const ROOT::Math::Transform3D &	getTransformation () const
	Returns transformation from internal (= nominal & displaced) to Belle II frame. More...

const ROOT::Math::Transform3D &	getTransformationNominal () const
	Returns transformation from nominal to Belle II frame. More...

ROOT::Math::XYZPoint	pointToLocal (const ROOT::Math::XYZPoint &point) const
	Transforms 3D point from Belle II to module internal (= nominal & displaced) frame. More...

ROOT::Math::XYZVector	momentumToLocal (const ROOT::Math::XYZVector &momentum) const
	Transforms momentum vector from Belle II to module internal (= nominal & displaced) frame. More...

ROOT::Math::XYZPoint	pointToGlobal (const ROOT::Math::XYZPoint &point) const
	Transforms 3D point from module internal (= nominal & displaced) frame to Belle II frame. More...

ROOT::Math::XYZVector	momentumToGlobal (const ROOT::Math::XYZVector &momentum) const
	Transforms momentum vector from module internal (= nominal & displaced) frame to Belle II frame. More...

ROOT::Math::XYZPoint	pointGlobalToNominal (const ROOT::Math::XYZPoint &point) const
	Transforms 3D point from Belle II to module nominal frame. More...

ROOT::Math::XYZVector	momentumGlobalToNominal (const ROOT::Math::XYZVector &momentum) const
	Transforms momentum vector from Belle II to module nominal frame. More...

ROOT::Math::XYZPoint	pointNominalToGlobal (const ROOT::Math::XYZPoint &point) const
	Transforms 3D point from module nominal frame to Belle II frame. More...

ROOT::Math::XYZVector	momentumNominalToGlobal (const ROOT::Math::XYZVector &momentum) const
	Transforms momentum vector from module nominal frame to Belle II frame. More...

bool	isConsistent () const override
	Check for consistency of data members. More...

void	print (const std::string &title="Module geometry parameters") const override
	Print the content of the class. More...

void	setName (const std::string &name)
	Sets object name. More...

const std::string &	getName () const
	Returns object name. More...

virtual void	printSurface (const GeoOpticalSurface &surface) const
	Print the content of optical surface. More...

double	getReflectivity (const GeoOpticalSurface &surface, double energy) const
	Returns reflectivity of optical surface at given photon energy. More...

Protected Member Functions
void	printUnderlined (const std::string &title) const
	Print the content of the class. More...

	ClassDef (TOPGeoBase, 1)
	ClassDef.

Protected Attributes
std::string	m_name
	geometry object name

Static Protected Attributes
static double	s_unit = Unit::cm
	conversion unit for length

static std::string	s_unitName
	conversion unit name

Private Member Functions
void	setTransformation () const
	Sets transformation cache.

	ClassDefOverride (TOPGeoModule, 3)
	do not write out More...

Private Attributes
int	m_moduleID = 0
	module ID

float	m_radius = 0
	radius of bar central plane in Belle II frame

float	m_phi = 0
	azimuthal angle in Belle II frame

float	m_backwardZ = 0
	z position of prism-bar joint in Belle II frame

unsigned	m_moduleCNumber = 0
	module construction number, 0 = ideal module

TOPGeoBarSegment	m_bar1
	bar segment 1 (forward bar)

TOPGeoBarSegment	m_bar2
	bar segment 2 (backward bar)

TOPGeoMirrorSegment	m_mirror
	mirror segment

TOPGeoPrism	m_prism
	prism

TOPGeoPMTArray	m_pmtArray
	geometry parameters of PMT array

TOPGeoPMTArrayDisplacement	m_arrayDisplacement
	PMT array displacement.

TOPGeoModuleDisplacement	m_moduleDisplacement
	module displacement

ROOT::Math::Transform3D *	m_transform = 0
	cache for transformation from internal (= nominal & displaced) to Belle II frame

ROOT::Math::Transform3D *	m_transformNominal = 0
	do not write out More...

Detailed Description

Geometry parameters of a module (optical components + positioning)

Definition at line 31 of file TOPGeoModule.h.

Constructor & Destructor Documentation

◆ TOPGeoModule()

TOPGeoModule	(	int	moduleID,
		double	radius,
		double	phi,
		double	backwardZ,
		const std::string &	name = `"TOPModule"`
	)

inline

Useful constructor.

Parameters

moduleID	module ID
radius	radius of the bar central plane in Belle II frame
phi	azimuthal angle in Belle II frame
backwardZ	z position of prism-bar joint in Belle II frame
name	object name

Definition at line 48 of file TOPGeoModule.h.

