SVDDQMExpressRecoModule Class Reference

SVD DQM Module for Express Reco. More...

#include <SVDDQMExpressRecoModule.h>

Inheritance diagram for SVDDQMExpressRecoModule:
Collaboration diagram for SVDDQMExpressRecoModule:

Public Types

enum  EModulePropFlags {
  c_Input = 1,
  c_Output = 2,
  c_ParallelProcessingCertified = 4,
  c_HistogramManager = 8,
  c_InternalSerializer = 16,
  c_TerminateInAllProcesses = 32,
  c_DontCollectStatistics = 64
}
 Each module can be tagged with property flags, which indicate certain features of the module. More...

typedef ModuleCondition::EAfterConditionPath EAfterConditionPath
 Forward the EAfterConditionPath definition from the ModuleCondition.


Public Member Functions

 SVDDQMExpressRecoModule ()
 Constructor.

void initialize () override final
 Module function initialize.

void terminate () override final
 Module function terminate.

void beginRun () override final
 Module function beginRun.

void event () override final
 Module function event.

void defineHisto () override final
 Histogram definitions such as TH1(), TH2(), TNtuple(), TTree().... More...

virtual void endRun () override
 Function to process end_run record.

virtual std::vector< std::string > getFileNames (__attribute__((unused)) bool outputFiles)
 Return a list of output filenames for this modules. More...

const std::string & getName () const
 Returns the name of the module. More...

const std::string & getType () const
 Returns the type of the module (i.e. More...

const std::string & getPackage () const
 Returns the package this module is in.

const std::string & getDescription () const
 Returns the description of the module.

void setName (const std::string &name)
 Set the name of the module. More...

void setPropertyFlags (unsigned int propertyFlags)
 Sets the flags for the module properties. More...

LogConfiggetLogConfig ()
 Returns the log system configuration.

void setLogConfig (const LogConfig &logConfig)
 Set the log system configuration.

void setLogLevel (int logLevel)
 Configure the log level.

void setDebugLevel (int debugLevel)
 Configure the debug messaging level.

void setAbortLevel (int abortLevel)
 Configure the abort log level.

void setLogInfo (int logLevel, unsigned int logInfo)
 Configure the printed log information for the given level. More...

void if_value (const std::string &expression, const std::shared_ptr< Path > &path, EAfterConditionPath afterConditionPath=EAfterConditionPath::c_End)
 Add a condition to the module. More...

void if_false (const std::shared_ptr< Path > &path, EAfterConditionPath afterConditionPath=EAfterConditionPath::c_End)
 A simplified version to add a condition to the module. More...

void if_true (const std::shared_ptr< Path > &path, EAfterConditionPath afterConditionPath=EAfterConditionPath::c_End)
 A simplified version to set the condition of the module. More...

bool hasCondition () const
 Returns true if at least one condition was set for the module.

const ModuleConditiongetCondition () const
 Return a pointer to the first condition (or nullptr, if none was set)

const std::vector< ModuleCondition > & getAllConditions () const
 Return all set conditions for this module.

bool evalCondition () const
 If at least one condition was set, it is evaluated and true returned if at least one condition returns true. More...

std::shared_ptr< PathgetConditionPath () const
 Returns the path of the last true condition (if there is at least one, else reaturn a null pointer). More...

Module::EAfterConditionPath getAfterConditionPath () const
 What to do after the conditional path is finished. More...

std::vector< std::shared_ptr< Path > > getAllConditionPaths () const
 Return all condition paths currently set (no matter if the condition is true or not).

bool hasProperties (unsigned int propertyFlags) const
 Returns true if all specified property flags are available in this module. More...

bool hasUnsetForcedParams () const
 Returns true and prints error message if the module has unset parameters which the user has to set in the steering file.

const ModuleParamListgetParamList () const
 Return module param list.

template<typename T >
ModuleParam< T > & getParam (const std::string &name) const
 Returns a reference to a parameter. More...

bool hasReturnValue () const
 Return true if this module has a valid return value set.

int getReturnValue () const
 Return the return value set by this module. More...

std::shared_ptr< PathElementclone () const override
 Create an independent copy of this module. More...

std::shared_ptr< boost::python::list > getParamInfoListPython () const
 Returns a python list of all parameters. More...


Static Public Member Functions

static void exposePythonAPI ()
 Exposes methods of the Module class to Python.


Protected Member Functions

virtual void def_initialize ()
 Wrappers to make the methods without "def_" prefix callable from Python. More...

virtual void def_beginRun ()
 Wrapper method for the virtual function beginRun() that has the implementation to be used in a call from Python.

virtual void def_event ()
 Wrapper method for the virtual function event() that has the implementation to be used in a call from Python.

virtual void def_endRun ()
 This method can receive that the current run ends as a call from the Python side. More...

virtual void def_terminate ()
 Wrapper method for the virtual function terminate() that has the implementation to be used in a call from Python.

void setDescription (const std::string &description)
 Sets the description of the module. More...

void setType (const std::string &type)
 Set the module type. More...

template<typename T >
void addParam (const std::string &name, T &paramVariable, const std::string &description, const T &defaultValue)
 Adds a new parameter to the module. More...

template<typename T >
void addParam (const std::string &name, T &paramVariable, const std::string &description)
 Adds a new enforced parameter to the module. More...

void setReturnValue (int value)
 Sets the return value for this module as integer. More...

void setReturnValue (bool value)
 Sets the return value for this module as bool. More...

void setParamList (const ModuleParamList &params)
 Replace existing parameter list.


Private Member Functions

std::list< ModulePtrgetModules () const override
 no submodules, return empty list

std::string getPathString () const override
 return the module name.

void setParamPython (const std::string &name, const boost::python::object &pyObj)
 Implements a method for setting boost::python objects. More...

void setParamPythonDict (const boost::python::dict &dictionary)
 Implements a method for reading the parameter values from a boost::python dictionary. More...


Private Attributes

StoreObjPtr< SVDEventInfom_svdEventInfo
 SVDEventInfo data object.

bool m_desynchSVDTime = false
 if TRUE: svdTime back in SVD time reference

StoreObjPtr< SoftwareTriggerResultm_resultStoreObjectPointer
 Store Object for reading the trigger decision.

bool m_skipRejectedEvents = true
 if true skip events rejected by HLT (default)

TList * m_histoList = nullptr
 list of cumulative histograms

int m_expNumber = 0
 experiment number

int m_runNumber = 0
 run number

int m_ShowAllHistos = 0
 Flag to show all histos in DQM, default = 0 (do not show)

float m_CutSVDCharge = 0.0
 cut for accepting strips to hitmap histogram default = 0 ADU

float m_CutSVDClusterCharge = 0.0
 cut for accepting clusters to hitmap histogram, default = 0 ke-

std::string m_histogramDirectoryName
 Name of the histogram directory in ROOT file.

std::string m_storeNoZSSVDShaperDigitsName
 not zero-suppressed SVDShaperDigits StoreArray name

std::string m_storeSVDShaperDigitsName
 SVDShaperDigits StoreArray name.

std::string m_storeSVDClustersName
 SVDClusters StoreArray name.

TH1F * m_nEvents = nullptr
 number of events

TH1F * m_hitMapCountsU = nullptr
 Hitmaps u of Digits.

TH1F * m_hitMapCountsV = nullptr
 Hitmaps v of Digits.

TH1F * m_hitMapClCountsU = nullptr
 Hitmaps u of Clusters.

TH1F * m_hitMapClCountsV = nullptr
 Hitmaps v of Clusters.

TH1F * m_hitMapCountsChip = nullptr
 Hitmaps of digits on chips.

TH1F * m_hitMapClCountsChip = nullptr
 Hitmaps of clusters on chips.

TH1F ** m_firedU = nullptr
 Fired u strips per event.

TH1F ** m_firedV = nullptr
 Fired v strips per event.

