Belle II Software  release-05-01-25
CDCTrigger2DFinderFirmwareModule Class Reference

This class is the interface between the 2D finder fast simulation module and the firmware simulation core of ISim. More...

#include <CDCTrigger2DFinderFirmwareModule.h>

Inheritance diagram for CDCTrigger2DFinderFirmwareModule:
Collaboration diagram for CDCTrigger2DFinderFirmwareModule:

Public Types

enum  EModulePropFlags {
  c_Input = 1,
  c_Output = 2,
  c_ParallelProcessingCertified = 4,
  c_HistogramManager = 8,
  c_InternalSerializer = 16,
  c_TerminateInAllProcesses = 32,
  c_DontCollectStatistics = 64
}
 Each module can be tagged with property flags, which indicate certain features of the module. More...

typedef ModuleCondition::EAfterConditionPath EAfterConditionPath
 Forward the EAfterConditionPath definition from the ModuleCondition.


Public Member Functions

 CDCTrigger2DFinderFirmwareModule ()
 Constructor. More...

virtual ~CDCTrigger2DFinderFirmwareModule ()
 Destructor.

void initialize () override
 Load the design snapshot and register the signal ports.

void event () override
 Things to do for each event. More...

virtual std::vector< std::string > getFileNames (__attribute__((unused)) bool outputFiles)
 Return a list of output filenames for this modules. More...

virtual void beginRun ()
 Called when entering a new run. More...

virtual void endRun ()
 This method is called if the current run ends. More...

virtual void terminate ()
 This method is called at the end of the event processing. More...

const std::string & getName () const
 Returns the name of the module. More...

const std::string & getType () const
 Returns the type of the module (i.e. More...

const std::string & getPackage () const
 Returns the package this module is in.

const std::string & getDescription () const
 Returns the description of the module.

void setName (const std::string &name)
 Set the name of the module. More...

void setPropertyFlags (unsigned int propertyFlags)
 Sets the flags for the module properties. More...

LogConfiggetLogConfig ()
 Returns the log system configuration.

void setLogConfig (const LogConfig &logConfig)
 Set the log system configuration.

void setLogLevel (int logLevel)
 Configure the log level.

void setDebugLevel (int debugLevel)
 Configure the debug messaging level.

void setAbortLevel (int abortLevel)
 Configure the abort log level.

void setLogInfo (int logLevel, unsigned int logInfo)
 Configure the printed log information for the given level. More...

void if_value (const std::string &expression, const std::shared_ptr< Path > &path, EAfterConditionPath afterConditionPath=EAfterConditionPath::c_End)
 Add a condition to the module. More...

void if_false (const std::shared_ptr< Path > &path, EAfterConditionPath afterConditionPath=EAfterConditionPath::c_End)
 A simplified version to add a condition to the module. More...

void if_true (const std::shared_ptr< Path > &path, EAfterConditionPath afterConditionPath=EAfterConditionPath::c_End)
 A simplified version to set the condition of the module. More...

bool hasCondition () const
 Returns true if at least one condition was set for the module.

const ModuleConditiongetCondition () const
 Return a pointer to the first condition (or nullptr, if none was set)

const std::vector< ModuleCondition > & getAllConditions () const
 Return all set conditions for this module.

bool evalCondition () const
 If at least one condition was set, it is evaluated and true returned if at least one condition returns true. More...

std::shared_ptr< PathgetConditionPath () const
 Returns the path of the last true condition (if there is at least one, else reaturn a null pointer). More...

Module::EAfterConditionPath getAfterConditionPath () const
 What to do after the conditional path is finished. More...

std::vector< std::shared_ptr< Path > > getAllConditionPaths () const
 Return all condition paths currently set (no matter if the condition is true or not).

bool hasProperties (unsigned int propertyFlags) const
 Returns true if all specified property flags are available in this module. More...

bool hasUnsetForcedParams () const
 Returns true and prints error message if the module has unset parameters which the user has to set in the steering file.

const ModuleParamListgetParamList () const
 Return module param list.

template<typename T >
ModuleParam< T > & getParam (const std::string &name) const
 Returns a reference to a parameter. More...

bool hasReturnValue () const
 Return true if this module has a valid return value set.

int getReturnValue () const
 Return the return value set by this module. More...

std::shared_ptr< PathElementclone () const override
 Create an independent copy of this module. More...

std::shared_ptr< boost::python::list > getParamInfoListPython () const
 Returns a python list of all parameters. More...


Static Public Member Functions

static void exposePythonAPI ()
 Exposes methods of the Module class to Python.


Protected Types

using tsVector = std::array< char, m_tsVectorWidth >
 array of TS

using tsArrayPerSL = std::vector< std::bitset< m_tsVectorWidth > >
 TS array per SL.

using tsArrayPerClock = std::array< tsArrayPerSL, nAxialSuperLayer >
 TS array per clock.

using tsArray = std::vector< tsArrayPerClock >
 TS array.

using inputVector = std::array< char, width_in >
 input array


Protected Member Functions

int localSegmentID (int globalID)
 Calculate local segment ID from global ID. More...

auto encodeTSHit (CDCTriggerSegmentHit const *)
 Encode a TS hit into std_logic_vector. More...

auto toTSSLV (const std::bitset< m_tsVectorWidth >)
 Turn TS bitset into char array. More...

TRGFinderTrack decodeTrack (std::string trackIn)
 decode the 2D track info

void decodeOutput (short latency)
 decode the output info

void initializeFastSim ()
 initialize fast TSIM function

void loadFromFirmware (int iclock)
 load data from firmware

void loadFromFastSim (unsigned iclock)
 load data from fast TSIM function

virtual void def_initialize ()
 Wrappers to make the methods without "def_" prefix callable from Python. More...

virtual void def_beginRun ()
 Wrapper method for the virtual function beginRun() that has the implementation to be used in a call from Python.

virtual void def_event ()
 Wrapper method for the virtual function event() that has the implementation to be used in a call from Python.

virtual void def_endRun ()
 This method can receive that the current run ends as a call from the Python side. More...

virtual void def_terminate ()
 Wrapper method for the virtual function terminate() that has the implementation to be used in a call from Python.

void setDescription (const std::string &description)
 Sets the description of the module. More...

void setType (const std::string &type)
 Set the module type. More...

template<typename T >
void addParam (const std::string &name, T &paramVariable, const std::string &description, const T &defaultValue)
 Adds a new parameter to the module. More...

template<typename T >
void addParam (const std::string &name, T &paramVariable, const std::string &description)
 Adds a new enforced parameter to the module. More...

void setReturnValue (int value)
 Sets the return value for this module as integer. More...

void setReturnValue (bool value)
 Sets the return value for this module as bool. More...

void setParamList (const ModuleParamList &params)
 Replace existing parameter list.


Protected Attributes

std::string m_hitCollectionName
 Name of the StoreArray containing the input track segment hits.

std::string m_outputCollectionName
 Name of the StoreArray containing the tracks found by the Hough tracking.

std::string m_bitstreamNameTo2D
 Name of the StoreArray holding the raw bit content to 2D trackers


bool m_fromFastSim = false
 flag to read TS hits from the output of TSF firmware simulation

int m_nClockPerEvent = 32
 how many clocks to simulate per event

int m_debugLevel = 0
 debug level: better description needed. More...

std::string lib_extension = ".so"
 extension of lib

std::string cwd = getcurrentdir()
 current diretory

std::string design_libname = cwd + "/xsim.dir/t2d/xsimk" + lib_extension
 path to the simulation snapshot

std::string simengine_libname = "librdi_simulator_kernel" + lib_extension
 path to the simulation engine

Xsi::LoaderXsi_Instance
 Xsi loader from Xilinx software.

s_xsi_setup_info info
 s_xsi_setup_info from Xilinx software

tsArray m_tsHitVector
 TS array.

std::array< inputVector, 5 > tsfInput
 array holding 5 axial TSF input data

std::array< char, width_outfinderOutput
 array holding 2D output data

char t2d_out [width_out] = {}
 char array holding 2D output data

int clk = 0
 clock signal port handle. More...

int tsfPort [5] = {0}
 input signal port handle. More...

int out = 0
 output signal port handle. More...


Static Protected Attributes

static const int m_tsVectorWidth = 21
 width of TS hit input signal vector

static const int m_nInTSPerClock = 10
 number of input ts hits per clock

static const int m_nOutTracksPerClock = 4
 number of output tracks per clock

static const int width_in = 219
 width of (half-speed) input data width

static const int width_out = 732
 width of output data width, not including the clock counter

static constexpr int nAxialSuperLayer = 5
 number of axial SL


Private Member Functions

std::list< ModulePtrgetModules () const override
 no submodules, return empty list

std::string getPathString () const override
 return the module name.

void setParamPython (const std::string &name, const boost::python::object &pyObj)
 Implements a method for setting boost::python objects. More...

void setParamPythonDict (const boost::python::dict &dictionary)
 Implements a method for reading the parameter values from a boost::python dictionary. More...


