PXDGeometryPar Class Reference

The Class for VXD geometry. More...

#include <PXDGeometryPar.h>

Inheritance diagram for PXDGeometryPar:

Collaboration diagram for PXDGeometryPar:

Public Member Functions
	PXDGeometryPar ()
	Default constructor.
	PXDGeometryPar (PXDGeometryPar &geo)
	Copy constructor.
PXDGeometryPar &	operator= (PXDGeometryPar &geo)
	Assignemnt operator.
	~PXDGeometryPar ()
	Destructor.
bool	getBuildSupport () const
	build support
int	getNCutOuts () const
	get number of cutouts
void	setNCutOuts (int nCutouts)
	set number of cutouts
double	getCutOutWidth () const
	get width of cutouts
void	setCutOutWidth (double width)
	set width of cutouts
double	getCutOutHeight () const
	get height of cutouts
void	setCutOutHeight (double height)
	set height of cutouts
double	getCutOutShift () const
	get shift of cutouts
void	setCutOutShift (double shift)
	set shift of cutouts
double	getCutOutRPhi () const
	get rphi of cutouts
void	setCutOutRPhi (double rphi)
	set rphi of cutouts
double	getCutOutStartPhi () const
	get start phi of cutouts
void	setCutOutStartPhi (double start)
	set start phi of cutouts
double	getCutOutDeltaPhi () const
	get deltaphi of cutouts
void	setCutOutDeltaPhi (double delta)
	set deltaphi of cutouts
int	getNTubes () const
	get number of tubes
void	setNTubes (int nTubes)
	set number of tubes
double	getTubesMinZ () const
	get tubes minZ
void	setTubesMinZ (double minZ)
	set tubes minZ
double	getTubesMaxZ () const
	get tubes maxZ
void	setTubesMaxZ (double maxZ)
	set tubes maxZ
double	getTubesMinR () const
	get tubes minR
void	setTubesMinR (double minR)
	set tubes minR
double	getTubesMaxR () const
	get tubes maxR
void	setTubesMaxR (double maxR)
	set tubes maxR
double	getTubesRPhi () const
	get tubes tubes RPhi
void	setTubesRPhi (double rphi)
	set tubes tubes RPhi
double	getTubesStartPhi () const
	get tubes tubes StartPhi
void	setTubesStartPhi (double start)
	set tubes tubes StartPhi
double	getTubesDeltaPhi () const
	get tubes tubes DeltaPhi
void	setTubesDeltaPhi (double delta)
	set tubes tubes DeltaPhi
const std::string &	getTubesMaterial () const
	get tubes tubes material
void	setTubesMaterial (const std::string &material)
	set tubes tubes material
const std::vector< VXDPolyConePar > &	getEndflanges () const
	get Endflanges
std::vector< VXDPolyConePar > &	getEndflanges ()
	get Endflanges
std::vector< PXDSensorInfoPar * > &	getSensorInfos ()
	get sensorInfos
std::string	getPrefix () const
	get prefix
void	setPrefix (const std::string &prefix)
	set prefix
const VXDGlobalPar &	getGlobalParams () const
	get global parameters
void	setGlobalParams (const VXDGlobalPar &globals)
	set global parameters
const VXDEnvelopePar &	getEnvelope () const
	get envelope parameters
void	setEnvelope (const VXDEnvelopePar &envelope)
	set envelope parameters
const VXDGeoRadiationSensorsPar &	getRadiationSensors () const
	get radiation sensor parameters
void	setRadiationSensors (const VXDGeoRadiationSensorsPar &diamonds)
	set radiation sensor parameters
std::map< std::string, VXDAlignmentPar > &	getAlignmentMap ()
	get alignmant map
VXDAlignmentPar	getAlignment (std::string name) const
	get alignment parameters for component name
const std::vector< VXDHalfShellPar > &	getHalfShells () const
	get half-shell
std::vector< VXDHalfShellPar > &	getHalfShells ()
	get half-shell
std::map< int, VXDGeoLadderPar > &	getLadderMap ()
	get ladder map
const VXDGeoLadderPar &	getLadder (int layerID) const
	get ladder for given layer
const VXDGeoSensorPar &	getSensor (std::string sensorTypeID) const
	get sensor type
const VXDGeoComponentPar &	getComponent (std::string name) const
	get component
const std::map< std::string, VXDGeoSensorPar > &	getSensorMap () const
	get sensor map
std::map< std::string, VXDGeoSensorPar > &	getSensorMap ()
	get sensor map
const std::map< std::string, VXDGeoComponentPar > &	getComponentMap () const
	get component maps
std::map< std::string, VXDGeoComponentPar > &	getComponentMap ()
	get component maps
int	getSensitiveChipID (std::string name) const
	get Bkg sensitive chip Id
std::map< std::string, int > &	getSensitiveChipIdMap ()
	get sensitive chip id map
const std::vector< std::string > &	getComponentInsertOder () const
	get component insert order
std::vector< std::string > &	getComponentInsertOder ()
	get component insert order

