TRGCDCFitter3D Class Reference

A class to fit tracks in 3D. More...

#include <Fitter3D.h>

Collaboration diagram for TRGCDCFitter3D:

Public Member Functions
	TRGCDCFitter3D (const std::string &name, const std::string &rootFitter3DFile, const TRGCDC &, const std::map< std::string, bool > &flags)
	Constructor.
virtual	~TRGCDCFitter3D ()
	Destructor.
void	initialize ()
	Initialization.
void	terminate ()
	Termination.
int	doit (std::vector< TRGCDCTrack * > &trackList)
	Does track fitting.
int	doitComplex (std::vector< TRGCDCTrack * > &trackList)
	Does track fitting using JSignals.
bool	isAxialTrackFull (const TRGCDCTrack &aTrack)
	Checks if axial track has 5 TSs. One per each superlayer.
bool	isStereoTrackFull (const TRGCDCTrack &aTrack)
	Checks if stereo track has 4 TSs. One per each superlayer.
void	removeImpossibleStereoSuperlayers (std::vector< double > &useStSL)
	Removes TSs that are not possible with track Pt.
void	print3DInformation (int iTrack)
	Print's information for debugging 3D.
void	saveVhdlAndCoe ()
	Functions for saving. More...
void	saveAllSignals ()
	Saves all signals for debugging.
void	saveIoSignals ()
	Saves all I/O signals for debugging.
std::string	name (void) const
	Gets name of class.
std::string	version (void) const
	Gets version of class.

Static Public Member Functions
static double	calPhi (TRGCDCSegmentHit const *segmentHit, double eventTime)
	Utility functions.
static void	getMCValues (const TRGCDC &m_cdc_in, TRGCDCTrack *aTrack, const std::map< std::string, double > &m_mConstD_in, std::map< std::string, double > &m_mDouble_in, std::map< std::string, std::vector< double > > &m_mVector_in)
	Function for mc debugging.
static void	findHitAxialSuperlayers (const TRGCDCTrack &aTrack, std::vector< double > &useAxSL, bool printError)
	Finds which axial superlayers has TSs. useAxSL array indicating hit superlayers.
static void	findHitStereoSuperlayers (const TRGCDCTrack &aTrack, std::vector< double > &useStSL, bool printError)
	Finds which stereo superlayers has TSs. useStSL array indicating hit superlayers.
static void	selectAxialTSs (const TRGCDCTrack &aTrack, std::vector< int > &bestTSIndex)
	Selects priority TSs when there are multiple candidate TSs for a superlayer.
static int	do2DFit (TRGCDCTrack &aTrack, const std::map< std::string, bool > &m_mBool_in, const std::map< std::string, double > &m_mConstD_in, std::map< std::string, std::vector< double > > &m_mConstV_in, std::map< std::string, double > &m_mDouble_in, std::map< std::string, std::vector< double > > &m_mVector_in)
	Does 2D fit. Returns 0 if fit is done successfully. m_mBool should have fIsPrintError, fmcLR, fLRLUT, fmcLR, f2DFit, f2DFitDrift. m_mConstD should have Trg_PI. m_mConstV should have nWires, driftPhi2DError, wirePhi2DError, rr, rr2D.
static void	getStereoGeometry (std::map< std::string, std::vector< double > > &stGeometry)
	Get stereo geometry.
static void	getStereoXt (std::vector< double > const &stPriorityLayer, std::vector< std::vector< double > > &stXts, bool isSimple=0)
	Get stereo Xt.
static void	getConstants (std::map< std::string, double > &mConstD, std::map< std::string, std::vector< double > > &mConstV, bool isXtSimple=0)
	Get constants for firmwareFit.

Private Attributes
const std::string	m_name
	Name.
const TRGCDC &	m_cdc
	CDCTRG.
std::map< std::string, double >	m_mDouble
	Map to hold double values for Fitter3D.
std::map< std::string, std::vector< double > >	m_mVector
	Map to hold vector values for Fitter3D.
std::map< std::string, double >	m_mConstD
	Map to hold constant values for Fitter3D.
std::map< std::string, std::vector< double > >	m_mConstV
	Map to hold constant vectcors for Fitter3D.
std::map< std::string, bool >	m_mBool
	Map to hold input options.
std::map< std::string, TRGCDCJSignal >	m_mSignalStorage
	Map to hold JSignals.
std::map< std::string, TRGCDCJLUT * >	m_mLutStorage
	Map to hold JLuts.
TRGCDCJSignalData *	m_commonData
	For VHDL code.
std::string	m_rootFitter3DFileName
	Members for saving.
TFile *	m_fileFitter3D
	Tfile for Fitter3D root file.
TTree *	m_treeTrackFitter3D
	TTree for tracks of fitter3D.
TTree *	m_treeConstantsFitter3D
	TTree for constants of fitter3D.
std::map< std::string, TVectorD * >	m_mTVectorD
	TVectorD map for saving values to root file.
std::map< std::string, TClonesArray * >	m_mTClonesArray
	TClonesArray map for saving values to root file.
std::map< std::string, std::vector< signed long long > >	m_mSavedSignals
	Array of saved signals.
std::map< std::string, std::vector< signed long long > >	m_mSavedIoSignals
	Array of I/O signals.

Detailed Description

A class to fit tracks in 3D.

Definition at line 40 of file Fitter3D.h.

---

The documentation for this class was generated from the following files:

• trg/cdc/include/Fitter3D.h
• trg/cdc/src/Fitter3D.cc