Private Attributes

std::string m_name
 The name of the module, saved as a string (user-modifiable)

std::string m_type
 The type of the module, saved as a string.

std::string m_package
 Package this module is found in (may be empty).

std::string m_description
 The description of the module.

unsigned int m_propertyFlags
 The properties of the module as bitwise or (with |) of EModulePropFlags.

LogConfig m_logConfig
 The log system configuration of the module.

ModuleParamList m_moduleParamList
 List storing and managing all parameter of the module.

bool m_hasReturnValue
 True, if the return value is set.

int m_returnValue
 The return value.

std::vector< ModuleConditionm_conditions
 Module condition, only non-null if set.


Detailed Description

This class is the interface between the 2D finder fast simulation module and the firmware simulation core of ISim.

Definition at line 43 of file CDCTrigger2DFinderFirmwareModule.h.

Member Enumeration Documentation

◆ EModulePropFlags

enum EModulePropFlags
inherited

Each module can be tagged with property flags, which indicate certain features of the module.

Enumerator
c_Input

This module is an input module (reads data).

c_Output

This module is an output module (writes data).

c_ParallelProcessingCertified

This module can be run in parallel processing mode safely (All I/O must be done through the data store, in particular, the module must not write any files.)

c_HistogramManager

This module is used to manage histograms accumulated by other modules.

c_InternalSerializer

This module is an internal serializer/deserializer for parallel processing.

c_TerminateInAllProcesses

When using parallel processing, call this module's terminate() function in all processes().

This will also ensure that there is exactly one process (single-core if no parallel modules found) or at least one input, one main and one output process.

c_DontCollectStatistics

No statistics is collected for this module.

Definition at line 79 of file Module.h.

Constructor & Destructor Documentation

◆ CDCTrigger2DFinderFirmwareModule()

Constructor.


Definition at line 54 of file CDCTrigger2DFinderFirmwareModule.cc.

54  : Module(),
55  Xsi_Instance(0)
56 // Xsi_Instance->design_libname, simengine_libname)
57 {
58  //Set module properties
59  setDescription("Firmware simulation of Hough tracking algorithm for CDC trigger.");
60
61  // Define module parameters
62  addParam("hitCollectionName", m_hitCollectionName,
63  "Name of the input StoreArray of CDCTriggerSegmentHits.",
64  string(""));
65  addParam("outputCollectionName", m_outputCollectionName,
66  "Name of the StoreArray holding the tracks found in the Hough tracking.",
67  string("TRGCDC2DFinderFirmwareTracks"));
68  addParam("bitstreamNameTo2D", m_bitstreamNameTo2D,
69  "Name of the StoreArray holding the raw bit content to 2D trackers",
70  string("BitstreamTSF-2D"));
71  addParam("fromFastSim", m_fromFastSim,
72  "flag to read TS hits from the output of TSF firmware simulation",
73  false);
74  addParam("nClocks", m_nClockPerEvent,
75  "how many clocks to simulate in each event",
76  32);
77
78 }

Member Function Documentation

◆ beginRun()

virtual void beginRun ( )
inlinevirtualinherited

Called when entering a new run.

Called at the beginning of each run, the method gives you the chance to change run dependent constants like alignment parameters, etc.

This method can be implemented by subclasses.