Private Member Functions
	ClassDef (PXDGeometryPar, 5)
	ClassDef, must be the last term before the closing {}.

Private Attributes
std::vector< PXDSensorInfoPar * >	m_SensorInfo
	Vector of points to SensorInfo objects.
std::vector< VXDPolyConePar >	m_endflanges
	PXD Endflanges.
int	m_nCutouts {0}
	Number of PXD endflange coutOuts.
double	m_cutOutWidth {0}
	Width of PXD endflange coutOuts.
double	m_cutOutHeight {0}
	Height of PXD endflange coutOuts.
double	m_cutOutShift {0}
	Shift of PXD endflange coutOuts.
double	m_cutOutRphi {0}
	Rphi of PXD endflange coutOuts.
double	m_cutOutStartPhi {0}
	Start Rphi of PXD endflange coutOuts.
double	m_cutOutDeltaPhi {0}
	Delta Rphi of PXD endflange coutOuts.
int	m_nTubes {0}
	Number of PXD carbon tubes.
double	m_tubesMinZ {0}
	MinZ of PXD carbon tubes.
double	m_tubesMaxZ {0}
	MaxZ of PXD carbon tubes.
double	m_tubesMinR {0}
	MinR of PXD carbon tubes.
double	m_tubesMaxR {0}
	MaxZ of PXD carbon tubes.
double	m_tubesRPhi {0}
	Rphi of PXD carbon tubes.
double	m_tubesStartPhi {0}
	Start Rphi of PXD carbon tubes.
double	m_tubesDeltaPhi {0}
	Delta Phi of PXD carbon tubes.
std::string	m_tubesMaterial {"Carbon"}
	Material of PXD carbon tubes.
std::string	m_prefix {""}
	Prefix to prepend to all volume names.
VXDGlobalPar	m_globals
	Container for a few general parameters.
std::map< std::string, VXDAlignmentPar >	m_alignment
	Alignment parameters for all components.
VXDEnvelopePar	m_envelope
	Envelope parameters.
std::vector< VXDHalfShellPar >	m_halfShells
	Cache for half shells
std::map< std::string, VXDGeoComponentPar >	m_componentCache
	Cache of all previously created components.
std::vector< std::string >	m_componentInsertOrder
	Vector remembering the order of insertions into component cache.
std::map< std::string, VXDGeoSensorPar >	m_sensorMap
	Map containing Information about all defined sensor types.
VXDGeoRadiationSensorsPar	m_radiationsensors
	Diamond radiation sensors.
std::map< int, VXDGeoLadderPar >	m_ladders
	Parameters of the detector ladders.
std::map< std::string, int >	m_sensitiveIDCache
	Cache of all Bkg sensitive chip Ids.

Detailed Description

The Class for VXD geometry.

Definition at line 25 of file PXDGeometryPar.h.

Constructor & Destructor Documentation

PXDGeometryPar() [1/2]

PXDGeometryPar ( )

inline

Default constructor.

Definition at line 28 of file PXDGeometryPar.h.

{}

PXDGeometryPar() [2/2]

PXDGeometryPar ( PXDGeometryPar &  geo )

inline

Copy constructor.

Definition at line 30 of file PXDGeometryPar.h.