                                                      : TOPGeoBase(name),
       m_moduleID(moduleID), m_radius(radius), m_phi(phi), m_backwardZ(backwardZ)
     {}

Member Function Documentation

◆ appendPeelOffRegion()

void appendPeelOffRegion	(	unsigned	ID,
		double	fraction,
		double	angle
	)

inline

Appends peel-off cookie region.

Parameters

ID	region ID (1-based)
fraction	fraction of the area
angle	angle of the area

Definition at line 142 of file TOPGeoModule.h.

◆ ClassDefOverride()

ClassDefOverride	(	TOPGeoModule	,
		3
	)

private

do not write out

ClassDef

◆ generateDecoupledPMTs()

void generateDecoupledPMTs ( double fraction )

inline

Generate randomly a fraction of PMT's to be optically decoupled.

Parameters

fraction decoupled fraction

Definition at line 114 of file TOPGeoModule.h.

◆ getBackwardZ()

double getBackwardZ ( void ) const

inline

Returns the z position of prism-bar joint in Belle II frame.

Returns: z position

Definition at line 188 of file TOPGeoModule.h.

◆ getBarLength()

double getBarLength ( ) const

inline

Returns bar length (w/o prism) including glue joints.

Returns: length

Definition at line 248 of file TOPGeoModule.h.

◆ getBarSegment1()

const TOPGeoBarSegment& getBarSegment1 ( ) const

inline

Returns bar segment No.1 (forward bar)

Returns: bar segment geometry parameters

Definition at line 200 of file TOPGeoModule.h.

◆ getBarSegment2()

const TOPGeoBarSegment& getBarSegment2 ( ) const

inline

Returns bar segment No.2 (backward bar)

Returns: bar segment geometry parameters

Definition at line 206 of file TOPGeoModule.h.

◆ getBarThickness()

double getBarThickness ( ) const

inline

Returns average bar thickness (weigthed by segment lengths)

Returns: average bar thickness

Definition at line 269 of file TOPGeoModule.h.

◆ getBarWidth()

double getBarWidth ( ) const

inline

Returns average bar width (weigthed by segment lengths)

Returns: average bar width

Definition at line 280 of file TOPGeoModule.h.

◆ getForwardZ()

double getForwardZ ( void ) const

inline

Returns the z position of the bar forward end in Belle II frame.

Returns: z position

Definition at line 263 of file TOPGeoModule.h.

◆ getFullLength()

double getFullLength ( ) const

inline

Returns full length (including prism, wavelenght filter and glue joints)

Returns: length

Definition at line 257 of file TOPGeoModule.h.

◆ getInnerRadius()

double getInnerRadius ( ) const

inline

Returns inner surface radius in Belle II frame.

Returns: radius

Definition at line 320 of file TOPGeoModule.h.

◆ getMirrorSegment()

const TOPGeoMirrorSegment& getMirrorSegment ( ) const

inline

Returns mirror segment.

Returns: mirror segment geometry parameters

Definition at line 212 of file TOPGeoModule.h.

◆ getModuleCNumber()

unsigned getModuleCNumber ( ) const

inline

Returns module construction number (0 = ideal module)

Returns: construction number

Definition at line 194 of file TOPGeoModule.h.

◆ getModuleDisplacement()

const TOPGeoModuleDisplacement& getModuleDisplacement ( ) const

inline

Returns module displacement.

Returns: module displacement parameters

Definition at line 239 of file TOPGeoModule.h.

◆ getModuleID()

int getModuleID ( ) const

inline

Returns module ID.

Returns: module ID

Definition at line 170 of file TOPGeoModule.h.

◆ getName()

const std::string& getName ( void ) const

inlineinherited

Returns object name.

Returns: object name

Definition at line 51 of file TOPGeoBase.h.

◆ getPhi()

double getPhi ( void ) const

inline

Returns module azimuthal angle in Belle II frame.

Returns: azimuthal angle

Definition at line 182 of file TOPGeoModule.h.

◆ getPMTArray()

const TOPGeoPMTArray& getPMTArray ( ) const

inline

Returns PMT array.

Returns: PMT array geometry parameters

Definition at line 224 of file TOPGeoModule.h.

◆ getPMTArrayDisplacement()

const TOPGeoPMTArrayDisplacement& getPMTArrayDisplacement ( ) const

inline

Returns PMT array displacement.