Reimplemented in DQMHistAnalysisPXDTrackChargeModule, DQMHistOutputToEPICSModule, DQMHistInjectionModule, DQMHistAnalysisRooFitExampleModule, DQMHistAnalysisPXDCMModule, DQMHistAnalysisPXDReductionModule, DQMHistAnalysisPXDChargeModule, DQMHistAnalysisPXDDAQModule, DQMHistAnalysisPXDEffModule, DQMHistAnalysisPXDInjectionModule, DQMHistAnalysisTrackingModule, PXDDigitizerModule, ECLDQMInjectionModule, PXDGatedModeDQMModule, PXDDAQDQMModule, PXDInjectionDQMModule, PXDBgTupleProducerModule, PXDMCBgTupleProducerModule, SVDDQMInjectionModule, PXDDQMEfficiencySelftrackModule, DQMHistComparitorModule, PXDDQMEfficiencyModule, PyModule, PXDGatedDHCDQMModule, PXDROIFinderAnalysisModule, AlignDQMModule, SVDDQMExpressRecoModule, DQMHistAnalysisInputRootFileModule, SVDDQMClustersOnTrackModule, SVDUnpackerDQMModule, TrackDQMModule, PXDTrackClusterDQMModule, PXDRawDQMModule, PXDclusterFilterModule, PXDdigiFilterModule, DQMHistAnalysisPXDERModule, PXDDQMCorrModule, PXDDQMExpressRecoModule, PXDROIDQMModule, PXDDQMClustersModule, DelayDQMModule, VXDDQMExpressRecoModule, vxdDigitMaskingModule, PXDRawDQMCorrModule, DQMHistAnalysisIPModule, DQMHistAnalysisEpicsExampleModule, DQMHistAnalysisPXDFitsModule, DQMHistAnalysisExampleFlagsModule, V0ObjectsDQMModule, TRGCDCT3DUnpackerModule, TRGCDCTSFUnpackerModule, TRGGRLUnpackerModule, TRGCDCETFUnpackerModule, MaterialScanModule, TOPUnpackerModule, B2BIIConvertMdstModule, ECLWaveformFitModule, FindletModule< AFindlet >, FindletModule< FacetCreator >, FindletModule< TrackFinderAutomaton >, FindletModule< CKFToCDCFromEclFindlet >, FindletModule< CKFToCDCFindlet >, FindletModule< CKFToSVDSeedFindlet >, FindletModule< AxialTrackCreatorMCTruth >, FindletModule< AxialStraightTrackFinder >, FindletModule< SegmentLinker >, FindletModule< TrackCreatorSegmentTripleAutomaton >, FindletModule< TrackCreatorSegmentPairAutomaton >, FindletModule< SegmentCreatorFacetAutomaton >, FindletModule< SegmentOrienter >, FindletModule< SegmentFinderFacetAutomaton >, FindletModule< CKFToSVDFindlet >, FindletModule< TrackFinderSegmentTripleAutomaton >, FindletModule< TrackRejecter >, FindletModule< SegmentCreatorMCTruth >, FindletModule< HitBasedT0Extractor >, FindletModule< TrackFinderCosmics >, FindletModule< SuperClusterCreator >, FindletModule< AsicBackgroundLibraryCreator >, FindletModule< TrackExporter >, FindletModule< ClusterPreparer >, FindletModule< CosmicsTrackMergerFindlet >, FindletModule< AxialTrackFinderHough >, FindletModule< TrackFinderSegmentPairAutomaton >, FindletModule< TrackLinker >, FindletModule< TrackOrienter >, FindletModule< TrackFinder >, FindletModule< AxialTrackFinderLegendre >, FindletModule< AxialTrackCreatorSegmentHough >, FindletModule< MonopoleAxialTrackFinderLegendre >, FindletModule< ClusterRefiner< BridgingWireHitRelationFilter > >, FindletModule< SegmentPairCreator >, FindletModule< HitReclaimer >, FindletModule< CKFToPXDFindlet >, FindletModule< TrackQualityEstimator >, FindletModule< StereoHitFinder >, FindletModule< TrackCreatorSingleSegments >, FindletModule< TrackFlightTimeAdjuster >, FindletModule< SegmentFitter >, FindletModule< SegmentRejecter >, FindletModule< WireHitPreparer >, FindletModule< SegmentTripleCreator >, FindletModule< SegmentTrackCombiner >, FindletModule< MCVXDCDCTrackMergerFindlet >, FindletModule< MonopoleStereoHitFinder >, FindletModule< TrackCombiner >, FindletModule< AxialSegmentPairCreator >, FindletModule< WireHitBackgroundDetector >, FindletModule< ClusterBackgroundDetector >, FindletModule< CDCTrackingEventLevelMdstInfoFillerFindlet >, FindletModule< MonopoleStereoHitFinderQuadratic >, FindletModule< TrackQualityAsserter >, FindletModule< WireHitCreator >, SVDBackgroundModule, TOPTimeBaseCalibratorModule, TOPTBCComparatorModule, B2BIIFixMdstModule, ECLChargedPIDModule, SVDDigitizerModule, ARICHNtupleModule, ECLDigitizerModule, BeamBkgTagSetterModule, PXDBackgroundModule, ParticleKinematicFitterModule, ECLShowerShapeModule, TOPGainEfficiencyCalculatorModule, SoftwareTriggerModule, ChargedPidMVAModule, ChargedPidMVAMulticlassModule, KLMClustersReconstructorModule, OpticalGunModule, SegmentNetworkProducerModule, TagVertexModule, CDCDedxValidationModule, TOPDQMModule, KLMDQMModule, CDCDQMModule, TOPDigitizerModule, TOPLaserHitSelectorModule, BKLMDigitAnalyzerModule, TOPModuleT0CalibratorModule, DQMHistAnalysisTRGGDLModule, GearboxModule, KLMUnpackerModule, TOPChannelT0CalibratorModule, TOPCommonT0CalibratorModule, ParticleVertexFitterModule, DQMHistAnalysisKLMModule, ECLCRFinderModule, KLMReconstructorModule, SVDUnpackerModule, TOPRawDigitConverterModule, DQMHistAnalysisCDCMonObjModule, ECLDigitizerPureCsIModule, ECLLocalRunCalibratorModule, KLMDigitizerModule, CDCCRTestModule, EKLMDataCheckerModule, TOPReconstructorModule, TrackFinderVXDBasicPathFinderModule, TrackFinderVXDCellOMatModule, ECLDataAnalysisModule, KLMPackerModule, FullSimModule, TOPChannelMaskerModule, TRGGDLUnpackerModule, HLTDQM2ZMQModule, ECLShowerCorrectorModule, MdstPIDModule, SVDCoGTimeEstimatorModule, ARICHDigitizerModule, ARICHDQMModule, BelleMCOutputModule, CsIDigitizerModule, DQMHistAnalysisARICHModule, ECLDQMModule, TOPAlignerModule, ARICHFillHitsModule, ARICHPackerModule, ARICHReconstructorModule, BeamBkgHitRateMonitorModule, BeamBkgMixerModule, CDCCosmicAnalysisModule, ECLSplitterN1Module, PXDPerformanceModule, TOPPDFCheckerModule, ARICHRelateModule, CsIStudyModule, CDCPackerModule, DQMHistAnalysisMiraBelleModule, ECLDigitCalibratorModule, TOPPDFDebuggerModule, ARICHUnpackerModule, BKLMSimHistogrammerModule, SVDROIFinderAnalysisModule, VXDTFTrainingDataCollectorModule, ARICHMCParticlesModule, ARICHRateCalModule, CDCUnpackerModule, TOPBackgroundModule, TOPTimeRecalibratorModule, TrackFinderMCTruthRecoTracksModule, ReprocessorModule, ECLChargedPIDDataAnalysisModule, ECLChargedPIDDataAnalysisValidationModule, EclDisplayModule, EvtGenDecayModule, EKLMADCModule, SVDDQMHitTimeModule, TOPDoublePulseGeneratorModule, SVDROIFinderModule, TRGCDCT3DConverterModule, TRGGRLMatchModule, BGOverlayExecutorModule, DQMHistAnalysisECLModule, ECLLocalMaximumFinderModule, SVDPackerModule, TOPBunchFinderModule, VXDSimpleClusterizerModule, ARICHRawUnpackerModule, NtuplePhase1_v6Module, TpcDigitizerModule, ExportGeometryModule, SoftwareTriggerHLTDQMModule, KLMClusterEfficiencyModule, CDCDedxDQMModule, SVDLocalCalibrationsMonitorModule, SVDPerformanceModule, TOPCalPulseGeneratorModule, TOPNtupleModule, TOPPackerModule, TOPWaveformFeatureExtractorModule, ExtModule, MCTrackCandClassifierModule, MuidModule, SPTCmomentumSeedRetrieverModule, TrackFinderVXDAnalizerModule, TRGTOPDQMModule, BeamBkgGeneratorModule, DQMHistAnalysisInputPVSrvModule, ECLClusterPSDModule, EventInfoPrinterModule, BKLMTrackingModule, KLMExpertModule, SVDOccupancyAnalysisModule, TOPInterimFENtupleModule, TOPMCTrackMakerModule, BGOverlayInputModule, CDCRecoTrackFilterModule, ECLBackgroundModule, ECLDQMEXTENDEDModule, EvtGenInputModule, OverrideGenerationFlagsModule, MCMatcherKLMClustersModule, PIDNtupleModule, SVDDataFormatCheckModule, SPTCvirtualIPRemoverModule, HitXPModule, arichBtestModule, BgoStudyModule, CsiStudy_v2Module, FANGSDigitizerModule, MicrotpcStudyModule, PlumeDigitizerModule, DQMHistAnalysisARICHMonObjModule, PXDClustersFromTracksModule, EventT0DQMModule, TOPXTalkChargeShareSetterModule, PXDROIFinderModule, VXDQualityEstimatorMVAModule, AnalysisPhase1StudyModule, DosiStudyModule, He3tubeStudyModule, ECLCovarianceMatrixModule, ECLFinalizerModule, ECLSplitterN2Module, KKGenInputModule, BKLMAnaModule, SVDLocalCalibrationsCheckModule, SVDClusterEvaluationTrueInfoModule, TOPTriggerDigitizerModule, TrackingPerformanceEvaluationModule, SecMapTrainerVXDTFModule, TRGECLRawdataAnalysisModule, TRGTOPUnpackerModule, BgoDigitizerModule, CsiDigitizer_v2Module, DosiDigitizerModule, TPCStudyModule, PinDigitizerModule, ECLShowerCalibratorModule, MVAExpertModule, MVAMultipleExpertsModule, SVDLatencyCalibrationModule, SVDB4CommissioningPlotsModule, SVDClusterEvaluationModule, EffPlotsModule, SecMapTrainerBaseModule, He3DigitizerModule, DQMHistAnalysisMonObjModule, DQMHistSnapshotsModule, ECLUnpackerModule, MCMatcherECLClustersModule, KlongValidationModule, TOPCosmicT0FinderModule, TrackQualityEstimatorMVAModule, BeamabortStudyModule, ClawStudyModule, ClawsStudyModule, PindiodeStudyModule, QcsmonitorStudyModule, DQMHistAnalysisCDCDedxModule, DQMHistAnalysisHLTMonObjModule, IPDQMExpressRecoModule, PXDRawDQMChipsModule, SVDClusterCalibrationsMonitorModule, SVDMissingAPVsClusterCreatorModule, SectorMapBootstrapModule, CurlTaggerModule, BeamDigitizerModule, ECLPackerModule, EventLimiterModule, RandomBarrierModule, V0findingPerformanceEvaluationModule, DQMHistDeltaHistoModule, StatisticsSummaryModule, MVAPrototypeModule, DataWriterModule, SVDClusterFilterModule, SVDMaxStripTTreeModule, SVDShaperDigitsFromTracksModule, SVD3SamplesEmulatorModule, QualityEstimatorVXDModule, VXDQETrainingDataCollectorModule, MCMatcherTRGECLModule, TRGGDLModule, EventKinematicsModule, ClawDigitizerModule, ClawsDigitizerModule, ECLHitDebugModule, SubEventModule, SVDCoGTimeCalibrationsMonitorModule, SVDHotStripFinderModule, TOPLaserCalibratorModule, BeamSpotMonitorModule, TrackQETrainingDataCollectorModule, CDCTriggerNeuroDQMModule, TRGECLModule, FANGSStudyModule, QcsmonitorDigitizerModule, DQMHistAnalysisTOPModule, TOPChannelT0MCModule, B2BIIConvertBeamParamsModule, ProgressModule, TRGECLFAMModule, B2BIIMdstInputModule, CsiModule, CreateFieldMapModule, TRGGRLModule, DQMHistAnalysisSVDOnMiraBelleModule, Convert2RawDetModule, TRGGRLProjectsModule, TRGCDCModule, DQMHistAnalysisOutputMonObjModule, CosmicsAlignmentValidationModule, TRGCDCTSStreamModule, VXDMisalignmentModule, TreeFitterModule, DQMHistAnalysisInputModule, SwitchDataStoreModule, TRGECLQAMModule, TRGECLTimingCalModule, IoVDependentConditionModule, StatisticsTimingHLTDQMModule, PhysicsObjectsMiraBelleModule, KLMTriggerModule, cdcDQM7Module, DQMHistAnalysisInputSrvModule, SeqRootOutputModule, DQMHistAnalysisEventT0Module, DQMHistAnalysisSVDGeneralModule, PhysicsObjectsMiraBelleDst2Module, PhysicsObjectsMiraBelleDstModule, HistoModule, TxModule, TRGGRLDQMModule, TRGGDLDQMModule, DQMHistAnalysisOutputNSMModule, DQMHistAnalysisPlotOnlyModule, DQMHistAnalysisSVDEfficiencyModule, RxModule, svdDumpModule, B2BIIMCParticlesMonitorModule, DQMHistAnalysisExampleModule, DQMHistAnalysisOutputRelayMsgModule, DQMHistAnalysisOutputFileModule, MCV0MatcherModule, TRGECLDQMModule, DQMHistAnalysisOutputModule, HistoManagerModule, SeqRootInputModule, TRGCDCT2DDQMModule, TRGCDCT3DDQMModule, TRGGDLSummaryModule, PhysicsObjectsDQMModule, TRGCDCTSFDQMModule, TRGGDLDSTModule, CalibrationCollectorModule, DQMHistAnalysisHLTModule, CDCTriggerUnpackerModule, ARICHBackgroundModule, TRGECLUnpackerModule, EvReductionModule, Raw2DsModule, RawInputModule, StorageDeserializerModule, BeamabortModule, BgoModule, CaveModule, ClawModule, CLAWSModule, DosiModule, FANGSModule, He3tubeModule, MicrotpcModule, Ph1bpipeModule, Ph1sustrModule, PindiodeModule, PlumeModule, QcsmonitorModule, SrsensorModule, SerializerModule, FastRbuf2DsModule, Ds2SampleModule, DeSerializerPXDModule, Rbuf2RbufModule, Rbuf2DsModule, TxSocketModule, DqmHistoManagerModule, Ds2RawModule, Ds2RawFileModule, Ds2RbufModule, StorageSerializerModule, GetEventFromSocketModule, ReceiveEventModule, ElapsedTimeModule, GenRawSendModule, MonitorDataCOPPERModule, RxSocketModule, CertifyParallelModule, SeqRootMergerModule, DAQPerfModule, MonitorDataModule, TrackAnaModule, and PartialSeqRootReaderModule.

