Collaboration diagram for tracking modules:

Classes
class	BeamSpotCollectorModule
	This collects the track parameters of the mu+mu- events for calibration of the BeamSpot using CAF and AirFlow. More...

class	BoostVectorCollectorModule
	This collects the track parameters and momenta of the mu+mu- events for calibration of the BoostVector using CAF and AirFlow. More...

class	CDCToSVDSpacePointCKFModule
	Combinatorical Kalman Filter used for extrapolating CDC tracks into SVD and create merged tracks. More...

class	CDCToSVDSeedCKFModule
	Seed-finding combinatorical Kalman Filter that combines every RecoTrack with every SVD track, then filters the combinations. More...

class	ToPXDCKFModule
	Combinatorical Kalman Filter that extrapolates every RecoTrack into the PXD and collects space points. More...

class	ToCDCCKFModule
	Combinatorical Kalman Filter that extrapolates every RecoTrack into the CDC and collects wire hits. More...

class	ToCDCFromEclCKFModule
	Combinatorical Kalman Filter that extrapolates every ECLShower into the CDC and collects wire hits. More...

class	CosmicsTrackMergerFindlet
	Links tracks based on a filter criterion. It is based on the TrackLinker in the TF_CDC package. More...

class	CosmicsTrackMergerModule
	Module linking tracks based on their Phi parameter. More...

class	PhiRecoTrackRelationFilter
	Relation filter that lets only possibilities with small phi distance pass. More...

class	DATCONHoughCand
	Hough Candidates class. More...

class	DATCONHoughSpaceClusterCand
	The Hough Space Cluster Candidate represents the candidates of clusters found in the Hough Space. More...

class	DATCONPXDExtrapolationModule
	The DATCONPXDExtrapolationModule does an extrapolation to the PXD and creates "Most Probable Hits" (MPH) on the PXD. More...

class	DATCONROICalculationModule
	The DATCONROICalculationModule calculates ROI from the DATCONMostProbableHit / PXDIntercepts calculated by the DATCONMPHCalculationModule and saves the ROI in a ROIid StoreArray. More...

struct	ClustersOnSensor
	small struct for storing all clusters of the same sensor in one container. More...

class	DATCONSVDSimpleClusterCandidate
	Class representing a cluster candidate for DATCON during simple clustering of the SVD. More...

class	DATCONSVDSimpleClusterizerModule
	DATCONSVDSimpleClusterizerModule: This class performs a simple clusterisation and noise filtering of SVD hits (DATCONSVDDigits in this case). More...

class	DATCONSVDSpacePointCreatorModule
	This module creates DATCONSVDSpacePoints from the DATCONSVDCluster. More...

class	DATCONTrackCand
	The DATCONTrackCand represents the candidates of tracks found by the DATCON algoritms for u-side and v-side SVD hits independently. More...

class	DATCONTrackingModule
	DATCONTrackingModule class. More...

class	SVDShaperDigitToDATCONSVDDigitConverterModule
	SVDShaperDigitToDATCONSVDDigitConverterModule: More...

class	DriftLengthBasedT0ExtractorModule
	Module implementation using only the drift lengths. More...

class	Chi2BasedT0ExtractorModule
	Module implementation using only the chi2. More...

class	FullGridChi2TrackTimeExtractorModule
	Module implementation using only the chi2. More...

class	FullGridDriftLengthTrackTimeExtractorModule
	Module implementation using the drift length and the chi2. More...

class	CDCHitBasedT0ExtractionModule
	Module implementation using the CDCHitBasedT0Extractor. More...

class	ExtModule
	The geant4e-based track extrapolation module. More...

class	BaseRecoFitterModule
	A base class for all modules that implement a fitter for reco tracks. More...

class	DAFRecoFitterModule
	DAF fitter. More...

class	FittedTracksStorerModule
	A module to copy only the fitted reco tracks to the output store array. More...

class	GenfitTrackCandidatesCreatorModule
	Module turning reco tracks to genfit trackcands (will be unneeded once we use reco tracks everywhere). More...

class	GenfitTrackCreatorModule
	Module turning reco tracks to genfit tracks (will be unneeded once we use reco tracks everywhere). More...