TH1F ** m_clustersU = nullptr
 number of u clusters per event

TH1F ** m_clustersV = nullptr
 number of v clusters per event

TH1F ** m_clusterChargeU = nullptr
 u charge of clusters

TH1F ** m_clusterChargeV = nullptr
 v charge of clusters

TH1F * m_clusterChargeUAll = nullptr
 u charge of clusters for all sensors

TH1F * m_clusterChargeVAll = nullptr
 v charge of clusters for all sensors

TH1F * m_clusterChargeU3 = nullptr
 u charge of clusters for layer 3 sensors

TH1F * m_clusterChargeV3 = nullptr
 v charge of clusters for layer 3 sensors

TH1F * m_clusterChargeU456 = nullptr
 u charge of clusters for layer 4,5,6 sensors

TH1F * m_clusterChargeV456 = nullptr
 v charge of clusters for layer 4,5,6 sensors

TH1F ** m_clusterSNRU = nullptr
 u SNR of clusters per sensor

TH1F ** m_clusterSNRV = nullptr
 v SNR of clusters per sensor

TH1F * m_clusterSNRUAll = nullptr
 u SNR of clusters for all sensors

TH1F * m_clusterSNRVAll = nullptr
 v SNR of clusters for all sensors

TH1F * m_clusterSNRU3 = nullptr
 u SNR of clusters for layer 3 sensors

TH1F * m_clusterSNRV3 = nullptr
 v SNR of clusters for layer 3 sensors

TH1F * m_clusterSNRU456 = nullptr
 u SNR of clusters for layer 4,5,6 sensors

TH1F * m_clusterSNRV456 = nullptr
 v SNR of clusters for layer 4,5,6 sensors

TH1F * m_stripMaxBinUAll = nullptr
 u MaxBin of strips for all sensors (offline Zero Suppression)

TH1F * m_stripMaxBinVAll = nullptr
 v MaxBin of strips for all sensors (offline Zero Suppression)

TH1F * m_stripMaxBinU3 = nullptr
 u MaxBin of strips for layer 3 sensors (offline Zero Suppression)

TH1F * m_stripMaxBinV3 = nullptr
 v MaxBin of strips for layer 3 sensors (offline Zero Suppression)

TH1F * m_stripMaxBinU6 = nullptr
 u MaxBin of strips for layer 6 sensors (offline Zero Suppression)

TH1F * m_stripMaxBinV6 = nullptr
 v MaxBin of strips for layer 6 sensors (offline Zero Suppression)

TH1F ** m_stripSignalU = nullptr
 u charge of strips

TH1F ** m_stripSignalV = nullptr
 v charge of strips

TH1F ** m_stripCountU = nullptr
 u strip count

TH1F ** m_stripCountV = nullptr
 v strip count

TH1F ** m_onlineZSstripCountU = nullptr
 u strip count (online Zero Suppression)

TH1F ** m_onlineZSstripCountV = nullptr
 v strip count (online Zero Suppression

TH1F ** m_clusterSizeU = nullptr
 u size

TH1F ** m_clusterSizeV = nullptr
 v size

TH1F ** m_clusterTimeU = nullptr
 u time

TH1F ** m_clusterTimeV = nullptr
 v time

TH1F * m_clusterTimeUAll = nullptr
 u time of clusters for all sensors

TH1F * m_clusterTimeVAll = nullptr
 v time of clusters for all sensors

TH1F * m_clusterTimeU3 = nullptr
 u Time of clusters for layer 3 sensors

TH1F * m_clusterTimeV3 = nullptr
 v Time of clusters for layer 3 sensors

TH1F * m_clusterTimeU456 = nullptr
 u Time of clusters for layer 4,5,6 sensors

TH1F * m_clusterTimeV456 = nullptr
 v Time of clusters for layer 4,5,6 sensors

TH2F ** m_hitMapU = nullptr
 Hitmaps pixels for u.

TH2F ** m_hitMapV = nullptr
 Hitmaps pixels for v.

TH1F ** m_hitMapUCl = nullptr
 Hitmaps clusters for u.

TH1F ** m_hitMapVCl = nullptr
 Hitmaps clusters for v.

std::string m_name
 The name of the module, saved as a string (user-modifiable)

std::string m_type
 The type of the module, saved as a string.

std::string m_package
 Package this module is found in (may be empty).

std::string m_description
 The description of the module.

unsigned int m_propertyFlags
 The properties of the module as bitwise or (with |) of EModulePropFlags.

LogConfig m_logConfig
 The log system configuration of the module.

ModuleParamList m_moduleParamList
 List storing and managing all parameter of the module.

bool m_hasReturnValue
 True, if the return value is set.

int m_returnValue
 The return value.

std::vector< ModuleConditionm_conditions
 Module condition, only non-null if set.


Detailed Description

SVD DQM Module for Express Reco.

Definition at line 47 of file SVDDQMExpressRecoModule.h.

Member Enumeration Documentation

◆ EModulePropFlags

enum EModulePropFlags
inherited

Each module can be tagged with property flags, which indicate certain features of the module.

Enumerator
c_Input

This module is an input module (reads data).

c_Output

This module is an output module (writes data).

c_ParallelProcessingCertified

This module can be run in parallel processing mode safely (All I/O must be done through the data store, in particular, the module must not write any files.)

c_HistogramManager

This module is used to manage histograms accumulated by other modules.

c_InternalSerializer

This module is an internal serializer/deserializer for parallel processing.

c_TerminateInAllProcesses

When using parallel processing, call this module's terminate() function in all processes().

This will also ensure that there is exactly one process (single-core if no parallel modules found) or at least one input, one main and one output process.

c_DontCollectStatistics

No statistics is collected for this module.

Definition at line 79 of file Module.h.

Member Function Documentation

◆ clone()

std::shared_ptr< PathElement > clone ( ) const
overridevirtualinherited

Create an independent copy of this module.

Note that parameters are shared, so changing them on a cloned module will also affect the original module.

Implements PathElement.

Definition at line 181 of file Module.cc.

◆ def_endRun()

virtual void def_endRun ( )
inlineprotectedvirtualinherited

This method can receive that the current run ends as a call from the Python side.

For regular C++-Modules that forwards the call to the regular endRun() method.

Reimplemented in PyModule.

Definition at line 441 of file Module.h.

◆ def_initialize()

virtual void def_initialize ( )
inlineprotectedvirtualinherited

Wrappers to make the methods without "def_" prefix callable from Python.

Overridden in PyModule. Wrapper method for the virtual function initialize() that has the implementation to be used in a call from Python.

Reimplemented in PyModule.

Definition at line 422 of file Module.h.

◆ defineHisto()

void defineHisto ( )
finaloverridevirtual

Histogram definitions such as TH1(), TH2(), TNtuple(), TTree()....

are supposed to be placed in this function.

Reimplemented from HistoModule.

Definition at line 79 of file SVDDQMExpressRecoModule.cc.