Definition at line 149 of file Module.h.

◆ clone()

std::shared_ptr< PathElement > clone ( ) const
overridevirtualinherited

Create an independent copy of this module.

Note that parameters are shared, so changing them on a cloned module will also affect the original module.

Implements PathElement.

Definition at line 181 of file Module.cc.

◆ def_endRun()

virtual void def_endRun ( )
inlineprotectedvirtualinherited

This method can receive that the current run ends as a call from the Python side.

For regular C++-Modules that forwards the call to the regular endRun() method.

Reimplemented in PyModule.

Definition at line 441 of file Module.h.

◆ def_initialize()

virtual void def_initialize ( )
inlineprotectedvirtualinherited

Wrappers to make the methods without "def_" prefix callable from Python.

Overridden in PyModule. Wrapper method for the virtual function initialize() that has the implementation to be used in a call from Python.

Reimplemented in PyModule.

Definition at line 422 of file Module.h.

◆ encodeTSHit()

auto encodeTSHit ( CDCTriggerSegmentHit const *  hit)
protected

Encode a TS hit into std_logic_vector.

Parameters
CDCTriggerSegmentHitthe TS hit in question
Returns
the equivalent of std_logic_vector(20 downto 0), represented with a std::bitset<21>

Definition at line 147 of file CDCTrigger2DFinderFirmwareModule.cc.

◆ endRun()

virtual void endRun ( )
inlinevirtualinherited

This method is called if the current run ends.

Use this method to store information, which should be aggregated over one run.

This method can be implemented by subclasses.