class	KalmanRecoFitterModule
	Kalman fitter. More...

class	RecoTrackCreatorModule
	Module turning trackCands to reco tracks (will be unneeded once we create reco tracks from the beginning) More...

class	BaseTrackTimeEstimatorModule
	Base Module estimating the track time of RecoTracks - before or after the fit. More...

class	IPTrackTimeEstimatorModule
	Base Module estimating the track time of RecoTracks - before or after the fit. More...

class	PlaneTriggerTrackTimeEstimatorModule
	Module estimating the track time of RecoTracks - before or after the fit. More...

class	RadiusTrackTimeEstimatorModule
	Module estimating the track time of RecoTracks - before or after the fit. More...

class	RegisterEventLevelTrackingInfoModule
	Module to create the EventLevelTrackingInfo that is used to set general tracking-related flags. More...

class	Geant4MaterialInterface
	AbsMaterialInterface implementation for use with Geant4's navigator. More...

class	SetupGenfitExtrapolationModule
	Setup material handling and magnetic fields for use by genfit's extrapolation code (RKTrackRep). More...

class	Geant4MaterialInterfaceExceptioHandler
	This class implements a custom exception handler for Geant4 which is used to record whether a critical exception occurred when calling the G4Navigator. More...

class	G4SafeNavigator
	Guards against leaving the physical volume. More...

class	GenfitVisModule
	Visualize genfit::Tracks using the genfit::EventDisplay. More...

class	BeamSpotMonitorModule
	Module for the monitoring of the BeamSpot position and size. More...

class	MCRecoTracksMatcherModule
	This module compares tracks generated by some pattern recognition algorithm for PXD, SVD and CDC to ideal Monte Carlo tracks and performs a matching from the former to the underlying MCParticles. More...

class	MCV0MatcherModule
	A module matching the V0s from the mcV0Matcher to MC particles. More...

class	MCTrackCandClassifierModule
	The MCTrackCandClassifier Definition Module. More...

class	MuidModule
	The geant4e-based muon identification module. More...

class	PruneGenfitTracksModule
	Module to prune genfit::Tracks. More...

class	PruneRecoHitsModule
	Module to prune RecoTracks. More...

class	PruneRecoTracksModule
	Module to prune RecoTracks. More...

class	PXDclusterFilterModule
	The module produce a StoreArray of PXDCluster inside the ROIs. More...

class	PXDdigiFilterModule
	The module produce a StoreArray of PXDDigit inside the ROIs. More...

class	PXDRawHitFilterModule
	The module produce a StoreArray of PXDRawHit inside the ROIs. More...

class	PXDROIFinderAnalysisModule
	The PXD Data Reduction Analysis Module. More...

class	PXDROIFinderModule
	The PXD ROI Finder Module. More...

class	ROIDQMModule
	The HLT ROI DQM module. More...

class	ROIGeneratorModule
	The ROI generator Module. More...

class	ROIPayloadAssemblerModule
	The ROI Payload Assembler Module. More...

class	ROIReadTestModule
	The ROI to ONSEN Module. More...

class	ROISenderModule
	The ROI to ONSEN Module. More...

class	PXDSVDCutModule
	The module to deactivate the SpacePointTrackCandidates with less than minSVDSPs SVD SpacePoints. More...

class	RecoTrackParticleLoaderModule
	Takes fitted RecoTracks and creates Particles from them directly, skipping the step of creating Tracks and TrackFitResults. More...

class	RecoTracksCopierModule
	Module to copy RecoTracks. More...

class	CDCCKFTracksCombinerModule
	Module to combine RecoTracks. More...

class	MCRelationCreatorModule
	Module to combine RecoTracks. More...

class	RecoTrackStoreArrayCombinerModule
	Module to combine RecoTracks. More...

class	RelatedTracksCombinerModule
	Module to combine RecoTracks. More...

class	CurlingTrackCandSplitterModule
	Module for checking SpacePointTrackCandidates for curling behaviour and splitting them into Track Candidate Stubs (each of them being a SpacePointTrackCand again) which do not show curling behaviour. More...

class	GFTC2SPTCConverterModule
	Module for converting genfit::TrackCands to SpacePointTrackCands. More...