                                        : VXDGeometryPar(geo)
    {
      for (PXDSensorInfoPar* pxdSensor : geo.getSensorInfos()) {
        m_SensorInfo.push_back(new PXDSensorInfoPar(*pxdSensor));
      }
      m_endflanges = geo.getEndflanges();
      m_nCutouts = geo.getNCutOuts();
      m_cutOutWidth = geo.getCutOutWidth();
      m_cutOutHeight = geo.getCutOutHeight();
      m_cutOutRphi = geo.getCutOutRPhi();
      m_cutOutShift = geo.getCutOutShift();
      m_cutOutStartPhi = geo.getCutOutStartPhi();
      m_cutOutDeltaPhi = geo.getCutOutDeltaPhi();
      m_nTubes = geo.getNTubes();
      m_tubesMinZ = geo.getTubesMinZ();
      m_tubesMaxZ = geo.getTubesMaxZ();
      m_tubesMinR = geo.getTubesMinR();
      m_tubesMaxR = geo.getTubesMaxR();
      m_tubesRPhi = geo.getTubesRPhi();
      m_tubesStartPhi = geo.getTubesStartPhi();
      m_tubesDeltaPhi = geo.getTubesDeltaPhi();
      m_tubesMaterial = geo.getTubesMaterial();
    }

~PXDGeometryPar()

~PXDGeometryPar ( )

inline

Destructor.

Definition at line 80 of file PXDGeometryPar.h.

    {
      for (PXDSensorInfoPar* pxdSensor : m_SensorInfo) {
        delete pxdSensor;
      }
      m_SensorInfo.clear();
    }

Member Function Documentation

getAlignment()

VXDAlignmentPar getAlignment ( std::string  name ) const

inherited

get alignment parameters for component name

Definition at line 62 of file VXDGeometryPar.cc.

{
  //Check if component already exists
  map<string, VXDAlignmentPar>::const_iterator cached = m_alignment.find(name);
  if (cached == m_alignment.end()) {
    B2FATAL("Could not find alignment parameters for component " << name);
  }
  return cached->second;
}

getAlignmentMap()

std::map< std::string, VXDAlignmentPar > & getAlignmentMap ( )

inlineinherited

get alignmant map

Definition at line 58 of file VXDGeometryPar.h.

{return m_alignment;}

getBuildSupport()

bool getBuildSupport ( ) const

inline

build support

Definition at line 88 of file PXDGeometryPar.h.

{ return (m_nCutouts > 0); }

getComponent()

const VXDGeoComponentPar & getComponent ( std::string  name ) const

inherited

get component

Definition at line 17 of file VXDGeometryPar.cc.

{
  //Check if component already exists
  std::map<string, VXDGeoComponentPar>::const_iterator cached = m_componentCache.find(name);
  if (cached == m_componentCache.end()) {
    B2FATAL("Could not find component " << name);
  }
  return cached->second;
}

getComponentInsertOder() [1/2]

std::vector< std::string > & getComponentInsertOder ( )

inlineinherited

get component insert order

Definition at line 88 of file VXDGeometryPar.h.

{return m_componentInsertOrder;}

getComponentInsertOder() [2/2]

const std::vector< std::string > & getComponentInsertOder ( ) const

inlineinherited

get component insert order

Definition at line 86 of file VXDGeometryPar.h.

{return m_componentInsertOrder;}

getComponentMap() [1/2]

std::map< std::string, VXDGeoComponentPar > & getComponentMap ( )

inlineinherited

get component maps

Definition at line 80 of file VXDGeometryPar.h.

{return m_componentCache;   }

getComponentMap() [2/2]

const std::map< std::string, VXDGeoComponentPar > & getComponentMap ( ) const

inlineinherited

get component maps

Definition at line 78 of file VXDGeometryPar.h.

{return m_componentCache;   }

getCutOutDeltaPhi()

double getCutOutDeltaPhi ( ) const

inline

get deltaphi of cutouts

Definition at line 114 of file PXDGeometryPar.h.

{ return m_cutOutDeltaPhi; }

getCutOutHeight()

double getCutOutHeight ( ) const

inline

get height of cutouts

Definition at line 98 of file PXDGeometryPar.h.

{ return m_cutOutHeight; }

getCutOutRPhi()

double getCutOutRPhi ( ) const

inline

get rphi of cutouts

Definition at line 106 of file PXDGeometryPar.h.

{ return m_cutOutRphi; }

getCutOutShift()

double getCutOutShift ( ) const

inline

get shift of cutouts

Definition at line 102 of file PXDGeometryPar.h.

{ return m_cutOutShift; }

getCutOutStartPhi()

double getCutOutStartPhi ( ) const

inline

get start phi of cutouts

Definition at line 110 of file PXDGeometryPar.h.