80 {
81  auto gTools = VXD::GeoCache::getInstance().getGeoTools();
82  if (gTools->getNumberOfLayers() == 0) {
83  B2FATAL("Missing geometry for VXD, check steering file.");
84  }
85  if (gTools->getNumberOfSVDLayers() == 0) {
86  B2WARNING("Missing geometry for SVD, SVD-DQM is skiped.");
87  return;
88  }
89
90  // Create a separate histogram directories and cd into it.
91  TDirectory* oldDir = gDirectory;
92  if (m_histogramDirectoryName != "") {
93  oldDir->mkdir(m_histogramDirectoryName.c_str());// do not use return value with ->cd(), its ZERO if dir already exists
94  oldDir->cd(m_histogramDirectoryName.c_str());
95  }
96
97  // basic constants presets:
98  int nSVDSensors = gTools->getNumberOfSVDSensors();
99  int nSVDChips = gTools->getTotalSVDChips();
100
101  // number of events counter
102  m_nEvents = new TH1F("SVDDQM_nEvents", "SVD Number of Events", 1, -0.5, 0.5);
103  m_nEvents->GetYaxis()->SetTitle("N events");
104  m_histoList->Add(m_nEvents);
105
106  // Create basic histograms:
107  // basic counters per sensor:
108  m_hitMapCountsU = new TH1F("SVDDQM_StripCountsU", "SVD Integrated Number of ZS5 Fired U-Strips per sensor",
109  nSVDSensors, 0, nSVDSensors);
110  m_hitMapCountsU->GetXaxis()->SetTitle("Sensor ID");
111  m_hitMapCountsU->GetYaxis()->SetTitle("counts");
113  m_hitMapCountsV = new TH1F("SVDDQM_StripCountsV", "SVD Integrated Number of ZS5 Fired V-Strips per sensor",
114  nSVDSensors, 0, nSVDSensors);
115  m_hitMapCountsV->GetXaxis()->SetTitle("Sensor ID");
116  m_hitMapCountsV->GetYaxis()->SetTitle("counts");
118  m_hitMapClCountsU = new TH1F("SVDDQM_ClusterCountsU", "SVD Integrated Number of U-Clusters per sensor",
119  nSVDSensors, 0, nSVDSensors);
120  m_hitMapClCountsU->GetXaxis()->SetTitle("Sensor ID");
121  m_hitMapClCountsU->GetYaxis()->SetTitle("counts");
123  m_hitMapClCountsV = new TH1F("SVDDQM_ClusterCountsV", "SVD Integrated Number of V-Clusters per sensor",
124  nSVDSensors, 0, nSVDSensors);
125  m_hitMapClCountsV->GetXaxis()->SetTitle("Sensor ID");
126  m_hitMapClCountsV->GetYaxis()->SetTitle("counts");
128  for (int i = 0; i < nSVDSensors; i++) {
129  VxdID id = gTools->getSensorIDFromSVDIndex(i);
130  int iLayer = id.getLayerNumber();
131  int iLadder = id.getLadderNumber();
132  int iSensor = id.getSensorNumber();
133  TString AxisTicks = Form("%i_%i_%i", iLayer, iLadder, iSensor);
134  m_hitMapCountsU->GetXaxis()->SetBinLabel(i + 1, AxisTicks.Data());
135  m_hitMapCountsV->GetXaxis()->SetBinLabel(i + 1, AxisTicks.Data());
136  m_hitMapClCountsU->GetXaxis()->SetBinLabel(i + 1, AxisTicks.Data());
137  m_hitMapClCountsV->GetXaxis()->SetBinLabel(i + 1, AxisTicks.Data());
138  }
139
140  // basic counters per chip:
141  m_hitMapCountsChip = new TH1F("SVDDQM_StripCountsChip", "SVD Integrated Number of ZS5 Fired Strips per chip",
142  nSVDChips, 0, nSVDChips);
143  m_hitMapCountsChip->GetXaxis()->SetTitle("Chip ID");
144  m_hitMapCountsChip->GetYaxis()->SetTitle("counts");
146  m_hitMapClCountsChip = new TH1F("SVDDQM_ClusterCountsChip", "SVD Integrated Number of Clusters per chip",
147  nSVDChips, 0, nSVDChips);
148  m_hitMapClCountsChip->GetXaxis()->SetTitle("Chip ID");
149  m_hitMapClCountsChip->GetYaxis()->SetTitle("counts");
151
152  m_firedU = new TH1F*[nSVDSensors];
153  m_firedV = new TH1F*[nSVDSensors];
154  m_clustersU = new TH1F*[nSVDSensors];
155  m_clustersV = new TH1F*[nSVDSensors];
156
157
158  m_clusterChargeU = new TH1F*[nSVDSensors];
159  m_clusterChargeV = new TH1F*[nSVDSensors];
160  m_clusterSNRU = new TH1F*[nSVDSensors];
161  m_clusterSNRV = new TH1F*[nSVDSensors];
162  m_stripSignalU = new TH1F*[nSVDSensors];
163  m_stripSignalV = new TH1F*[nSVDSensors];
164  m_stripCountU = new TH1F*[nSVDSensors];
165  m_stripCountV = new TH1F*[nSVDSensors];
166  m_onlineZSstripCountU = new TH1F*[nSVDSensors];
167  m_onlineZSstripCountV = new TH1F*[nSVDSensors];
168  m_clusterSizeU = new TH1F*[nSVDSensors];
169  m_clusterSizeV = new TH1F*[nSVDSensors];
170  m_clusterTimeU = new TH1F*[nSVDSensors];
171  m_clusterTimeV = new TH1F*[nSVDSensors];
172
173  int ChargeBins = 80;
174  float ChargeMax = 80;
175  int SNRBins = 50;
176  float SNRMax = 100;
177  int TimeBins = 300;
178  float TimeMin = -150;
179  float TimeMax = 150;
180
181  int MaxBinBins = 6;
182  int MaxBinMax = 6;
183
184  TString refFrame = "in FTSW reference";
185  if (m_desynchSVDTime)
186  refFrame = "in SVD reference";
187
188
189  //----------------------------------------------------------------
190  // Charge of clusters for all sensors
191  //----------------------------------------------------------------
192  string name = str(format("SVDDQM_ClusterChargeUAll"));
193  string title = str(format("SVD U-Cluster Charge for all sensors"));
194  m_clusterChargeUAll = new TH1F(name.c_str(), title.c_str(), ChargeBins, 0, ChargeMax);
195  m_clusterChargeUAll->GetXaxis()->SetTitle("cluster charge [ke-]");
196  m_clusterChargeUAll->GetYaxis()->SetTitle("count");
198  name = str(format("SVDDQM_ClusterChargeVAll"));
199  title = str(format("SVD V-Cluster Charge for all sensors"));
200  m_clusterChargeVAll = new TH1F(name.c_str(), title.c_str(), ChargeBins, 0, ChargeMax);
201  m_clusterChargeVAll->GetXaxis()->SetTitle("cluster charge [ke-]");
202  m_clusterChargeVAll->GetYaxis()->SetTitle("count");
204  //----------------------------------------------------------------
205  // Charge of clusters for L3/L456 sensors
206  //----------------------------------------------------------------
207  name = str(format("SVDDQM_ClusterChargeU3"));
208  title = str(format("SVD U-Cluster Charge for layer 3 sensors"));
209  m_clusterChargeU3 = new TH1F(name.c_str(), title.c_str(), ChargeBins, 0, ChargeMax);
210  m_clusterChargeU3->GetXaxis()->SetTitle("cluster charge [ke-]");
211  m_clusterChargeU3->GetYaxis()->SetTitle("count");
213  name = str(format("SVDDQM_ClusterChargeV3"));
214  title = str(format("SVD V-Cluster Charge for layer 3 sensors"));
215  m_clusterChargeV3 = new TH1F(name.c_str(), title.c_str(), ChargeBins, 0, ChargeMax);
216  m_clusterChargeV3->GetXaxis()->SetTitle("cluster charge [ke-]");
217  m_clusterChargeV3->GetYaxis()->SetTitle("count");
219
220  name = str(format("SVDDQM_ClusterChargeU456"));
221  title = str(format("SVD U-Cluster Charge for layers 4,5,6 sensors"));
222  m_clusterChargeU456 = new TH1F(name.c_str(), title.c_str(), ChargeBins, 0, ChargeMax);
223  m_clusterChargeU456->GetXaxis()->SetTitle("cluster charge [ke-]");
224  m_clusterChargeU456->GetYaxis()->SetTitle("count");
226
227  name = str(format("SVDDQM_ClusterChargeV456"));
228  title = str(format("SVD V-Cluster Charge for layers 4,5,6 sensors"));
229  m_clusterChargeV456 = new TH1F(name.c_str(), title.c_str(), ChargeBins, 0, ChargeMax);
230  m_clusterChargeV456->GetXaxis()->SetTitle("cluster charge [ke-]");
231  m_clusterChargeV456->GetYaxis()->SetTitle("count");
233
234  //----------------------------------------------------------------
235  // SNR of clusters for all sensors
236  //----------------------------------------------------------------
237  name = str(format("SVDDQM_ClusterSNRUAll"));
238  title = str(format("SVD U-Cluster SNR for all sensors"));
239  m_clusterSNRUAll = new TH1F(name.c_str(), title.c_str(), SNRBins, 0, SNRMax); // max = ~ 60
240  m_clusterSNRUAll->GetXaxis()->SetTitle("cluster SNR");
241  m_clusterSNRUAll->GetYaxis()->SetTitle("count");
243  name = str(format("SVDDQM_ClusterSNRVAll"));
244  title = str(format("SVD V-Cluster SNR for all sensors"));
245  m_clusterSNRVAll = new TH1F(name.c_str(), title.c_str(), SNRBins, 0, SNRMax);
246  m_clusterSNRVAll->GetXaxis()->SetTitle("cluster SNR");
247  m_clusterSNRVAll->GetYaxis()->SetTitle("count");
249  //----------------------------------------------------------------
250  // SNR of clusters for L3/L456 sensors
251  //----------------------------------------------------------------
252  name = str(format("SVDDQM_ClusterSNRU3"));
253  title = str(format("SVD U-Cluster SNR for layer 3 sensors"));
254  m_clusterSNRU3 = new TH1F(name.c_str(), title.c_str(), SNRBins, 0, SNRMax);
255  m_clusterSNRU3->GetXaxis()->SetTitle("cluster SNR");
256  m_clusterSNRU3->GetYaxis()->SetTitle("count");
258  name = str(format("SVDDQM_ClusterSNRV3"));
259  title = str(format("SVD V-Cluster SNR for layer 3 sensors"));
260  m_clusterSNRV3 = new TH1F(name.c_str(), title.c_str(), SNRBins, 0, SNRMax);
261  m_clusterSNRV3->GetXaxis()->SetTitle("cluster SNR");
262  m_clusterSNRV3->GetYaxis()->SetTitle("count");
264
265  name = str(format("SVDDQM_ClusterSNRU456"));
266  title = str(format("SVD U-Cluster SNR for layers 4,5,6 sensors"));
267  m_clusterSNRU456 = new TH1F(name.c_str(), title.c_str(), SNRBins, 0, SNRMax);
268  m_clusterSNRU456->GetXaxis()->SetTitle("cluster SNR");
269  m_clusterSNRU456->GetYaxis()->SetTitle("count");
271  name = str(format("SVDDQM_ClusterSNRV456"));