class	PhaseSpaceAnalysisModule
	Module for analysing the phase space of genfit::TrackCand(s) and SpacePointTrackCand(s) NOTE: this is just a very simple module that takes the MCParticleID of any TC and collects some information from them. More...

class	RT2SPTCConverterModule
	Module for converting RecoTracks to SpacePointTrackCands. More...

struct	TrueHitInfo
	helper struct that holds information that is needed for the registration of the relation between SpacePoint and TrueHit More...

class	SpacePoint2TrueHitConnectorModule
	Module that tries to register a relation between SpacePoints and TrueHits, hence making some MC Information easily accesible for other modules working with SpacePoints (e.g. More...

class	simpleBitfield< T >
	helper class for setting up a bitfield that can be used to store several flags in one variable TODO: move this from this header (possibly to some helperStuff header) and make some tests! More...

class	SpacePointCreatorTestModule
	Tester module for the validity of the SpacePointCreatorModule. More...

class	SPTC2GFTCConverterModule
	Module for converting SpacePointTrackCands to genfit::SpacePointTrackCands. More...

class	SPTCmomentumSeedRetrieverModule
	A module for creating momentum seeds for spacepoint track candidates. More...

class	SPTCRefereeModule
	Module that does some sanity checks on SpacePointTrackCands that have been created by conversion from genfit::TrackCands by the TrackFinderMCTruth (or any other for that matter) More...

class	SPTCvirtualIPRemoverModule
	A module for checking and removing the virtual IP if wanted. More...

class	TCConvertersTestModule
	Module for testing if the converting Modules do their job as intened. More...

struct	ParticleProperties
	This struct is used by the StandardTrackingPerformanceModule to save information of reconstructed tracks. More...

class	StoreArray< T >
	Accessor to arrays stored in the data store. More...

class	StandardTrackingPerformanceModule
	This module takes the MCParticle and the genfit::Track collection as input and writes out a root file with some information of the reconstructed tracks. More...

class	SVDROIDQMModule
	Creates basic DQM for ROI creation on ExpressReco More...

class	SVDROIFinderAnalysisDataModule
	The Module evaluates the efficiency on SVD based on the number of empty ROIs. More...

class	SVDROIFinderAnalysisModule
	This module performs the analysis of the SVD data reduction module performances More...

class	SVDROIFinderModule
	The SVD ROI Finder Module. More...

class	SVDShaperDigitFilterModule
	The module produce a StoreArray of SVDShaperDigit inside the ROIs. More...

class	TrackCreatorModule
	Takes RecoTracks coming from the event reconstructions and fits them with the configured list of particles hypothesis and stores the result in MDST-usable Belle2::Track and Belle2::TrackFitResult classes. More...

class	TrackFilterModule
	generates a new StoreArray from the input StoreArray which has all specified Tracks removed More...

class	TrackFinderMCTruthRecoTracksModule
	This module uses the simulated truth information (MCParticles and their relations) to determine which hits belong to which particles and writes track candidates filled with necessary information into the DataStore. More...

class	CollectorTestModule
	CollectorTestModules. More...

class	StudyMaterialEffectsModule
	StudyMaterialEffectsModule. More...

class	TrackDQMModule
	DQM of tracks their momentum, Number of hits in tracks, Number of tracks. More...

class	EffPlotsModule
	This module takes the MCParticles, the RecoTracks and Tracks/V0 in input and produce a root file containing various histograms showing the efficiencies (as a function of different variables) of the V0 finding module. More...

class	FillTrackFitNtupleModule
	This module takes the Tracks and the RecoTrack input and produce a root file containing an nutple showing the track fit members in parallel for different particle hypotheses. More...

class	HitXPModule
	This module from a data root file builds a tree of hitXP (see the class to know all the informations contained). More...

class	PerformanceEvaluationBaseClass
	This module takes the MCParticles, the genfit Tracks, the genfit TrackCand, and the MCTrackCands input and produce a root file containing various histograms showing the performance of the tracking package: fitter, pattern recongnition algorithms. More...