Reimplemented in DQMHistAnalysisPXDTrackChargeModule, DQMHistOutputToEPICSModule, DQMHistAnalysisRooFitExampleModule, DQMHistAnalysisPXDChargeModule, PyModule, DQMHistComparitorModule, TrackSetEvaluatorHopfieldNNDEVModule, DQMHistAnalysisInputRootFileModule, AlignDQMModule, SVDUnpackerDQMModule, DQMHistAnalysisPXDERModule, vxdDigitMaskingModule, DQMHistAnalysisEpicsExampleModule, DQMHistAnalysisPXDFitsModule, DQMHistAnalysisExampleFlagsModule, TRGCDCT3DUnpackerModule, TRGCDCTSFUnpackerModule, TRGGRLUnpackerModule, TRGCDCETFUnpackerModule, TOPUnpackerModule, FindletModule< AFindlet >, FindletModule< FacetCreator >, FindletModule< TrackFinderAutomaton >, FindletModule< CKFToCDCFromEclFindlet >, FindletModule< CKFToCDCFindlet >, FindletModule< CKFToSVDSeedFindlet >, FindletModule< AxialTrackCreatorMCTruth >, FindletModule< AxialStraightTrackFinder >, FindletModule< SegmentLinker >, FindletModule< TrackCreatorSegmentTripleAutomaton >, FindletModule< TrackCreatorSegmentPairAutomaton >, FindletModule< SegmentCreatorFacetAutomaton >, FindletModule< SegmentOrienter >, FindletModule< SegmentFinderFacetAutomaton >, FindletModule< CKFToSVDFindlet >, FindletModule< TrackFinderSegmentTripleAutomaton >, FindletModule< TrackRejecter >, FindletModule< SegmentCreatorMCTruth >, FindletModule< HitBasedT0Extractor >, FindletModule< TrackFinderCosmics >, FindletModule< SuperClusterCreator >, FindletModule< AsicBackgroundLibraryCreator >, FindletModule< TrackExporter >, FindletModule< ClusterPreparer >, FindletModule< CosmicsTrackMergerFindlet >, FindletModule< AxialTrackFinderHough >, FindletModule< TrackFinderSegmentPairAutomaton >, FindletModule< TrackLinker >, FindletModule< TrackOrienter >, FindletModule< TrackFinder >, FindletModule< AxialTrackFinderLegendre >, FindletModule< AxialTrackCreatorSegmentHough >, FindletModule< MonopoleAxialTrackFinderLegendre >, FindletModule< ClusterRefiner< BridgingWireHitRelationFilter > >, FindletModule< SegmentPairCreator >, FindletModule< HitReclaimer >, FindletModule< CKFToPXDFindlet >, FindletModule< TrackQualityEstimator >, FindletModule< StereoHitFinder >, FindletModule< TrackCreatorSingleSegments >, FindletModule< TrackFlightTimeAdjuster >, FindletModule< SegmentFitter >, FindletModule< SegmentRejecter >, FindletModule< WireHitPreparer >, FindletModule< SegmentTripleCreator >, FindletModule< SegmentTrackCombiner >, FindletModule< MCVXDCDCTrackMergerFindlet >, FindletModule< MonopoleStereoHitFinder >, FindletModule< TrackCombiner >, FindletModule< AxialSegmentPairCreator >, FindletModule< WireHitBackgroundDetector >, FindletModule< ClusterBackgroundDetector >, FindletModule< CDCTrackingEventLevelMdstInfoFillerFindlet >, FindletModule< MonopoleStereoHitFinderQuadratic >, FindletModule< TrackQualityAsserter >, FindletModule< WireHitCreator >, ECLWaveformFitModule, B2BIIConvertMdstModule, TOPTimeBaseCalibratorModule, TOPTBCComparatorModule, ECLChargedPIDModule, SVDBackgroundModule, ARICHNtupleModule, ECLDigitizerModule, BeamBkgTagSetterModule, TOPGainEfficiencyCalculatorModule, ECLShowerShapeModule, KLMClustersReconstructorModule, OpticalGunModule, ParticleKinematicFitterModule, PXDBackgroundModule, CDCDedxValidationModule, ARICHDigitizerModule, TOPDQMModule, CDCDQMModule, KLMDQMModule, TOPLaserHitSelectorModule, TOPModuleT0CalibratorModule, DQMHistAnalysisTRGGDLModule, BKLMDigitAnalyzerModule, TOPChannelT0CalibratorModule, TOPCommonT0CalibratorModule, KLMUnpackerModule, TOPRawDigitConverterModule, TOPReconstructorModule, ARICHFillHitsModule, DQMHistAnalysisCDCMonObjModule, DQMHistAnalysisKLMModule, KLMReconstructorModule, CDCCRTestModule, KLMDigitizerModule, ECLDigitizerPureCsIModule, EKLMDataCheckerModule, ARICHReconstructorModule, ECLLocalRunCalibratorModule, KLMPackerModule, MdstPIDModule, FullSimModule, ARICHDQMModule, DQMHistAnalysisARICHModule, ECLCRFinderModule, TOPAlignerModule, TOPPDFDebuggerModule, ARICHPackerModule, BelleMCOutputModule, BeamBkgMixerModule, CDCPackerModule, TOPBackgroundModule, TOPPDFCheckerModule, ARICHRelateModule, BeamBkgHitRateMonitorModule, CsIDigitizerModule, DQMHistAnalysisMiraBelleModule, ARICHUnpackerModule, CDCUnpackerModule, ARICHMCParticlesModule, ARICHRateCalModule, CDCCosmicAnalysisModule, ECLShowerCorrectorModule, SVDCoGTimeEstimatorModule, SVDUnpackerModule, SVDROIFinderAnalysisModule, ECLDataAnalysisModule, EclDisplayModule, TOPDoublePulseGeneratorModule, TOPWaveformQualityPlotterModule, BGOverlayExecutorModule, ECLChargedPIDDataAnalysisValidationModule, ECLDigitCalibratorModule, ECLSplitterN1Module, EvtGenDecayModule, EKLMADCModule, SVDROIFinderModule, TRGGDLUnpackerModule, ARICHRawUnpackerModule, NtuplePhase1_v6Module, ECLDQMModule, TOPCalPulseGeneratorModule, TOPNtupleModule, TOPPackerModule, TOPWaveformFeatureExtractorModule, TrackFinderMCTruthRecoTracksModule, VXDTFTrainingDataCollectorModule, BeamBkgGeneratorModule, EventInfoPrinterModule, BKLMSimHistogrammerModule, KLMClusterEfficiencyModule, PXDPerformanceModule, TOPInterimFENtupleModule, TOPMCTrackMakerModule, VXDSimpleClusterizerModule, BGOverlayInputModule, TpcDigitizerModule, PIDNtupleModule, SPTCvirtualIPRemoverModule, arichBtestModule, ReprocessorModule, CsIStudyModule, ECLChargedPIDDataAnalysisModule, OverrideGenerationFlagsModule, MCMatcherKLMClustersModule, PrintDataModule, SPTCmomentumSeedRetrieverModule, TrackFinderVXDAnalizerModule, TRGGRLMatchModule, DQMHistAnalysisARICHMonObjModule, ECLLocalMaximumFinderModule, CDCDedxDQMModule, FANGSDigitizerModule, CDCRecoTrackFilterModule, ECLClusterPSDModule, SVDLocalCalibrationsMonitorModule, TOPTriggerDigitizerModule, ExtModule, MCTrackCandClassifierModule, MuidModule, HLTDQM2ZMQModule, DQMHistAnalysisECLModule, IPDQMExpressRecoModule, BKLMTrackingModule, TOPCosmicT0FinderModule, HitXPModule, TRGCDCT3DConverterModule, DQMHistAnalysisMonObjModule, ECLBackgroundModule, EventT0DQMModule, SVDDataFormatCheckModule, TRGTOPDQMModule, BgoStudyModule, CsiStudy_v2Module, MicrotpcStudyModule, PlumeDigitizerModule, DQMHistAnalysisCDCDedxModule, DQMHistAnalysisHLTMonObjModule, PXDClustersFromTracksModule, SVDPackerModule, SVDClusterEvaluationTrueInfoModule, TOPXTalkChargeShareSetterModule, SecMapTrainerVXDTFModule, AnalysisPhase1StudyModule, DosiStudyModule, He3tubeStudyModule, ECLCovarianceMatrixModule, ECLDQMEXTENDEDModule, ECLFinalizerModule, ECLSplitterN2Module, MCMatcherECLClustersModule, BKLMAnaModule, SVDHotStripFinderModule, SVDPerformanceModule, SecMapTrainerBaseModule, NoKickCutsEvalModule, TRGECLRawdataAnalysisModule, TRGTOPUnpackerModule, BgoDigitizerModule, CsiDigitizer_v2Module, DosiDigitizerModule, TPCStudyModule, PinDigitizerModule, HLTDs2ZMQModule, DQMHistAnalysisInputPVSrvModule, ECLShowerCalibratorModule, SVDLatencyCalibrationModule, SVDOccupancyAnalysisModule, TOPLaserCalibratorModule, PXDROIFinderModule, KlongValidationModule, TrackingPerformanceEvaluationModule, MCMatcherTRGECLModule, BeamabortStudyModule, ClawStudyModule, ClawsStudyModule, PindiodeStudyModule, QcsmonitorStudyModule, ECLHitDebugModule, SVDClusterCalibrationsMonitorModule, TOPChannelT0MCModule, EffPlotsModule, CurlTaggerModule, BeamDigitizerModule, He3DigitizerModule, ECLUnpackerModule, StatisticsSummaryModule, DataWriterModule, SVDB4CommissioningPlotsModule, SVDClusterEvaluationModule, SVDClusterFilterModule, SVDShaperDigitsFromTracksModule, SVD3SamplesEmulatorModule, RT2SPTCConverterModule, SVDROIDQMModule, TRGGDLModule, EventKinematicsModule, ClawDigitizerModule, ClawsDigitizerModule, DQMHistSnapshotsModule, ECLPackerModule, PrintEventRateModule, SVDCoGTimeCalibrationsMonitorModule, V0findingPerformanceEvaluationModule, TRGECLModule, CosmicsAlignmentValidationModule, FANGSStudyModule, QcsmonitorDigitizerModule, SectorMapBootstrapModule, CsiModule, DQMHistDeltaHistoModule, RandomBarrierModule, TRGGRLModule, GenfitVisModule, CDCTriggerNeuroDQMModule, TRGECLFAMModule, TRGGRLProjectsModule, B2BIIMdstInputModule, DQMHistAnalysisTOPModule, SubEventModule, TRGCDCModule, DQMHistAnalysisSVDOnMiraBelleModule, TRGCDCTSStreamModule, Convert2RawDetModule, DQMHistAnalysisOutputMonObjModule, TRGECLQAMModule, TRGECLTimingCalModule, MCV0MatcherModule, DQMHistAnalysisInputModule, cdcDQM7Module, SwitchDataStoreModule, PhysicsObjectsMiraBelleModule, HistoModule, TRGGRLDQMModule, KLMTriggerModule, DQMHistAnalysisEventT0Module, DQMHistAnalysisInputSrvModule, SeqRootOutputModule, TRGGDLDQMModule, DQMHistAnalysisSVDGeneralModule, PhysicsObjectsMiraBelleDst2Module, PhysicsObjectsMiraBelleDstModule, TxModule, B2BIIMCParticlesMonitorModule, DQMHistAnalysisOutputNSMModule, DQMHistAnalysisPlotOnlyModule, DQMHistAnalysisSVDEfficiencyModule, RxModule, Root2BinaryModule, DQMHistAnalysisExampleModule, DQMHistAnalysisOutputRelayMsgModule, svdDumpModule, TRGECLDQMModule, DQMHistAnalysisOutputFileModule, TRGCDCT2DDQMModule, DQMHistAnalysisOutputModule, SeqRootInputModule, TRGCDCT3DDQMModule, TRGGDLSummaryModule, HistoManagerModule, TRGCDCTSFDQMModule, TRGGDLDSTModule, PhysicsObjectsDQMModule, CalibrationCollectorModule, ARICHBackgroundModule, TRGECLUnpackerModule, EvReductionModule, Raw2DsModule, RawInputModule, StorageDeserializerModule, BeamabortModule, BgoModule, CaveModule, ClawModule, CLAWSModule, DosiModule, FANGSModule, He3tubeModule, MicrotpcModule, Ph1bpipeModule, Ph1sustrModule, PindiodeModule, PlumeModule, QcsmonitorModule, SrsensorModule, SerializerModule, FastRbuf2DsModule, Ds2SampleModule, DeSerializerPXDModule, Rbuf2RbufModule, GenRawSendModule, Rbuf2DsModule, TxSocketModule, Ds2RawModule, Ds2RawFileModule, DqmHistoManagerModule, Ds2RbufModule, StorageSerializerModule, GetEventFromSocketModule, ReceiveEventModule, ElapsedTimeModule, MonitorDataCOPPERModule, Root2RawModule, RxSocketModule, CertifyParallelModule, SeqRootMergerModule, DAQPerfModule, MonitorDataModule, TrackAnaModule, and PartialSeqRootReaderModule.

Definition at line 168 of file Module.h.

◆ evalCondition()

bool evalCondition ( ) const
inherited

If at least one condition was set, it is evaluated and true returned if at least one condition returns true.

If no condition or result value was defined, the method returns false. Otherwise, the condition is evaluated and true returned, if at least one condition returns true. To speed up the evaluation, the condition strings were already parsed in the method if_value().

Returns
True if at least one condition and return value exists and at least one condition expression was evaluated to true.

Definition at line 98 of file Module.cc.

◆ event()

void event ( )
overridevirtual

Things to do for each event.

When used with upstream firmware simulation module (i.e. TSF), read the input signal vectors from it.

When used with fast simulation, the input will be prepared by reading the CDC segment hits from the DataStore, and assigning them with clocks by found time.

The signals are written to the firmware sim clock-by-clock.

Reimplemented from Module.

Definition at line 322 of file CDCTrigger2DFinderFirmwareModule.cc.

◆ getAfterConditionPath()

Module::EAfterConditionPath getAfterConditionPath ( ) const
inherited

What to do after the conditional path is finished.

(defaults to c_End if no condition is set)

Definition at line 135 of file Module.cc.

◆ getConditionPath()

std::shared_ptr< Path > getConditionPath ( ) const
inherited

Returns the path of the last true condition (if there is at least one, else reaturn a null pointer).


Definition at line 115 of file Module.cc.

◆ getFileNames()

virtual std::vector<std::string> getFileNames ( __attribute__((unused)) bool  outputFiles)
inlinevirtualinherited

Return a list of output filenames for this modules.

This will be called when basf2 is run with "--dry-run" if the module has set either the c_Input or c_Output properties.

If the parameter outputFiles is false (for modules with c_Input) the list of input filenames should be returned (if any). If outputFiles is true (for modules with c_Output) the list of output files should be returned (if any).

If a module has sat both properties this member is called twice, once for each property.

The module should return the actual list of requested input or produced output filenames (including handling of input/output overrides) so that the grid system can handle input/output files correctly.

This function should return the same value when called multiple times. This is especially important when taking the input/output overrides from Environment as they get consumed when obtained so the finalized list of output files should be stored for subsequent calls.

Definition at line 136 of file Module.h.