272  title = str(format("SVD V-Cluster SNR for layers 4,5,6 sensors"));
273  m_clusterSNRV456 = new TH1F(name.c_str(), title.c_str(), SNRBins, 0, SNRMax);
274  m_clusterSNRV456->GetXaxis()->SetTitle("cluster SNR");
275  m_clusterSNRV456->GetYaxis()->SetTitle("count");
277  //----------------------------------------------------------------
278  // Cluster time distribution for all sensors
279  //----------------------------------------------------------------
280  TString Name = "SVDDQM_ClusterTimeUAll";
281  TString Title = Form("SVD U-Cluster Time %s for all sensors", refFrame.Data());
282  m_clusterTimeUAll = new TH1F(Name.Data(), Title.Data(), TimeBins, TimeMin, TimeMax);
283  m_clusterTimeUAll->GetXaxis()->SetTitle("cluster time (ns)");
284  m_clusterTimeUAll->GetYaxis()->SetTitle("count");
286  Name = "SVDDQM_ClusterTimeVAll";
287  Title = Form("SVD V-Cluster Time %s for all sensors", refFrame.Data());
288  m_clusterTimeVAll = new TH1F(Name.Data(), Title.Data(), TimeBins, TimeMin, TimeMax);
289  m_clusterTimeVAll->GetXaxis()->SetTitle("cluster time (ns)");
290  m_clusterTimeVAll->GetYaxis()->SetTitle("count");
292  //----------------------------------------------------------------
293  // Time of clusters for L3/L456 sensors
294  //----------------------------------------------------------------
295  Name = "SVDDQM_ClusterTimeU3";
296  Title = Form("SVD U-Cluster Time %s for layer 3 sensors", refFrame.Data());
297  m_clusterTimeU3 = new TH1F(Name.Data(), Title.Data(), TimeBins, TimeMin, TimeMax);
298  m_clusterTimeU3->GetXaxis()->SetTitle("cluster time (ns)");
299  m_clusterTimeU3->GetYaxis()->SetTitle("count");
301  name = str(format("SVDDQM_ClusterTimeV3"));
302  Title = Form("SVD V-Cluster Time %s for layer 3 sensors", refFrame.Data());
303  m_clusterTimeV3 = new TH1F(name.c_str(), Title.Data(), TimeBins, TimeMin, TimeMax);
304  m_clusterTimeV3->GetXaxis()->SetTitle("cluster time (ns)");
305  m_clusterTimeV3->GetYaxis()->SetTitle("count");
307
308  name = str(format("SVDDQM_ClusterTimeU456"));
309  Title = Form("SVD U-Cluster Time %s for layers 4,5,6 sensors", refFrame.Data());
310  m_clusterTimeU456 = new TH1F(name.c_str(), Title.Data(), TimeBins, TimeMin, TimeMax);
311  m_clusterTimeU456->GetXaxis()->SetTitle("cluster time (ns)");
312  m_clusterTimeU456->GetYaxis()->SetTitle("count");
314  name = str(format("SVDDQM_ClusterTimeV456"));
315  Title = Form("SVD V-Cluster Time %s for layers 4,5,6 sensors", refFrame.Data());
316  m_clusterTimeV456 = new TH1F(name.c_str(), Title.Data(), TimeBins, TimeMin, TimeMax);
317  m_clusterTimeV456->GetXaxis()->SetTitle("cluster time (ns)");
318  m_clusterTimeV456->GetYaxis()->SetTitle("count");
320
321  //----------------------------------------------------------------
322  // MaxBin of strips for all sensors (offline ZS)
323  //----------------------------------------------------------------
324  name = str(format("SVDDQM_StripMaxBinUAll"));
325  title = str(format("SVD U-Strip MaxBin for all sensors"));
326  m_stripMaxBinUAll = new TH1F(name.c_str(), title.c_str(), MaxBinBins, 0, MaxBinMax);
327  m_stripMaxBinUAll->GetXaxis()->SetTitle("max bin");
328  m_stripMaxBinUAll->GetYaxis()->SetTitle("count");
330  name = str(format("SVDDQM_StripMaxBinVAll"));
331  title = str(format("SVD V-Strip MaxBin for all sensors"));
332  m_stripMaxBinVAll = new TH1F(name.c_str(), title.c_str(), MaxBinBins, 0, MaxBinMax);
333  m_stripMaxBinVAll->GetXaxis()->SetTitle("max bin");
334  m_stripMaxBinVAll->GetYaxis()->SetTitle("count");
336
337  name = str(format("SVDDQM_StripMaxBinU3"));
338  title = str(format("SVD U-Strip MaxBin for layer 3 sensors"));
339  m_stripMaxBinU3 = new TH1F(name.c_str(), title.c_str(), MaxBinBins, 0, MaxBinMax);
340  m_stripMaxBinU3->GetXaxis()->SetTitle("max bin");
341  m_stripMaxBinU3->GetYaxis()->SetTitle("count");
343  name = str(format("SVDDQM_StripMaxBinV3"));
344  title = str(format("SVD V-Strip MaxBin for layer 3 sensors"));
345  m_stripMaxBinV3 = new TH1F(name.c_str(), title.c_str(), MaxBinBins, 0, MaxBinMax);
346  m_stripMaxBinV3->GetXaxis()->SetTitle("max bin");
347  m_stripMaxBinV3->GetYaxis()->SetTitle("count");
349
350  name = str(format("SVDDQM_StripMaxBinU6"));
351  title = str(format("SVD U-Strip MaxBin for layer 6 sensors"));
352  m_stripMaxBinU6 = new TH1F(name.c_str(), title.c_str(), MaxBinBins, 0, MaxBinMax);
353  m_stripMaxBinU6->GetXaxis()->SetTitle("max bin");
354  m_stripMaxBinU6->GetYaxis()->SetTitle("count");
356  name = str(format("SVDDQM_StripMaxBinV6"));
357  title = str(format("SVD V-Strip MaxBin for layer 6 sensors"));
358  m_stripMaxBinV6 = new TH1F(name.c_str(), title.c_str(), MaxBinBins, 0, MaxBinMax);
359  m_stripMaxBinV6->GetXaxis()->SetTitle("max bin");
360  m_stripMaxBinV6->GetYaxis()->SetTitle("count");
362
363  for (int i = 0; i < nSVDSensors; i++) {
364  VxdID id = gTools->getSensorIDFromSVDIndex(i);
365  int iLayer = id.getLayerNumber();
366  int iLadder = id.getLadderNumber();
367  int iSensor = id.getSensorNumber();
368  VxdID sensorID(iLayer, iLadder, iSensor);
369  SVD::SensorInfo SensorInfo = dynamic_cast<const SVD::SensorInfo&>(VXD::GeoCache::get(sensorID));
370  string sensorDescr = str(format("%1%_%2%_%3%") % iLayer % iLadder % iSensor);
371  //----------------------------------------------------------------
372  // Number of fired strips per sensor
373  //----------------------------------------------------------------
374  name = str(format("SVDDQM_%1%_FiredU") % sensorDescr);
375  title = str(format("SVD Sensor %1% Number of Fired U-Strips") % sensorDescr);
376  m_firedU[i] = new TH1F(name.c_str(), title.c_str(), 50, 0, 50);
377  m_firedU[i]->GetXaxis()->SetTitle("# fired strips");
378  m_firedU[i]->GetYaxis()->SetTitle("count");
379  m_histoList->Add(m_firedU[i]);
380  name = str(format("SVDDQM_%1%_FiredV") % sensorDescr);
381  title = str(format("SVD Sensor %1% Number of Fired V-Strips") % sensorDescr);
382  m_firedV[i] = new TH1F(name.c_str(), title.c_str(), 50, 0, 50);
383  m_firedV[i]->GetXaxis()->SetTitle("# fired strips");
384  m_firedV[i]->GetYaxis()->SetTitle("count");
385  m_histoList->Add(m_firedV[i]);
386  //----------------------------------------------------------------
387  // Number of clusters per sensor
388  //----------------------------------------------------------------
389  name = str(format("SVDDQM_%1%_ClustersU") % sensorDescr);
390  title = str(format("SVD Sensor %1% Number of U-Clusters") % sensorDescr);
391  m_clustersU[i] = new TH1F(name.c_str(), title.c_str(), 20, 0, 20);
392  m_clustersU[i]->GetXaxis()->SetTitle("# clusters");
393  m_clustersU[i]->GetYaxis()->SetTitle("count");
394  m_histoList->Add(m_clustersU[i]);
395  name = str(format("SVDDQM_%1%_ClustersV") % sensorDescr);
396  title = str(format("SVD Sensor %1% Number of V-Clusters") % sensorDescr);
397  m_clustersV[i] = new TH1F(name.c_str(), title.c_str(), 20, 0, 20);
398  m_clustersV[i]->GetXaxis()->SetTitle("# clusters");
399  m_clustersV[i]->GetYaxis()->SetTitle("count");
400  m_histoList->Add(m_clustersV[i]);
401  //----------------------------------------------------------------
402  // Charge of clusters
403  //----------------------------------------------------------------
404  name = str(format("SVDDQM_%1%_ClusterChargeU") % sensorDescr);
405  title = str(format("SVD Sensor %1% U-Cluster Charge") % sensorDescr);
406  m_clusterChargeU[i] = new TH1F(name.c_str(), title.c_str(), ChargeBins, 0, ChargeMax);
407  m_clusterChargeU[i]->GetXaxis()->SetTitle("cluster charge [ke-]");
408  m_clusterChargeU[i]->GetYaxis()->SetTitle("count");
409  m_histoList->Add(m_clusterChargeU[i]);
410  name = str(format("SVDDQM_%1%_ClusterChargeV") % sensorDescr);
411  title = str(format("SVD Sensor %1% V-Cluster Charge") % sensorDescr);
412  m_clusterChargeV[i] = new TH1F(name.c_str(), title.c_str(), ChargeBins, 0, ChargeMax);
413  m_clusterChargeV[i]->GetXaxis()->SetTitle("cluster charge [ke-]");
414  m_clusterChargeV[i]->GetYaxis()->SetTitle("count");
415  m_histoList->Add(m_clusterChargeV[i]);
416  //----------------------------------------------------------------
417  // SNR of clusters
418  //----------------------------------------------------------------
419  name = str(format("SVDDQM_%1%_ClusterSNRU") % sensorDescr);
420  title = str(format("SVD Sensor %1% U-Cluster SNR") % sensorDescr);
421  m_clusterSNRU[i] = new TH1F(name.c_str(), title.c_str(), SNRBins, 0, SNRMax);
422  m_clusterSNRU[i]->GetXaxis()->SetTitle("cluster SNR");
423  m_clusterSNRU[i]->GetYaxis()->SetTitle("count");
424  m_histoList->Add(m_clusterSNRU[i]);
425  name = str(format("SVDDQM_%1%_ClusterSNRV") % sensorDescr);
426  title = str(format("SVD Sensor %1% V-Cluster SNR") % sensorDescr);
427  m_clusterSNRV[i] = new TH1F(name.c_str(), title.c_str(), SNRBins, 0, SNRMax);
428  m_clusterSNRV[i]->GetXaxis()->SetTitle("cluster SNR");