{ return m_cutOutStartPhi; }

getCutOutWidth()

double getCutOutWidth ( ) const

inline

get width of cutouts

Definition at line 94 of file PXDGeometryPar.h.

{ return m_cutOutWidth; }

getEndflanges() [1/2]

std::vector< VXDPolyConePar > & getEndflanges ( )

inline

get Endflanges

Definition at line 156 of file PXDGeometryPar.h.

{return m_endflanges;}

getEndflanges() [2/2]

const std::vector< VXDPolyConePar > & getEndflanges ( ) const

inline

get Endflanges

Definition at line 154 of file PXDGeometryPar.h.

{return m_endflanges;}

getEnvelope()

const VXDEnvelopePar & getEnvelope ( ) const

inlineinherited

get envelope parameters

Definition at line 50 of file VXDGeometryPar.h.

{return m_envelope;}

getGlobalParams()

const VXDGlobalPar & getGlobalParams ( ) const

inlineinherited

get global parameters

Definition at line 46 of file VXDGeometryPar.h.

{return m_globals;}

getHalfShells() [1/2]

std::vector< VXDHalfShellPar > & getHalfShells ( )

inlineinherited

get half-shell

Definition at line 64 of file VXDGeometryPar.h.

{return m_halfShells;}

getHalfShells() [2/2]

const std::vector< VXDHalfShellPar > & getHalfShells ( ) const

inlineinherited

get half-shell

Definition at line 62 of file VXDGeometryPar.h.

{return m_halfShells;}

getLadder()

const VXDGeoLadderPar & getLadder ( int  layerID ) const

inherited

get ladder for given layer

Definition at line 51 of file VXDGeometryPar.cc.

{
  //Check if component already exists
  map<int, VXDGeoLadderPar>::const_iterator cached = m_ladders.find(layer);
  if (cached == m_ladders.end()) {
    B2FATAL("Could not find ladder for layer " << (boost::format("%1%") % layer).str());
  }
  return cached->second;
}

getLadderMap()

std::map< int, VXDGeoLadderPar > & getLadderMap ( )

inlineinherited

get ladder map

Definition at line 66 of file VXDGeometryPar.h.

{ return m_ladders; }

getNCutOuts()

int getNCutOuts ( ) const

inline

get number of cutouts

Definition at line 90 of file PXDGeometryPar.h.

{ return m_nCutouts; }

getNTubes()

int getNTubes ( ) const

inline

get number of tubes

Definition at line 118 of file PXDGeometryPar.h.

{ return m_nTubes; }

getPrefix()

std::string getPrefix ( ) const

inlineinherited

get prefix

Definition at line 42 of file VXDGeometryPar.h.

{return m_prefix;}

getRadiationSensors()

const VXDGeoRadiationSensorsPar & getRadiationSensors ( ) const

inlineinherited

get radiation sensor parameters

Definition at line 54 of file VXDGeometryPar.h.

{return m_radiationsensors;}

getSensitiveChipID()

int getSensitiveChipID ( std::string  name ) const

inherited

get Bkg sensitive chip Id

Definition at line 29 of file VXDGeometryPar.cc.

{
  //Check if sensorType already exists
  std::map<string, int>::const_iterator cached = m_sensitiveIDCache.find(name);
  if (cached == m_sensitiveIDCache.end()) {
    return -1;
  }
  return cached->second;
}

getSensitiveChipIdMap()

std::map< std::string, int > & getSensitiveChipIdMap ( )

inlineinherited

get sensitive chip id map

Definition at line 84 of file VXDGeometryPar.h.

{return m_sensitiveIDCache;}

getSensor()

const VXDGeoSensorPar & getSensor ( std::string  sensorTypeID ) const

inherited

get sensor type

Definition at line 41 of file VXDGeometryPar.cc.

{
  //Check if sensorType already exists
  std::map<string, VXDGeoSensorPar>::const_iterator cached = m_sensorMap.find(sensorTypeID);
  if (cached == m_sensorMap.end()) {
    B2FATAL("Invalid SensorTypeID " << sensorTypeID);
  }
  return cached->second;
}

getSensorInfos()

std::vector< PXDSensorInfoPar * > & getSensorInfos ( )

inline

get sensorInfos

Definition at line 158 of file PXDGeometryPar.h.