◆ getName()

const std::string& getName ( ) const
inlineinherited

Returns the name of the module.

This can be changed via e.g. set_name() in the steering file to give more useful names if there is more than one module of the same type.

For identifying the type of a module, using getType() (or type() in Python) is recommended.

Definition at line 189 of file Module.h.

◆ getParamInfoListPython()

std::shared_ptr< boost::python::list > getParamInfoListPython ( ) const
inherited

Returns a python list of all parameters.

Each item in the list consists of the name of the parameter, a string describing its type, a python list of all default values and the description of the parameter.

Returns
A python list containing the parameters of this parameter list.

Definition at line 281 of file Module.cc.

◆ getReturnValue()

int getReturnValue ( ) const
inlineinherited

Return the return value set by this module.

This value is only meaningful if hasReturnValue() is true

Definition at line 383 of file Module.h.

◆ getType()

const std::string & getType ( ) const
inherited

Returns the type of the module (i.e.

class name minus 'Module')

Definition at line 43 of file Module.cc.

◆ hasProperties()

bool hasProperties ( unsigned int  propertyFlags) const
inherited

Returns true if all specified property flags are available in this module.

Parameters
propertyFlagsOred EModulePropFlags which should be compared with the module flags.

Definition at line 162 of file Module.cc.

◆ if_false()

void if_false ( const std::shared_ptr< Path > &  path,
EAfterConditionPath  afterConditionPath = EAfterConditionPath::c_End
)
inherited

A simplified version to add a condition to the module.

Please note that successive calls of this function will add more than one condition to the module. If more than one condition results in true, only the last of them will be used.

Please be careful: Avoid creating cyclic paths, e.g. by linking a condition to a path which is processed before the path where this module is located in.

It is equivalent to the if_value() method, using the expression "<1". This method is meant to be used together with the setReturnValue(bool value) method.

Parameters
pathShared pointer to the Path which will be executed if the return value is false.
afterConditionPathWhat to do after executing 'path'.

Definition at line 87 of file Module.cc.

◆ if_true()

void if_true ( const std::shared_ptr< Path > &  path,
EAfterConditionPath  afterConditionPath = EAfterConditionPath::c_End
)
inherited

A simplified version to set the condition of the module.

Please note that successive calls of this function will add more than one condition to the module. If more than one condition results in true, only the last of them will be used.

Please be careful: Avoid creating cyclic paths, e.g. by linking a condition to a path which is processed before the path where this module is located in.

It is equivalent to the if_value() method, using the expression ">=1". This method is meant to be used together with the setReturnValue(bool value) method.

Parameters
pathShared pointer to the Path which will be executed if the return value is true.
afterConditionPathWhat to do after executing 'path'.

Definition at line 92 of file Module.cc.

◆ if_value()

void if_value ( const std::string &  expression,
const std::shared_ptr< Path > &  path,
EAfterConditionPath  afterConditionPath = EAfterConditionPath::c_End
)
inherited

Add a condition to the module.

Please note that successive calls of this function will add more than one condition to the module. If more than one condition results in true, only the last of them will be used.

See https://confluence.desy.de/display/BI/Software+ModCondTut or ModuleCondition for a description of the syntax.

Please be careful: Avoid creating cyclic paths, e.g. by linking a condition to a path which is processed before the path where this module is located in.

Parameters
expressionThe expression of the condition.
pathShared pointer to the Path which will be executed if the condition is evaluated to true.
afterConditionPathWhat to do after executing 'path'.

Definition at line 81 of file Module.cc.

◆ localSegmentID()

int localSegmentID ( int  globalID)
protected

Calculate local segment ID from global ID.

Parameters
globalIDglobal TS ID
Returns
local TS ID in the Super Layer. TS in SL8 is shifted by 16.

Definition at line 133 of file CDCTrigger2DFinderFirmwareModule.cc.

◆ setDescription()

void setDescription ( const std::string &  description)
protectedinherited

Sets the description of the module.

Parameters
descriptionA description of the module.

Definition at line 216 of file Module.cc.

◆ setLogInfo()

void setLogInfo ( int  logLevel,
unsigned int  logInfo
)
inherited

Configure the printed log information for the given level.

Parameters
logLevelThe log level (one of LogConfig::ELogLevel)
logInfoWhat kind of info should be printed? ORed combination of LogConfig::ELogInfo flags.

Definition at line 75 of file Module.cc.

◆ setName()

void setName ( const std::string &  name)
inlineinherited

Set the name of the module.

Note
The module name is set when using the REG_MODULE macro, but the module can be renamed before calling process() using the set_name() function in your steering file.
Parameters
nameThe name of the module

Definition at line 216 of file Module.h.

◆ setParamPython()

void setParamPython ( const std::string &  name,
const boost::python::object &  pyObj
)
privateinherited

Implements a method for setting boost::python objects.

The method supports the following types: list, dict, int, double, string, bool The conversion of the python object to the C++ type and the final storage of the parameter value is done in the ModuleParam class.

Parameters
nameThe unique name of the parameter.
pyObjThe object which should be converted and stored as the parameter value.

Definition at line 236 of file Module.cc.

◆ setParamPythonDict()

void setParamPythonDict ( const boost::python::dict &  dictionary)
privateinherited

Implements a method for reading the parameter values from a boost::python dictionary.

The key of the dictionary has to be the name of the parameter and the value has to be of one of the supported parameter types.

Parameters
dictionaryThe python dictionary from which the parameter values are read.

Definition at line 251 of file Module.cc.

◆ setPropertyFlags()

void setPropertyFlags ( unsigned int  propertyFlags)
inherited

Sets the flags for the module properties.

Parameters
propertyFlagsbitwise OR of EModulePropFlags

Definition at line 210 of file Module.cc.

◆ setReturnValue() [1/2]

void setReturnValue ( bool  value)
protectedinherited

Sets the return value for this module as bool.

The bool value is saved as an integer with the convention 1 meaning true and 0 meaning false. The value can be used in the steering file to divide the analysis chain into several paths.

Parameters
valueThe value of the return value.

Definition at line 229 of file Module.cc.

◆ setReturnValue() [2/2]

void setReturnValue ( int  value)
protectedinherited

Sets the return value for this module as integer.

The value can be used in the steering file to divide the analysis chain into several paths.

Parameters
valueThe value of the return value.

Definition at line 222 of file Module.cc.

◆ setType()

void setType ( const std::string &  type)
protectedinherited

Set the module type.

Only for use by internal modules (which don't use the normal REG_MODULE mechanism).

Definition at line 50 of file Module.cc.

◆ terminate()

virtual void terminate ( )
inlinevirtualinherited

This method is called at the end of the event processing.

This method is called only once after the event processing finished. Use this method for cleaning up, closing files, etc.

This method can be implemented by subclasses.

