SddCreator Class Reference

The creator for the SDD geometry. More...

#include <SddCreator.h>

Inheritance diagram for SddCreator:

Collaboration diagram for SddCreator:

Public Member Functions
	SddCreator ()
	Constructor.
virtual	~SddCreator ()
	Destructor.
virtual void	create (const GearDir &content, G4LogicalVolume &topVolume, geometry::GeometryTypes type)
	Creation of the detector geometry from Gearbox (XML). More...
	BELLE2_DEFINE_EXCEPTION (DBNotImplemented, "Cannot create geometry from Database.")
	Exception that will be thrown in createFromDB if member is not yet implemented by creator.
virtual void	createFromDB (const std::string &name, G4LogicalVolume &topVolume, GeometryTypes type)
	Function to create the geometry from the Database. More...
virtual void	createPayloads (const GearDir &content, const IntervalOfValidity &iov)
	Function to create the geometry database. More...

Protected Attributes
SensitiveDetector *	m_sensitive
	SensitiveDetector SDD.

Detailed Description

The creator for the SDD geometry.

Definition at line 27 of file SddCreator.h.

Member Function Documentation

create()

void create ( const GearDir &  content, G4LogicalVolume &  topVolume, geometry::GeometryTypes  type  )

virtual

Creation of the detector geometry from Gearbox (XML).

Parameters

[in]	content	XML data directory.
[in]	topVolume	Geant world volume.
[in]	type	Geometry type.

Implements CreatorBase.

Definition at line 55 of file SddCreator.cc.

    {

      m_sensitive = new SensitiveDetector();

      //lets get the stepsize parameter with a default value of 5 µm
      double stepSize = content.getLength("stepSize", 5 * CLHEP::um);

      //no get the array. Notice that the default framework unit is cm, so the
      //values will be automatically converted
      vector<double> bar_sdd = content.getArray("bar_sdd");
      B2INFO("Contents of bar_sdd: ");
      BOOST_FOREACH(double value, bar_sdd) {
        B2INFO("value: " << value);
      }
      int sddNb = 0;
      //Lets loop over all the Active nodes
      BOOST_FOREACH(const GearDir & activeParams, content.getNodes("Active")) {

        //create sdd volume
        G4double startAngle = 0.*CLHEP::deg;
        G4double spanningAngle = 360.*CLHEP::deg;
        G4Tubs* s_SDD = new G4Tubs("s_SDD",
                                   activeParams.getLength("sdd_innerRadius")*CLHEP::cm,
                                   activeParams.getLength("sdd_outerRadius")*CLHEP::cm,
                                   activeParams.getLength("sdd_hz")*CLHEP::cm,
                                   startAngle, spanningAngle);

        string matSDD = activeParams.getString("MaterialSDD");
        G4LogicalVolume* l_SDD = new G4LogicalVolume(s_SDD, geometry::Materials::get(matSDD), "l_SDD", 0, m_sensitive);

        //Lets limit the Geant4 stepsize inside the volume
        l_SDD->SetUserLimits(new G4UserLimits(stepSize));

        //position sdd volume
        G4ThreeVector SDDpos = G4ThreeVector(
                                 activeParams.getLength("x_sdd") * CLHEP::cm,
                                 activeParams.getLength("y_sdd") * CLHEP::cm,
                                 activeParams.getLength("z_sdd") * CLHEP::cm
                               );

        G4RotationMatrix* rot_sdd = new G4RotationMatrix();
        rot_sdd->rotateX(activeParams.getAngle("AngleX"));
        rot_sdd->rotateY(activeParams.getAngle("AngleY"));
        rot_sdd->rotateZ(activeParams.getAngle("AngleZ"));
        //geometry::setColor(*l_SDD, "#006699");

        new G4PVPlacement(rot_sdd, SDDpos, l_SDD, "p_SDD", &topVolume, false, sddNb);

        sddNb++;
      }
    }

createFromDB()

void createFromDB ( const std::string &  name, G4LogicalVolume &  topVolume, GeometryTypes  type  )

virtualinherited

Function to create the geometry from the Database.

Parameters

name	name of the component in the database, could be used to disambiguate multiple components created with the same creator
topVolume	Top volume in which the geometry has to be placed
type	Type of geometry to be build

Reimplemented in GeoVXDServiceCreator, GeoHeavyMetalShieldCreator, GeoTOPCreator, GeoSVDCreator, GeoSTRCreator, GeoServiceMaterialCreator, GeoCOILCreator, GeoPXDCreator, GeoKLMCreator, GeoEKLMCreator, GeoBKLMCreator, GeoFarBeamLineCreator, GeoCryostatCreator, GeoBeamPipeCreator, MyDBCreator, GeoECLCreator, GeoCDCCreator, GeoARICHCreator, and GeoMagneticField.

Definition at line 17 of file CreatorBase.cc.

createPayloads()

void createPayloads ( const GearDir &  content, const IntervalOfValidity &  iov  )

virtualinherited

Function to create the geometry database.

This function should be implemented to convert Gearbox parameters to one ore more database payloads

Parameters

content	GearDir pointing to the parameters which should be used for construction
iov	interval of validity to use when generating payloads

Reimplemented in GeoVXDServiceCreator, GeoHeavyMetalShieldCreator, GeoTOPCreator, GeoSVDCreator, GeoSTRCreator, GeoServiceMaterialCreator, GeoCOILCreator, GeoPXDCreator, GeoKLMCreator, GeoEKLMCreator, GeoBKLMCreator, GeoFarBeamLineCreator, GeoCryostatCreator, GeoBeamPipeCreator, MyDBCreator, GeoMagneticField, GeoECLCreator, GeoCDCCreator, and GeoARICHCreator.

Definition at line 24 of file CreatorBase.cc.

---

The documentation for this class was generated from the following files:

• beast/srsensor/geometry/include/SddCreator.h
• beast/srsensor/geometry/src/SddCreator.cc