{return m_SensorInfo;}

getSensorMap() [1/2]

std::map< std::string, VXDGeoSensorPar > & getSensorMap ( )

inlineinherited

get sensor map

Definition at line 76 of file VXDGeometryPar.h.

{return m_sensorMap;}

getSensorMap() [2/2]

const std::map< std::string, VXDGeoSensorPar > & getSensorMap ( ) const

inlineinherited

get sensor map

Definition at line 74 of file VXDGeometryPar.h.

{return m_sensorMap;}

getTubesDeltaPhi()

double getTubesDeltaPhi ( ) const

inline

get tubes tubes DeltaPhi

Definition at line 146 of file PXDGeometryPar.h.

{ return m_tubesDeltaPhi; }

getTubesMaterial()

const std::string & getTubesMaterial ( ) const

inline

get tubes tubes material

Definition at line 150 of file PXDGeometryPar.h.

{ return m_tubesMaterial; }

getTubesMaxR()

double getTubesMaxR ( ) const

inline

get tubes maxR

Definition at line 134 of file PXDGeometryPar.h.

{ return m_tubesMaxR; }

getTubesMaxZ()

double getTubesMaxZ ( ) const

inline

get tubes maxZ

Definition at line 126 of file PXDGeometryPar.h.

{ return m_tubesMaxZ; }

getTubesMinR()

double getTubesMinR ( ) const

inline

get tubes minR

Definition at line 130 of file PXDGeometryPar.h.

{ return m_tubesMinR; }

getTubesMinZ()

double getTubesMinZ ( ) const

inline

get tubes minZ

Definition at line 122 of file PXDGeometryPar.h.

{ return m_tubesMinZ; }

getTubesRPhi()

double getTubesRPhi ( ) const

inline

get tubes tubes RPhi

Definition at line 138 of file PXDGeometryPar.h.

{ return m_tubesRPhi; }

getTubesStartPhi()

double getTubesStartPhi ( ) const

inline

get tubes tubes StartPhi

Definition at line 142 of file PXDGeometryPar.h.

{ return m_tubesStartPhi; }

operator=()

PXDGeometryPar & operator= ( PXDGeometryPar &  geo )

inline

Assignemnt operator.

Definition at line 54 of file PXDGeometryPar.h.

    {
      VXDGeometryPar::operator=(geo);
      for (PXDSensorInfoPar* pxdSensor : geo.getSensorInfos()) {
        m_SensorInfo.push_back(new PXDSensorInfoPar(*pxdSensor));
      }
      m_endflanges = geo.getEndflanges();
      m_nCutouts = geo.getNCutOuts();
      m_cutOutWidth = geo.getCutOutWidth();
      m_cutOutHeight = geo.getCutOutHeight();
      m_cutOutRphi = geo.getCutOutRPhi();
      m_cutOutShift = geo.getCutOutShift();
      m_cutOutStartPhi = geo.getCutOutStartPhi();
      m_cutOutDeltaPhi = geo.getCutOutDeltaPhi();
      m_nTubes = geo.getNTubes();
      m_tubesMinZ = geo.getTubesMinZ();
      m_tubesMaxZ = geo.getTubesMaxZ();
      m_tubesMinR = geo.getTubesMinR();
      m_tubesMaxR = geo.getTubesMaxR();
      m_tubesRPhi = geo.getTubesRPhi();
      m_tubesStartPhi = geo.getTubesStartPhi();
      m_tubesDeltaPhi = geo.getTubesDeltaPhi();
      m_tubesMaterial = geo.getTubesMaterial();
      return *this;
    }

setCutOutDeltaPhi()

void setCutOutDeltaPhi ( double  delta )

inline

set deltaphi of cutouts

Definition at line 116 of file PXDGeometryPar.h.

{ m_cutOutDeltaPhi = delta; }

setCutOutHeight()

void setCutOutHeight ( double  height )

inline

set height of cutouts

Definition at line 100 of file PXDGeometryPar.h.

{ m_cutOutHeight = height; }

setCutOutRPhi()

void setCutOutRPhi ( double  rphi )

inline

set rphi of cutouts

Definition at line 108 of file PXDGeometryPar.h.

{ m_cutOutRphi = rphi; }

setCutOutShift()

void setCutOutShift ( double  shift )

inline

set shift of cutouts

Definition at line 104 of file PXDGeometryPar.h.