Reimplemented in ROIDQMModule, DQMHistAnalysisPXDTrackChargeModule, DQMHistOutputToEPICSModule, DQMHistInjectionModule, DQMHistAnalysisRooFitExampleModule, DQMHistAnalysisPXDCMModule, DQMHistAnalysisPXDReductionModule, DQMHistAnalysisPXDChargeModule, DQMHistAnalysisPXDDAQModule, DQMHistAnalysisPXDEffModule, PXDBgTupleProducerModule, PXDMCBgTupleProducerModule, PyModule, PXDDQMEfficiencyNtupleSelftrackModule, DQMHistComparitorModule, PXDDQMEfficiencyNtupleModule, DQMHistAnalysisInputRootFileModule, PXDROIFinderAnalysisModule, ROISenderModule, PXDUnpackerModule, PXDUnpackerOTModule, PXDPackerErrModule, PXDPackerModule, SVDDQMExpressRecoModule, DQMHistAnalysisPXDERModule, SVDDQMClustersOnTrackModule, PXDReadRawONSENModule, PXDReadRawBonnDAQMatchedModule, DQMHistAnalysisEpicsExampleModule, DQMHistAnalysisIPModule, PXDReadRawBonnDAQModule, DQMHistAnalysisPXDFitsModule, DQMHistAnalysisExampleFlagsModule, TRGCDCT3DUnpackerModule, TRGCDCTSFUnpackerModule, TRGGRLUnpackerModule, TRGCDCETFUnpackerModule, CDCTriggerUnpackerModule, TOPUnpackerModule, FindletModule< AFindlet >, FindletModule< FacetCreator >, FindletModule< TrackFinderAutomaton >, FindletModule< CKFToCDCFromEclFindlet >, FindletModule< CKFToCDCFindlet >, FindletModule< CKFToSVDSeedFindlet >, FindletModule< AxialTrackCreatorMCTruth >, FindletModule< AxialStraightTrackFinder >, FindletModule< SegmentLinker >, FindletModule< TrackCreatorSegmentTripleAutomaton >, FindletModule< TrackCreatorSegmentPairAutomaton >, FindletModule< SegmentCreatorFacetAutomaton >, FindletModule< SegmentOrienter >, FindletModule< SegmentFinderFacetAutomaton >, FindletModule< CKFToSVDFindlet >, FindletModule< TrackFinderSegmentTripleAutomaton >, FindletModule< TrackRejecter >, FindletModule< SegmentCreatorMCTruth >, FindletModule< HitBasedT0Extractor >, FindletModule< TrackFinderCosmics >, FindletModule< SuperClusterCreator >, FindletModule< AsicBackgroundLibraryCreator >, FindletModule< TrackExporter >, FindletModule< ClusterPreparer >, FindletModule< CosmicsTrackMergerFindlet >, FindletModule< AxialTrackFinderHough >, FindletModule< TrackFinderSegmentPairAutomaton >, FindletModule< TrackLinker >, FindletModule< TrackOrienter >, FindletModule< TrackFinder >, FindletModule< AxialTrackFinderLegendre >, FindletModule< AxialTrackCreatorSegmentHough >, FindletModule< MonopoleAxialTrackFinderLegendre >, FindletModule< ClusterRefiner< BridgingWireHitRelationFilter > >, FindletModule< SegmentPairCreator >, FindletModule< HitReclaimer >, FindletModule< CKFToPXDFindlet >, FindletModule< TrackQualityEstimator >, FindletModule< StereoHitFinder >, FindletModule< TrackCreatorSingleSegments >, FindletModule< TrackFlightTimeAdjuster >, FindletModule< SegmentFitter >, FindletModule< SegmentRejecter >, FindletModule< WireHitPreparer >, FindletModule< SegmentTripleCreator >, FindletModule< SegmentTrackCombiner >, FindletModule< MCVXDCDCTrackMergerFindlet >, FindletModule< MonopoleStereoHitFinder >, FindletModule< TrackCombiner >, FindletModule< AxialSegmentPairCreator >, FindletModule< WireHitBackgroundDetector >, FindletModule< ClusterBackgroundDetector >, FindletModule< CDCTrackingEventLevelMdstInfoFillerFindlet >, FindletModule< MonopoleStereoHitFinderQuadratic >, FindletModule< TrackQualityAsserter >, FindletModule< WireHitCreator >, SpacePoint2TrueHitConnectorModule, ECLWaveformFitModule, TOPTimeBaseCalibratorModule, B2BIIConvertMdstModule, TOPTBCComparatorModule, ECLChargedPIDModule, SVDBackgroundModule, B2BIIFixMdstModule, ARICHNtupleModule, ParticleLoaderModule, BeamBkgTagSetterModule, ECLDigitizerModule, SVDDigitizerModule, CDCTriggerHoughETFModule, TOPGainEfficiencyCalculatorModule, CDCTrigger2DFinderModule, OpticalGunModule, ARICHDigitizerModule, KLMClustersReconstructorModule, CDCDedxValidationModule, ParticleKinematicFitterModule, TOPDQMModule, ECLShowerShapeModule, CDCDQMModule, TOPLaserHitSelectorModule, KLMDQMModule, PXDBackgroundModule, TOPModuleT0CalibratorModule, DQMHistAnalysisTRGGDLModule, CDCDedxPIDModule, TOPChannelT0CalibratorModule, TOPCommonT0CalibratorModule, TOPReconstructorModule, DATCONTrackingModule, BKLMDigitAnalyzerModule, TOPRawDigitConverterModule, ARICHFillHitsModule, DQMHistAnalysisCDCMonObjModule, KLMUnpackerModule, DQMHistAnalysisKLMModule, KLMReconstructorModule, ARICHReconstructorModule, CDCCRTestModule, KLMDigitizerModule, SoftwareTriggerModule, EKLMDataCheckerModule, TOPPDFDebuggerModule, ARICHDQMModule, DQMHistAnalysisARICHModule, KLMPackerModule, MdstPIDModule, FullSimModule, TOPAlignerModule, TOPBackgroundModule, ARICHPackerModule, BeamBkgMixerModule, ECLDigitizerPureCsIModule, TOPPDFCheckerModule, ARICHRelateModule, BelleMCOutputModule, BeamBkgHitRateMonitorModule, CDCPackerModule, DQMHistAnalysisMiraBelleModule, GFTC2SPTCConverterModule, ARICHUnpackerModule, ECLCRFinderModule, ARICHMCParticlesModule, ARICHRateCalModule, CDCUnpackerModule, CsIDigitizerModule, TOPDoublePulseGeneratorModule, SVDROIFinderAnalysisModule, BGOverlayExecutorModule, CDCCosmicAnalysisModule, ECLDataAnalysisModule, EclDisplayModule, VXDDedxPIDModule, ARICHRawUnpackerModule, NtuplePhase1_v6Module, ECLChargedPIDDataAnalysisValidationModule, ECLShowerCorrectorModule, EvtGenDecayModule, EKLMADCModule, HitLevelInfoWriterModule, SVDCoGTimeEstimatorModule, TOPCalPulseGeneratorModule, TOPNtupleModule, TOPPackerModule, TOPWaveformFeatureExtractorModule, SVDROIFinderModule, ParticleWeightingLookUpCreatorModule, BeamBkgGeneratorModule, RootOutputModule, TOPInterimFENtupleModule, TOPMCTrackMakerModule, BGOverlayInputModule, CsIStudyModule, ECLDigitCalibratorModule, ECLSplitterN1Module, ProfileModule, KLMClusterEfficiencyModule, PIDNtupleModule, VXDTFTrainingDataCollectorModule, arichBtestModule, CDCDigitizerModule, TpcDigitizerModule, ECLDQMModule, OverrideGenerationFlagsModule, BKLMSimHistogrammerModule, MCMatcherKLMClustersModule, DQMHistAnalysisARICHMonObjModule, PXDPerformanceModule, TOPBunchFinderModule, TOPTriggerDigitizerModule, TrackFinderVXDAnalizerModule, FlavorTaggerInfoFillerModule, HLTDQM2ZMQModule, ECLChargedPIDDataAnalysisModule, FragmentationModule, TOPCosmicT0FinderModule, TRGGRLMatchModule, ReprocessorModule, FANGSDigitizerModule, CDCRecoTrackFilterModule, IPDQMExpressRecoModule, ECLLocalMaximumFinderModule, CDCDedxCorrectionModule, CDCDedxDQMModule, DQMHistAnalysisMonObjModule, ECLClusterPSDModule, ExtModule, MCTrackCandClassifierModule, MuidModule, DQMHistAnalysisCDCDedxModule, DQMHistAnalysisHLTMonObjModule, BKLMTrackingModule, SVDROIFinderAnalysisDataModule, HitXPModule, DQMHistAnalysisECLModule, ECLBackgroundModule, BabayagaNLOInputModule, EventT0DQMModule, SVDDataFormatCheckModule, TOPLaserCalibratorModule, SecMapTrainerVXDTFModule, arichToNtupleModule, BgoStudyModule, CsiStudy_v2Module, MicrotpcStudyModule, PlumeDigitizerModule, PXDClustersFromTracksModule, SVDClusterEvaluationTrueInfoModule, TOPXTalkChargeShareSetterModule, SecMapTrainerBaseModule, SegmentNetworkAnalyzerModule, TRGGDLUnpackerModule, TRGTOPDQMModule, AnalysisPhase1StudyModule, DosiStudyModule, He3tubeStudyModule, ECLCovarianceMatrixModule, ECLFinalizerModule, ECLSplitterN2Module, MCMatcherECLClustersModule, RootInputModule, BKLMAnaModule, MVAExpertModule, MVAMultipleExpertsModule, KLMExpertModule, SVDHotStripFinderModule, TOPChannelT0MCModule, NoKickCutsEvalModule, TRGECLRawdataAnalysisModule, TRGTOPUnpackerModule, TPCStudyModule, ECLDQMEXTENDEDModule, ECLShowerCalibratorModule, ECLTrackClusterMatchingModule, PhokharaInputModule, CDCDedxSkimCDSTModule, SVDPackerModule, CurlingTrackCandSplitterModule, SpacePointCreatorTestModule, MLSegmentNetworkProducerModule, BgoDigitizerModule, CsiDigitizer_v2Module, DosiDigitizerModule, PinDigitizerModule, HLTDs2ZMQModule, TeeggInputModule, KlongValidationModule, SVDPerformanceModule, MCMatcherTRGECLModule, ParticleStatsModule, BeamabortStudyModule, ClawStudyModule, ClawsStudyModule, PindiodeStudyModule, QcsmonitorStudyModule, DQMHistAnalysisInputPVSrvModule, ECLHitDebugModule, AsyncWrapper, HepMCOutputModule, KKGenInputModule, CombinedPIDPerformanceModule, SVDOccupancyAnalysisModule, SVDSpacePointCreatorModule, TrackingPerformanceEvaluationModule, CurlTaggerModule, BHWideInputModule, PXDSpacePointCreatorModule, CDCDedxSkimModule, EffPlotsModule, CDCTriggerTSFFirmwareModule, ParticleMCDecayStringModule, VariablesToNtupleModule, BeamDigitizerModule, He3DigitizerModule, CDCCrossTalkAdderModule, ECLUnpackerModule, BBBremInputModule, GeneratedVertexDisplacerModule, KoralWInputModule, DataWriterModule, FullSimTimingModule, SVDCrossTalkFinderModule, SVDClusterFilterModule, SVDShaperDigitsFromTracksModule, SVD3SamplesEmulatorModule, RT2SPTCConverterModule, FastBDTClassifierTrainingModule, TRGGDLModule, EventKinematicsModule, CDCInitialT0DeterminationModule, DisplayModule, SVDChannelMappingModule, SVDClusterQualityEstimatorCalibrationModule, SVDSpacePointQICalibrationModule, ROIReadTestModule, TRGCDCT3DConverterModule, TRGECLModule, CosmicsAlignmentValidationModule, ClawDigitizerModule, ClawsDigitizerModule, FANGSStudyModule, ECLPackerModule, ECLTRGInformationModule, SVDB4CommissioningPlotsModule, SVDClusterEvaluationModule, V0findingPerformanceEvaluationModule, RemoveParticlesNotInListsModule, QcsmonitorDigitizerModule, DQMHistSnapshotsModule, ECLFillCellIdMappingModule, HepMCInputModule, HepevtOutputModule, RemoveMCParticlesModule, SVDChargeSharingAnalysisModule, VXDQETrainingDataCollectorModule, CsiModule, AafhInputModule, BeamSpotMonitorModule, TrackQETrainingDataCollectorModule, TRGGRLModule, VariablesToHistogramModule, ECLTrackClusterMatchingParametrizationExpertModule, RandomBarrierModule, CRYInputModule, MasterClassModule, GenfitVisModule, SPTCRefereeModule, FillTrackFitNtupleModule, TRGGRLProjectsModule, DQMHistDeltaHistoModule, GeneratorPreselectionModule, TCConvertersTestModule, TRGCDCModule, TRGECLFAMModule, VariablesToEventBasedTreeModule, B2BIIMdstInputModule, SubEventModule, TrepsInputModule, CDCDedxScanModule, CDCTriggerNeuroDQMModule, DQMHistAnalysisSVDOnMiraBelleModule, DQMHistAnalysisTOPModule, ECLCompressBGOverlayModule, ECLMatchingPerformanceExpertModule, TRGCDCTSStreamModule, ParticleMassUpdaterModule, SkimFilterModule, SVDClusterQualityEstimatorModule, MCV0MatcherModule, ECLDigiStudyModule, TrackFilterModule, EclCovMatrixNtupleModule, Convert2RawDetModule, TOPRingPlotterModule, PhaseSpaceAnalysisModule, TreeFitterModule, TRGECLQAMModule, TRGECLTimingCalModule, DQMHistAnalysisOutputMonObjModule, SoftwareTriggerResultPrinterModule, SVDMaxStripTTreeModule, FastBDTClassifierAnalyzerModule, VXDMisalignmentModule, StandardTrackingPerformanceModule, cdcDQM7Module, DQMHistAnalysisInputModule, SwitchDataStoreModule, DQMHistAnalysisEventT0Module, ECLTrackClusterMatchingPerformanceModule, HistoModule, ZMQRxOutputModule, ZMQTxInputModule, SPTC2GFTCConverterModule, TRGGRLDQMModule, PhysicsObjectsMiraBelleModule, ZMQRxWorkerModule, SPTC2RTConverterModule, TRGGDLDQMModule, KLMTriggerModule, DQMHistAnalysisInputSrvModule, ProgressBarModule, SeqRootOutputModule, GeometryModule, CDCTriggerTSFModule, DQMHistAnalysisSVDGeneralModule, PhysicsObjectsMiraBelleDst2Module, PhysicsObjectsMiraBelleDstModule, TxModule, SVDPerformanceTTreeModule, CDCTriggerNeuroTrainerModule, B2BIIMCParticlesMonitorModule, ZMQTxWorkerModule, Root2BinaryModule, ScanCDCGeoModule, DQMHistAnalysisOutputNSMModule, DQMHistAnalysisPlotOnlyModule, DQMHistAnalysisSVDEfficiencyModule, RxModule, svdDumpModule, TRGECLDQMModule, GRLNeuroTrainerModule, DQMHistAnalysisExampleModule, DQMHistAnalysisOutputRelayMsgModule, CheckErrorEventModule, DQMHistAnalysisOutputFileModule, TRGCDCT2DDQMModule, StudyMaterialEffectsModule, TRGCDCT3DDQMModule, TRGGDLSummaryModule, DQMHistAnalysisOutputModule, HistoManagerModule, SeqRootInputModule, TRGCDCTSFDQMModule, TRGGDLDSTModule, PhysicsObjectsDQMModule, CollectorTestModule, CalibrationCollectorModule, ARICHBackgroundModule, EvReductionModule, Raw2DsModule, BeamabortModule, BgoModule, CaveModule, ClawModule, CLAWSModule, DosiModule, FANGSModule, He3tubeModule, MicrotpcModule, Ph1bpipeModule, Ph1sustrModule, PindiodeModule, PlumeModule, QcsmonitorModule, SrsensorModule, RawInputModule, StorageDeserializerModule, TRGECLUnpackerModule, SerializerModule, FastRbuf2DsModule, Ds2SampleModule, DeSerializerPXDModule, GenRawSendModule, DeSerializerModule, Rbuf2RbufModule, Rbuf2DsModule, TxSocketModule, DqmHistoManagerModule, Ds2RawModule, Ds2RawFileModule, Ds2RbufModule, Root2RawModule, StorageSerializerModule, GetEventFromSocketModule, ReceiveEventModule, ElapsedTimeModule, MonitorDataCOPPERModule, RxSocketModule, CertifyParallelModule, SeqRootMergerModule, DAQPerfModule, MonitorDataModule, TrackAnaModule, and PartialSeqRootReaderModule.