429  m_clusterSNRV[i]->GetYaxis()->SetTitle("count");
430  m_histoList->Add(m_clusterSNRV[i]);
431  //----------------------------------------------------------------
432  // Charge of strips
433  //----------------------------------------------------------------
434  name = str(format("SVDDQM_%1%_ADCStripU") % sensorDescr);
435  title = str(format("SVD Sensor %1% U-Strip signal in ADC Counts, all 6 APV samples") % sensorDescr);
436  m_stripSignalU[i] = new TH1F(name.c_str(), title.c_str(), 256, -0.5, 255.5);
437  m_stripSignalU[i]->GetXaxis()->SetTitle("signal ADC");
438  m_stripSignalU[i]->GetYaxis()->SetTitle("count");
439  m_histoList->Add(m_stripSignalU[i]);
440  name = str(format("SVDDQM_%1%_ADCStripV") % sensorDescr);
441  title = str(format("SVD Sensor %1% V-Strip signal in ADC Counts, all 6 APV samples") % sensorDescr);
442  m_stripSignalV[i] = new TH1F(name.c_str(), title.c_str(), 256, -0.5, 255.5);
443  m_stripSignalV[i]->GetXaxis()->SetTitle("signal ADC");
444  m_stripSignalV[i]->GetYaxis()->SetTitle("count");
445  m_histoList->Add(m_stripSignalV[i]);
446  //----------------------------------------------------------------
447  // Strips Counts
448  //----------------------------------------------------------------
449  name = str(format("SVDDQM_%1%_StripCountU") % sensorDescr);
450  title = str(format("SVD Sensor %1% Integrated Number of ZS5 Fired U-Strip vs Strip Number") % sensorDescr);
451  m_stripCountU[i] = new TH1F(name.c_str(), title.c_str(), 768, -0.5, 767.5);
452  m_stripCountU[i]->GetXaxis()->SetTitle("cellID");
453  m_stripCountU[i]->GetYaxis()->SetTitle("count");
454  m_histoList->Add(m_stripCountU[i]);
455  name = str(format("SVDDQM_%1%_StripCountV") % sensorDescr);
456  title = str(format("SVD Sensor %1% Integrated Number of ZS5 Fired V-Strip vs Strip Number") % sensorDescr);
457  m_stripCountV[i] = new TH1F(name.c_str(), title.c_str(), 768, -0.5, 767.5);
458  m_stripCountV[i]->GetXaxis()->SetTitle("cellID");
459  m_stripCountV[i]->GetYaxis()->SetTitle("count");
460  m_histoList->Add(m_stripCountV[i]);
461  //----------------------------------------------------------------
462  // Strips Counts with online ZS
463  //----------------------------------------------------------------
464  name = str(format("SVDDQM_%1%_OnlineZSStripCountU") % sensorDescr);
465  title = str(format("SVD Sensor %1% Integrated Number of online-ZS Fired U-Strip vs Strip Number") % sensorDescr);
466  m_onlineZSstripCountU[i] = new TH1F(name.c_str(), title.c_str(), 768, -0.5, 767.5);
467  m_onlineZSstripCountU[i]->GetXaxis()->SetTitle("cellID");
468  m_onlineZSstripCountU[i]->GetYaxis()->SetTitle("count");
470  name = str(format("SVDDQM_%1%_OnlineZSStripCountV") % sensorDescr);
471  title = str(format("SVD Sensor %1% Integrated Number of online-ZS Fired V-Strip vs Strip Number") % sensorDescr);
472  m_onlineZSstripCountV[i] = new TH1F(name.c_str(), title.c_str(), 768, -0.5, 767.5);
473  m_onlineZSstripCountV[i]->GetXaxis()->SetTitle("cellID");
474  m_onlineZSstripCountV[i]->GetYaxis()->SetTitle("count");
476  //----------------------------------------------------------------
477  // Cluster size distribution
478  //----------------------------------------------------------------
479  name = str(format("SVDDQM_%1%_ClusterSizeU") % sensorDescr);
480  title = str(format("SVD Sensor %1% U-Cluster Size") % sensorDescr);
481  m_clusterSizeU[i] = new TH1F(name.c_str(), title.c_str(), 9, 1, 10);
482  m_clusterSizeU[i]->GetXaxis()->SetTitle("cluster size");
483  m_clusterSizeU[i]->GetYaxis()->SetTitle("count");
484  m_histoList->Add(m_clusterSizeU[i]);
485  name = str(format("SVDDQM_%1%_ClusterSizeV") % sensorDescr);
486  title = str(format("SVD Sensor %1% V-Cluster Size") % sensorDescr);
487  m_clusterSizeV[i] = new TH1F(name.c_str(), title.c_str(), 9, 1, 10);
488  m_clusterSizeV[i]->GetXaxis()->SetTitle("cluster size");
489  m_clusterSizeV[i]->GetYaxis()->SetTitle("count");
490  m_histoList->Add(m_clusterSizeV[i]);
491  //----------------------------------------------------------------
492  // Cluster time distribution
493  //----------------------------------------------------------------
494  name = str(format("SVDDQM_%1%_ClusterTimeU") % sensorDescr);
495  Title = Form("SVD Sensor %s U-Cluster Time %s", sensorDescr.c_str(), refFrame.Data());
496  m_clusterTimeU[i] = new TH1F(name.c_str(), Title.Data(), TimeBins, TimeMin, TimeMax);
497  m_clusterTimeU[i]->GetXaxis()->SetTitle("cluster time (ns)");
498  m_clusterTimeU[i]->GetYaxis()->SetTitle("count");
499  m_histoList->Add(m_clusterTimeU[i]);
500  name = str(format("SVDDQM_%1%_ClusterTimeV") % sensorDescr);
501  Title = Form("SVD Sensor %s V-Cluster Time %s", sensorDescr.c_str(), refFrame.Data());
502  m_clusterTimeV[i] = new TH1F(name.c_str(), Title.Data(), TimeBins, TimeMin, TimeMax);
503  m_clusterTimeV[i]->GetXaxis()->SetTitle("cluster time (ns)");
504  m_clusterTimeV[i]->GetYaxis()->SetTitle("count");
505  m_histoList->Add(m_clusterTimeV[i]);
506  }
507
508  for (int i = 0; i < nSVDChips; i++) {
509  VxdID id = gTools->getChipIDFromSVDIndex(i);
510  int iLayer = id.getLayerNumber();
511  int iLadder = id.getLadderNumber();
512  int iSensor = id.getSensorNumber();
513  int iChip = gTools->getSVDChipNumber(id);
514  int IsU = gTools->isSVDSideU(id);
515  TString AxisTicks = Form("%i_%i_%i_u%i", iLayer, iLadder, iSensor, iChip);
516  if (!IsU)
517  AxisTicks = Form("%i_%i_%i_v%i", iLayer, iLadder, iSensor, iChip);
518  m_hitMapCountsChip->GetXaxis()->SetBinLabel(i + 1, AxisTicks.Data());
519  m_hitMapClCountsChip->GetXaxis()->SetBinLabel(i + 1, AxisTicks.Data());
520  }
521
522
523
524  //----------------------------------------------------------------
525  // Additional histograms for out of ExpressReco
526  //----------------------------------------------------------------
527
528  if (m_ShowAllHistos == 1) {
529  TDirectory* dirShowAll = NULL;
530  dirShowAll = oldDir->mkdir("SVDDQMAll");
531  dirShowAll->cd();
532
533  m_hitMapU = new TH2F*[nSVDSensors];
534  m_hitMapV = new TH2F*[nSVDSensors];
535  m_hitMapUCl = new TH1F*[nSVDSensors];
536  m_hitMapVCl = new TH1F*[nSVDSensors];
537  for (int i = 0; i < nSVDSensors; i++) {
538  VxdID id = gTools->getSensorIDFromSVDIndex(i);
539  int iLayer = id.getLayerNumber();
540  int iLadder = id.getLadderNumber();
541  int iSensor = id.getSensorNumber();
542  VxdID sensorID(iLayer, iLadder, iSensor);
543  SVD::SensorInfo SensorInfo = dynamic_cast<const SVD::SensorInfo&>(VXD::GeoCache::get(sensorID));
544  string sensorDescr = str(format("%1%_%2%_%3%") % iLayer % iLadder % iSensor);
545  //----------------------------------------------------------------
546  // Hitmaps: Number of strips by coordinate
547  //----------------------------------------------------------------
548  name = str(format("SVD_%1%_StripHitmapU") % sensorDescr);
549  title = str(format("SVD Sensor %1% Strip Hitmap in U") % sensorDescr);
550  int nStrips = SensorInfo.getUCells();
551  m_hitMapU[i] = new TH2F(name.c_str(), title.c_str(), nStrips, 0, nStrips, SVDShaperDigit::c_nAPVSamples, 0,
553  m_hitMapU[i]->GetXaxis()->SetTitle("u position [pitch units]");
554  m_hitMapU[i]->GetYaxis()->SetTitle("timebin [time units]");
555  m_hitMapU[i]->GetZaxis()->SetTitle("hits");
556  m_histoList->Add(m_hitMapU[i]);
557  name = str(format("SVD_%1%_StripHitmapV") % sensorDescr);
558  title = str(format("SVD Sensor %1% Strip Hitmap in V") % sensorDescr);
559  nStrips = SensorInfo.getVCells();
560  m_hitMapV[i] = new TH2F(name.c_str(), title.c_str(), nStrips, 0, nStrips, SVDShaperDigit::c_nAPVSamples, 0,
562  m_hitMapV[i]->GetXaxis()->SetTitle("v position [pitch units]");
563  m_hitMapV[i]->GetYaxis()->SetTitle("timebin [time units]");
564  m_hitMapV[i]->GetZaxis()->SetTitle("hits");
565  m_histoList->Add(m_hitMapV[i]);
566  //----------------------------------------------------------------
567  // Hitmaps: Number of clusters by coordinate
568  //----------------------------------------------------------------
569  name = str(format("SVD_%1%_HitmapClstU") % sensorDescr);
570  title = str(format("SVD Sensor %1% Hitmap Clusters in U") % sensorDescr);
571  nStrips = SensorInfo.getUCells();
572  m_hitMapUCl[i] = new TH1F(name.c_str(), title.c_str(), nStrips, 0, nStrips);
573  m_hitMapUCl[i]->GetXaxis()->SetTitle("u position [pitch units]");
574  m_hitMapUCl[i]->GetYaxis()->SetTitle("hits");
575  m_histoList->Add(m_hitMapUCl[i]);
576  name = str(format("SVD_%1%_HitmapClstV") % sensorDescr);
577  title = str(format("SVD Sensor %1% Hitmap Clusters in V") % sensorDescr);
578  nStrips = SensorInfo.getVCells();
579  m_hitMapVCl[i] = new TH1F(name.c_str(), title.c_str(), nStrips, 0, nStrips);
580  m_hitMapVCl[i]->GetXaxis()->SetTitle("v position [pitch units]");
581  m_hitMapVCl[i]->GetYaxis()->SetTitle("hits");
582  m_histoList->Add(m_hitMapVCl[i]);
583  }
584  }
585
586  oldDir->cd();
587 }