class	TrackingPerformanceEvaluationModule
	This module takes the MCParticles, the Tracks, the RecoTrack, and the MCRecoTracks input and produce a root file containing various histograms showing the performance of the tracking package: fitter, pattern recongnition algorithms. More...

class	V0findingPerformanceEvaluationModule
	This module takes the MCParticles, the V0 candidates input and produce a root file containing various histograms showing the performance of the V0 finding module. More...

class	TrackQETrainingDataCollectorModule
	Quality Estimator Data Collector Module to collect data for a MVA training using VXDQE_teacher.py. More...

class	TrackQualityEstimatorMVAModule
	Quality estimation module for SpacePointTrackCandidates using multivariate analysis (MVA). More...

class	AddVXDTrackCandidateSubSetsModule
	Module that creates additional candidates that each miss a different SpacePoint. More...

class	BestVXDFamilyCandidateSelectorModule
	Module that selects the best candidate for each SPTC family. More...

class	BestVXDTrackCandidatesSelectorModule
	Module that selects a subset with a fixed size x out of all SpacePointTrackCandidates. More...

class	SVDOverlapResolverModule

class	TrackSetEvaluatorGreedyDEVModule
	The Greedy algoritm Track-set-evaluator. More...

class	TrackSetEvaluatorHopfieldNNDEVModule
	The Hopfield algoritm Trackset Evaluator. More...

class	VXDTrackCandidatesQualityIndicatorCutterModule
	Module that selects a subset with a fixed minimum qualityIndicator out of all SpacePointTrackCandidates. More...

class	V0FinderModule
	A V0 finder module. More...

class	MCVXDCDCTrackMergerFindlet
	Findlet for merging VXD and CDC tracks with MC information. More...

class	MCVXDCDCTrackMergerModule
	This module merges tracks which are reconstructed, separately, in the silicon (PXD+VXD) and in the CDC using MC. More...

class	StoreArrayMerger
	This findlet has helper function to. More...

class	VXDCDCTrackMergerModule
	VXDCDCTrackMergerModule a module to merge VXD and CDC tracks. More...

class	OverlapResidualsModule
	The module studies VXD hits from overlapping sensors of a same VXD layer. More...

class	RawSecMapMergerModule
	The RawSecMapMergerModule. More...

class	SecMapTrainerBaseModule
	The SecMapTrainerBaseModule this module analyzes a big number of events (pGun or evtGen) to create raw sectorMaps which are needed for the VXDTF 2.0. More...

class	SecMapTrainerVXDTFModule
	The SecMapTrainerVXDTFModule this module analyzes a big number of events (pGun or evtGen) to create raw sectorMaps which are needed for the VXDTF. More...

class	VXDSimpleClusterizerModule
	Module to convert TrueHits into Clusters using a simplified process. More...

class	QualityEstimatorVXDModule
	Quality estimation module for SpacePointTrackCandidates. More...

class	VXDQETrainingDataCollectorModule
	VXD Quality Estimator Data Collector Module to collect data for a MVA training using VXDQE_teacher.py. More...

class	VXDQualityEstimatorMVAModule
	Quality estimation module for SpacePointTrackCandidates using multivariate analysis (MVA). More...

class	FastBDTClassifierAnalyzerModule
	Module to evaluate a trained fastBDT. More...

class	FastBDTClassifierTrainingModule
	Module for collecting the data and training a FastBDT classifier. More...

class	MLSegmentNetworkProducerModule
	Segment network producer module with a Machine Learning classifier. More...

class	NoKickCutsEvalModule
	This module evaluate the cuts used to select the training sample of the SectorMap. More...

class	SectorMapBootstrapModule
	The SegmentFilterConverterModule is a module able to read the cutoff values for filtering the Segments written in the xml gear box and write it in the new redesigned format. More...

class	SegmentNetworkAnalyzerModule
	class for analyzing the contents of the SegmentNetwork More...

class	SegmentNetworkProducerModule
	The Segment Network Producer Module. More...

class	SPTC2RTConverterModule
	Module turning SpacePointsTrackCands to RecoTracks. More...

class	TrackFinderVXDBasicPathFinderModule
	The TrackFinderVXDBasicPathFinder is a low momentum Si-only trackfinder. More...

class	TrackFinderVXDCellOMatModule
	The TrackFinderVXDCellOMatModule is a low momentum Si-only trackfinder. More...

class	TrackFinderVXDCosmicsStandaloneModule
	The TrackFinderVXDCosmicsStandaloneModule Track finder for linear cosmic tracks measured by the VXD without magnetic field and without other subdetectors. More...

class	VXDTFTrainingDataCollectorModule
	The VXDTFTrainingDataCollectorModule. More...