{ m_cutOutShift = shift; }

setCutOutStartPhi()

void setCutOutStartPhi ( double  start )

inline

set start phi of cutouts

Definition at line 112 of file PXDGeometryPar.h.

{ m_cutOutStartPhi = start; }

setCutOutWidth()

void setCutOutWidth ( double  width )

inline

set width of cutouts

Definition at line 96 of file PXDGeometryPar.h.

{ m_cutOutWidth = width; }

setEnvelope()

void setEnvelope ( const VXDEnvelopePar &  envelope )

inlineinherited

set envelope parameters

Definition at line 52 of file VXDGeometryPar.h.

{m_envelope = envelope;}

setGlobalParams()

void setGlobalParams ( const VXDGlobalPar &  globals )

inlineinherited

set global parameters

Definition at line 48 of file VXDGeometryPar.h.

{ m_globals = globals;}

setNCutOuts()

void setNCutOuts ( int  nCutouts )

inline

set number of cutouts

Definition at line 92 of file PXDGeometryPar.h.

{ m_nCutouts = nCutouts; }

setNTubes()

void setNTubes ( int  nTubes )

inline

set number of tubes

Definition at line 120 of file PXDGeometryPar.h.

{ m_nTubes = nTubes; }

setPrefix()

void setPrefix ( const std::string &  prefix )

inlineinherited

set prefix

Definition at line 44 of file VXDGeometryPar.h.

{ m_prefix = prefix;}

setRadiationSensors()

void setRadiationSensors ( const VXDGeoRadiationSensorsPar &  diamonds )

inlineinherited

set radiation sensor parameters

Definition at line 56 of file VXDGeometryPar.h.

{m_radiationsensors = diamonds;}

setTubesDeltaPhi()

void setTubesDeltaPhi ( double  delta )

inline

set tubes tubes DeltaPhi

Definition at line 148 of file PXDGeometryPar.h.

{ m_tubesDeltaPhi = delta; }

setTubesMaterial()

void setTubesMaterial ( const std::string &  material )

inline

set tubes tubes material

Definition at line 152 of file PXDGeometryPar.h.

{ m_tubesMaterial = material; }

setTubesMaxR()

void setTubesMaxR ( double  maxR )

inline

set tubes maxR

Definition at line 136 of file PXDGeometryPar.h.

{ m_tubesMaxR = maxR; }

setTubesMaxZ()

void setTubesMaxZ ( double  maxZ )

inline

set tubes maxZ

Definition at line 128 of file PXDGeometryPar.h.

{ m_tubesMaxZ = maxZ; }

setTubesMinR()

void setTubesMinR ( double  minR )

inline

set tubes minR

Definition at line 132 of file PXDGeometryPar.h.

{ m_tubesMinR = minR; }

setTubesMinZ()

void setTubesMinZ ( double  minZ )

inline

set tubes minZ

Definition at line 124 of file PXDGeometryPar.h.

{ m_tubesMinZ = minZ; }

setTubesRPhi()

void setTubesRPhi ( double  rphi )

inline

set tubes tubes RPhi

Definition at line 140 of file PXDGeometryPar.h.

{ m_tubesRPhi = rphi; }

setTubesStartPhi()

void setTubesStartPhi ( double  start )

inline

set tubes tubes StartPhi

Definition at line 144 of file PXDGeometryPar.h.

{ m_tubesStartPhi = start; }

Member Data Documentation

m_alignment

std::map<std::string, VXDAlignmentPar> m_alignment

privateinherited

Alignment parameters for all components.

Definition at line 97 of file VXDGeometryPar.h.

m_componentCache

std::map<std::string, VXDGeoComponentPar> m_componentCache

privateinherited

Cache of all previously created components.

Definition at line 103 of file VXDGeometryPar.h.

m_componentInsertOrder

std::vector<std::string> m_componentInsertOrder

privateinherited

Vector remembering the order of insertions into component cache.

Definition at line 105 of file VXDGeometryPar.h.

m_cutOutDeltaPhi

double m_cutOutDeltaPhi {0}

private

Delta Rphi of PXD endflange coutOuts.

Definition at line 181 of file PXDGeometryPar.h.

m_cutOutHeight

double m_cutOutHeight {0}

private

Height of PXD endflange coutOuts.