◆ evalCondition()

bool evalCondition ( ) const
inherited

If at least one condition was set, it is evaluated and true returned if at least one condition returns true.

If no condition or result value was defined, the method returns false. Otherwise, the condition is evaluated and true returned, if at least one condition returns true. To speed up the evaluation, the condition strings were already parsed in the method if_value().

Returns
True if at least one condition and return value exists and at least one condition expression was evaluated to true.

Definition at line 98 of file Module.cc.

◆ getAfterConditionPath()

Module::EAfterConditionPath getAfterConditionPath ( ) const
inherited

What to do after the conditional path is finished.

(defaults to c_End if no condition is set)

Definition at line 135 of file Module.cc.

◆ getConditionPath()

std::shared_ptr< Path > getConditionPath ( ) const
inherited

Returns the path of the last true condition (if there is at least one, else reaturn a null pointer).


Definition at line 115 of file Module.cc.

◆ getFileNames()

virtual std::vector<std::string> getFileNames ( __attribute__((unused)) bool  outputFiles)
inlinevirtualinherited

Return a list of output filenames for this modules.

This will be called when basf2 is run with "--dry-run" if the module has set either the c_Input or c_Output properties.

If the parameter outputFiles is false (for modules with c_Input) the list of input filenames should be returned (if any). If outputFiles is true (for modules with c_Output) the list of output files should be returned (if any).

If a module has sat both properties this member is called twice, once for each property.

The module should return the actual list of requested input or produced output filenames (including handling of input/output overrides) so that the grid system can handle input/output files correctly.

This function should return the same value when called multiple times. This is especially important when taking the input/output overrides from Environment as they get consumed when obtained so the finalized list of output files should be stored for subsequent calls.

Definition at line 136 of file Module.h.

◆ getName()

const std::string& getName ( ) const
inlineinherited

Returns the name of the module.

This can be changed via e.g. set_name() in the steering file to give more useful names if there is more than one module of the same type.

For identifying the type of a module, using getType() (or type() in Python) is recommended.

Definition at line 189 of file Module.h.

◆ getParamInfoListPython()

std::shared_ptr< boost::python::list > getParamInfoListPython ( ) const
inherited

Returns a python list of all parameters.

Each item in the list consists of the name of the parameter, a string describing its type, a python list of all default values and the description of the parameter.

Returns
A python list containing the parameters of this parameter list.

Definition at line 281 of file Module.cc.

◆ getReturnValue()

int getReturnValue ( ) const
inlineinherited

Return the return value set by this module.

This value is only meaningful if hasReturnValue() is true

Definition at line 383 of file Module.h.

◆ getType()

const std::string & getType ( ) const
inherited

Returns the type of the module (i.e.

class name minus 'Module')

Definition at line 43 of file Module.cc.

◆ hasProperties()

bool hasProperties ( unsigned int  propertyFlags) const
inherited

Returns true if all specified property flags are available in this module.

Parameters
propertyFlagsOred EModulePropFlags which should be compared with the module flags.

Definition at line 162 of file Module.cc.

◆ if_false()

void if_false ( const std::shared_ptr< Path > &  path,
EAfterConditionPath  afterConditionPath = EAfterConditionPath::c_End
)
inherited

A simplified version to add a condition to the module.

Please note that successive calls of this function will add more than one condition to the module. If more than one condition results in true, only the last of them will be used.

Please be careful: Avoid creating cyclic paths, e.g. by linking a condition to a path which is processed before the path where this module is located in.

It is equivalent to the if_value() method, using the expression "<1". This method is meant to be used together with the setReturnValue(bool value) method.

Parameters
pathShared pointer to the Path which will be executed if the return value is false.
afterConditionPathWhat to do after executing 'path'.

Definition at line 87 of file Module.cc.

◆ if_true()

void if_true ( const std::shared_ptr< Path > &  path,
EAfterConditionPath  afterConditionPath = EAfterConditionPath::c_End
)
inherited

A simplified version to set the condition of the module.