Definition at line 178 of file Module.h.

◆ toTSSLV()

auto toTSSLV ( const std::bitset< m_tsVectorWidth ts)
protected

Turn TS bitset into char array.

Parameters
tsthe TS hit in question
Returns
the equivalent of std_logic_vector(20 downto 0), represented with a std::array<char, 21>

Definition at line 160 of file CDCTrigger2DFinderFirmwareModule.cc.

Member Data Documentation

◆ clk

int clk = 0
protected

clock signal port handle.

Initialized at 0 by the SW shifter

Definition at line 180 of file CDCTrigger2DFinderFirmwareModule.h.

◆ m_debugLevel

int m_debugLevel = 0
protected

debug level: better description needed.

Does it make sense to initialize it at 0?

Definition at line 87 of file CDCTrigger2DFinderFirmwareModule.h.

◆ out

int out = 0
protected

output signal port handle.

Initialized at 0 by the SW shifter

Definition at line 184 of file CDCTrigger2DFinderFirmwareModule.h.

◆ tsfPort

int tsfPort[5] = {0}
protected

input signal port handle.

Initialized at 0 by the SW shifter

Definition at line 182 of file CDCTrigger2DFinderFirmwareModule.h.


The documentation for this class was generated from the following files:
Belle2::CDCTrigger2DFinderFirmwareModule::m_nClockPerEvent
int m_nClockPerEvent
how many clocks to simulate per event
Definition: CDCTrigger2DFinderFirmwareModule.h:84
Belle2::Module::setDescription
void setDescription(const std::string &description)
Sets the description of the module.
Definition: Module.cc:216
Belle2::CDCTrigger2DFinderFirmwareModule::m_outputCollectionName
std::string m_outputCollectionName
Name of the StoreArray containing the tracks found by the Hough tracking.
Definition: CDCTrigger2DFinderFirmwareModule.h:75
Belle2::CDCTrigger2DFinderFirmwareModule::m_hitCollectionName
std::string m_hitCollectionName
Name of the StoreArray containing the input track segment hits.
Definition: CDCTrigger2DFinderFirmwareModule.h:72
Belle2::CDCTrigger2DFinderFirmwareModule::m_fromFastSim
bool m_fromFastSim
flag to read TS hits from the output of TSF firmware simulation
Definition: CDCTrigger2DFinderFirmwareModule.h:81
Belle2::Module::Module
Module()
Constructor.
Definition: Module.cc:32
Belle2::Module::addParam
void addParam(const std::string &name, T &paramVariable, const std::string &description, const T &defaultValue)
Adds a new parameter to the module.
Definition: Module.h:562
Belle2::CDCTrigger2DFinderFirmwareModule::Xsi_Instance
Xsi::Loader * Xsi_Instance
Xsi loader from Xilinx software.
Definition: CDCTrigger2DFinderFirmwareModule.h:147
Belle2::CDCTrigger2DFinderFirmwareModule::m_bitstreamNameTo2D
std::string m_bitstreamNameTo2D
Name of the StoreArray holding the raw bit content to 2D trackers
Definition: CDCTrigger2DFinderFirmwareModule.h:78