Returns: PMT array displacement parameters

Definition at line 230 of file TOPGeoModule.h.

◆ getPrism()

const TOPGeoPrism& getPrism ( ) const

inline

Returns prism.

Returns: prism geometry parameters

Definition at line 218 of file TOPGeoModule.h.

◆ getRadius()

double getRadius ( ) const

inline

Returns radius of the bar central plane in Belle II frame.

Returns: radius

Definition at line 176 of file TOPGeoModule.h.

◆ getSigmaAlpha()

double getSigmaAlpha ( ) const

inline

Returns average surface roughness parameter (weigthed by segment lengths)

Returns: average surface roughness

Definition at line 303 of file TOPGeoModule.h.

◆ getSurfaceReflectivity()

double getSurfaceReflectivity ( double energy ) const

inline

Returns average surface reflectivity at given photon energy (weigthed by segment lengths)

Parameters

energy photon energy in [eV]

Returns: average reflectivity

Definition at line 292 of file TOPGeoModule.h.

◆ getTransformation()

const ROOT::Math::Transform3D& getTransformation ( ) const

inline

Returns transformation from internal (= nominal & displaced) to Belle II frame.

Returns: transformation

Definition at line 326 of file TOPGeoModule.h.

◆ getTransformationNominal()

const ROOT::Math::Transform3D& getTransformationNominal ( ) const

inline

Returns transformation from nominal to Belle II frame.

Returns: transformation

Definition at line 336 of file TOPGeoModule.h.

◆ getZc()

double getZc ( ) const

inline

Returns z of bar center (w/o prism) in Belle II frame.

Returns: z coordinate if bar center

Definition at line 314 of file TOPGeoModule.h.

◆ setBarSegment1()

void setBarSegment1 ( const TOPGeoBarSegment & bar )

inline

Sets bar segment No.1 (forward bar)

Parameters

bar	segment No.1 geometry parameters

Definition at line 78 of file TOPGeoModule.h.

◆ setBarSegment2()

void setBarSegment2 ( const TOPGeoBarSegment & bar )

inline

Sets bar segment No.2 (backward bar)

Parameters

bar	segment No.2 geometry parameters

Definition at line 84 of file TOPGeoModule.h.

◆ setDecoupledPMT()

void setDecoupledPMT ( unsigned pmtID )

inline

Sets PMT as optically decoupled.

Parameters

pmtID ID of PMT to be set as decoupled (1-based)

Definition at line 108 of file TOPGeoModule.h.

◆ setMirrorSegment()

void setMirrorSegment ( const TOPGeoMirrorSegment & mirror )

inline

Sets mirror segment.

Parameters

mirror mirror segment geometry parameters

Definition at line 90 of file TOPGeoModule.h.

◆ setModuleCNumber()

void setModuleCNumber ( unsigned moduleCNumber )

inline

Sets module construction number (0 = ideal module = default)

Parameters

moduleCNumber construction number

Definition at line 72 of file TOPGeoModule.h.

◆ setModuleDisplacement()

void setModuleDisplacement ( const TOPGeoModuleDisplacement & displ )

inline

Sets module displacement.

Parameters

displ module displacement parameters

Definition at line 161 of file TOPGeoModule.h.

◆ setName()

void setName ( const std::string & name )

inlineinherited

Sets object name.

Parameters

name	object name

Definition at line 45 of file TOPGeoBase.h.

◆ setPMTArray()

void setPMTArray ( const TOPGeoPMTArray & array )

inline

Sets PMT array.

Parameters

array PMT array geometry parameters

Definition at line 102 of file TOPGeoModule.h.

◆ setPMTArrayDisplacement()

void setPMTArrayDisplacement ( const TOPGeoPMTArrayDisplacement & displ )

inline

Sets PMT array displacement.

Parameters

displ PMT array displacement parameters

Definition at line 152 of file TOPGeoModule.h.

◆ setPrism()

void setPrism ( const TOPGeoPrism & prism )

inline

Sets prism.

Parameters

prism prism geometry parameters

Definition at line 96 of file TOPGeoModule.h.

Member Data Documentation

◆ m_transformNominal

ROOT::Math::Transform3D* m_transformNominal = 0

mutableprivate

do not write out

cache for transformation from nominal to Belle II frame

Definition at line 435 of file TOPGeoModule.h.

The documentation for this class was generated from the following files:

top/dbobjects/include/TOPGeoModule.h
top/dbobjects/src/TOPGeoModule.cc