Definition at line 173 of file PXDGeometryPar.h.

m_cutOutRphi

double m_cutOutRphi {0}

private

Rphi of PXD endflange coutOuts.

Definition at line 177 of file PXDGeometryPar.h.

m_cutOutShift

double m_cutOutShift {0}

private

Shift of PXD endflange coutOuts.

Definition at line 175 of file PXDGeometryPar.h.

m_cutOutStartPhi

double m_cutOutStartPhi {0}

private

Start Rphi of PXD endflange coutOuts.

Definition at line 179 of file PXDGeometryPar.h.

m_cutOutWidth

double m_cutOutWidth {0}

private

Width of PXD endflange coutOuts.

Definition at line 171 of file PXDGeometryPar.h.

m_endflanges

std::vector<VXDPolyConePar> m_endflanges

private

PXD Endflanges.

Definition at line 166 of file PXDGeometryPar.h.

m_envelope

VXDEnvelopePar m_envelope

privateinherited

Envelope parameters.

Definition at line 99 of file VXDGeometryPar.h.

m_globals

VXDGlobalPar m_globals

privateinherited

Container for a few general parameters.

Definition at line 95 of file VXDGeometryPar.h.

m_halfShells

std::vector<VXDHalfShellPar> m_halfShells

privateinherited

Cache for half shells

Definition at line 101 of file VXDGeometryPar.h.

m_ladders

std::map<int, VXDGeoLadderPar> m_ladders

privateinherited

Parameters of the detector ladders.

Definition at line 111 of file VXDGeometryPar.h.

m_nCutouts

int m_nCutouts {0}

private

Number of PXD endflange coutOuts.

Definition at line 169 of file PXDGeometryPar.h.

m_nTubes

int m_nTubes {0}

private

Number of PXD carbon tubes.

Definition at line 183 of file PXDGeometryPar.h.

m_prefix

std::string m_prefix {""}

privateinherited

Prefix to prepend to all volume names.

Definition at line 93 of file VXDGeometryPar.h.

m_radiationsensors

VXDGeoRadiationSensorsPar m_radiationsensors

privateinherited

Diamond radiation sensors.

Definition at line 109 of file VXDGeometryPar.h.

m_sensitiveIDCache

std::map<std::string, int> m_sensitiveIDCache

privateinherited

Cache of all Bkg sensitive chip Ids.

Definition at line 113 of file VXDGeometryPar.h.

m_SensorInfo

std::vector<PXDSensorInfoPar*> m_SensorInfo

private

Vector of points to SensorInfo objects.

Definition at line 163 of file PXDGeometryPar.h.

m_sensorMap

std::map<std::string, VXDGeoSensorPar> m_sensorMap

privateinherited

Map containing Information about all defined sensor types.

Definition at line 107 of file VXDGeometryPar.h.

m_tubesDeltaPhi

double m_tubesDeltaPhi {0}

private

Delta Phi of PXD carbon tubes.

Definition at line 197 of file PXDGeometryPar.h.

m_tubesMaterial

std::string m_tubesMaterial {"Carbon"}

private

Material of PXD carbon tubes.

Definition at line 199 of file PXDGeometryPar.h.

m_tubesMaxR

double m_tubesMaxR {0}

private

MaxZ of PXD carbon tubes.

Definition at line 191 of file PXDGeometryPar.h.

m_tubesMaxZ

double m_tubesMaxZ {0}

private

MaxZ of PXD carbon tubes.

Definition at line 187 of file PXDGeometryPar.h.

m_tubesMinR

double m_tubesMinR {0}

private

MinR of PXD carbon tubes.

Definition at line 189 of file PXDGeometryPar.h.

m_tubesMinZ

double m_tubesMinZ {0}

private

MinZ of PXD carbon tubes.

Definition at line 185 of file PXDGeometryPar.h.

m_tubesRPhi

double m_tubesRPhi {0}

private

Rphi of PXD carbon tubes.

Definition at line 193 of file PXDGeometryPar.h.

m_tubesStartPhi

double m_tubesStartPhi {0}

private

Start Rphi of PXD carbon tubes.

Definition at line 195 of file PXDGeometryPar.h.

---

The documentation for this class was generated from the following file:

• pxd/dbobjects/include/PXDGeometryPar.h