Please note that successive calls of this function will add more than one condition to the module. If more than one condition results in true, only the last of them will be used.

Please be careful: Avoid creating cyclic paths, e.g. by linking a condition to a path which is processed before the path where this module is located in.

It is equivalent to the if_value() method, using the expression ">=1". This method is meant to be used together with the setReturnValue(bool value) method.

Parameters
pathShared pointer to the Path which will be executed if the return value is true.
afterConditionPathWhat to do after executing 'path'.

Definition at line 92 of file Module.cc.

◆ if_value()

void if_value ( const std::string &  expression,
const std::shared_ptr< Path > &  path,
EAfterConditionPath  afterConditionPath = EAfterConditionPath::c_End
)
inherited

Add a condition to the module.

Please note that successive calls of this function will add more than one condition to the module. If more than one condition results in true, only the last of them will be used.

See https://confluence.desy.de/display/BI/Software+ModCondTut or ModuleCondition for a description of the syntax.

Please be careful: Avoid creating cyclic paths, e.g. by linking a condition to a path which is processed before the path where this module is located in.

Parameters
expressionThe expression of the condition.
pathShared pointer to the Path which will be executed if the condition is evaluated to true.
afterConditionPathWhat to do after executing 'path'.

Definition at line 81 of file Module.cc.

◆ setDescription()

void setDescription ( const std::string &  description)
protectedinherited

Sets the description of the module.

Parameters
descriptionA description of the module.

Definition at line 216 of file Module.cc.

◆ setLogInfo()

void setLogInfo ( int  logLevel,
unsigned int  logInfo
)
inherited

Configure the printed log information for the given level.

Parameters
logLevelThe log level (one of LogConfig::ELogLevel)
logInfoWhat kind of info should be printed? ORed combination of LogConfig::ELogInfo flags.

Definition at line 75 of file Module.cc.

◆ setName()

void setName ( const std::string &  name)
inlineinherited

Set the name of the module.

Note
The module name is set when using the REG_MODULE macro, but the module can be renamed before calling process() using the set_name() function in your steering file.
Parameters
nameThe name of the module

Definition at line 216 of file Module.h.

◆ setParamPython()

void setParamPython ( const std::string &  name,
const boost::python::object &  pyObj
)
privateinherited

Implements a method for setting boost::python objects.

The method supports the following types: list, dict, int, double, string, bool The conversion of the python object to the C++ type and the final storage of the parameter value is done in the ModuleParam class.

Parameters
nameThe unique name of the parameter.
pyObjThe object which should be converted and stored as the parameter value.

Definition at line 236 of file Module.cc.

◆ setParamPythonDict()

void setParamPythonDict ( const boost::python::dict &  dictionary)
privateinherited

Implements a method for reading the parameter values from a boost::python dictionary.

The key of the dictionary has to be the name of the parameter and the value has to be of one of the supported parameter types.

Parameters
dictionaryThe python dictionary from which the parameter values are read.

Definition at line 251 of file Module.cc.

◆ setPropertyFlags()

void setPropertyFlags ( unsigned int  propertyFlags)
inherited

Sets the flags for the module properties.

Parameters
propertyFlagsbitwise OR of EModulePropFlags

Definition at line 210 of file Module.cc.

◆ setReturnValue() [1/2]

void setReturnValue ( bool  value)
protectedinherited

Sets the return value for this module as bool.

The bool value is saved as an integer with the convention 1 meaning true and 0 meaning false. The value can be used in the steering file to divide the analysis chain into several paths.

Parameters
valueThe value of the return value.

Definition at line 229 of file Module.cc.

◆ setReturnValue() [2/2]

void setReturnValue ( int  value)
protectedinherited

Sets the return value for this module as integer.

The value can be used in the steering file to divide the analysis chain into several paths.

Parameters
valueThe value of the return value.

Definition at line 222 of file Module.cc.

◆ setType()

void setType ( const std::string &  type)
protectedinherited

Set the module type.

Only for use by internal modules (which don't use the normal REG_MODULE mechanism).

Definition at line 50 of file Module.cc.