Typedefs
using	CellularRecoTrack = TrackFindingCDC::WithAutomatonCell< const RecoTrack * >
	Type of a reco track with automaton cell.

typedef std::pair< TVector2, TVector2 >	coord2dPair
	Typedef for the coord2dPair, which represents the DATCONHoughCand. More...

typedef std::pair< VxdID, TVector3 >	svdHitPair
	The DATCON Tracking Module performs track finding / pattern recognition based on SVD hit information. More...

typedef std::map< int, svdHitPair >	svdHitMap
	Map containing integer ID and svdHitPair.

typedef std::pair< VxdID, TVector2 >	houghPair
	Hough Tuples. More...

typedef std::map< int, houghPair >	houghMap
	Map containing integer ID and corresponding houghPair for the HS TODO make this description better.

Functions
std::string	getClassMnemomicParameterName (const CellularRecoTrack *dispatchTag __attribute__((unused)))
	Returns a short name for class CellularRecoTrack to be used in names of parameters.

std::string	getClassMnemomicParameterDescription (const CellularRecoTrack *dispatchTag __attribute__((unused)))
	Returns a short description for class CellularRecoTrack to be used in descriptions of parameters.

void	provideDATCONSVDClusterSingles (const StoreArray< SVDCluster > &DATCONSVDClusters, StoreArray< DATCONSVDSpacePoint > &spacePoints)
	simply store one spacePoint for each existing DATCONSVDCluster. More...

void	findPossibleCombinations (const Belle2::ClustersOnSensor &aSensor, std::vector< std::vector< const SVDCluster * > > &foundCombinations)
	stores all possible 2-Cluster-combinations. More...

void	provideDATCONSVDClusterCombinations (const StoreArray< SVDCluster > &DATCONSVDClusters, StoreArray< DATCONSVDSpacePoint > &spacePoints)
	finds all possible combinations of U and V Clusters for DATCONSVDClusters. More...

std::ostream &	operator<< (std::ostream &os, const TrueHitInfo &thInfo)
	extraction operator of TrueHitInfo

	DATCONSVDSimpleClusterCandidate (VxdID vxdID, bool isUside)
	Constructor indicating vxdid and u-side information.

	DATCONSVDSimpleClusterCandidate (VxdID vxdID, bool isUside, unsigned short maxClusterSize)
	Constructor indicating vxdid, u-side information in case of a maximum cluster size.

bool	add (VxdID vxdID, bool isUside, unsigned short index, unsigned short charge, unsigned short cellID)
	Add a Strip to the current cluster. More...

void	finalizeCluster ()
	compute the position of the cluster

void	finalizeSimpleCluster ()
	compute the simple cluster position as in phase 2 FPGA implementation

bool	isGoodCluster ()
	return true if the cluster candidate can be promoted to cluster

Detailed Description

Typedef Documentation

◆ coord2dPair

typedef std::pair< TVector2, TVector2 > coord2dPair

Typedef for the coord2dPair, which represents the DATCONHoughCand.

Hough Tuples.

The coord2dPair consists of the lower left and upper right corner of a Hough Space (sub) sector

Definition at line 32 of file DATCONHoughCand.h.

◆ houghPair

typedef std::pair<VxdID, TVector2> houghPair

Hough Tuples.

Pair containing VxdID ant TVector2 of TODO

Definition at line 71 of file DATCONTrackingModule.h.

◆ svdHitPair

typedef std::pair<VxdID, TVector3> svdHitPair

The DATCON Tracking Module performs track finding / pattern recognition based on SVD hit information.