The documentation for this class was generated from the following files:
Belle2::VXD::SensorInfoBase::getUCells
int getUCells() const
Return number of pixel/strips in u direction.
Definition: SensorInfoBase.h:223
Belle2::SVDDQMExpressRecoModule::m_clusterSNRUAll
TH1F * m_clusterSNRUAll
u SNR of clusters for all sensors
Definition: SVDDQMExpressRecoModule.h:155
Belle2::SVDDQMExpressRecoModule::m_hitMapCountsChip
TH1F * m_hitMapCountsChip
Hitmaps of digits on chips.
Definition: SVDDQMExpressRecoModule.h:121
Belle2::SVDDQMExpressRecoModule::m_firedU
TH1F ** m_firedU
Fired u strips per event.
Definition: SVDDQMExpressRecoModule.h:125
Belle2::SVDDQMExpressRecoModule::m_onlineZSstripCountU
TH1F ** m_onlineZSstripCountU
u strip count (online Zero Suppression)
Definition: SVDDQMExpressRecoModule.h:189
Belle2::VxdID
Class to uniquely identify a any structure of the PXD and SVD.
Definition: VxdID.h:43
Belle2::SVDDQMExpressRecoModule::m_clusterSNRV
TH1F ** m_clusterSNRV
v SNR of clusters per sensor
Definition: SVDDQMExpressRecoModule.h:153
Belle2::SVDDQMExpressRecoModule::m_histoList
TList * m_histoList
list of cumulative histograms
Definition: SVDDQMExpressRecoModule.h:83
Belle2::SVDDQMExpressRecoModule::m_clusterSizeV
TH1F ** m_clusterSizeV
v size
Definition: SVDDQMExpressRecoModule.h:195
Belle2::VXD::GeoCache::get
static const SensorInfoBase & get(Belle2::VxdID id)
Return a reference to the SensorInfo of a given SensorID.
Definition: GeoCache.h:141
Belle2::SVDDQMExpressRecoModule::m_hitMapClCountsU
TH1F * m_hitMapClCountsU
Hitmaps u of Clusters.
Definition: SVDDQMExpressRecoModule.h:117
Belle2::SVDDQMExpressRecoModule::m_clusterSNRU3
TH1F * m_clusterSNRU3
u SNR of clusters for layer 3 sensors
Definition: SVDDQMExpressRecoModule.h:159
Belle2::SVDDQMExpressRecoModule::m_clusterTimeV456
TH1F * m_clusterTimeV456
v Time of clusters for layer 4,5,6 sensors
Definition: SVDDQMExpressRecoModule.h:212
Belle2::SVDDQMExpressRecoModule::m_clusterSNRV456
TH1F * m_clusterSNRV456
v SNR of clusters for layer 4,5,6 sensors
Definition: SVDDQMExpressRecoModule.h:165
Belle2::SVDDQMExpressRecoModule::m_clusterTimeU
TH1F ** m_clusterTimeU
u time
Definition: SVDDQMExpressRecoModule.h:198
Belle2::SVDDQMExpressRecoModule::m_stripMaxBinVAll
TH1F * m_stripMaxBinVAll
v MaxBin of strips for all sensors (offline Zero Suppression)
Definition: SVDDQMExpressRecoModule.h:170
Belle2::SVD::SensorInfo
Specific implementation of SensorInfo for SVD Sensors which provides additional sensor specific infor...
Definition: SensorInfo.h:35
Belle2::SVDDQMExpressRecoModule::m_stripCountU
TH1F ** m_stripCountU
u strip count
Definition: SVDDQMExpressRecoModule.h:185
Belle2::SVDDQMExpressRecoModule::m_clusterTimeUAll
TH1F * m_clusterTimeUAll
u time of clusters for all sensors
Definition: SVDDQMExpressRecoModule.h:202
Belle2::SVDDQMExpressRecoModule::m_stripMaxBinUAll
TH1F * m_stripMaxBinUAll
u MaxBin of strips for all sensors (offline Zero Suppression)
Definition: SVDDQMExpressRecoModule.h:168
Belle2::SVDDQMExpressRecoModule::m_clusterSNRU456
TH1F * m_clusterSNRU456
u SNR of clusters for layer 4,5,6 sensors
Definition: SVDDQMExpressRecoModule.h:163
Belle2::SVDDQMExpressRecoModule::m_desynchSVDTime
bool m_desynchSVDTime
if TRUE: svdTime back in SVD time reference
Definition: SVDDQMExpressRecoModule.h:75
Belle2::SVDDQMExpressRecoModule::m_clustersU
TH1F ** m_clustersU
number of u clusters per event
Definition: SVDDQMExpressRecoModule.h:129
Belle2::SVDDQMExpressRecoModule::m_stripMaxBinU6
TH1F * m_stripMaxBinU6
u MaxBin of strips for layer 6 sensors (offline Zero Suppression)
Definition: SVDDQMExpressRecoModule.h:176
Belle2::SVDDQMExpressRecoModule::m_hitMapU
TH2F ** m_hitMapU
Hitmaps pixels for u.
Definition: SVDDQMExpressRecoModule.h:219
Belle2::SVDDQMExpressRecoModule::m_onlineZSstripCountV
TH1F ** m_onlineZSstripCountV
v strip count (online Zero Suppression
Definition: SVDDQMExpressRecoModule.h:191
Belle2::SVDDQMExpressRecoModule::m_clustersV
TH1F ** m_clustersV
number of v clusters per event
Definition: SVDDQMExpressRecoModule.h:131
Belle2::SVDDQMExpressRecoModule::m_firedV
TH1F ** m_firedV
Fired v strips per event.
Definition: SVDDQMExpressRecoModule.h:127
Belle2::SVDDQMExpressRecoModule::m_clusterTimeU456
TH1F * m_clusterTimeU456
u Time of clusters for layer 4,5,6 sensors
Definition: SVDDQMExpressRecoModule.h:210
Belle2::SVDDQMExpressRecoModule::m_stripSignalV
TH1F ** m_stripSignalV
v charge of strips
Definition: SVDDQMExpressRecoModule.h:183
Belle2::PXD::SensorInfo
Specific implementation of SensorInfo for PXD Sensors which provides additional pixel specific inform...
Definition: SensorInfo.h:34
Belle2::SVDDQMExpressRecoModule::m_clusterChargeV
TH1F ** m_clusterChargeV
v charge of clusters
Definition: SVDDQMExpressRecoModule.h:136
Belle2::VXD::GeoCache::getInstance
static GeoCache & getInstance()
Return a reference to the singleton instance.
Definition: GeoCache.cc:215
Belle2::SVDDQMExpressRecoModule::m_clusterTimeU3
TH1F * m_clusterTimeU3
u Time of clusters for layer 3 sensors
Definition: SVDDQMExpressRecoModule.h:206
Belle2::VXD::SensorInfoBase::getVCells
int getVCells() const
Return number of pixel/strips in v direction.
Definition: SensorInfoBase.h:225
Belle2::SVDDQMExpressRecoModule::m_stripSignalU
TH1F ** m_stripSignalU
u charge of strips
Definition: SVDDQMExpressRecoModule.h:181
Belle2::SVDDQMExpressRecoModule::m_hitMapClCountsChip
TH1F * m_hitMapClCountsChip
Hitmaps of clusters on chips.
Definition: SVDDQMExpressRecoModule.h:123
Belle2::SVDDQMExpressRecoModule::m_hitMapCountsU
TH1F * m_hitMapCountsU
Hitmaps u of Digits.
Definition: SVDDQMExpressRecoModule.h:113
Belle2::SVDDQMExpressRecoModule::m_stripCountV
TH1F ** m_stripCountV
v strip count
Definition: SVDDQMExpressRecoModule.h:187
Belle2::VXD::GeoCache::getGeoTools
const GeoTools * getGeoTools()
Return a raw pointer to a GeoTools object.
Definition: GeoCache.h:149
Belle2::SVDDQMExpressRecoModule::m_clusterSizeU
TH1F ** m_clusterSizeU
u size
Definition: SVDDQMExpressRecoModule.h:193
Belle2::SVDDQMExpressRecoModule::m_clusterChargeV3
TH1F * m_clusterChargeV3
v charge of clusters for layer 3 sensors
Definition: SVDDQMExpressRecoModule.h:144
Belle2::SVDDQMExpressRecoModule::m_histogramDirectoryName
std::string m_histogramDirectoryName
Name of the histogram directory in ROOT file.
Definition: SVDDQMExpressRecoModule.h:100
Belle2::SVDDQMExpressRecoModule::m_clusterChargeU
TH1F ** m_clusterChargeU
u charge of clusters
Definition: SVDDQMExpressRecoModule.h:134
Belle2::SVDDQMExpressRecoModule::m_clusterChargeV456
TH1F * m_clusterChargeV456
v charge of clusters for layer 4,5,6 sensors
Definition: SVDDQMExpressRecoModule.h:148
Belle2::SVDDQMExpressRecoModule::m_clusterChargeVAll
TH1F * m_clusterChargeVAll
v charge of clusters for all sensors
Definition: SVDDQMExpressRecoModule.h:140
Belle2::SVDDQMExpressRecoModule::m_clusterTimeV3
TH1F * m_clusterTimeV3
v Time of clusters for layer 3 sensors
Definition: SVDDQMExpressRecoModule.h:208
Belle2::SVDDQMExpressRecoModule::m_clusterChargeU3
TH1F * m_clusterChargeU3
u charge of clusters for layer 3 sensors
Definition: SVDDQMExpressRecoModule.h:142
Belle2::SVDDQMExpressRecoModule::m_hitMapVCl
TH1F ** m_hitMapVCl
Hitmaps clusters for v.
Definition: SVDDQMExpressRecoModule.h:225
Belle2::SVDDQMExpressRecoModule::m_hitMapClCountsV
TH1F * m_hitMapClCountsV
Hitmaps v of Clusters.
Definition: SVDDQMExpressRecoModule.h:119
Belle2::SVDDQMExpressRecoModule::m_hitMapV
TH2F ** m_hitMapV
Hitmaps pixels for v.
Definition: SVDDQMExpressRecoModule.h:221
Belle2::SVDDQMExpressRecoModule::m_stripMaxBinU3
TH1F * m_stripMaxBinU3
u MaxBin of strips for layer 3 sensors (offline Zero Suppression)
Definition: SVDDQMExpressRecoModule.h:172
Belle2::SVDDQMExpressRecoModule::m_clusterTimeVAll
TH1F * m_clusterTimeVAll
v time of clusters for all sensors
Definition: SVDDQMExpressRecoModule.h:204
Belle2::SVDDQMExpressRecoModule::m_hitMapUCl
TH1F ** m_hitMapUCl
Hitmaps clusters for u.
Definition: SVDDQMExpressRecoModule.h:223
Belle2::SVDDQMExpressRecoModule::m_ShowAllHistos
int m_ShowAllHistos
Flag to show all histos in DQM, default = 0 (do not show)
Definition: SVDDQMExpressRecoModule.h:91
Belle2::SVDDQMExpressRecoModule::m_clusterSNRVAll
TH1F * m_clusterSNRVAll
v SNR of clusters for all sensors
Definition: SVDDQMExpressRecoModule.h:157
Belle2::SVDDQMExpressRecoModule::m_hitMapCountsV
TH1F * m_hitMapCountsV
Hitmaps v of Digits.
Definition: SVDDQMExpressRecoModule.h:115
Belle2::SVDDQMExpressRecoModule::m_stripMaxBinV3
TH1F * m_stripMaxBinV3
v MaxBin of strips for layer 3 sensors (offline Zero Suppression)
Definition: SVDDQMExpressRecoModule.h:174
Belle2::SVDShaperDigit::c_nAPVSamples
static const std::size_t c_nAPVSamples
Number of APV samples stored.
Definition: SVDShaperDigit.h:51
Belle2::SVDDQMExpressRecoModule::m_clusterChargeUAll
TH1F * m_clusterChargeUAll
u charge of clusters for all sensors
Definition: SVDDQMExpressRecoModule.h:138
Belle2::SVDDQMExpressRecoModule::m_nEvents
TH1F * m_nEvents
number of events
Definition: SVDDQMExpressRecoModule.h:110
Belle2::SVDDQMExpressRecoModule::m_clusterTimeV
TH1F ** m_clusterTimeV
v time
Definition: SVDDQMExpressRecoModule.h:200
Belle2::VxdID::getLayerNumber
baseType getLayerNumber() const
Get the layer id.
Definition: VxdID.h:106
Belle2::SVDDQMExpressRecoModule::m_stripMaxBinV6
TH1F * m_stripMaxBinV6
v MaxBin of strips for layer 6 sensors (offline Zero Suppression)
Definition: SVDDQMExpressRecoModule.h:178
Belle2::SVDDQMExpressRecoModule::m_clusterSNRU
TH1F ** m_clusterSNRU
u SNR of clusters per sensor
Definition: SVDDQMExpressRecoModule.h:151
Belle2::SVDDQMExpressRecoModule::m_clusterSNRV3
TH1F * m_clusterSNRV3
v SNR of clusters for layer 3 sensors
Definition: SVDDQMExpressRecoModule.h:161
Belle2::SVDDQMExpressRecoModule::m_clusterChargeU456
TH1F * m_clusterChargeU456
u charge of clusters for layer 4,5,6 sensors
Definition: SVDDQMExpressRecoModule.h:146