The SVD hit information undergo a Hough Transformation (HT) and based on the sinoidal curves obtained by this, interceptions of these sinoidal curves are searched in two Hough Spaces (HS), one HS to obtain (r-phi) and (z-theta) information each. The intercept coordinates of the (r-phi) / (z-theta) combinations found are combined in clustering to reduce the number of fake / clone combinations. Afterwards the remaining 2 x 2D information are combined to 3D tracks, assuming the originating vertex of these tracks to be at (x=0, y=0, z=0). These tracks can again be merged and are finally stored as DATCONTracks and as RecoTracks. Tracks found by this module are the input for the DATCONMPHCalculationModule and afterwards for the DATCONROICalculationModule. Useful typedefs for easier data access Pair containing VxdID and corresponding position vector

Definition at line 66 of file DATCONTrackingModule.h.

Function Documentation

◆ add()

bool add	(	VxdID	vxdID,
		bool	isUside,
		unsigned short	index,
		unsigned short	charge,
		unsigned short	cellID
	)

Add a Strip to the current cluster.

Update the cluster seed seed.

Parameters

vxdID	VxdID of the strip that is to be added to the cluster
isUSide	Is the strip a u-side strip?
index	Index of the strip inside the DATCONSVDDigit StoreArray
charge	Charge of the strip that is to be added
cellID	CellID of the strip that is to be added

Returns: true if the strip is on the expected side and sensor and it's next to the last strip added to the cluster candidate

add if it adjacent to the last strip added (we assume that SVDRecoDigits are ordered) and if cluster size would still be <= 4 strips

Definition at line 32 of file DATCONSVDSimpleClusterCandidate.cc.

   {

     bool added = false;

     // do not add if you are on the wrong sensor or side
     if ((m_vxdID != vxdID) || (m_isUside != isUside))
       return false;

     // add if it's the first strip
     if (m_size == 0)
       added = true;

     if (m_size > 0 && cellID == m_strips.at(m_strips.size() - 1) + 1
         && cellID < m_strips.at(0) + m_maxClusterSize)
       added  = true;

     //add it to the vector od strips, update the seed charge and index:
     if (added) {
       m_size++;
       m_strips.push_back(cellID);
       m_charges.push_back(charge);
       m_digitIndices.push_back(index);

       if (charge > m_seedCharge) {
         m_seedCharge = charge;
 //         m_seedIndex = m_strips.size() - 1;
       }
     }
     return added;

   };

◆ findPossibleCombinations()

void Belle2::findPossibleCombinations	(	const Belle2::ClustersOnSensor &	aSensor,
		std::vector< std::vector< const SVDCluster * > > &	foundCombinations
	)

inline

stores all possible 2-Cluster-combinations.

first parameter is a struct containing all clusters on current sensor. second parameter is the container which collects all combinations found.

for each u cluster, a v cluster is combined to a possible combination. Condition which has to be fulfilled: the first entry is always an u cluster, the second always a v-cluster

Definition at line 100 of file DATCONSpacePointHelperFunctions.h.

                                     {uCluster, vCluster});

       }
     }
   }


◆ provideDATCONSVDClusterCombinations()

void Belle2::provideDATCONSVDClusterCombinations	(	const StoreArray< SVDCluster > &	DATCONSVDClusters,
		StoreArray< DATCONSVDSpacePoint > &	spacePoints
	)

finds all possible combinations of U and V Clusters for DATCONSVDClusters.

first parameter is a StoreArray containing DATCONSVDClusters. second parameter is a StoreArray containing SpacePoints (will be filled in the function). third parameter tells the spacePoint where to get the name of the storeArray containing the related clusters relationweights code the type of the cluster. +1 for u and -1 for v

Definition at line 124 of file DATCONSpacePointHelperFunctions.h.

◆ provideDATCONSVDClusterSingles()

void Belle2::provideDATCONSVDClusterSingles	(	const StoreArray< SVDCluster > &	DATCONSVDClusters,
		StoreArray< DATCONSVDSpacePoint > &	spacePoints
	)

simply store one spacePoint for each existing DATCONSVDCluster.

first parameter is a storeArray containing DATCONSVDCluster. second parameter is a storeArray containing DATCONSVDSpacePoint (will be filled in the function).

Definition at line 79 of file DATCONSpacePointHelperFunctions.h.

Classes

Typedefs

Functions
